Search Results (42)

A multiphysics theoretical framework is presented for CO₂ phase-change ejection power units, integrating the GERG-2008 equation of state for multiphase CO₂ thermophysical properties with the Jones–Wilkins–Lee (JWL) combustion model through customized Abaqus VUEOS and VHETVAL subroutines. The Coupled Eulerian–Lagrangian (CEL) method resolves the strongly coupled interaction between high-pressure compressible CO₂ and solid structures across supercritical, liquid–vapor coexistence, and gaseous phases. Validation against experimental pressure–time measurements demonstrates a maximum relative error below 10% throughout the pressurization trajectory, with peak pressure prediction accuracy of 4.1%. This validated framework offers quantitative design guidance for next-generation cold launch systems, enabling systematic optimization of high-pressure chamber configurations, release pressures, and operational parameters for enhanced energy efficiency and reliable performance in variable deployment environments. Full article

Co-firing biomass with coal in existing circulating fluidized bed (CFB) boilers is a promising strategy for reducing net CO₂ emissions and utilizing renewable energy. However, the impact of biomass-blending ratio on the complexity of multiphase flow, combustion characteristics, and pollutant formation inside a full-scale CFB boiler is not fully understood yet. This study developed Eulerian–Lagrangian Multiphase Particle-In-Cell (MP-PIC) model and this model was employed to simulate the co-combustion of coal and rice husk in a 72 MW industrial-scale CFB boiler. The pyrolysis kinetics of the coal and biomass were first measured experimentally via thermogravimetric analyzer and integrated into the model via source terms. The experimentally validated model was further used to investigate the effects of biomass-blending ratio (0–40 wt.%) on hydrodynamics, temperature distribution, and gaseous pollutant emissions (NO, SO₂). Results indicated that biomass addition has a negligible impact on the overall particle flow patterns and particle volume fraction distribution in the boiler. However, it significantly lowered the average furnace temperature due to the lower calorific value of biomass. A blending ratio of 40 wt.% biomass yielded the most substantial reduction in pollutant emissions at the outlet, with decreases of 51.99% for CO₂, 15.70% for NO, and 49.50% for SO₂ compared to single coal combustion. This study presents the MP-PIC model as an efficient numerical framework for optimizing co-firing operations and shows that a high ratio of biomass co-firing (40 wt.%) is technically feasible and environmentally advantageous in existing CFB boilers. Full article

This study employs numerical simulation methods to systematically analyze the multiphase flow and heat transfer characteristics in a circulating fluidized bed flue gas desulfurization (CFB-FGD) reactor handling ascharite ore roasting flue gas. Based on the simulation results, key structural optimization strategies are proposed. A three-dimensional mathematical model was developed based on the Fluent 19.1 platform, and the multiphase flow process was simulated using the Eulerian-Lagrangian method. The study examined the effects of venturi tube structure, atomized water nozzle installation height, and gas injection disruptor configuration on reactor performance. Optimization strategies for key structural components were systematically evaluated. The results show that the conventional inlet structure leads to significant non-uniformity in the velocity field. Targeted adjustments to the dimensions of venturi tubes at different positions markedly improve the velocity distribution uniformity. Reducing the atomized water nozzle installation height from 1.50 m to 0.75 m increased the temperature distribution uniformity index in the middle part of the straight pipe section by 5.5%. Moreover, a gas injection disruptor was installed in the upper part of the straight pipe section of the CFB-FGD reactor. Increasing the gas injection velocity from 15 m/s to 30 m/s increased the average residence time of desulfurization sorbents by 17.0%. This increase effectively enhances gas–solid mixing within the CFB-FGD reactor. The optimization strategies described above significantly reduced the extent of flow dead zones and low-temperature regions in the CFB-FGD reactor and improved flow conditions. This study provides important theoretical and technical support for the optimization and industrial application of CFB-FGD technology for ascharite ore roasting flue gas. Full article

Smoothed particle hydrodynamics (SPHs) is a Lagrangian meshless method with distinct strengths in managing unstable and complex interface behaviors. This study develops an integrated multiphase SPH framework by merging multiple algorithms and techniques to enhance stability and accuracy. The multiphase model is validated by several benchmark examples, including square droplet deformation, single bubble rising, and two bubbles rising. The selection of numerical parameters for multiphase simulations is also discussed. The validated model is then applied to simulate oil–water–gas bubbly flows. Interface behaviors, such as coalescence, fragmentation, deformation, etc., are reproduced, which helps to take into account multiphysics interactions in industrial processes. The rising processes of many oil droplets for oil–water separation are first simulated, showing the advantages and stability of the SPH model in dealing with complex interface behaviors. To fully explore the potential of the model, the model is further extended to the field of wax removal. The melting process of the wax layer due to heat conduction is simulated by coupling the thermodynamic model and the phase change model. Interesting behaviors such as wax layer cracking, droplet detachment, and thermally driven flow instabilities are captured, providing insights into wax deposition mitigation strategies. This study provides an effective numerical model for bubbly flows in petroleum engineering and lays a research foundation for extending the application of the SPH method in other engineering fields, such as multiphase reactor design and environmental fluid dynamics. Full article

A multiphase model of hydrothermal liquefaction (HTL) using the computational fluid dynamics coupling discrete element method (CFD-DEM) is used to simulate biocrude oil production from sludge flocs in a continuous stirred tank reactor (CSTR). Additionally, the influence of the agitator speed and the slurry flow rate on dynamic biocrude oil production is investigated through full transient CFD analysis in a scaled-up CSTR study. The kinetics of the HTL mechanism as a function of temperature, pressure, and residence time distribution were employed in the model through a user-defined function (UDF). The multiphysics simulation of the HTL process in a stirred tank reactor using the Lagrangian–Eulerian (LE) approach, along with a standard k-ε turbulence model, integrated HTL kinetics. The simulation accounts for particle–fluid interactions by coupling CFD-derived hydrodynamic fields with discrete particle motion, enabling prediction of individual particle trajectories based on drag, buoyancy, and interphase momentum exchange. The three-phase flow using a compressible non-ideal gas model and multiphase interaction as design requirements increased process efficiency in high-pressure and high-temperature model conditions. Full article

To accommodate the extreme thermodynamic effects and erosion damage in throttling equipment for ultra-high-pressure natural gas wells (175 MPa), a coupled multiphase flow erosion numerical model for nozzles was established. This model incorporates a real gas compressibility factor correction and is based on the renormalized k-ε RNG (Renormalization Group k-epsilon model, a turbulence model that simulates the effects of vortices and rotation in the mean flow by modifying turbulent viscosity) turbulence model and the Discrete Phase Model (DPM, a multiphase flow model based on the Eulerian–Lagrangian framework). The study revealed that the nozzle flow characteristics follow an equal-percentage nonlinear regulation pattern. Choked flow occurs at the throttling orifice throat due to supersonic velocity (Ma ≈ 3.5), resulting in a mass flow rate governed solely by the upstream total pressure. The Joule–Thomson effect induces a drastic temperature drop of 273 K. The outlet temperature drops below the critical temperature for methane hydrate phase transition, thereby presenting a substantial risk of hydrate formation and ice blockage in the downstream outlet segment. Erosion analysis indicates that particles accumulate in the 180° backside region of the cage sleeve under the influence of secondary flow. At a 30% opening, micro-jet impact causes the maximum erosion rate to surge to 3.47 kg/(m²·s), while a minimum erosion rate is observed at a 50% opening. Across all opening levels, the maximum erosion rate consistently concentrates on the oblique section of the plunger front. Results demonstrate that removing the front chamfer of the plunger effectively improves the internal erosion profile. These findings provide a theoretical basis for the reliability design and risk prevention of surface equipment in deep ultra-high-pressure gas wells. Full article

Maintaining air quality in operating rooms is critical for infection control and patient safety. Particulate matter, originating from surgical instruments, personnel, and external sources, is influenced by airflow patterns and ventilation efficiency. This study employs Computational Fluid Dynamics (CFD) simulations using Simcenter STAR-CCM+ 2410 to analyze airflow and particulate behavior in a surgical-grade operating room. A steady-state solver with the k–ε turbulence model was used to replicate airflow, while the Lagrangian multiphase method simulated particle trajectories (0.5 µm, 1 µm, and 5 µm). The simulation results demonstrated close agreement with the experimental data, with average errors of 17.3%, 17.7%, and 39.7% for 0.5 µm, 1 µm, and 5 µm particles, respectively. These error margins are considered acceptable given the device’s 10% measurement sensitivity and the observed experimental asymmetry—attributable to equipment placement—which resulted in variations of 17.2%, 18.0%, and 26.5% at corresponding symmetric points. Collectively, these findings support the validity of the simulation model in accurately predicting particulate transport and deposition within the operating room environment. Findings confirm that optimizing airflow can achieve ISO Class 7 cleanroom standards and highlight the potential for future studies incorporating dynamic elements, such as personnel movement and equipment placement, to further improve contamination control in critical environments. Full article

This study presents a novel unresolved SPH-DEM coupling framework to investigate the complex interactions between rising gas bubbles and sinking solid particles in multiphase systems. Traditional numerical methods often struggle with large deformations, multiphase interfaces, and computational efficiency when simulating dense particle-laden flows. To address these challenges, the proposed model leverages SPH’s Lagrangian nature to resolve fluid motion and bubble dynamics, while the DEM captures particle–particle and particle–bubble interactions. An unresolved coupling strategy is introduced to bridge the scales between fluid and particle phases, enabling efficient simulations of large-scale systems with discrete bubbles/particles. The model is validated against benchmark cases, including single bubbles rising and single particle’s sedimentation. Simulation studies reveal the effects of particle/bubble number and initial distance on phase interaction patterns and clustering behaviors. Results further illustrate the model’s capability to capture complex phenomena such as particle entrainment by bubble wakes and hindered settling in dense suspensions. The framework offers a robust and efficient tool for optimizing industrial processes like mineral flotation, where bubble–particle dynamics play a critical role. Full article

Spray dry scrubbing is widely used for SO₂ abatement, but high removal efficiencies are required for economical operation. Whereas SO₂ removal dependence on the drying rate has been investigated, available modelling work has not addressed the impact of selected drying models on the removal efficiency; instead, a single drying model is often assumed. In the present work, computational fluid dynamics is used to numerically model the SO₂ removal in a laboratory-scale spray dry scrubber. The Euler–Lagrangian framework is used to simulate the multiphase interaction and two drying models are used: the widely used classical D2-law model and the mechanistic model. In addressing shortcomings from previous works, this study also provides a comprehensive model development and robust model validation with quantifiable metrics for goodness-of-fit, including R². Also presented are key parameters associated with SO₂-removal efficiency, including the exit product moisture content and droplet dynamics. The mechanistic model gave a better representation of the SO₂-removal efficiency. The latter was found to be dependent on the inlet temperature, the calcium-to-sulphur and liquid-to-gas (L/G) ratios, with a high L/G ratio having the most significant impact on the removal efficiency, although resulting in a higher product outlet moisture content. Full article

Nowadays, almost all countries in the world are intensifying their search for locally available energy sources to become independent of external supplies. The production of alternative fuels from biomass and waste by thermal treatment or direct use in the combustion process is still the simplest method for fast and cheap heat production. However, the different characteristics of these fuels can cause problems in the operation of the plants, resulting in increased air pollution. Therefore, the analysis of the thermal treatment of solid fuels is still an important issue from a practical point of view. This work aimed to study biomass combustion in a small-scale reactor using the in-house Extended DEM (XDEM) method based on mixed Lagrangian–Eulerian approaches. This was provided by a novel, independently developed coupling computational interface. This interface allows for a seamless integration between CFD and DEM, improving computational efficiency and accuracy. In addition, significant advances have been made in the underlying physical models. Within the DEM framework, each particle undergoes the thermochemical processes, allowing for the prediction of its shape and structural changes during heating. Together, these changes contribute to a more robust and reliable simulation tool capable of providing detailed insights into complex multi-phase flows and granular material behavior. Numerical results were obtained for a non-typical geometry to check the influence of the walls on the distribution of the parameters in the reactor. The results show that XDEM is a very good tool for predicting the phenomena during the thermal treatment of solid fuels. In particular, it provides information about all the moving particles undergoing chemical reactions, which is very difficult to obtain from measurements. Full article

A recovery system for an automatic spraying robot to conduct the spraying operation outdoors for ships is designed in this paper, which addresses the pollution problem of volatile organic compounds (VOCs) by employing the vacuum recovery method. The recovery system consists of the recovery hood, nozzle, and vacuum tubes. The recovery hood is the critical part of the recovery system and is designed with internal and external cavities, as well as four vacuum tubes for recycling VOCs. Based on the computational fluid dynamics (CFD) method, simulation in the time domain of the gas–liquid interaction, droplet evaporation, and wall impingement is conducted. To identify the better recovery performance, three vacuum recovery-hood schemes are designed, and their performance is compared. The numerical results show that the distance between the vacuum tubes and the intake gap has a significant impact on the VOCs’ recovery effect. One of the main reasons for the escape of VOCs is that the swirling airflows in the baffle plane act as vortices which may capture VOCs, causing the accumulation of VOCs beyond the capacity of the external cavity. Dividing the external cavity into four chambers with deflectors (with each chamber equipped with one vacuum tube only) can significantly reduce the leakage rate of the recovery system. The recovery system provides a theoretical solution for implementing the prevention and control of VOCs in shipyards as soon as possible. Full article

The interfacial area between two phases plays a crucial role in the mass transfer rate of gas–liquid processes such as absorption. In this context, the droplet size distribution within the flow field of a droplet-based absorber significantly affects the surface area, thereby influencing the absorption efficiency. This study focuses on developing a computational fluid dynamics (CFD) model to predict the size and distribution of water droplets free-falling in a transparent square tube. This model serves as a digital twin of our experimental setup, enabling a comparative analysis of experimental and computational results. For the accurate measurement of droplet size and distribution, specialized experimental equipment was developed, and a high-speed camera along with Fiji software was used for the capturing and processing of droplet images. At the point of injection and at two different heights, the sizes and distributions of falling droplets were measured using this setup. The interaction between the liquid water droplets and the gas phase within the square tube was modeled using the Eulerian–Lagrangian (E-L) framework in the STAR-CCM+ software. The E-L multiphase CFD model yielded approximations with errors ranging from 11 to 27% for various average mean diameters, including $d_{10}$, $d_{20}$, $d_{30}$, and $d_{32}$, of the liquid droplets at two distinct heights (200 mm and 400 mm) for both nozzle plates. This comprehensive approach provides valuable insights into the dynamics of droplet-based absorption processes. Full article

Recent advancements in particle dispersion modeling have significantly enhanced our understanding and capabilities in predicting and analyzing the behavior of particulate matter in various environments. However, this field still confronts several research gaps and challenges that span across scientific inquiry and technological applications. This paper reviews the current state of particle dispersion modeling, focusing on various models such as Lagrangian, Eulerian, Gaussian, and Box models, each with unique strengths and limitations. It highlights the importance of accurately simulating multi-phase interactions, addressing computational intensity for practical applications, and considering environmental and public health implications. Furthermore, the integration of emerging technologies like machine learning (ML) and artificial intelligence (AI) presents promising avenues for future advancements. These technologies could potentially enhance model accuracy, reduce computational demands, and enable handling complex, multi-variable scenarios. The paper also emphasizes the need for real-time monitoring and predictive capabilities in particle dispersion models, which are crucial for environmental monitoring, industrial safety, and public health preparedness. Full article

Positron emission particle tracking (PEPT) has offered important insights into the internal dynamics of multiphase flows. High precision and frequency measurements of the location of the tracer particle are required to resolve individual eddies at the millimetre scale or smaller. To explore the potential of PEPT to perform these measurements, a model was developed of the Siemens ECAT “EXACT3D” HR++ positron emission tomography (PET) scanner at the PEPT Cape Town facility in South Africa with the software Geant4 Application for Tomographic Emission (GATE) and was used to generate Lagrangian tracks from simulations of moving tracer particles. The model was validated with measurements from both experiment and simulation and was extended to two virtual scenarios inspired by turbulent flows. The location data from the simulation accurately captured linear portions of an oscillating path up to high speeds of 25 m s${}^{-1}$; however, tracking tended to undercut the turning points due to the high tracer acceleration. For a particle moving on a spiral path of decreasing radius, the location data tracked the path above a radius of 2.0 mm with an uncertainty equivalent to the radius of the tracer particle, 300 $\mathsf{\mu }$m. Improvements to the measurement are required to track sub-millimetre flow structures, such as the application of PET scanners with higher spatial resolution and upgrades to the sampling processes used in location algorithms. Full article

When a Pelton turbine operates in sand laden water, the abrasive wear of its overflow components by high-speed jets is serious. Based on the VOF (volume of fluid) multiphase flow model, the SST (shear stress transfer) k-ω turbulence model, the particle motion Lagrangian model, the generic wear model, and the SIMPLEC (Semi-Implicit Method for Pressure Linked Equations Consistent) algorithm, the liquid–air–solid three-phase flow in the key overflow components of a Pelton turbine were simulated, the abrasive wear was predicted, and the internal sand-water flow characteristics and the abrasive wear of the overflow components were analyzed. The results show that the trailing edge at the root of the runner bucket, the leading face of the bucket near the root, the notch, and the splitter are severely worn. The abrasive wear of the splitter and the notch is more severe than that of the leading face of the bucket. The wear rate from the splitter to the trailing edge increases first and then decreases. The wear pattern of the needle tip is mainly “dotted”, while that of the nozzle opening is “flaky”, and the abrasive wear of the nozzle opening is more severe than that of the needle. The predicted results are consistent with the actual conditions at the site of the power station. This study provides a technical method for the prediction of abrasive wear of the Pelton turbine and a technical basis for the operation and maintenance of the power station. Full article
