Glucose (Glu) detection, as a fundamental analytical technique, has applications in medical diagnostics, clinical testing, bioanalysis and environmental monitoring. In this work, a solid-phase electrochemiluminescence (ECL) enzyme sensor was developed by immobilizing the ECL emitter in a stable manner within bipolar silica nanochannel array film (bp-SNA), enabling sensitive glucose detection. The sensor was constructed using an electrochemical-assisted self-assembly (EASA) method with various siloxane precursors to quickly modify the surface of indium tin oxide (ITO) electrodes with a bilayer SNA of different charge properties. The inner layer, including negatively charged SNA (n-SNA), attracted the positively charged ECL emitter tris(2,2′-bipyridyl)ruthenium(II) (Ru(bpy)₃²⁺) via electrostatic interaction, while the outer layer, including positively charged SNA (p-SNA), repelled it, forming a barrier that efficiently concentrated the Ru(bpy)₃²⁺ emitter in a stable manner. After modifying the amine groups on the p-SNA surface with aldehyde groups, glucose oxidase (GOx) was covalently immobilized, forming the enzyme electrode. In the presence of glucose, GOx catalyzed the conversion of glucose to hydrogen peroxide (H₂O₂), which acted as a quencher for the Ru(bpy)₃²⁺/triethanolamine (TPA) system, reducing the ECL signal and enabling quantitative glucose analysis. The sensor exhibited a wide linear range from 10 μM to 7.0 mM and a limit of detection (LOD) of 1 μM (S/N = 3). Glucose detection in fetal bovine serum was realized. By replacing the enzyme type on the electrode surface, this sensing strategy holds the potential to provide a universal platform for the detection of different metabolites. Full article

This study proposed a novel perovskite/silicon heterojunction (SHJ) tandem device structure without an interlayer, represented as ITO/NiO/perovskite/SnO₂/MoO_X/i-a-Si:H/n-c-Si/i-a-Si:H/n-a-Si:H/Ag, which was investigated by Silvaco TCAD software. The recombination layer in this structure comprises the carrier transport layers of SnO₂ and MoO_X, where MoO_X serves dual functions, acting as the emitter for the SHJ bottom cell and as part of the recombination layer in the tandem cell. First, the effects of different recombination layers are analyzed, and the SnO₂/MoO_X layer demonstrates the best performance. Then, we systematically investigated the impact of the carrier concentration, interface defect density, thicknesses of the SnO₂/MoO_X layer, different hole transport layers (HTLs) for the top cell, absorption layer thicknesses, and perovskite defect density on device performance. The optimal carrier concentration in the recombination layer should exceed 5 × 10¹⁹ cm⁻³, the interface defect density should be below 1 × 10¹⁶ cm⁻², and the thicknesses of SnO₂/MoO_X should be kept at 20 nm/20 nm. CuSCN has been found to be the optimal HTL for the top cell. When the silicon absorption layer is 200 μm, the perovskite layer thickness is 470 nm, and the defect density of the perovskite layer is 10¹¹ cm⁻³, the planar structure can achieve the best performance of 32.56%. Finally, we studied the effect of surface texturing on the SHJ bottom cell, achieving a power conversion efficiency of 35.31% for the tandem cell. Our simulation results suggest that the simplified perovskite/SHJ tandem solar cell with a dual-functional MoO_X layer has the potential to provide a viable pathway for developing high-efficiency tandem devices. Full article

The interrelationships between the topological features, such as surface roughness deduced from atomic force microscopy (AFM), and wettability properties expressed by the contact angle of a water droplet on the surface of nanostructured wide bandgap oxide films prepared by spray pyrolysis are investigated for a wide range of compositions. A direct relationship between the surface roughness and the value of the contact angle was found for nanocomposite (In₂O₃)_1−x(MgO)_x, (In_1−xGa_x)₂O₃, and Zn_1−xMg_xO films, for which both the surface roughness and the contact angle increase with the increasing x-value. On the other hand, in ITO films doped with Ga, it was found that the surface roughness increases by increasing the Ga doping, while the contact angle decreases. Both the surface roughness and the contact angle proved to increase in Ga₂O₃ films when they were alloyed with Al₂O₃, similar to other nanocomposite films. An inverse relationship was revealed for a nanocomposite formed from Ga₂O₃ and SnO₂. The contact angle for a (Ga₂O₃)_0.75(SnO₂)_0.25 film was larger as compared to that of the Ga₂O₃ film, while the surface roughness was lower, similar to ITO films. The highest value of the contact angle equal to 128° was found for a (In₂O₃)_1−x(MgO)_x film with an x-value of 0.8, and the largest RMS roughness of 20 nm was showed by a Ga_1.75Al_0.25O₃ film. The optical properties of the prepared films were also analyzed from optical absorption spectroscopy, demonstrating their bandgap variation in the range of (4 to 4.85) eV, corresponding to the middle ultraviolet spectral range. Full article

Zinc–tin oxide (ZTO) thin films (ZnO)_x(SnO₂)_1−x with different material composition x (0 < x < 1) are deposited by spin coating on glass substrates at room temperature. The Differential Scanning Calorimetry (DSC) data of the precursor compounds show gradual phase transitions up to 480 °C. These data are used for an appropriate regime for thermal annealing of the layers. X-ray photoelectron spectroscopy (XPS) data show mixed oxide compound formation in states Zn²⁺, Sn⁴⁺ and O²⁻ of the constituents. Optical investigation manifests high transmittance above 80% in the visible spectral range and an optical band gap of 3.3–3.7 eV. The work functions vary between 4.1 eV and 5 eV, depending on the annealing, with deviations less than 1% for surface 1 mm² scans. Stack devices ITO/ZTO/metal with different metal contacts are formed. The I–V (current–voltage) measurements of the fabricated stacks exhibit Ohmic or nonlinear behavior, depending on the material composition and the work function levels. Full article

This study investigates the structural, optical, and photocatalytic properties of cadmium oxide (CdO) nanoparticles (NPs) and indium–tin oxide (ITO)-doped CdO NPs. The synthesis of CdO NPs and ITO NPs was accomplished through the co-precipitation method. Scanning electron microscopy (SEM) analysis indicates that pure CdO NPs exhibit agglomerated structures, whereas ITO doping introduces porosity and roughness, thereby improving particle dispersion and facilitating electron transport. Energy dispersive spectroscopy (EDS) corroborates the successful incorporation of tin (Sn) and indium (In) within indium–tin oxide (ITO)-doped cadmium oxide (CdO) nanoparticles (NPs) in addition to cadmium (Cd) and oxygen (O). X-ray diffraction (XRD) analysis demonstrates that an increase in ITO doping results in a reduction of the crystallite size, decreasing from 23.43 nm for pure CdO to 18.42 nm at a 10% doping concentration, which can be attributed to lattice distortion. Simultaneously, the band gap exhibits a narrowing from 2.92 eV to 2.52 eV, achieving an optimal value at 10% ITO doping before experiencing a slight increase at higher doping concentrations. This tuneable band gap improves light absorption, which is crucial for photocatalysis. The photocatalytic degradation of rhodamine B (RhB) highlights the superior efficiency of ITO-doped CdO nanoparticles, achieving a remarkable 94.68% degradation under sunlight within 120 min, up 81.01%, significantly surpassing the performance of pure CdO. The optimal RhB concentration for achieving maximum degradation was determined to be 5 mg/L. This enhanced catalytic activity demonstrates the effectiveness of ITO-doped CdO NPs under both UV and visible light, showcasing their potential for efficient pollutant degradation in sunlight-driven applications. Full article

The measurement of cardiac troponin I (cTnI) is of vital importance for the early diagnosis of acute myocardial infarction. In this study, an enhanced electrochemiluminescent immunoassay for the highly sensitive and precise determination of cTnI was reported. A biomimetic chip with nepenthes peristome surface microstructures to achieve single-layer microbead arrays and integrated microelectrode arrays (MEAs) for ECL detection was microfabricated. Ru@SiO₂ nanoparticles were prepared as signal amplificators labeling immunomagnetic beads. Dendrimer-encapsulated platinum nanoparticles (Pt DENs) were electrochemically modified on ITO MEAs. The resulting Pt DEN-modified ITO MEAs preserved good optical transparency and exhibited an approximately 20-fold ECL signal amplification compared to that obtained from bare ITO. The method made full use of the biomimetic chip with Pt DENs to develop single-layer immunomagnetic bead arrays with increasingly catalyzed electrochemical oxidation of the [Ru(bpy)₃]²⁺–TPA system. Consequently, a limit of detection calculated as 0.38 pg/mL (S/N = 3) was obtained with excellent selectivity, demonstrating significant potential for the detection of cTnI in clinical diagnostics. Full article

Simple development of an electrochemiluminescence (ECL) immunosensor for convenient detection of tumor biomarker is of great significance for early cancer diagnosis, treatment evaluation, and improving patient survival rates and quality of life. In this work, an immunosensor is demonstrated based on an enhanced ECL signal boosted by nanochannel-confined Au nanomaterial, which enables sensitive detection of the tumor biomarker—carcinoembryonic antigen (CEA). Vertically-ordered mesoporous silica film (VMSF) with a nanochannel array and amine groups was rapidly grown on a simple and low-cost indium tin oxide (ITO) electrode using the electrochemically assisted self-assembly (EASA) method. Au nanomaterials were confined in situ on the VMSF through electrodeposition, which catalyzed both the conversion of dissolved oxygen (O₂) to reactive oxygen species (ROS) and the oxidation of a luminol emitter and improved the electrode active surface. The ECL signal was enhanced fivefold after Au nanomaterial deposition. The recognitive interface was fabricated by covalent immobilization of the CEA antibody on the outer surface of the VMSF, followed with the blocking of non-specific binding sites. In the presence of CEA, the formed immunocomplex reduced the diffusion of the luminol emitter, resulting in the reduction of the ECL signal. Based on this mechanism, the constructed immunosensor was able to provide sensitive detection of CEA ranging from 1 pg·mL⁻¹ to 100 ng·mL⁻¹ with a low limit of detection (LOD, 0.37 pg·mL⁻¹, S/N = 3). The developed immunosensor exhibited high selectivity and good stability. ECL determination of CEA in fetal bovine serum was achieved. Full article

We performed an electrochromic investigation to optimize the composition of reactive magnetron-sputtered mixed layers of zinc oxide and tin oxide (ZnO-SnO₂). Deposition experiments were conducted as a combinatorial material synthesis approach. The binary system for the samples of SnO₂-ZnO represented the full composition range. The coloration efficiency (CE) was determined for the mixed oxide films with the simultaneous measurement of layer transmittance, in a conventional three-electrode configuration, and an electric current was applied by using organic propylene carbonate electrolyte cells. The optical parameters and composition were measured and mapped by using spectroscopic ellipsometry (SE). Scanning Electron Microscopy (SEM) and Energy-Dispersive X-ray Spectroscopy (EDS) measurements were carried out to check the SE results, for (TiO₂-SnO₂). Pure metal targets were placed separately from each other, and the indium–tin-oxide (ITO)-covered glass samples and Si-probes on a glass holder were moved under the two separated targets (Zn and Sn) in a reactive argon–oxygen (Ar-O₂) gas mixture. This combinatorial process ensured that all the compositions (from 0 to 100%) were achieved in the same sputtering chamber after one sputtering preparation cycle. The CE data evaluated from the electro-optical measurements plotted against the composition displayed a characteristic maximum at around 29% ZnO. The accuracy of our combinatorial approach was 5%. Full article

The aim of this work was to investigate the possibility of modifying the physical properties of indium tin oxide (ITO) layers by annealing them in different atmospheres and temperatures. Samples were annealed in vacuum, air, oxygen, nitrogen, carbon dioxide and a mixture of nitrogen with hydrogen (NHM) at temperatures from 200 °C to 400 °C. Annealing impact on the crystal structure, optical, electrical, thermal and thermoelectric properties was examined. It has been found from XRD measurements that for samples annealed in air, nitrogen and NHM at 400 °C, the In₂O₃/In₄Sn₃O₁₂ share ratio decreased, resulting in a significant increase of the In₄Sn₃O₁₂ phase. The annealing at the highest temperature in air and nitrogen resulted in larger grains and the mean grain size increase, while vacuum, NHM and carbon dioxide atmospheres caused the decrease in the mean grain size. The post-processing in vacuum and oxidizing atmospheres effected in a drop in optical bandgap and poor electrical properties. The carbon dioxide seems to be an optimal atmosphere to obtain good TE generator parameters—high ZT. The general conclusion is that annealing in different atmospheres allows for controlled changes in the structure and physical properties of ITO layers. Full article

Energy harvesting from cleaner sources and preserving the environment from dangerous gasses are presently the key priorities globally to maintain sustainable development. In this context, photovoltaic technology plays a vital role in generating energy from ternary organic solar cells. Ternary organic solar cells display significant potential for achieving outstanding photovoltaic performance compared to binary structures. Over the past few years, significant endeavors to develop novel organic materials have led to a consistent rise in efficiency, surpassing 19% for single-junction devices. In our study, we simulated an inverted ternary organic solar cell (TOSC) structure employing the one-dimensional optical and drift diffusion model and using “Oghma-Nano 8.0.034” software by optimizing the active blend thickness at 80 nm within the structure of ITO/SnO₂/PM6:D18:L8-BO/PEDOT:PSS/Ag. We simulated different performance parameters such as EQE, Photo-CELIV, PCE, J_sc, V_oc, and FF with different active layer thicknesses ranging from 50 to 200 nm to discover the behavior of the device in terms of efficiency parameters. Furthermore, the structure attained a PCE of 20% for an active layer thickness of 80 nm within a J_sc of 27.2 mA cm⁻², a V_oc of 0.89 V, and an FF of 82.3%. This approach can potentially be valuable in constructing a highly effective TOSC model in the laboratory. Full article

Perovskite solar cells with an indium tin oxide (ITO)/SnO₂/CH₃NH₃PbI₃/Spiro-OMeTAD/2,2,2-trifluoroethanol (TFE) doped single-walled carbon nanotube (SWCNT) structure were developed by dropping TFE onto SWCNTs, which replaced the metal back electrode, and a conversion efficiency of 14.1% was achieved. Traditionally, acidic doping of the back electrode, SWCNT, has been challenging due to the potential damage it may cause to the perovskite layer. However, TFE has facilitated easy doping of SWCNT as the back electrode. The sheet resistance of the SWCNTs decreased and their ionization potential shifted to deeper levels, resulting in improved hole transport properties with a lower barrier to carrier transport. Furthermore, the Seebeck coefficient (S) increased from 34.5 μV/K to 73.1 μV/K when TFE was dropped instead of EtOH, indicating an enhancement in the behavior of p-type charge carriers. It was observed that hydrophilic substances adhered less to the SWCNT surface, and the formation of PbI₂ was suppressed. These effects resulted in higher conversion efficiency and improved solar cell performance. Furthermore, the decrease in conversion efficiency after 260 days was suppressed, showing improved durability. The study suggests that combining SWCNTs and TFEs improves solar cell performance and stability. Full article

Extensive research on organic solar cells (OSCs) over the past decade has led to efficiency improvements exceeding 18%. Enhancing the efficacy of binary organic solar cells involves multiple factors, including the strategic selection of materials. The choice of donor and acceptor materials, which must exhibit complementary absorption spectra, is crucial. Additionally, optimizing the solar cell structure, such as adjusting the thickness of layers and incorporating hole-transporting layers, can further increase efficiency. In this study, we simulated three different novels within the use of the inorganic SnO₂ on the OSCs within this specific arrangement of structures using a drift-diffusion model: direct and inverted binary; direct ternary configurations of OSCs, specifically ITO/PEDOT: PSS/PM6:L8-BO/SnO₂/Ag, ITO/SnO₂/PM6:L8-BO/PEDOT: PSS/Ag; and FTO/PEDOT: PSS/PM6:D18:L8-BO/SnO₂/Ag. These structures achieved power conversion efficiencies (PCE) of 18.34%, 18.37%, and 19.52%, respectively. The direct ternary device achieved an important V_oc of 0.89 V and an FF of 82.3%, which is high in comparison with other simulated results in the literature. Our research focused on the role of SnO₂ as an inorganic electron transport layer in enhancing efficiency in all three configurations. We also evaluated the properties of these structures by simulating external quantum efficiency (EQE), which results in a broadened absorption spectrum from 380 nm to 900 nm for both binary and ternary devices. Furthermore, we measured the spectral distribution of absorbed photons, and photo-charge extraction by linearly increasing voltage (photo-CELIV) to assess charge extraction and generation rates as well as charge mobility. These measurements help establish a robust model for practical application. Full article

This study examined the impact of temperature optimization on indium tin oxide (ITO) films in monolithic HJT/perovskite tandem solar cells. ITO films were deposited using magnetron sputtering at temperatures ranging from room temperature (25 °C) to 250 °C. The sputtering target was ITO, with a mass ratio of In₂O₃ to SnO₂ of 90% to 10%. The effects of temperature on the ITO film were analyzed using X-ray diffraction (XRD), spectroscopic ellipsometry, and sheet resistance measurements. Results showed that all ITO films exhibited a polycrystalline morphology, with diffraction peaks corresponding to planes (211), (222), (400), (440), and (622), indicating a cubic bixbyite crystal structure. The light transmittance exceeded 80%, and the sheet resistance was 75.1 Ω/sq for ITO deposited at 200 °C. The optical bandgap of deposited ITO films ranged between 3.90 eV and 3.93 eV. Structural and morphological characterization of the perovskite solar cell was performed using XRD and FE-SEM. Tandem solar cell performance was evaluated by analyzing current density-voltage characteristics under simulated sunlight. By optimizing the ITO deposition temperature, the tandem cell achieved a power conversion efficiency (PCE) of 16.74%, resulting in enhanced tandem cell efficiency. Full article

In this study, the electrical performance and bias stability of InSnO/a-InGaZnO (ITO/a-IGZO) heterojunction thin-film transistors (TFTs) are investigated. Compared to a-IGZO TFTs, the mobility (µ_FE) and bias stability of ITO/a-IGZO heterojunction TFTs are enhanced. The band alignment of the ITO/a-IGZO heterojunction is analyzed by using X-ray photoelectron spectroscopy (XPS). A conduction band offset (∆E_C) of 0.5 eV is observed in the ITO/a-IGZO heterojunction, resulting in electron accumulation in the formed potential well. Meanwhile, the ∆E_C of the ITO/a-IGZO heterojunction can be modulated by nitrogen doping ITO (ITON), which can affect the carrier confinement and transport properties at the ITO/a-IGZO heterojunction interface. Moreover, the carrier concentration distribution at the ITO/a-IGZO heterointerface is extracted by means of TCAD silvaco 2018 simulation, which is beneficial for enhancing the electrical performance of ITO/a-IGZO heterojunction TFTs. Full article

Perovskite thin films directly impact solar cell properties, making defect reduction crucial in perovskite solar cell research. In our study, we used perovskite quantum dots in the anti-solvent to act as nucleation centers in MAPbI3 thin films. These centers had lower nucleation barriers than homogeneous nucleation, improving perovskite crystallinity, reducing defects, and extending carrier lifetime. Fine-tuning the energy band also enhanced carrier transport. The most effective results were obtained using CsPb(Br_0.5 I_0.5)₃ perovskite quantum dots. The resulting device, ITO/SnO₂/MAPbI₃ (300 nm)/spiro-OMeTAD (200 nm)/Ag (100 nm), achieved a 12.88% power conversion efficiency, a 16% increase from the standard element. The modified device maintained approximately 95% of its efficiency over 100 h in a 70% humidity environment. Full article
