Accurate estimation of Interrupted Sampling Repeater Jamming (ISRJ) sampling duration is essential for effective radar anti-jamming. However, in complex electromagnetic environments, the simultaneous presence of suppressive and deceptive jamming, coupled with significant signal overlap in the time–frequency domain, renders ISRJ separation and parameter estimation considerably challenging. To address this challenge, this paper proposes a method utilizing the Fractional Fourier Transform (FRFT) and a Hybrid Modality Fusion Network (HMFN) for ISRJ signal separation and sampling-duration estimation. The proposed method first employs FRFT and a time–frequency mask to separate the ISRJ and target echo from the mixed signal. This process effectively suppresses interference and extracts the ISRJ signal. Subsequently, an HMFN is employed for high-precision estimation of the ISRJ sampling duration, offering crucial parameter support for active electromagnetic countermeasures. Simulation results validate the performance of the proposed method. Specifically, even under strong interference conditions with a Signal-to-Jamming Ratio (SJR) of −5 dB for deceptive jamming and as low as −10 dB for suppressive jamming, the regression model’s coefficient of determination still reaches 0.91. This result clearly demonstrates the method’s robustness and effectiveness in complex electromagnetic environments. Full article

To enhance the perception capability of radar in complex electromagnetic environments, this paper proposes an intelligent jamming recognition and parameter estimation method based on deep learning. The core idea of the method is to reformulate the jamming perception problem as an object detection task in computer vision, and we pioneer the application of oriented object detection to this problem, enabling simultaneous jamming classification and key parameter estimation. This method takes the time–frequency spectrogram of jamming signals as input. First, it employs the oriented object detection network YOLOv8-OBB (You Only Look Once Version 8–oriented bounding box) to identify three types of classic suppression jamming and five types of Interrupted Sampling Repeater Jamming (ISRJ) and outputs the positional information of the jamming in the time–frequency spectrogram. Second, for the five ISRJ types, a post-processing algorithm based on boxes fusion is designed to further extract features for secondary recognition. Finally, by integrating the detection box information and secondary recognition results, parameters of different ISRJ are estimated. In this paper, ablation experiments from the perspective of Non-Maximum Suppression (NMS) are conducted to simulate and compare the OBB method with the traditional horizontal bounding box-based detection approaches, highlighting OBB’s detection superiority in dense jamming scenarios. Experimental results show that, compared with existing jamming detection methods, the proposed method achieves higher detection probabilities under the jamming-to-noise ratio (JNR) ranging from 0 to 20 dB, with correct identification rates exceeding 98.5% for both primary and secondary recognition stages. Moreover, benefiting from the advanced YOLOv8 network, the method exhibits an absolute error of less than 1.85% in estimating six types of jamming parameters, outperforming existing methods in estimation accuracy across different JNR conditions. Full article

Interrupted sampling repeater jamming (ISRJ) is characterized by its coherent processing gains and flexible modulation techniques. ISRJ generates spurious targets along the range, which presents significant challenges to the radar systems. However, existing ISRJ countermeasure methods struggle to eliminate ISRJ signals without compromising the integrity of the real target signal, especially under low-signal-to-noise-ratio (SNR) conditions, resulting in a deteriorated sidelobe and diminished detection performance. We propose a complex-valued encoder–decoder network (CVEDNet) to address these challenges based on signal decomposition. This network offers an end-to-end ISRJ suppression approach, working on complex-valued time-domain signals without the need for additional preprocessing. The encoding and decoding structure suppresses noise components and obtains more compact echo feature representations through layer-by-layer compression and reconstruction. A stacked dual-branch structure and multi-scale dilated convolutions are adopted to further separate the echo signal and ISRJ based on high-dimensional features. A multi-domain combined loss function integrates the waveform and range-pulse-compression information to ensure the amplitude and phase integrity of the reconstructed echo waveform during the training process. The effectiveness of the proposed method was validated in terms of its jamming suppression capability, echo fidelity, and detection performance indicators under low-SNR conditions compared to conventional methods. Full article

A linear frequency modulation (LFM) signal and its corresponding de-chirp operation are one of the basic methods for wideband radar signal processing, which can reduce the burden of the radar system sampling rate and is more suitable for large-bandwidth signal processing. More importantly, most existing methods against interrupted sampling repeater jamming (ISRJ) are based on time–frequency (TF) or frequency domain analysis of the de-chirped signal. However, the above anti-ISRJ methods cannot be directly applied to multiple-input multiple-output (MIMO) radar with multiple beams, because the angular waveform (AW) in mainlobe directions does not possess the TF properties of the LFM signal. Consequently, this work focuses on the co-optimization of transmit beampattern and AW similarity in wideband MIMO radar systems. Different from the existing works, which only concern the space–frequency pattern of the transmit waveform, we recast the transmit beampattern and AW expressions for wideband MIMO radar in a more compact form. Based on the compact expressions, a co-optimization model of the transmit beampattern and AWs is formulated where the similarity constraint is added to force the AW to share the TF properties of the LFM signal. An algorithm based on the alternating direction method of multipliers (ADMM) framework is proposed to address the aforementioned problem. Numerical simulations show that the optimized waveform can form the desired transmit beampattern and its AWs have similar TF properties and de-chirp results to the LFM signal. Full article

Faced with increasingly complex electronic jamming environments, intra-pulse agility has become a primary method of anti-interrupted-sampling repeater jamming (ISRJ) for radar systems. However, existing intra-pulse agile signals suffer from high autocorrelation sidelobe levels and limited jamming suppression capabilities. These issues restrict the performance of intra-pulse agile signals in complex electromagnetic environments.This paper proposes an anti-interrupted-sampling repeater jamming method based on Simulated Annealing–2-optimization (SA-2opt) parallel optimization of waveforms and fractional domain extraction. Firstly, the proposed method employs the SA-2opt parallel optimization algorithm to optimize the joint frequency and chirp rate encoding waveform. Then, the received signal is subjected to the fractional Fourier transform (FrFT) and inverse transform to extract the target signal. Finally, jamming detection is conducted based on the multi-dimensional features of the pulse-compressed signal. After this detection, a time-domain filter is constructed to achieve jamming suppression. The optimized waveform exhibits the following advantages: the sub-pulses are orthogonal to each other, and autocorrelation sidelobe levels are as low as -20.7dB. The method proposed in this paper can achieve anti-ISRJ in the case of a high jamming-to-signal ratio (JSR). Simulation experiments validate both the effectiveness of the optimized waveform in achieving low autocorrelation sidelobes and the anti-ISRJ performance of the proposed method. Full article

Multiple-input multiple-output synthetic aperture radar (MIMO-SAR) anti-jamming waveform design relies on accurate prior information about the interference. However, it is difficult to obtain accurate prior knowledge about uncertain intermittent sampling repeater jamming (ISRJ), leading to a severe decline in the detection performance of MIMO-SAR systems. Therefore, this article studies the robust joint design problem of MIMO radar transmit waveform and filter against uncertain ISRJ. We characterize two categories of uncertain interference, including sample length uncertainty and sample-time uncertainty, modeled as Gaussian distribution in different range bins. Based on the uncertain interference model, we formulate the maximizing SINR as a figure of merit, which is a non-convex quadratic optimization problem under specific waveform constraints. Based on the alternating direction method of multipliers (ADMM) framework, a novel joint design algorithm of waveform and filter is proposed. In order to improve the convergence performance of ADMM, the difference in convex functions (DC) programming is applied to the ADMM iterations framework to solve the problem of waveform energy inequality constraint. Finally, numerical results demonstrate the effectiveness and robustness of the proposed method, compared to the existing methods that utilize deterministic interference models in the uncertain ISRJ environment. Moreover, the spaceborne SAR real scene imaging simulations are conducted to evaluate the anti-ISRJ performance. Full article

Compared with the amplitude modulation of conventional interrupted sampling repeater jamming (ISRJ), the image feature control method based on phase modulation exhibits greater energy efficiency and, therefore, has received wide attention recently. In this paper, an Inverse Synthetic Aperture Radar (ISAR) image feature suppression method based on arbitrary phase encoding (APE) is proposed. The parameter design criterion is further analyzed. Through the nonperiodic segmented coding and modulation of the imaging signal in fast and slow time domains, the modulated signal produces a two-dimensional suppression region with uniform energy distribution in the ISAR image. Simulations via the measured Yak-42 aircraft data have verified the effectiveness of the proposed method for target feature control. Compared to binary phase modulation jamming, the APE method with a phase modulation accuracy of 1 degree can achieve the same jamming effect while reducing the jamming power requirement by 3 dB. By optimizing with the proposed method, the image entropy of the interfered image increases by 1.1 to 1.5 compared to the original image. Full article

Interrupted-sampling repeater jamming (ISRJ) is widely used in the field of electronic countermeasures, and can severely affect radar detection. Therefore, the problem of ISRJ suppression is a compelling task. In this paper, we propose an ISRJ suppression method based on an intrapulse frequency-coded joint frequency modulation (FM) slope agile waveform. The intrapulse frequency-coded joint FM slope agile waveform is first designed. The delay inserted between subpulses makes the waveform easy to implement in engineering, and the ambiguity function diagram of the waveform approximates the ideal thumbtack type. Next, the echo slices are classified in the fractional domain utilizing the discontinuity of ISRJ and the focusing property of fractional Fourier transform for chirp signals. Then, the target and interference in the interfered echo slices are reconstructed by compressed sensing, and a time-domain filter is constructed based on interference-free echo slices. Finally, the echo signal after interference suppression is further filtered in the time domain to degrade range sidelobes. Simulation results show that the proposed method can effectively suppress three typical types of ISRJ. Moreover, the probability of target detection after interference suppression exceeds 90% when the jamming-to-signal ratio equals 50 dB. Full article

Distributed interrupted sampling repeater jamming (D-ISRJ) is the application of interrupted sampling repeater jamming technology within the framework of distributed jamming systems. It can generate coherent false targets after passing through the target radar’s matched filter, but these false targets exhibit strong regularity in range and amplitude. Addressing this issue, a distributed interrupted sampling frequency-shifted repeater jamming method based on the group teaching optimization algorithm (GTOA) is proposed in this paper. By introducing frequency-shifted modulation during the retransmission of the jamming signal, the frequency shift amount of the jamming unit in each round of repeater jamming is used as an optimization variable to construct an optimization model for distributed interrupted sampling frequency-shifted repeater jamming. The parameters are then solved by using GTOA. Simulations are conducted to analyze the jamming effects under different distributed jamming modes, and the proposed optimization algorithm is compared to common swarm intelligence algorithms in the same optimization model. The method proposed in this paper can be used in the field of precision electronic warfare to improve the jamming effect of synthetic aperture radar. Experimental results show that under the given simulation conditions, the jamming signal generated by the proposed method can achieve better jamming effects. Full article

In recent decades, the deception jamming approach based on digital radio frequency memory (DRFM) for inverse synthetic aperture radar (ISAR) has been a well-researched topic. Various types of jamming signals based on interrupted-sampling repeater jamming (ISRJ) can induce one-dimensional multiple high-resolution range profile (HRRP) false targets or two-dimensional realistic multiple ISAR false targets for deception. However, these existing methods generate false targets that are identical to the real target. The ISRJ false target also generates a main false target whose energy is much higher than other sub-false targets. Thus, it is easy to discover that the radar has suffered jamming. In order to generate better, more confusing jamming signals, this paper proposes a jamming method based on sub-Nyquist sampling jamming to induce realistic, multiple false targets on ISAR images. It improves a template multiplication modulated time-delay method to eliminate and add scatterers on the selected false target to change its ISAR shape. The frequency-shift parameters of the template jamming signal are analyzed and derived in detail for eliminating and adding scatterers at the specified location. Thus, multiple false targets with different ISAR shapes and similar energy are generated, which can create better deception effects. Meanwhile, this method can adjust the number of false targets and the location of changed-shape false targets. Furthermore, the resolution of the false target can adaptively change with the radar pulse width and the accumulated pulse number. The simulation results show that the proposed deception jamming strategy works. Full article

Interrupted-sampling repeater jamming (ISRJ) is a kind of intra-pulse coherent deception jamming that can generate false target peaks in the range profile and interfere with the detection and tracking of real targets. In this paper, an anti-ISRJ method based on the intra-pulse orthogonal waveform is proposed, which can recognize common interference signals by comparing sub-signal matched filtering results. For some special scenes where real targets cannot be directly differentiated from false targets, a new recognition method based on the energy discontinuity of the interference signal in the time domain is proposed in this paper. The method proposed in this paper can recognize real and false targets in all ISRJ modes without any prior information, such as jammer parameters, with a small amount of calculation, which is suitable for actual radar systems. Simulation experiments using different interference parameters show that although this method has a 3 dB loss of pulse compression gain, it can completely suppress different kinds of ISRJ interference when the SNR before pulse compression is higher than −20 dB, with 100% target detection probability. Full article

Digital radio frequency memory (DRFM) based repeater jamming can create false targets, which can lead to a loss of situational awareness, misidentification of targets, and decreased overall performance of the radar system. Traditional jamming suppression methods do not give due importance to the accurate estimation of the jamming edge, resulting in jamming residual and poor anti-jamming performance. To tackle this issue, this paper explores the reason and impact of inaccurate jamming edge estimation and proposes a DRFM-based repeater jamming reconstruction and cancellation method with accurate edge detection. In the proposed method, firstly, multiple jamming parameters are obtained by computing the short-time fractional Fourier transformation (STFRFT) spectrogram of the received signal. To avoid jamming residue, the proposed method estimates the accurate jamming edges by the joint use of the difference of box (DOB) filters and time domain deconvolution (TDDC) curves. Numerical simulations and experiments are conducted to evaluate the algorithm’s effectiveness in countering smeared spectrum (SMSP) and interrupted sampling repeater jamming (ISRJ). The results demonstrate its superior jamming reconstruction and suppression performance than other methods. Full article

Interrupted sampling repeater jamming (ISRJ) is a classic active coherent jamming. Due to its structural limitations, it has inherent defects such as a discontinuous time–frequency (TF) distribution, strong distribution regularity of pulse compression results, limited jamming amplitude, and strong false targets lagging behind the real target. These defects have not been fully resolved yet due to the limitation of the theoretical analysis system. Based on the analysis of the influence factors of ISRJ on the interference performance for linear-frequency-modulated (LFM) and phase-coded signals, this paper proposes an improved ISRJ method based on the joint subsection frequency shift and two-phase modulation. The coherent superposition of jamming signals at different positions for LFM signals is achieved by controlling the frequency shift matrix and the phase modulation parameters to form a strong pre-lead false target or multiple positions and ranges of blanket jamming areas. For the phase-coded signal, the pre-lead false targets are generated through code prediction and the two-phase modulation of the code sequence, resulting in similar noise interference. The simulation results show that this method can overcome the inherent defects of ISRJ. Full article

Jamming will seriously affect the detection ability of radar, so it is essential to suppress the jamming of radar echoes. Interrupted-sampling repeater jamming (ISRJ) based on a digital-radio-frequency-memory (DRFM) device can generate false targets at the victim radar by the interception and repeating of the radar transmission signal, which is highly correlated with the true target signal. ISRJ can achieve main lobe jamming and has both deception and oppressive jamming effects, so it is difficult for the existing methods to suppress this jamming effectively. In this paper, we propose a deep-learning-based anti-jamming network, named MSMD-net (Multi-stage Multi-domain joint anti-jamming depth network), for suppressing ISRJ main lobe jamming in the radar echo. In the first stage of MSMD-net, considering that the target signal is difficult to detect under a high jamming-to-signal ratio (JSR), we propose a preprocessing method of limiting filtering on the time-frequency domain to reduce the JSR using the auxiliary knowledge of radar. In the second stage, taking advantage of the discontinuity of the jamming in the time domain, we propose a UT-net network that combines the U-net structure and the transformer module. The UT-net performs target feature extraction and signal reconstruction in the signal time-frequency domain and preliminarily realizes the suppression of the jamming component. In the third stage, combined with phase information, a one-dimensional complex residual convolution U-net network (ResCU-net) is constructed in the time domain to realize jamming filtering and signal recovery further. The experimental results show that MSMD-net can obtain the best jamming suppression effect under different transmitted signals, different jamming modes, and different jamming parameters. Full article

Interrupted sampling repeater jamming (ISRJ) is an attracted coherent jamming method to inverse synthetic aperture radar (ISAR) in the past decades. By means of different jamming parameters settings, realistic dense false targets can be formed around the true target. This paper proposed an adaptive anti-jamming method against ISRJ by adjusting the number of measurements based on compressed sensing (CS). The jamming signal is energy concentrated and segmented sparse in the frequency domain. The measurements number of the reconstructed target signal and the jamming signal is different. According to the restricted isometry property (RIP) condition of CS theory, signal reconstructing performance depends on the number of measurements that varies with the sparsity of the vector. Thus, the jamming signal is suppressed, and the true target signal is retained by altering the measurements number of echo signals. Besides, the two-dimensional (2D) anti-jamming method is derived in detail. The anti-jamming effect is analyzed with different signal-to-noise ratios (SNR), sampling rates, and jam-to-signal ratios (JSR). Simulations prove the effectiveness of the proposed anti-jamming method. Full article
