Search Results (49)

Search Parameters:
Keywords = GaAs pHEMT process

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 3788 KiB
Article
On-Wafer Gate Screening Test for Improved Pre-Reliability in p-GaN HEMTs
by Giovanni Giorgino, Cristina Miccoli, Marcello Cioni, Santo Reina, Tariq Wakrim, Virgil Guillon, Nossikpendou Yves Sama, Pauline Gaillard, Mohammed Zeghouane, Hyon-Ju Chauveau, Maria Eloisa Castagna, Aurore Constant, Ferdinando Iucolano and Alessandro Chini
Micromachines 2025, 16(8), 873; https://doi.org/10.3390/mi16080873 - 29 Jul 2025
Viewed by 355
Abstract
In this paper, preliminary gate reliability of p-GaN HEMTs under high positive gate bias is studied. Gate robustness is of great interest both from an academic and industrial point of view; in fact, different tests and models can be explored to estimate the [...] Read more.
In this paper, preliminary gate reliability of p-GaN HEMTs under high positive gate bias is studied. Gate robustness is of great interest both from an academic and industrial point of view; in fact, different tests and models can be explored to estimate the device lifetime, which must meet some minimum product requirements, as specified by international standards (AEC Q101, JESD47, etc.). However, reliability characterizations are usually time-consuming and are performed in parallel on multiple packaged devices. Therefore, it would be useful to have a faster method to screen out weaker gate trials, already on-wafer, before reaching the packaging step. For this purpose, a room-temperature stress procedure is presented and described in detail. Then, this screening test is applied to devices with a reference gate process, and, as a result, high gate leakage degradation is observed. Afterwards, a different process implementing a dielectric layer between p-GaN and gate metal is evaluated, highlighting the improved behavior during the stress test. However, it is also observed that devices with this process suffer from very high drain leakage, and this effect is then studied and understood through TCAD (technology computer-aided design) simulations. Finally, the effect of a surface treatment performed on the p-GaN is analyzed, showing improved gate pre-reliability while maintaining low drain leakage. Full article
(This article belongs to the Special Issue III–V Compound Semiconductors and Devices, 2nd Edition)
Show Figures

Figure 1

14 pages, 2327 KiB
Article
A 17–38 GHz Cascode Low-Noise Amplifier in 150-nm GaAs Adopting Simultaneous Noise- and Input-Matched Gain Stage with Shunt-Only Input Matching
by Dongwan Kang, Yeonggeon Lee and Dae-Woong Park
Electronics 2025, 14(14), 2771; https://doi.org/10.3390/electronics14142771 - 10 Jul 2025
Viewed by 288
Abstract
This paper presents a 17–38 GHz wideband low-noise amplifier (LNA) designed in a 150-nm GaAs pHEMT process. The proposed amplifier adopts a cascode topology with an interstage inductor between the common-source (CS) and common-gate (CG) stages, and a series inductor at the source [...] Read more.
This paper presents a 17–38 GHz wideband low-noise amplifier (LNA) designed in a 150-nm GaAs pHEMT process. The proposed amplifier adopts a cascode topology with an interstage inductor between the common-source (CS) and common-gate (CG) stages, and a series inductor at the source node of the CS stage for source degeneration. By incorporating these inductors in the amplification stage, simultaneous noise and input matching is facilitated, while achieving flat gain characteristics over a broad frequency range and ensuring stability. In addition, the amplification stage with inductors achieves input matching using only a shunt component in the DC bias path, without any series matching elements. This approach allows the amplifier to achieve simultaneous noise and input matching (SNIM), ensuring low-noise performance over a wide bandwidth. The simulation results show a flat gain of 20–23 dB and a low noise figure of 1.1–2.1 dB over the 17–38 GHz band. Full article
(This article belongs to the Special Issue Radio Frequency/Microwave Integrated Circuits and Design Automation)
Show Figures

Figure 1

16 pages, 3537 KiB
Article
A 5–18 GHz Four-Channel Multifunction Chip Using 3D Heterogeneous Integration of GaAs pHEMT and Si-CMOS
by Bai Du, Zhiyu Wang and Faxin Yu
Electronics 2025, 14(12), 2342; https://doi.org/10.3390/electronics14122342 - 7 Jun 2025
Viewed by 505
Abstract
Compact, broadband, multi-channel RF chips with low loss and high integration are required for high-performance phased-array systems. Presented in this paper is a four-channel, multifunction RF chip operating in the 5–18 GHz frequency range that integrates broadband phase shifting, amplitude control, power amplification, [...] Read more.
Compact, broadband, multi-channel RF chips with low loss and high integration are required for high-performance phased-array systems. Presented in this paper is a four-channel, multifunction RF chip operating in the 5–18 GHz frequency range that integrates broadband phase shifting, amplitude control, power amplification, and switching functions. The chip is designed to have flip-chip bonding and stacked gold bumps to enable the compact 3D integration of the GaAs pHEMT and Si-CMOS. To ensure high-density interconnects with minimal parasitic effects, a fan-in redistribution process is implemented. The RF front-end part of this chip, fabricated through a 0.15 µm GaAs pHEMT process, integrates 6-bit digital phase shifters, 6-bit digital attenuators, low-noise amplifiers (LNAs), power amplifiers (PAs), and single-pole double-throw (SPDT) switches. To enhance multi-channel isolation and reduce crosstalk between RF chips and digital circuits, high isolation techniques, including a ground-coupled shield layer in the fan-in process and on-chip shield cavities, are utilized, which achieve isolation levels greater than 41 dB between adjacent RF channels. The measurement results demonstrate a reception gain of 0 dB with ±0.6 dB flatness, an NF below 11 dB, and transmit gain of more than 10 dB, with a VSWR of below 1.6 over the entire 5–18 GHz frequency band. The 6-bit phase shifter achieves a root mean square (RMS) phase error below 2.5° with an amplitude variation of less than 0.8 dB, while the 6-bit attenuator exhibits an RMS attenuation error of below 0.5 dB and a phase variation of less than 7°. The RF and digital chips are heterogeneously integrated using flip-chip and fan-in technology, resulting in a compact chip size of 6.2 × 6.2 × 0.33 mm3. These results validate that this is a compact, high-performance solution for advanced phased-array radar applications. Full article
Show Figures

Figure 1

12 pages, 5077 KiB
Article
Optimization of Low-Voltage p-GaN Gate HEMTs for High-Efficiency Secondary Power Conversion
by Lili Zhai, Xiangdong Li, Jian Ji, Lu Yu, Liang Chen, Yaoming Chen, Haonan Xia, Zhanfei Han, Junbo Wang, Xi Jiang, Song Yuan, Tao Zhang, Yue Hao and Jincheng Zhang
Micromachines 2025, 16(5), 556; https://doi.org/10.3390/mi16050556 - 2 May 2025
Viewed by 593
Abstract
The explosive demand for high-performance secondary power sources in artificial intelligence (AI) has brought significant opportunities for low-voltage GaN devices. This paper focuses on research on high-efficiency and high-reliability low-voltage p-GaN gate HEMTs with a gate–drain distance, LGD, of 1 to [...] Read more.
The explosive demand for high-performance secondary power sources in artificial intelligence (AI) has brought significant opportunities for low-voltage GaN devices. This paper focuses on research on high-efficiency and high-reliability low-voltage p-GaN gate HEMTs with a gate–drain distance, LGD, of 1 to 3 μm in our pilot line, manufactured on 6-inch Si using a CMOS-compatible process, with extraordinary wafer-level uniformity. Specifically, these fabricated p-GaN gate HEMTs with an LGD of 1.5 μm demonstrate a blocking voltage of over 180 V and a high VTH of 1.6 V and exhibit a low RON of 2.8 Ω·mm. It is found that device structure optimization can significantly enhance device reliability. That is, through the dedicated optimization of source field plate structure and interlayer dielectric (ILD) thickness, the dynamic ON-resistance, RON, degradation of devices with an LGD of 1.5 µm was successfully suppressed from 60% to 20%, and the VTH shift was significantly reduced from 1.1 to 0.5 V. Further, the devices also passed preliminary gate bias stress and high-voltage OFF-state stress tests, providing guidance for preparing high-performance, low-voltage p-GaN gate HEMTs in the future. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

10 pages, 3458 KiB
Communication
Sub-6 GHz GaAs SPDT Switch Co-Designed with Shunt Inductor for ESD Protection
by Jaehyun Kwon, Jaeyong Lee, Jinho Yoo, Taehun Kim and Changkun Park
Electronics 2025, 14(9), 1707; https://doi.org/10.3390/electronics14091707 - 23 Apr 2025
Viewed by 555
Abstract
In this study, a single-pole double-throw (SPDT) switch for Sub-6 GHz application is designed. In particular, a shunt inductor is connected to the antenna port of the switch for ESD (electrostatic discharge) protection in RF (radio frequency) front end module. The shunt inductor [...] Read more.
In this study, a single-pole double-throw (SPDT) switch for Sub-6 GHz application is designed. In particular, a shunt inductor is connected to the antenna port of the switch for ESD (electrostatic discharge) protection in RF (radio frequency) front end module. The shunt inductor not only serves as an ESD protection device, but also serves as a component of a parallel resonance circuit to suppress insertion loss of the switch. In addition, in order to secure the power handling capability, transistors turned off in the transmit (Tx) mode are implemented as quadruple-gate transistors. An SPDT switch is fabricated using GaAs pHEMT provided in the 500 nm GaAs BiFET process to verify the feasibility of the proposed switch structure. The operating frequency is set from 3 GHz to 5 GHz. The insertion loss and isolation measured in the Tx mode are lower than 0.35 dB and higher than 31.6 dB, respectively. The insertion loss and isolation measured in the Rx mode are lower than 0.32 dB and higher than 33.9 dB, respectively. The chip size including test pads is 0.890 × 0.875 mm2. Full article
Show Figures

Figure 1

12 pages, 6694 KiB
Article
Normally Off AlGaN/GaN MIS-HEMTs with Self-Aligned p-GaN Gate and Non-Annealed Ohmic Contacts via Gate-First Fabrication
by Yinmiao Yin, Qian Fan, Xianfeng Ni, Chao Guo and Xing Gu
Micromachines 2025, 16(4), 473; https://doi.org/10.3390/mi16040473 - 16 Apr 2025
Cited by 1 | Viewed by 767
Abstract
This study introduces an enhancement-mode AlGaN/GaN metal-insulator-semiconductor high-electron-mobility transistor (MIS-HEMT) featuring a self-aligned p-GaN gate structure, fabricated using a gate-first process. The key innovation of this work lies in simplifying the fabrication process by utilizing gate metallization for both electrical contact and etching [...] Read more.
This study introduces an enhancement-mode AlGaN/GaN metal-insulator-semiconductor high-electron-mobility transistor (MIS-HEMT) featuring a self-aligned p-GaN gate structure, fabricated using a gate-first process. The key innovation of this work lies in simplifying the fabrication process by utilizing gate metallization for both electrical contact and etching mask functions, enabling precise self-alignment. A highly selective Cl2/N2/O2 inductively coupled plasma (ICP) etching process was optimized to etch the p-GaN layer in the access regions, with a selectivity ratio of 33:1 and minimal damage to the AlGaN barrier. Additionally, a novel, non-annealed ohmic contact formation technique was developed, leveraging ICP etching to create nitrogen vacancies that facilitate contact formation without requiring thermal annealing. This technique streamlines the process by combining ohmic contact formation and mesa isolation into a single lithographic step. Incorporating a SiNx gate dielectric layer led to a 4.5 V threshold voltage shift in the fabricated devices. The resulting devices exhibited improved electrical performance, including a wide gate voltage swing (>10 V), a high on/off current ratio (~107), and clear pinch-off characteristics. These results demonstrate the effectiveness of the proposed fabrication approach, offering significant improvements in process efficiency and manufacturability. Full article
Show Figures

Figure 1

6 pages, 2491 KiB
Communication
A 6–18 GHz Low-Noise Amplifier with 19 dBm OP1dB and 2.6 ± 0.3 dB NF in 0.15 μm GaAs Process
by Xiyang Wang, Tao Men and Buwen Cheng
Electronics 2025, 14(8), 1600; https://doi.org/10.3390/electronics14081600 - 15 Apr 2025
Cited by 1 | Viewed by 563
Abstract
A three-stage low-noise amplifier (LNA) operating over the 6–18 GHz frequency range is designed and implemented, featuring a flat noise figure (NF) and enhanced output 1 dB compression point (OP1dB). To improve linearity and minimize distortion, a power high-electron-mobility transistor (HEMT) [...] Read more.
A three-stage low-noise amplifier (LNA) operating over the 6–18 GHz frequency range is designed and implemented, featuring a flat noise figure (NF) and enhanced output 1 dB compression point (OP1dB). To improve linearity and minimize distortion, a power high-electron-mobility transistor (HEMT) is employed in the final stage. Additionally, resistive feedback and self-biasing techniques are integrated to extend the amplifier’s bandwidth. The proposed LNA exhibits a high and flat power gain of 25 ± 1 dB, with an input return loss of more than 10 dB. The measured NF remains stable at 2.6 ± 0.3 dB over the 6–18 GHz range. Furthermore, the OP1dB exceeds 19.5 dBm across the entire 3 dB gain bandwidth (BW). The circuit is fabricated using a 0.15 μm GaAs pHEMT process, occupying a compact chip area of 1.2 × 1.8 mm2. Full article
Show Figures

Figure 1

12 pages, 7647 KiB
Article
Cryogenic MMIC Low-Noise Amplifiers for Radio Telescope Applications
by Haohui Wang and Maozheng Chen
Electronics 2025, 14(8), 1572; https://doi.org/10.3390/electronics14081572 - 13 Apr 2025
Viewed by 678
Abstract
This paper presents two cryogenic low-noise amplifiers (LNAs) based on the WIN’s 0.18 μm gate length gallium arsenide (GaAs) pseudomorphic high electron mobility transistor (pHEMT) process designed for radio telescope receivers. Discrete transistors with gate peripheries spanning 50–600 μm were DC-characterized [...] Read more.
This paper presents two cryogenic low-noise amplifiers (LNAs) based on the WIN’s 0.18 μm gate length gallium arsenide (GaAs) pseudomorphic high electron mobility transistor (pHEMT) process designed for radio telescope receivers. Discrete transistors with gate peripheries spanning 50–600 μm were DC-characterized at 290 K and 15 K, respectively. The LNAs underwent on-chip noise characterization under 15 K using a Y-factor measurement setup, which integrated a calibrated noise source and a noise figure analyzer. This approach directly quantified the noise temperature—critical metrics for radio telescope receiver front-ends. The top-performing LNA variant identified through on-chip characterization was packaged and evaluated in a cryogenic test-bed. This LNA, spanning a bandwidth of 0.3–15 GHz, demonstrated a gain of 26 dB and a minimum noise temperature of 6 K when operated at an ambient temperature of 15 K. In contrast, a second LNA architecture, tested solely on-chip, demonstrated a gain of 30 dB and a minimum noise temperature of 15 K across the 0.3–7 GHz range. Full article
Show Figures

Figure 1

11 pages, 6073 KiB
Article
Surge Current Capability and Failure Modes of 650 V p-GaN Gate HEMTs: A Multiphysics Study on Thermal–Electrical Coupling Effects
by Kuangli Chen, Rong Peng, Shuting Huang, Long Wang, Jianggen Zhu, Enchuan Duan, Bo Zhang and Qi Zhou
Electronics 2025, 14(7), 1321; https://doi.org/10.3390/electronics14071321 - 27 Mar 2025
Viewed by 497
Abstract
In this study, we present a comprehensive comparative analysis of the surge current capability in the third quadrant for four commercial 650 V p-GaN gate HEMTs. Temperature-dependent experiments reveal varying degrees of negative correlation between surge current capability and device junction temperature across [...] Read more.
In this study, we present a comprehensive comparative analysis of the surge current capability in the third quadrant for four commercial 650 V p-GaN gate HEMTs. Temperature-dependent experiments reveal varying degrees of negative correlation between surge current capability and device junction temperature across the four devices. Gate leakage testing and the decapsulation of failed devices identified two distinct failure modes. Through failure analysis techniques and TCAD simulations, the characteristics of these failure modes were thoroughly revealed. For Failure Mode I, the combined impact of electrical and thermal stress during the surge current process leads to extensive damage in the upper interconnect metal layer. For Failure Mode II, degradation of the metal to p-GaN Schottky contact under a strong electric field causes a rapid increase in the gate current, and the high gate current, coupled with the strong electric field, results in severe electromigration of the gate metal. Among the four tested devices, those exhibiting higher surge energy are more prone to gate damage, making them more susceptible to Failure Mode II. Full article
(This article belongs to the Special Issue Advances in Pulsed-Power and High-Power Electronics)
Show Figures

Figure 1

11 pages, 5969 KiB
Article
W-Band Low-Noise Amplifier with Improved Stability Using Dual RC Traps in Bias Networks on a 0.1 μm GaAs pHEMT Process
by Seong-Hee Han and Dong-Wook Kim
Micromachines 2025, 16(2), 219; https://doi.org/10.3390/mi16020219 - 15 Feb 2025
Viewed by 912
Abstract
This paper demonstrates that potential oscillations in various frequency bands of monolithic microwave integrated circuits (MMICs) can be effectively suppressed using well-designed dual RC traps in the bias networks. The proposed approach is applied to the design and development of a highly stable [...] Read more.
This paper demonstrates that potential oscillations in various frequency bands of monolithic microwave integrated circuits (MMICs) can be effectively suppressed using well-designed dual RC traps in the bias networks. The proposed approach is applied to the design and development of a highly stable W-band low-noise amplifier (LNA) MMIC for high-precision millimeter-wave applications. The amplifier is fabricated using the 0.1 µm GaAs pHEMT process from Win Semiconductors. The cascaded four-stage design consists of two low-noise-optimized stages, followed by two high-gain-tuned stages. Stability is enhanced through the integration of dual RC traps in the bias networks, which is rigorously evaluated using stability factors (K and μ) and network determinant function (NDF) encirclement analysis. In low-noise mode, the developed low-noise amplifier MMIC achieves a noise figure of 5.6−6.2 dB and a linear gain of 17.8−19.8 dB over the 90−98 GHz frequency range, while only consuming a DC power of 96 mW. In high-gain mode, it has a noise figure of 6.2−6.9 dB and a linear gain of 19.8−21.7 dB. Full article
(This article belongs to the Special Issue RF Devices: Technology and Progress)
Show Figures

Figure 1

14 pages, 4022 KiB
Article
A 13–33 GHz Wideband Low-Noise Amplifier in 150-nm GaAs Based on Simultaneous Noise- and Input-Matched Gain-Core with R-L-C Shunt Feedback Network
by Seonyeong Hwang, Dongwan Kang, Yeonggeon Lee and Dae-Woong Park
Electronics 2025, 14(3), 450; https://doi.org/10.3390/electronics14030450 - 23 Jan 2025
Cited by 2 | Viewed by 1098
Abstract
This work reports the concept of a shunt negative feedback technique for implementing a millimeter-wave wideband low-noise amplifier. The proposed shunt negative feedback network consists of a resistor–capacitor–inductor configuration. The proposed feedback network can achieve simultaneous noise and input matching (SNIM) over a [...] Read more.
This work reports the concept of a shunt negative feedback technique for implementing a millimeter-wave wideband low-noise amplifier. The proposed shunt negative feedback network consists of a resistor–capacitor–inductor configuration. The proposed feedback network can achieve simultaneous noise and input matching (SNIM) over a wide frequency range by adjusting the values of the resistor–capacitor–inductor configuration based on numerical analysis. By adopting the SNIM-based gain core as the first stage of the amplifier, the simulation results of the three-stage low-noise amplifier in a 150-nm GaAs pHEMT process achieve a gain of 15.6–18.6 dB and a noise figure of 1.05–2.8 dB in the frequency range of 13–33 GHz, respectively, while dissipating 99 mW. Full article
(This article belongs to the Special Issue RF/MM-Wave Circuits Design and Applications, 2nd Edition)
Show Figures

Figure 1

9 pages, 6003 KiB
Article
W-Band GaAs pHEMT Power Amplifier MMIC Stabilized Using Network Determinant Function
by Seong-Hee Han and Dong-Wook Kim
Micromachines 2025, 16(1), 81; https://doi.org/10.3390/mi16010081 - 12 Jan 2025
Cited by 1 | Viewed by 1190
Abstract
This paper presents a W-band power amplifier monolithic microwave integrated circuit (MMIC) that is designed for high-precision millimeter-wave systems and fabricated using a 0.1 µm GaAs pHEMT process. The amplifier’s stability was evaluated using the network determinant function, ensuring robust performance under both [...] Read more.
This paper presents a W-band power amplifier monolithic microwave integrated circuit (MMIC) that is designed for high-precision millimeter-wave systems and fabricated using a 0.1 µm GaAs pHEMT process. The amplifier’s stability was evaluated using the network determinant function, ensuring robust performance under both linear and nonlinear conditions. Simultaneous matching for gain and output power was achieved with minimal passive elements. The developed power amplifier MMIC exhibits a linear gain exceeding 20 dB and an input return loss greater than 6 dB across the 88–98 GHz range. It delivers an output power of 23.8–24.1 dBm with a power gain of 17.3–17.9 dB in the 88–97 GHz range and achieves a maximum power-added efficiency (PAE) of 24% at 94 GHz. Full article
Show Figures

Figure 1

11 pages, 2521 KiB
Article
Threshold Voltage Recovery Time Measurement Technique Post VTH Instability in Normally-Off p-Gate GaN High Electron Mobility Transistors
by Karthick Murukesan and Florin Udrea
Electronics 2024, 13(20), 4118; https://doi.org/10.3390/electronics13204118 - 18 Oct 2024
Viewed by 1884
Abstract
In this study, we propose a simple measurement technique to quantitatively measure the time taken by threshold voltage of normally-off p-GaN AlGaN/GaN HEMTs to recover from a nominal operational gate stress-induced instability. The proposed technique eliminates the requirement to perform a full transfer [...] Read more.
In this study, we propose a simple measurement technique to quantitatively measure the time taken by threshold voltage of normally-off p-GaN AlGaN/GaN HEMTs to recover from a nominal operational gate stress-induced instability. The proposed technique eliminates the requirement to perform a full transfer characteristic sweep post-stress, thereby eliminating the measurement-induced instability effect, often colluding precise recovery time measurement. The rate of recovery and extracted recovery times hold significance in empirically correlating the location of traps in the p-GaN or AlGaN barrier region causing VTH instability. The gate of the HEMT is stressed at nominal operational drive voltages 1.5 V, 2 V, and 4 V for various time intervals from 500 μs to 100 s, and the time taken for the drain current to recover to prestress levels measured at near-threshold voltage (~1.1 VTH) is measured as the threshold voltage recovery time. With increasing gate stress voltages, 2DEG gets trapped at relatively deeper trap energy levels at the AlGaN/GaN interface requiring more emission time during the process of recovery, mandating larger recovery times. At higher stress voltage of 4 V, the Schottky gate leakage current is high enough enabling injected holes to cross the AlGaN barrier and counter-compensate for the deeply trapped 2DEG, requiring relatively the same recovery times as lower stress voltages where the gate leakage is negligibly small. With increasing stress time, the amount of 2DEG trapped increases, requiring more recovery time to de-trap and beyond a certain time, saturation of the trap density occurs causing the recovery time to plateau. Full article
(This article belongs to the Special Issue Research and Application of Wide Band Gap Semiconductors)
Show Figures

Figure 1

15 pages, 4820 KiB
Article
An S–K Band 6-Bit Digital Step Attenuator with Ultra Low Insertion Loss and RMS Amplitude Error in 0.25 μm GaAs p-HEMT Technology
by Quanzhen Liang, Kuisong Wang, Xiao Wang, Yuepeng Yan and Xiaoxin Liang
Appl. Sci. 2024, 14(9), 3887; https://doi.org/10.3390/app14093887 - 1 May 2024
Cited by 2 | Viewed by 3771
Abstract
This paper presents an ultra-wideband, low insertion loss, and high accuracy 6-bit digital step attenuator (DSA). To improve the accuracy of amplitude and phase shift of the attenuator, two innovative compensation structures are proposed in this paper: a series inductive compensation structure (SICS) [...] Read more.
This paper presents an ultra-wideband, low insertion loss, and high accuracy 6-bit digital step attenuator (DSA). To improve the accuracy of amplitude and phase shift of the attenuator, two innovative compensation structures are proposed in this paper: a series inductive compensation structure (SICS) designed to compensate for high frequency attenuation values and a small bit compensation structure (SBCS) intended for large attenuation bits. Additionally, we propose insertion loss reduction techniques (ILRTs) to reduce insertion loss. The fabricated 6-bit DSA core area is only 0.51 mm2, and it exhibits an attenuation range of 31.5 dB in 0.5 dB steps. Measurements reveal that the root-mean-square (RMS) attenuation and phase errors for the 64 attenuation states are within 0.18 dB and 7°, respectively. The insertion loss is better than 2.54 dB; the return loss is better than −17 dB; and the input 1 dB compression point (IP1 dB) is 29 dBm at IF 12 GHz. To the best of our knowledge, this chip presents the highest attenuation accuracy, the lowest insertion loss, the best IP1dB, and a good matching performance in the range of 2–22 GHz using the 0.25 μm GaAs p-HEMT process. Full article
(This article belongs to the Special Issue Trends and Prospects in Applied Electromagnetics)
Show Figures

Figure 1

15 pages, 5737 KiB
Article
A 28 GHz GaN 6-Bit Phase Shifter MMIC with Continuous Tuning Calibration Technique
by Soyeon Seo, Jinho Lee, Yongho Lee and Hyunchol Shin
Sensors 2024, 24(4), 1087; https://doi.org/10.3390/s24041087 - 7 Feb 2024
Viewed by 2292
Abstract
A 28 GHz digitally controlled 6-bit phase shifter with a precision calibration technique in GaN high-electron mobility transistor (HEMT) technology is presented for Ka-band phased-array systems and applications. It comprises six stages, in which stages 1 and 2 for 5.625° and 11.25° are [...] Read more.
A 28 GHz digitally controlled 6-bit phase shifter with a precision calibration technique in GaN high-electron mobility transistor (HEMT) technology is presented for Ka-band phased-array systems and applications. It comprises six stages, in which stages 1 and 2 for 5.625° and 11.25° are designed in the form of a switched-line circuit, and stages 3, 4, and 5 for 22.5°, 45°, and 90° are designed in the form of a switched-filter circuit. The final stage 6 for 180° is designed in a single-to-differential balun followed by a single-pole double-throw (SPDT) switch for achieving an efficient phase inversion. A novel continuous tuning calibration technique is proposed to improve the phase accuracy. It controls the gate bias voltage of off-state HEMTs at the stage 6 SPDT switch for fine calibration of the output phase. Fabricated in a 0.15 μm GaN HEMT process using a die size of 1.75 mm2, the circuit produces 64 phase states at 28 GHz with a 5.625° step. The experimental results show that the Root-Mean-Square (RMS) phase error is significantly improved from 8.56° before calibration to 1.08° after calibration. It is also found that the calibration does not induce significant changes for other performances such as the insertion loss, RMS amplitude error, and input-referred P1dB. This work successfully demonstrates that the GaN technology can be applied to millimeter-wave high-power phased-array transceiver systems. Full article
(This article belongs to the Special Issue Advanced RF/Microwave Electronics for Upcoming Wireless Generations)
Show Figures

Figure 1
