Search Results (48)

Since its launch in 2016, a number of wind speed retrieval algorithms have been developed for the NASA CYGNSS satellite observations. We assess their accuracy and precision and characterize the dependence of their performance on environmental factors. The dependence of retrieval uncertainty on the wind speed itself is considered. The triple colocation method of validation is used to correct for the quality of the reference wind speed products with which CYGNSS is compared. The dependence of retrieval performance on sea state is also considered, with particular attention being paid to the long wave portion of the surface roughness spectrum that is less closely coupled to the instantaneous local wind speed than the capillary wave portion of the spectrum. The dependence is found to be significant, and the efficacy of the approaches taken to account for it is examined. The dependence of retrieval accuracy on wind speed persistence (the change in wind speed prior to a measurement) is also characterized and is found to be significant when winds have increased markedly in the ~2 h preceding an observation. Full article

Vegetation water content (VWC) is a crucial parameter for evaluating vegetation growth, climate change, natural disasters such as forest fires, and drought prediction. Spaceborne global navigation satellite system reflectometry (GNSS-R) has become a valuable tool for soil moisture (SM) and biomass remote sensing (RS) due to its higher spatial resolution compared with microwave measurements. Although previous studies have confirmed the enormous potential of spaceborne GNSS-R for vegetation monitoring, the utilization of this technology to fuse multiple RS parameters to retrieve VWC is not yet mature. For this purpose, this paper constructs a local high-spatiotemporal-resolution spaceborne GNSS-R VWC retrieval model that integrates key information, such as bistatic radar cross section (BRCS), effective scattering area, CYGNSS variables, and surface auxiliary parameters based on five ensemble machine learning (ML) algorithms (i.e., bagging tree (BT), gradient boosting decision tree (GBDT), extreme gradient boosting (XGBoost), random forest (RF), and light gradient boosting machine (LightGBM)). We extensively tested the performance of different models using SMAP ancillary data as validation data, and the results show that the root mean square errors (RMSEs) of the BT, XGBoost, RF, and LightGBM models in VWC retrieval are better than 0.50 kg/m². Among them, the BT and RF models performed the best in localized VWC retrieval, with RMSE values of 0.50 kg/m². Conversely, the XGBoost model exhibits the worst performance, with an RMSE of 0.85 kg/m². In terms of RMSE, the RF model demonstrates improvements of 70.00%, 52.00%, and 32.00% over the XGBoost, LightGBM, and GBDT models, respectively. Full article

The GNSS-based bistatic SAR (GNSS-BSAR) system has emerged as a hotspot due to its low power consumption, nice concealment, and worldwide reach. However, the weak landing power density of the GNSS signal often necessitates prolonged integration to achieve an adequate signal-to-noise ratio (SNR). In this case, the effects of the receiver’s time-frequency errors and atmospheric disturbances are significant and cannot be ignored. Therefore, we propose an ionospheric scintillation compensation-based imaging scheme for dual-channel GNSS-BSAR system. This strategy first extracts the reference phase, which contains the ionospheric phase scintillation and other errors. Subsequently, the azimuth phase of the target is divided into difference phase and reference phase. We apply the two-step phase compensation to eliminate Doppler phase errors, thus achieving precise focusing of SAR images. Three sets of experiments using the GPS L5 signal as the illuminator were conducted, coherently processing a 1.5 km by 0.8 km scene about 300 s. The comparative results show that the proposed method exhibited better focusing performance, avoiding the practical challenges encountered by traditional autofocus algorithms. Additionally, ionospheric phase scintillation extracted at different times of the day suggest diurnal variations, preliminary illustrating the potential of this technology for ionospheric-related studies. Full article

GNSS-Reflectometry, a technique that harnesses the power of microwave remote sensing, is poised to revolutionize our ability to detect and monitor near-surface soil freeze/thaw processes. This technique’s theoretical underpinnings are deeply rooted in the comprehensive explanation of the Zhang–Zhao dielectric constant model, which provides crucial insights into the behavior of frozen and thawed soils. The model elucidates how the dielectric properties of soil change as it transitions between frozen and thawed states, offering a scientific basis for understanding reflectivity variations. Furthermore, the theoretical framework includes a set of formulas that are instrumental in calculating reflectivity at Lower Right (LR) polarization and in deriving Dual-Polarization Differential Observables (DDMs). These calculations are pivotal for interpreting the signals captured by GNSS-R sensors, allowing for the detection of subtle changes in the soil’s surface conditions. The evolution of GNSS-R as a tool for detecting freeze/thaw phenomena has been substantiated through qualitative analyses involving multiple satellite missions, such as SMAP-R, TDS-1, and CYGNSS. These analyses have provided empirical evidence of the technique’s effectiveness, illustrating its capacity to capture the dynamics of soil freezing and thawing processes. In addition to these qualitative assessments, the application of a discriminant retrieval algorithm using data from CYGNSS and F3E GNOS-R has further solidified the technique’s potential. This algorithm contributes to refining the accuracy of freeze/thaw detection by distinguishing between frozen and thawed soil states with greater precision. The deployment of space-borne GNSS-R for monitoring near-surface freeze/thaw cycles has yielded commendable results, exhibiting robust consistency and delivering relatively precise retrieval outcomes. These achievements stand as testaments to the technique’s viability and its growing significance in the field of remote sensing. However, it is imperative to recognize and actively address certain limitations that have been highlighted in this review. These limitations serve as critical focal points for future research endeavors, directing the efforts toward enhancing the technique’s overall performance and applicability. Addressing these challenges will be essential for leveraging the full potential of GNSS-R to advance our understanding and management of near-surface soil freeze/thaw processes. Full article

Feature capture and recognition of sea wave components in radar systems especially in global navigation satellite system reflectometry (GNSS-R) using signal processing approaches or computer simulative methods has become a research hotspot in recent years. At the same time, parameter inversion of marine phenomena from the discovered characteristics plays a significant role in monitoring and forewarning the different components of sea waves. This paper aims to investigate the impact of multiple parameters, such as the wind speed, directionality variable, wave amplitude, wave length, and directions of sea wave components, on the delay waveform of the delay–Doppler map (DDM). Two types of wind waves and the 2-D sinusoidal sea surface are chosen to be analyzed. By comparing and analyzing the discrepancy of delay waveforms under different conditions, it can be concluded that the increased MSS which arises from the increase in the roughness of the sea surface can lead to the difference in the peak value or trial edges exhibited in delay waveforms. The values of delay waveforms at zero chip along the increasing direction of long-crest wind waves exhibit the periodic spikes shape, which is the opposite of the short-crest wind waves, and the fluctuation of the periodic profiles decreases with the increase in the amplitude of waves. The results and conclusions can provide a foundation for the parameter inversion, tracking, and early warning of anomalous formations of waves in bistatic radar configuration. Full article

Measurements of grazing angle GNSS-R ocean reflections combined with meteorological troposphere data are used for retrieval of ocean wave heights and surface roughness parameters. The observational results are compared to multiphase screen simulations for the same atmosphere conditions. The retrieved data from observations and simulations give equal results within the error bounds of the methods. The obtained ocean mean wave-heights are almost proportional to the square of the wind speed when applying a first-order approximation model to the high-wave-number part of the measured GNSS-R power spectra. The spectral variances from the measurements link directly to the ocean surface roughness, which is also verified by the performed multiple phase-screen wave propagation simulations. Thus, grazing angle GNSS-R techniques are an efficient method for determining the ocean state and the conditions in the boundary layer of the troposphere. Full article

Global Navigation Satellite System Reflectometry (GNSS-R) is an emerging earth observation method for remote sensing of feature parameters using reflected signals from navigation satellites, and is a purely specular bistatic forward scattering observation means with special right-handed circular polarization incident wave. In this paper, the small-slope approximation model of non-Gaussian sea surface is used as the basis to construct the scattering model for the observation geometry of GNSS-R as well as the L-band characteristics, and the fully-polarization normalized bistatic radar scattering cross section (NBRCS) are simulated by the method of polarization synthesis to analyze the scattering characteristics under different wind speeds and directions on the ocean surface, which highlights the variation of NBRCS with wind direction, and the scattering modeling accuracy is improved by comparing with the data of CYGNSS. In addition, we adopt the observation geometry deviating from purely specular geometry, discuss the scattering azimuth angle, scattering influence, and the relative relationship between different polarizations of the scattering angle under the non-specular geometry. Full article

Inland water bodies, wetlands and their dynamics have a key role in a variety of scientific, economic, and social applications. They are significant in identifying climate change, water resource management, agricultural productivity, and the modeling of land–atmosphere exchange. Changes in the extent and position of water bodies are crucial to the ecosystems. Mapping water bodies at a global scale is a challenging task due to the global variety of terrains and water surface. However, the sensitivity of spaceborne Global Navigation Satellite System Reflectometry (GNSS-R) to different land surface properties offers the potential to detect and monitor inland water bodies. The extensive dataset available in the Cyclone Global Navigation Satellite System (CYGNSS), launched in December 2016, is used in our investigation. Although the main mission of CYGNSS was to measure the ocean wind speed in hurricanes and tropical cyclones, we show its capability of detecting and mapping inland water bodies. Both bistatic radar cross section (BRCS) and signal-to-noise ratio (SNR) can be used to detect, identify, and map the changes in the position and extent of inland waterbodies. We exploit the potential of unsupervised machine learning algorithms, more specifically the clustering methods, K-Means, Agglomerative, and Density-based Spatial Clustering of Applications with Noise (DBSCAN), for the detection of inland waterbodies. The results are evaluated based on the Copernicus land cover classification gridded maps, at 300 m spatial resolution. The outcomes demonstrate that CYGNSS data can identify and monitor inland waterbodies and their tributaries at high temporal resolution. K-Means has the highest Accuracy (93.5%) compared to the DBSCAN (90.3%) and Agglomerative (91.6%) methods. However, the DBSCAN method has the highest Recall (83.1%) as compared to Agglomerative (82.7%) and K-Means (79.2%). The current study offers valuable insights and analysis for further investigations in the field of GNSS-R and machine learning. Full article

A global navigation satellite system (GNSS)-based multistatic radar is explored for target localization and kinematic state estimation. Since any point on the earth can be illuminated by a minimum of four satellites of each GNSS constellation at any time, GNSS-based passive radars can be inherently considered multistatic radars. In this paper, a method for jointly estimating the target position and velocity by utilizing both the time delays and Doppler shifts has been proposed, and an analytical accuracy analysis is also provided. In the new method, the bistatic range and Doppler for each path are firstly estimated by the range-Doppler (RD) method, and then by using the bistatic ranges and Doppler shifts. The least squares method is applied to estimate the target position and velocity simultaneously. Compared with the precedent target localization and velocity estimation method, the proposed method achieves a better estimation result with simple procedures. Simulation results are provided to validate the effectiveness of the proposed method. Full article

The reflection of Global Navigation Satellite Systems (GNSS) signals, namely GNSS-Reflectometry (GNSS-R), has recently proven to be able to monitor land surface properties in the microwave spectrum, at a global scale, and with very low revisiting time. Moreover, this new technique has numerous additional advantages, including low cost, low power consumption, lightweight and small payloads, and near real-time massive data availability, as compared to conventional monostatic microwave remote sensing. However, the GNSS-R surface reflectivity values estimated through the bistatic radar equation, and the Fresnel coefficients have shown a lack of coincidence with real surface reflectivity data, mostly due to calibration issues. Previous studies have attempted to avoid this matter with direct regression methods between uncalibrated GNSS-R reflectivity data and external soil moisture content (SMC) products. However, calibration of GNSS-R reflectivity used in traditional inversion models is still a challenge, such as those to estimate SMC, freeze/thaw, or biomass. In this paper, a successful procedure for GNSS-R reflectivity calibration is established using data from the CYGNSS (Cyclone GNSS) constellation. The scale and bias parameters are estimated from the theoretical dielectric properties of water and dry sand, which are well-known and empirically validated values. We employ four calibration areas that provide maximum range limits of reflectivity, such as deserts and wetlands. The CYGNSS scale factor and the bias parameter resulted in a = 3.77 and b = 0.018, respectively. The derived scale and bias parameters are applied to the CYGNSS dataset, and the retrieved SMC values through the Fresnel reflection coefficients are in excellent agreement with the Soil Moisture Active Passive (SMAP) SMC product. Then, the SMAP SMC is used as a reference true value, and provides a standard linear regression with an R-square coefficient of 0.803, a root mean square error (RMSE) of 0.084, and a Pearson’s correlation coefficient of 0.896. Full article

This manuscript focuses on the need for tailoring flood assessment products to decision making within the humanitarian sector. Decision-makers often struggle to extract all of the information contained in scientific products, either because they come from different fields of expertise or because they have different needs that are not captured in the results or the processing of the data. Here we define the key elements of a flood assessment product designed for the humanitarian sector. From a remote sensing perspective, in order to assess flooding, the measurement sampling properties, i.e., spatial resolution and temporal repeat, are key. We have therefore implemented a methodology through the processing and interpretation of the measurements from the Cyclone Global Navigation Satellite System (CYGNSS) mission. CYGNSS measurements are usually parametrized in various possible observables. Those observables are then linked to the surface characteristics, such as, in this case, the presence of inundation in the CYGNSS footprint. Our methodology includes the variability of the pixels in landscapes with infrastructure, rivers, agricultural fields, rural areas, and other elements characteristic of the agricultural-urban interface. We provide an original methodology that uses CYGNSS mission bistatic radar measurements and an artificial intelligence classification algorithm based on statistical properties of the land pixels through a k-means clustering strategy to detect and monitor flooding events, as well as to characterize the land surface prior to and post flooding events. The novel methodology to derive a flooding product is then evaluated towards the needs of the humanitarian sector by a cognizant link (a translator) between technologists or scientists and decision-makers. The inclusion of humanitarian needs into product development following the advice of a cognizant link is novel to the applications developed employing GNSS bistatic radar data. Full article

In this article, we present a link budget analysis for Global Navigation Satellite System (GNSS) signals scattered off the sea surface in arbitrary acquisition geometries. The aim of our study is to investigate the reliability of the Geometrical Optics (GO) scattering model, which accurately describes sea surface scattering at and near the specular reflection direction, in properly modeling the sea surface return in far-from-specular acquisition geometries, which are of interest for maritime surveillance purposes and where GO is expected to fail. To this end, we adopted the recent Bistatic Anisotropic Polarimetric Two-Scale Model (BA-PTSM), which revealed good agreement with advanced scattering models, such as the second-order Small Slope Approximation (SSA2), regardless of the acquisition geometry, with the advantage of a reduced computational complexity. Numerical results have been derived for both circular polarization channels and for both spaceborne and airborne GNSS-Reflectometry (GNSS-R). It has been shown that, as long as conventional GNSS-R processing is assumed, GO can be safely adopted for simulation and analysis of spaceborne GNSS-R data regardless of the acquisition geometry and sea state, whereas more accurate scattering models, e.g., BA-PTSM, should be used for airborne receivers in far-from-specular configurations. Full article

The anomalous propagation conditions, particularly the tropospheric ducts, severely impact the regular operation and performance evaluation of radio devices in the atmospheric boundary layer. Therefore, it is necessary to provide the regional distribution of tropospheric ducts for utilizing or avoiding these abnormal propagation phenomena. As significant uncooperative signal sources, the global navigation satellite systems (GNSS) have been widely applied in the remote sensing of the ocean and atmosphere due to the greater convenience and lower cost. With the completed deployment of the BeiDou Navigation Satellite System (BDS) in 2020, an additional source can be chosen in the relevant studies. Taking the BDS as an example, since the scattered signals from the ocean surface at low satellite elevation angles can be effectively trapped by tropospheric ducts, we propose a method to invert for the regional distribution of tropospheric ducts using the received power of ocean-scattered signals in this paper. Firstly, the propagation model was built to calculate the received power, and a suite of simulations was made in various atmospheric environments. The results suggested that the received power is more sensitive to the surface duct without a base layer. Then, we made a preliminary estimation of the tropospheric ducts on the ocean nearby Qingdao utilizing the Weather Research and Forecasting (WRF) model as well as the echo data measured by a Doppler weather radar. Before the inversion, the actual satellite azimuth and elevation angles should be obtained to evaluate the bistatic scattering coefficients and the received powers of the selected satellite signals. Finally, we presented an inversion example using the proposed method. In absence of the actual measurements, the received powers pre-estimated at different SNRs served as the inputs of the inversion process and the estimated duct parameters were used to verify the validity of the proposed inversion method. For both the received power and modified refractivity profile, the fitness between the values pre-estimated using the estimated duct parameters and calculated by the inverted duct parameters gets better as the elevation angle decreases and the SNR increases. The variation of the fitness between the estimated and inverted values is slightly different for each duct parameter. Moreover, the calculation of inversion errors further explained the above behaviors, including the mean absolute error (MAE) and the root mean square error (RMSE). Despite some certain errors, the inversion results maintain the overall tendencies and most characteristics of the estimated values, thus proving the validity of the inversion method. Full article

Global Navigation Satellite System Reflectometry (GNSS-R) is a rapidly developing Earth observation technology that makes use of signals of opportunity from Global Navigation Satellite Systems that have been reflected off the Earth’s surface. The Cyclone Global Navigation Satellite System (CyGNSS) is a constellation of eight small satellites launched by NASA in 2016, carrying dedicated GNSS-R payloads to measure ocean surface wind speed at low latitudes (±35° North/South). The ESA ECOLOGY project evaluated CyGNSS v3.0 products, which were recently released following various calibration updates. This paper examines the performance of the new calibration by evaluating CyGNSS v3.0 Level-1 Normalised Bistatic Radar Cross Section (NBRCS) and Leading Edge Slope (LES) data from individual CyGNSS units and different GPS transmitters under constant ocean wind conditions. Results indicate that L1 NBRCS from individual CyGNSS units are well inter-calibrated and remarkably stable over time, a significant improvement over previous versions of the products. However, prominent geographical biases reaching over 3 dB are found in NBRCS, linked to factors including the choice of GPS transmitter and the bistatic geometry. L1 LES shows similar anomalies as well as a secondary geographical pattern of biases. These findings provide a basis for further improvement of CyGNSS Level-2 wind products and have wider applicability to improving the calibration of GNSS-R sensors for the remote sensing of non-ocean Earth surfaces. Full article

Deformation monitoring has been brought to the fore and extensively studied in recent years. Global Navigation Satellite System Reflectometry (GNSS-R) techniques have so far been developed in deformation estimation applications, which however, are subject to the influence of mobile satellites. Rather than compensating for the path delay variations caused by mobile satellites, adopting Beidou geostationary Earth orbit (GEO) satellites as transmitters directly eliminates the satellite-motion-induced phase error and thus provides access to stable phase information. This paper presents a novel deformation monitoring concept based on GNSS-R utilizing Beidou GEO satellites. The geometrical properties of the GEO-based bistatic GNSS radar system are explored to build a theoretical connection between deformation quantity and the echo carrier phases. A deformation retrieval algorithm is proposed based on the supporting software receiver, thus allowing echo carrier phases to be extracted and utilized in deformation retrieval. Two field validation experiments are conducted by constructing passive bistatic radars with reflecting plates and ground receiver. Utilizing the proposed algorithm, the experimental results suggested that the GEO-based GNSS reflectometry can achieve deformation estimations with an accuracy of around 1 cm when the extracted phases does not exceed one complete cycle, while better than 3 cm when considering the correct integer number of phase cycles. Consequently, based on the passive bistatic radar system, the potential of achieving continuous, low-cost deformation monitoring makes this novel technique noteworthy. Full article
