Search Results (30)

This paper proposes a frequency-modulated continuous-wave synthetic aperture radar (FMCW-SAR) imaging system for fast target detection. The system’s antenna array improves azimuthal resolution while maintaining low complexity using a 44-element equivalent virtual array and improves the data acquisition efficiency by employing the trigger and MCU control board. A series of improved algorithms are adopted to increase the speed of radar imaging and achieve fast detection. To solve the problem of large data volumes in traditional array antenna switching control methods, an array switching control algorithm is proposed based on the enhanced ordered statistical constant false alarm rate (EOS-CFAR). The data volume is reduced by dividing the array into several subarrays in advance. The echo signals acquired by the array switching control method are not continuous in the azimuthal direction, and data anomalies are handled by interpolating and compensating the received radar data to form compensated periodic data. The coherent background is subtracted from the padded signal using recursive averaging, resulting in high-resolution imaging while improving the data-processing speed. The TensorFlow-based Omega-K algorithm is employed for synthetic aperture radar (SAR) imaging, which customizes the optimization of TensorFlow for array radar signals. For the radar signal phase optimization, an improved Adam Optimizer optimizes the phase of the radar signal to maintain phase smoothing, thereby improving the clarity of the radar image. The Omega-K algorithm is optimized by TensorFlow and accelerated on the GPU to improve the efficiency of the large-scale fast Fourier transform (FFT) and Stolt interpolation operations, which improves the speed of radar imaging and enables fast detection. Full article

This paper introduces a high-resolution 77–81 GHz mmWave Synthetic Aperture Radar (SAR) imaging methodology integrating low-cost hardware with modified radar signal characteristics specifically for NDT applications. The system is optimized to detect minimal defects in materials, including low-reflectivity ones. In contrast to the existing studies, by optimizing key system parameters, including frequency slope, sampling interval, and scanning aperture, high-resolution SAR images are achieved with reduced computational complexity and storage requirements. The experiments demonstrate the effectiveness of the system in detecting optically undetectable minimal surface defects down to 0.4 mm, such as bonded adhesive lines on low-reflectivity materials with 2500 measurement points and sub-millimeter features on metallic targets at a distance of 30 cm. The results show that the proposed system achieves comparable or superior image quality to existing high-cost setups while requiring fewer data points and simpler signal processing. Low-cost, low-complexity, and easy-to-build mmWave SAR imaging is constructed for high-resolution SAR imagery of targets with a focus on detecting defects in low-reflectivity materials. This approach has significant potential for practical NDT applications with a unique emphasis on scalability, cost-effectiveness, and enhanced performance on low-reflectivity materials for industries such as manufacturing, civil engineering, and 3D printing. Full article

Spotlight/sliding spotlight modes can achieve higher resolution than the other imaging modes and are widely used in object detection and recognition applications. This paper reviews the progress of the spaceborne spotlight/sliding spotlight SAR imaging field. The three steps of the current spaceborne spotlight/sliding spotlight SAR imaging algorithm framework are discussed in this paper. These include the following: eliminating the azimuth spectral aliasing by azimuth deramp preprocessing; implementing imaging processing using imaging kernels (RD, CS, RMA, etc.); and degrading the back-folded phenomenon in the final focused image domain by reference function multiplication post-processing. The different imaging kernels, consisting of RD, CS, RMA, BAS, FS, and PFA, are presented. The phase errors in high-resolution spaceborne spotlight/sliding spotlight SAR imaging, especially the stop-and-go error, curved orbit error, and tropospheric delay error, are analyzed in detail. Furthermore, the autofocus methods are described. In addition, some new imaging SAR systems based on spotlight/sliding spotlight SAR mode, which have more advantages than the classic spaceborne spotlight/sliding spotlight SAR imaging, were shown in this paper. These include FMCW-based systems, multichannel systems, varying-PRF systems, and bistatic systems. Full article

This study presents a numerical modeling approach that utilizes millimeter-wave (mm-Wave) Frequency-Modulated Continuous-Wave (FMCW) radar to reconstruct and classify five weapon types: grenades, knives, guns, iron rods, and wrenches. A dataset of 1000 images of these weapons was collected from various online sources and subsequently used to generate 3605 samples in the MATLAB (R2022b) environment for creating reflectivity-added images. Background reflectivity was considered to range from 0 to 0.3 (with 0 being a perfect absorber), while object reflectivity was set between 0.8 and 1 (with 1 representing a perfect electric conductor). These images were employed to reconstruct high-resolution weapon profiles using a monostatic two-dimensional (2D) Synthetic Aperture Radar (SAR) imaging technique. Subsequently, the reconstructed images were classified using a Convolutional Neural Network (CNN) algorithm in a Python (3.10.14) environment. The CNN architecture consists of 10 layers, including multiple convolutional, pooling, and fully connected layers, designed to effectively extract features and perform classification. The CNN model achieved high accuracy, with precision and recall values exceeding 98% across most categories, demonstrating the robustness and reliability of the model. This approach shows considerable promise for enhancing security screening technologies across a range of applications. Full article

In recent years, drone-based Synthetic Aperture Radar (SAR) systems have emerged as flexible and cost-efficient solutions for detecting changes in the Earth’s surface, retrieving topographic data, or detecting ground displacement processes in localized areas, among other applications. These systems offer a unique combination of short and versatile revisit times and flexible acquisition geometries that are not achievable with space-borne, airborne, or ground-based SAR sensors. However, due to platform limitations and flight stability issues, they also present significant challenges regarding instrument design and data processing, particularly when generating interferometric repeat-pass datasets. This paper demonstrates the feasibility of repeat-pass interferometry using a Ku-band drone-based SAR system. The system integrates a dual-channel Ku-band Frequency Modulated Continuous Wave (FMCW) radar with cross-track single-pass interferometric capabilities, mounted on a drone platform. The proposed repeat-pass interferometric processing chain leverages an accurate Digital Elevation Model (DEM), generated from the single-pass interferograms, to precisely coregister the entire stack of acquisitions, thereby producing repeat-pass interferograms free from residual motion errors. The results underscore the potential of this system and the processing chain proposed for generating multi-temporal repeat-pass stacks suitable for repeat-pass applications. Full article

Flint Hall Farm in Godstone, Surrey, UK, is situated adjacent to the London Orbital Motorway, or M25, and contains several landslide systems which pose a significant geohazard risk to this critical infrastructure. The site has been routinely monitored by geotechnical engineers following a landslide that encroached onto the hard shoulder in December 2000; current in situ instrumentation includes inclinometers and piezoelectric sensors. Interferometric Synthetic Aperture Radar (InSAR) is an active remote sensing technique that can quantify millimetric rates of Earth surface and structural deformation, typically utilising satellite data, and is ideal for monitoring landslide movements. We have developed the hardware and software for an Unmanned Aerial Vehicle (UAV), or drone radar system, for improved operational flexibility and spatial–temporal resolutions in the InSAR data. The hardware payload includes an industrial-grade DJI drone, a high-performance Ettus Software Defined Radar (SDR), and custom Copper Clad Laminate (CCL) radar horn antennas. The software utilises Frequency Modulated Continuous Wave (FMCW) radar at 5.4 GHz for raw data collection and a Range Migration Algorithm (RMA) for focusing the data into a Single Look Complex (SLC) Synthetic Aperture Radar (SAR) image. We present the first SAR image acquired using the drone radar system at Flint Hall Farm, which provides an improved spatial resolution compared to satellite SAR. Discrete targets on the landslide slope, such as corner reflectors and the in situ instrumentation, are visible as bright pixels, with their size and positioning as expected; the surrounding grass and vegetation appear as natural speckles. Drone SAR imaging is an emerging field of research, given the necessary and recent technological advancements in drones and SDR processing power; as such, this is a novel achievement, with few authors demonstrating similar systems. Ongoing and future work includes repeat-pass SAR data collection and developing the InSAR processing chain for drone SAR data to provide meaningful deformation outputs for the landslides and other geotechnical hazards and infrastructure. Full article

In this work, the airborne Synthetic Aperture Radar (SAR) infrastructure developed at the Institute for Electromagnetic Sensing of the Environment (IREA) of the National Research Council of Italy (CNR) is described. This infrastructure allows IREA-CNR to plan and execute airborne SAR campaigns and to process the acquired data with a twofold aim. On one hand, the aim is to develop research activities; on the other hand, the aim is to support the emergency prevention and management activities of the Department of Civil Protection of the Italian Presidency of the Council of Ministers, for which IREA-CNR serves as National Centre of Competence. Such infrastructure consists of a flight segment and a ground segment that include a multi-frequency airborne SAR sensor based on the Frequency-Modulated Continuous Wave (FMCW) technology and operating in the X- and L-bands, an Information Technology (IT) platform for data storage and processing and an airborne SAR data processing chain. In this work, the technical aspects related to the flight and ground segments of the infrastructure are presented. Moreover, a discussion on the response times and characteristics of the final products that can be achieved with the infrastructure is provided with the aim of showing its capabilities to support the monitoring activities required in a possible emergency scenario. In particular, as a case study, the acquisition and subsequent interferometric processing of airborne SAR data relevant to the Stromboli volcanic area in the Sicily region, southern Italy, are presented Full article

In order to reduce the hardware cost and data acquisition time in near-field scenarios, such as airport security imaging systems, this paper discusses the layout of a multiple-input multiple-output (MIMO) radar array. In view of the existing multi-input multiple-output imaging algorithm, the reconstructed image artifacts and aliasing problems caused by sparse sampling are discussed. In this paper, a multi-station radar array and a corresponding sparse MIMO imaging algorithm based on combined sparse sub-channels are proposed. By studying the wave–number spectrum of backscattered MIMO synthetic aperture radar (SAR) data, the nonlinear relationship between the wave number spectrum and reconstructed image is established. By selecting a complex gain vector, multiple channels are coherently combined effectively, thus eliminating aliasing and artifacts in the reconstructed image. At the same time, the algorithm can be used for the MIMO–SAR configuration of arbitrarily distributed transmitting and receiving arrays. A new multi-station millimeter wave imaging system is designed by using a frequency-modulated continuous wave (FMCW) chip and sliding rail platform as a planar SAR. The combination of the hardware system provides reconfiguration, convenience and economy for the combination of millimeter wave imaging systems in multiple scenes. Full article

As the demand for precise navigation of aircraft increases in modern society, researching high-precision, high-autonomy navigation systems is both theoretically valuable and practically significant. Because the inertial navigation system (INS) has systematic and random errors, its output information diverges. Therefore, it is necessary to combine them with other navigation systems for real-time compensation and correction of these errors. The SAR matching positioning and navigation system uses synthetic aperture radar (SAR) image matching for platform positioning and compensates for the drift caused by errors in the inertial measurement unit (IMU). Images obtained by SAR are matched with digital landmark data, and the platform’s position is calculated based on the SAR imaging geometry. However, SAR matching positioning faces challenges due to seasonal variations in SAR images, the need for typical landmarks for matching, and the lack of elevation information in two-dimensional SAR image matching. This paper proposes an airborne platform positioning method based on interferometric SAR (InSAR) interferogram matching. InSAR interferograms contain terrain elevation information, are less affected by seasonal changes, and provide higher positioning accuracy and robustness. By matching real-time InSAR-processed interferograms with simulated interferograms using a digital elevation model (DEM), three-dimensional position information about the matching points has been obtained. Subsequently, a three-dimensional positioning model for the platform has bene established using the unit line-of-sight vector decomposition method. In actual flight experiments using an FMCW Ku-band Interferometric SAR system, the proposed platform positioning framework demonstrated its ability to achieve precise positioning in the absence of signals from the global navigation satellite system (GNSS). Full article

The synthetic aperture radar (SAR) imaging technique for a frequency-modulated continuous wave (FMCW) has attracted wide attention in the field of burden surface profile measurement. However, the imaging data are virtually under-sampled due to the severely restricted scan time, which prevents the antenna being exposed to high temperatures and heavy dust in the blast furnace (BF) for an extended period. In traditional SAR imaging algorithm research, the insufficient accumulation of scattered energy in reconstructing the burden surface profile leads to lower imaging precision, and the harsh smelting increases the probability of distortion in shape detection. In this study, to address these challenges, a novel rotating SAR imaging algorithm based on the constructed mechanical swing radar system is proposed. This algorithm is inspired by the low-rank property of the sampled signal matrix and the sparsity of burden surface profile images. First, the sparse FMCW signal is modeled, and the position transform matrix, calculated according to the BF dimensions, is embedded into the dictionary matrix. Then, the low-rank and sparsity priors are considered and reformulated as split variables in order to establish a convex optimization problem. Lastly, the augmented Lagrange multiplier (ALM) is employed to solve this problem under double constraints, and the imaging results are obtained using the alternating direction method of multipliers (ADMM). The experimental results demonstrate that, in the subsequent shape detection, the root mean square error (RMSE) is 15.38% lower than the previous algorithm and 15.63% lower under low signal-to-noise (SNR) conditions. In both enclosed and harsh environments, the proposed algorithm is able to achieve higher imaging precision even under high noise. It will be further optimized for speed and reliability, with plans to extend its application to 3D measurements in the future. Full article

Many fields of human activity benefit from the ability to create images of obscured objects placed behind walls and to map their displacement in a noninvasive way. Usually, imaging devices like Synthetic Aperture Radars (SARs) and Ground-Penetrating Radars (GPRs) use expensive dedicated electronics which results in prohibitive prices. This paper presents the experimental implementation and the results obtained from an imaging system capable of performing SAR imaging and interferometric displacement mapping of targets located behind walls, as well as 3D GPR imaging using a low-cost general-purpose radar sensor. The proposed solution uses for the RF section of the system a K-band microwave radar sensor module implementing Frequency-Modulated Continuous Wave (FMCW) operation. The low-cost sensor was originally intended for simple presence detection and ranging for domestic applications. The proposed system was tested in several scenarios and proved to operate as intended for a fraction of the cost of a commercial imaging device. In one scenario, it was able to detect and locate a 15 cm-diameter fire-extinguisher located at a distance of 3.5 m from the scanning system and 1.6 m behind a 3 cm-thick MDF (medium-density fiberboard) wall with cm-level accuracy. In a second test, the proposed system was used to perform interferometric displacement measurements, and it was capable of determining the displacement of a metal case with sub-millimeter accuracy. In a third experiment, the system was used to construct a 3D image of the inside of a wood table with cm-level resolution. Full article

In order to achieve miniaturization, short-range radar (SRR) generally adopts millimeter-wave (MMW) radar with a frequency-modulated continuous-wave (FMCW) system, which may make the stop–go–stop assumption in traditional synthetic aperture radar (SAR) imaging algorithms invalid. In addition, in order to observe a large enough area, SRR often needs a wide radar beam, which may cause serious range–azimuth coupling when using SRR for SAR imaging. The above two problems may make the traditional SAR imaging algorithm invalid in SRR SAR imaging. Taking the SRR SAR imaging application into account, traditional frequency domain SAR imaging algorithms are analyzed and improved in this paper. Firstly, the intra-pulse motion (IPM) caused by the FMCW system and the two-dimensional coupling (TDC) in the case of a wide beam are analyzed. Subsequently, the applicability of the range Doppler algorithm (RDA), the frequency scaling algorithm (FSA) and the range migration algorithm (RMA) for SRR SAR is analyzed. Then, improvement measures are put forward to address the aliasing and folding phenomena caused by the wide-beam problem in the FSA and RMA, respectively. Finally, the effectiveness of the proposed algorithm is verified using simulation data and real measured data collected using an MMW radar fixed on a slide rail. Full article

To address the limitations of wireless sensing in static gesture recognition and the issues of Computer Vision’s dependence on lighting conditions, we propose a method that utilizes millimeter-wave near-field SAR (Synthetic Aperture Radar) imaging for static gesture recognition. First, a millimeter-wave near-field SAR imaging system is used to scan the defined static gestures to obtain data. Then, based on the distance plane, the three-dimensional gesture is divided into multiple two-dimensional planes, constructing an imaging dataset. Finally, an HOG (Histogram of Oriented Gradients) is used to extract features from the imaging results, PCA (Principal Component Analysis) is applied for feature dimensionality reduction, and RF (Random Forest) performs classification. Experimental verification shows that the proposed method achieves an average recognition precision of 97% in unobstructed situations and 93% in obstructed situations, providing an effective means for wireless-sensing-based static gesture recognition. Full article

In this paper, we present a novel two dimensional (2D) frequency-modulated continuous-wave (FMCW) localization method for handheld systems based on the extraction of distinguishable subchannel fingerprints. Compared with other concepts, only one subdivided radar source channel is needed in order to instantly map a one-dimensional measurement to higher-dimensional space coordinates. The additional information of the detected target is implemented with low-cost hardware component features, which exhibit distinguishable space-dependent fingerprint codes. Using the given a priori information of the hardware thus leads to a universally applicable extension for low-cost synthetic aperture radar (SAR)-demining purposes. In addition to the description of the system concept and its requirements, the signal processing steps and the hardware components are presented. Furthermore, the 2D localization accuracy of the system and the classification accuracy of the frequency-coded fingerprints are described in a defined test environment to proof the operational reliability of the realized setup, reaching a classification accuracy of 94.7% and an averaged localization error of 4.9 mm. Full article

In this study, we investigate a millimeter wave (mmWave) synthetic aperture radar (SAR) imaging scheme utilizing a low-cost frequency modulated continuous wave (FMCW) radar to take part in non-destructive testing which could be a useful tool for both civilian and military demands. The FMCW radar working in the frequency range from 76 GHz to 81 GHz is equipped with a 2-D moving platform aiming to reconstruct the 2-D image of the shape of the target object. Due to the lab environment containing several devices and furniture, various noise and interference signals from the floor are not avoidable. Therefore, the digital signal processing algorithms are joined to remove the undesired signals as well as improve the target recognition. This study adopts the range migration algorithms (RMAs) on the processed reflected signal data to form the image of the target because of its verified ability in this type of mission. On the other hand, the integration of compressed sensing (CS) algorithms into the SAR imaging system is also researched which helps to improve the performance of the system by reducing the measurement duration while still maintaining the image quality. Three minimization algorithms are used involving the imaging system as the CS solvers reconstruct the radar data before being processed by RMA to form the image. The proposed imaging scheme demonstrates its good ability with high azimuth resolution in the mission of detecting tiny cracks in the rebar of reinforced concrete. In addition, the participation of CS algorithms improves the performance of the scheme as the cracks on the rebar can be located on the images, which are reconstructed from only 30% of the dataset. The comparison of CS solvers shows that ADMM outperforms the other candidates in the reconstruction task. Full article
