Search Results (23)

Miniaturized components for enhanced integrated functionality or thin sheets for lightweight applications often consist of face-centered cubic metals. They exhibit good strength, corrosion resistance, formability and recyclability. Microfabrication technologies, however, may introduce cold work or detrimental heat-induced lattice defects into the material, with consequences for the mechanical properties. Austenitic stainless steels (1.4310, 1.4301) and aluminum alloys (EN AW-5005-H24, EN AW-6082-T6) were selected for this study. The influence of pulsed fiber laser cutting, microwaterjet cutting, and annealing on the strain–stress behavior was investigated. The micro-tensile test setup comprised a flex-structure force sensor, a laser extensometer, and a dedicated sample holder. Fiber laser cut 1.4310 samples exhibited early failure at low fracture strain in narrow shear band zones. The shear band zones were detectable on the sample surface, in the laser extensometer images, in the horizontal sections of the stress–strain curves, and in the microstructure. Inside the shear band zones, grains were strongly elongated and exhibited numerous parallel planar defects. Heat-induced chromium carbides, in combination with low stacking fault energy (SFE) and elevated carbon content, favored shear band zone formation in 1.4310. In contrast, microwaterjet cut high SFE materials EN AW-5005-H24 and EN AW-6082-T6, as well as low-carbon austenitic stainless steel 1.4301, exhibited uniform plastic deformation. Full article

In recent years, Golden Hard Anodizing (G.H.A.^®) has been developed as a variant of the traditional hard anodizing process with the addition of Ag⁺ ions in the nanoporous structure. The tribological properties of this innovative surface treatment are still not well understood. In this study, ball-on-disk tests were conducted in dry sliding conditions using 100Cr6 (AISI 52100) bearing steel balls as a counterbody and GHA^®-anodized EN AW-6082 aluminum alloy disks. The novelty of this work lies in the mapping of the wear properties of the tribocouple under different test conditions for a better comparison of the results. Three different normal loads (equal to 5, 10, and 15 N) and three different reciprocating frequencies (equal to 2, 3, and 4 Hz) were selected to investigate a spectrum of operating conditions for polished and unpolished G.H.A.^®-anodized EN AW-6082 aluminum alloy. Quantitative wear maps were built based on the resulting wear rate values to define the critical operating limits of the considered tribocouple. The results suggest that the coefficient of friction (COF) was independent of test conditions, while different wear maps were found for polished and non-polished surfaces. Polishing before anodizing permitted the acquisition of lower wear for the anodized disks and the steel balls. Full article

In the project work, CES EDUPACK material selection software and Arc melter 500 arc remelting equipment were used to select good-performance materials and produce a sample. First, aluminum alloys were considered due to their low weight; alloys Al7075, Al6082, and EN AW 6022 in different states were examined for maximum hardness and electrical conductivity, and then the Cu–Cr–Zr alloy was analyzed. The test results showed that for the EN AW 6082 alloy, the specimens heat-treated at 480 °C for 2 h + 175 °C for 2 h following the ECAP (equal channel angular pressing) A route or C route technique gave the best hardness–electrical conductivity pair. In the case of the EN AW 7075 alloy, the artificially aged sample after 4× ECAP forming showed the maximum values. In the case of EN AW 6022, which according to the Ashby chart may be the best alloy for the value pair sought, this alloy was fabricated, resulting in only as-cast samples being analyzed. Of the Cu alloys, the Cu–0.49–0.21Zr alloy after heat treatment at 450 °C for 1 h gives the most favorable hardness–conductivity. Full article

Due to its good conductive properties, unalloyed (pure) aluminum, such as EN AW-1050A H24, finds new fields of application in electromobility. To optimize components, the cyclic material behavior must be understood and described precisely as a foundation of a proper fatigue life estimation. Various cyclic tests were performed to not only derive the cyclic parameters to describe the material but also to find the most suitable procedure to deal with the challenges faced during the experiments. The main point of interest is the comparison between a surface-mounted clip-on extensometer and an optical system both used for strain control in cyclic tests. For the analysis of the anisotropic behavior of EN AW-1050A H24, un-notched flat specimens were extracted from sheet metal lengthways and crossways in respect to the rolling direction. While the cyclic material behavior for specimens of both directions of extraction is characterized by cyclic softening in general, the specimens extracted crossways show a strain-amplitude-dependent cyclic softening with strong strain localization especially at the contact points of the knives of the clip-on extensometer leading to an increased quantity of invalid experiments as well as sudden fractures. In the study, it was possible to show the benefits of a contactless optical strain control system when dealing with very soft metallic materials such as EN AW-1050A H24. Full article

The growing use of aluminum and its compounds has increased the volume of aluminum waste. To mitigate environmental impacts and cut down on manufacturing expenses, extensive investigations have recently been undertaken to recycle aluminum compounds. This paper outlines the outcomes of a study on fabricating standard EN AW-2007 alloy using industrial and secondary scrap through continuous casting. The resultant recycled bars were analyzed for their chemical makeup and examined for microstructural features in both the cast and T4 states, undergoing mechanical property evaluations. The study identified several phases in the cast form through LM, SEM + EDS, and XRD techniques: Al₇Cu₂Fe, θ-Al₂Cu, β-Mg₂Si, Q-Al₄Cu₂Mg₈Si₇, and α-Al₁₅(FeMn)₃ (SiCu)_2, along with Pb particles. Most primary intermetallic precipitates such as θ-Al₂Cu, β-Mg₂Si, and Q-Al₄Cu₂Mg₈Si₇ dissolved into the α-Al solid solution during the solution heat treatment. In the subsequent natural aging process, the θ-Al₂Cu phase predominantly emerged as a finely dispersed hardening phase. The peak hardness achieved in the EN AW-2007 alloy was 124.8 HB, following a solution heat treatment at 500 °C and aging at 25 °C for 80 h. The static tensile test assessed the mechanical and ductility properties of the EN AW-2007 alloy in both the cast and T4 heat-treated states. Superior strength parameters were achieved after solution heat treatment at 500 °C for 6 h, followed by water quenching and natural aging at 25 °C/9 h, with a tensile strength of 435.0 MPa, a yield strength of 240.5 MPa, and an appreciable elongation of 18.1% at break. The findings demonstrate the feasibility of producing defect-free EN AW-2007 alloy ingots with excellent mechanical properties from recycled scrap using the continuous casting technique. Full article

The prerequisite of the weld bead finishing is intricately linked to the quality of the welded joint. It constitutes the final, yet pivotal, stage in its formation, significantly influencing the reliability of structural components and machines. This article delineates an innovative post-weld surface finishing method, distinguished by the movement of a specialized cutting tool along a butt weld. This method stands out due to its singular approach to machining allowance, wherein the weld bead height is considered and eradicated in a single pass of the cutting tool. Test samples were made of AISI 304L, AISI 316L stainless steels and EN AW-5058 H321, EN AW-7075 T651 aluminum alloys butt-welded with TIG methods. Following the welding process, the weld bead was finished in accordance with the innovative method to flush the bead and the base metal’s surface. For the quality control of welded joints before and after the weld finishing, two non-destructive testing methods were chosen: Penetrant Testing (PT) and Radiographic Testing (RT). This article provides results from the examination of 2D profile parameters and 3D stereometric characteristics of surface roughness using the optical method. Additionally, metallographic results are presented to assess changes in the microstructure, the microhardness, and the degree of hardening within the surface layer induced by the application of the innovative post-weld finishing method. Full article

Friction stir welding, as a solid-state welding technique, is especially suitable for effectively joining high-strength aluminum alloys, as well as for multi-material welds. This research investigates the friction stir welding of thin aluminum and steel sheets, an essential process in the production of hybrid tailor-welded blanks employed in deep drawing applications. Despite its proven advantages, the welding process exhibits variable outcomes concerning formability and joint strength when utilizing an H13 welding tool. To better understand these inconsistencies, multiple welds were performed in this study, joining 1 mm thick steel to 2 mm thick aluminum sheets, with a cumulative length of 7.65 m. The accumulation of material on the welding tool was documented through 3D scanning and weighing. The integrity of the resulting weld seam was analyzed through metallographic sections and X-ray imaging. It was found that the adhering material built up continuously around the tool pin over several welds totaling between 1.5 m and 2.5 m before ultimately detaching. This accretion of material notably affected the welding process, resulting in increased intermixing of steel particles within the aluminum matrix. This research provides detailed insights into the dynamics of friction stir welding in multi-material welds, particularly in the context of tool material interaction and its impact on weld quality. Full article

Civil engineering structures are often loaded cyclically in addition to static loading. For the design of cyclic-loaded aluminum structures, EN 1999-1-3 provides several notch cases for a verification based on the nominal stress concept. These notch cases do not distinguish between the different available alloys exhibiting varying characteristics, such as static mechanical properties in the heat-affected zone. Furthermore, for welded details only longitudinal or transverse welding is covered without the possibility for considering inclined welding with multiaxial stress states. However, load-controlled fatigue testing of two different alloys and specimens out of base material, specimens with 45° welding and transverse welding, respectively, have shown the clear influence of alloy and weld angle on the fatigue strength of welded aluminum details. In this paper, the respective experimental and numerical results of two alloys, EN AW-6082 T6 and EN AW-5754 O/H111, and two weld angles, 45° and 90°, are presented and discussed. Full article

Ensuring adequate reliability of the production process of packaging closures has made it necessary to study the effect of annealing and varnishing variants on the strength and structural properties of the stock material. As a test material, EN AW-5052-H28 aluminium alloy sheets with a thickness of 0.21 mm were used. The surface treatment of the test material involved varnishing the sheet metal surface using various varnishes and soaking the sheet metal. The coefficient of friction and the abrasion resistance of the coatings were determined using the T-21 ball-and-disc tribotester. The tested sheets were subjected to tribological analysis by the T-05 roller-block tribotester using countersamples made of Caldie and Sverker 21 tool steels. The results of the tests showed differences in mechanical and structural properties depending on the method of sample preparation. Based on the test results, significant differences in the adhesion of anti-wear coatings were found. The results revealed that the most favourable friction conditions are provided by the CrN coating. The (AlTi)N interlayer in the (AlTi)N/(AlCr)N coating adheres to the substrate over the entire tested area and no detachment from its surface was observed, which proves good bonding at the substrate/coating interface. The tested AlTiN/TiAlSiXN coating is characterised by a more homogeneous, compact microstructure compared to the (AlTi)N/(AlCr)N coating. Full article

The damage and failure behavior of anisotropic ductile metals depends on the material direction and on the stress state. Consequently, these effects have to be taken into account in material modeling and the corresponding numerical simulation, and also have to be experimentally investigated in a controlled and well-reproducible manner. In this context, the present paper focused on new biaxial experiments with the anisotropic aluminum alloy EN AW-2017A. Experiments with the newly developed, biaxially loaded H-specimen were performed with a focus on shear and shear-compression stress states. The formation of strain fields in critical parts of the H-specimen was monitored by digital image correlation, and fracture surfaces were visualized by scanning electron microscopy. Stress states were predicted by corresponding numerical simulations and they facilitated the comprehension of the damage and fracture processes at the micro level. The experiments with shear-compression stress states were realized with a special down-holder to avoid buckling, which enabled a well-controlled study in this generally difficult-to-access range. Furthermore, the anisotropic characterization of ductile sheet metals can be realized by an enhanced experimental program with a wide range of load ratios and loading directions. Full article

The article presents the effect of the thermo-chemical treatment of Al₂O₃ layers on their nanostructure, surface morphology, chemical composition as well as their micromechanical and sclerometric properties. Oxide layers were produced on EN AW-5251 aluminium alloy (AlMg₂) by the method of direct current anodizing in a three-component electrolyte. The thermo-chemical treatment was carried out in distilled water and aqueous solutions of Na₂SO₄·10H₂O and Na₂Cr₂O₇·2H₂O. It was shown that the thermo-chemical treatment process changes the morphology of the surface of the layers (the formation of a sub-layer from the Na₂SO₄·10H₂O and Na₂Cr₂O₇·2H₂O solutions), which directly increases the thickness of the layers by 0.37 and 1.77 µm, respectively. The thermo-chemical treatment in water also resulted in the formation of a 0.63 µm thick sub-layer. The micromechanical tests indicated a rise in the surface microhardness of the layers in the case of their thermo-chemical treatment in water and the Na₂SO₄·10H₂O solution and a decrease in the case of the layers modified in the Na₂Cr₂O₇·2H₂O solution. The highest microhardness (7.1 GPa) was exhibited by the layer modified in the Na₂SO₄·10H₂O solution. Scratch tests demonstrated that the thermo-chemically treated layers had better adhesive properties than the reference layer. The best scratch resistance was exhibited by the layer after thermo-chemical treatment in the Na₂SO₄·10H₂O solution (the highest values, practically for all the critical loads) which, together with its low roughness and high load capacity, predispose it to sliding contacts. Full article

The article presents the results of an aluminum oxide layer doped with monolayer 2H tungsten disulphide (Al₂O₃/WS₂) for applications in oil-free kinematic systems. The results concern the test carried out on the pneumatic actuator operational test stand, which is the actual pneumatic system with electromagnetic control. The cylinders of actuators are made of Ø 40 mm aluminum tube of EN-AW-6063 aluminum alloy which is used in the manufacture of commercial air cylinder actuators. The inner surfaces of the cylinder surfaces were covered with an Al₂O₃/WS₂ oxide layer obtained by anodic oxidation in a three-component electrolyte and in the same electrolyte with the addition of tungsten disulfide 2H-WS₂. The layers of Al₂O₃ and Al₂O₃/WS₂ obtained on the inner surface of the pneumatic actuators were combined with a piston ring made of polytetrafluoroethylene with carbon (T5W) material and piston seals made of polyurethane (PU). The cooperation occurred in the conditions of technically dry friction. After the test was carried out, the scanning electron microscopy with energy dispersive spectroscopy (SEM/EDS) analysis of the surface of the cylinder bearing surfaces and piston seals of the pneumatic cylinders was performed. The analysis revealed the formation of a sliding film on the cylinder surface modified with tungsten disulfide, as well as on the surface of wiper seals. Based on the SEM/EDSM tests, it was also found that the modification of the Al₂O₃ layer with tungsten disulfide contributed to the formation of a sliding film with the presence of WS₂ lubricant, which translated into smooth cylinder operation during 180 h of actuator operation. The cylinder with the unmodified layer showed irregular operation after approximately 70 h thereof. Full article

Friction stir welding has become important in many areas of production and is increasingly used for joining aluminum components. For long welding seams, conventional tools with only one welding pin reach their technical limitations due to low gap bridgeability. When welding aluminum, the stirred in surface layers, such as oxides, lead to a decrease in static and dynamic strength since linear accumulations are formed in the welding seam. The aim of the present study is to increase the gap bridgeability using tools with various welding pins and to prevent linear accumulation in the welding seam. The results show that a gap bridgeability of up to 2 mm for 4 mm material thickness is possible for the aluminum alloys EN AW 5083 H111 and EN AW 7020 T651. With the help of multi-pin tools, no impact of the gap width on the tensile strength was observed for joint gaps of up to 0.9 mm when using butt joint with a sheet thickness of 4 mm. Furthermore, the use of multi-pin tools showed significant influence on the prevention of linear accumulations in the welding seam. In addition, the oxide layers were finely distributed in welded joints using multi-pin tools. Full article

When extruding the casted rods from EN AW 2011 aluminium alloys, not only their homogenized structure, but also their extrudable properties were significantly influenced by the hardness of the alloy. In this study, the object of investigations was the EN AW 2011 aluminium alloy, and the effect of homogenisation time on hardness was investigated. First, homogenisation was carried out at 520 °C for different times, imitating industrial conditions. After homogenisation, the samples were analysed by hardness measurements and further characterised by microscopy and image analysis to verify the influence of homogenisation on the resulting microstructural constituents. In addition, non-equilibrium solidification was simulated using the program Thermo-Calc and phase formation during solidification was investigated. The homogenisation process enabled more rounded shape of the Al₂Cu eutectic phase, equilibrium formation of the phases, and the precipitation in the matrix, leading to a significant increase in the hardness of the EN AW 2011 aluminium alloy. The experimental data revealed a suitable homogenisation time of 4–6 h at a temperature of 520 °C, enabling optimal extrusion properties. Full article

A new method to determine electromagnetic forming limits curves (EM-FLCs) for sheet metals is proposed. The different strain paths (between uniaxial and biaxial tension) are achieved by specific tool coil and specimen designs. It is ensured that the apex of the specimen deforms on a constant strain path, and excess bending at the apex is avoided. This is done so that the determined EM-FLCs are comparable to their quasi-static counterparts. The method determines the EM-FLCs for the aluminum alloys AA-1050a-H24 and EN AW-5083-H111 and the magnesium alloy Mg AZ31-O. Overall, it is observed that the necking limits in electromagnetic forming (EMF) are higher compared to quasi-static forming. The fracture surfaces of electromagnetically deformed specimens are examined to reveal the existence of out-of-plane shear stresses. A numerical analysis corroborates this observation and their variation with strain rate. The presence of such stresses is proposed as a possible reason for the increased necking limits in EMF. As reasons for higher forming limits, previous research has identified inertial stabilization, strain rate hardening, die impact, and change in deformation mechanism. The current study reaffirms the positive effect of inertial stabilization and makes key observations in the increase of twinning in EMF of Mg AZ31-O. Full article
