Nowadays, high requirements imposed by mechanical components make it necessary to develop modern production methods. Additive technologies have been dynamically developing in recent years, showing many advantages associated with the fabrication of elements with complex geometries and structures. One of the areas where the potential of additive technologies is exploited is the rapid tooling sector, which is based on the rapid production of tools and components used in various manufacturing methods. Currently, apart from industrial additive fabrication using metal and plastic powders, desktop and low-cost devices for additive manufacturing are gaining more and more importance in the production of functional elements. This paper presents the experimental results obtained from testing the micro-abrasive acrylonitrile–butadiene–styrene ABS tools fabricated by fused filament fabrication (FFF) technology and reinforced with SD 28/20 diamond grains uniformly distributed on the working surface of the tools after they were made. Precision surface grinding operations of 41Cr4 alloy steel were carried out on a portable five-axis CNC milling machine using wheels with continuous and serrated working surfaces. The tool with a serrated working surface enabled a more efficient material removal and produced a better surface finish. In particular, a low wear rate of both FFF-printed tools was confirmed after all experiments. Promising results were obtained, showing the potential for a wider industrial application of the tested tools. Full article

Aspherical surfaces, with their varying curvature, minimize aberrations and enhance clarity, making them essential in optics, aerospace, medical devices, and telecommunications. However, manufacturing these surfaces is challenging because of systematic errors in CNC equipment, tool wear, measurement inaccuracies, and environmental disturbances. These issues necessitate precise error compensation to achieve the desired surface shape. Traditional methods for spherical optics are inadequate for aspherical components, making accurate surface shape error detection and compensation crucial. This study integrates advanced metrology with optimized material removal functions in the grinding and polishing processes. By combining numerical control technology, computer technology, and data analysis, we developed CAM software (version 1) tailored for aspherical surfaces. This software uses a compensation correction algorithm to process error data and generate NC programs for machining. Our approach automates and digitizes the grinding and polishing process, improving efficiency and surface accuracy. This advancement enables high-precision mass production of rotationally symmetrical aspherical optical components, addressing existing manufacturing challenges and enhancing optical system performance. Full article

The machinability of steel is a crucial factor in manufacturing, influencing tool life, cutting forces, surface finish, and production costs. Traditional machinability assessments are labor-intensive and costly. This study presents a novel methodology to rapidly determine steel machinability using spark testing and convolutional neural networks (CNNs). We evaluated 45 steel samples, including various low-alloy and high-alloy steels, with most samples being calcium steels known for their superior machinability. Grinding experiments were conducted using a CNC machine with a ceramic grinding wheel under controlled conditions to ensure a constant cutting force. Spark images captured during grinding were analyzed using CNN models with the ResNet18 architecture to predict V15 values, which were measured using the standard ISO 3685 test. Our results demonstrate that the created prediction models achieved a mean absolute percentage error (MAPE) of 12.88%. While some samples exhibited high MAPE values, the method overall provided accurate machinability predictions. Compared to the standard ISO test, which takes several hours to complete, our method is significantly faster, taking only a few minutes. This study highlights the potential for a cost-effective and time-efficient alternative testing method, thereby supporting improved manufacturing processes. Full article

The drive at the center of gravity (DCG) concept-based twin-ball-screw drive mechanism (TBSDM) is vital in automated factories for its robustness and reliability. However, changes in the worktable mass or position result in changes in the center of gravity (CG), significantly affecting the system’s dynamic properties. In this regard, this paper introduces a novel analytical model using improved receptance coupling to analyze vibrations in four modes. A mathematical framework for the twin TBSDM is generated, and the effect of changing the worktable position–mass on each mode is examined. The applicability of the proposed method is verified based on dynamic experiments that were carried out on a TBSDM of a CNC grinding wheel machine tool. After thoroughly analyzing the experimental and theoretical results, it is revealed that changing the worktable position primarily influences the rotational and axial vibrations of the twin ball screw (TBS). Furthermore, changes in the worktable mass significantly affect the coupling vibration among the TBSs and rotors or bearings. Moreover, in terms of performance, the variances between the theoretical and experimental natural frequencies are consistently below 5%. Thus, the proposed method is promising for the improvement of the modeling and analysis of the TBSDM. Full article

The use of CNC equipment that integrates several machining operations eliminates downtime due to changes in setup and clamping of workpieces in more than one machining device. A review of CNC equipment and tools known from the literature and from manufacturers’ offerings indicates that new technical solutions are being developed to integrate two or more technological operations. However, these examples have numerous limitations and are mostly not suitable for machining surfaces with complex shapes. An example of such solutions is the use of a dual-tool grinding head, which integrates the process of rough grinding with a ceramic grinding wheel and finish grinding with a flexible grinding wheel. Unfortunately, it has the disadvantage of being limited by the angular shape of the ceramic grinding wheel, making it unable to adapt to the complex geometries of the shaped surfaces being ground. The need to overcome this limitation became the motivation for the research work described in this article. By means of experimental research, it was verified what effect the radial outline on the periphery of a ceramic grinding wheel realized by rough grinding would have on the surface roughness parameters obtained in the process of grinding shaped surfaces. For this purpose, grinding processes using a ceramic wheel with a conical and radial outline were compared. The result of the study was a summary of the surface roughness parameters Sa, St, Sq, Spk, Str, and Sds obtained after two-stage machining (rough and finish grinding). The obtained analysis results showed that changing the axial outline of the ceramic grinding wheel makes it possible to significantly expand the range of applications of the dual-tool head without negatively affecting the quality of the machined surface. Thus, such an improvement will make it possible to increase the applicability of the head by grinding shaped surfaces with a radial profile of curvature. Full article

Gear drives are widely used in various fields and applications due to their properties and capacity. Their versatility, durability, and ability to transmit high torques as well as precision and reliability make them extremely useful in many fields of technology. They are widely used in industrial and energy machinery, vehicle drive systems, aerospace, medical devices, and many other areas. Gears can be manufactured using many technologies. This work focuses mainly on machining with particular emphasis on high-performance new technologies. The process of mathematical modeling of the gear and the machined profile is strongly related to CNC machining technologies. A robust correlation of systems supporting the design and modeling of sliding gears needed for the manufacturing process is presented in the article. It is very important to properly assess gears with correct manufacturing in accordance with a specific standard. The article presents an analysis of available methods for controlling gears using coordinate measurement techniques. Gear machining methods were assessed in terms of the technologies used as well as their productivity and manufacturing tolerance. Full article

A tool remaining useful life prediction method based on a non-homogeneous Poisson process and Weibull proportional hazard model (WPHM) is proposed, taking into account the grinding repair of machine tools during operation. The intrinsic failure rate model is built according to the tool failure data. The WPHM is established by collecting vibration information during operation and introducing covariates to describe the failure rate of the tool operation. In combination with the tool grinding repair, the NHPP-WPHM under different repair times is established to describe the tool comprehensive failure rate. The failure threshold of the tool life is determined by the maximum availability, and the remaining tool life is predicted. Take the cylindrical turning tool of the CNC lathe as an example, the root mean square error, mean absolute error, mean absolute percentage error, and determination coefficient (R²) are used as indicators. The proposed method is compared with the actual remaining useful life and the remaining useful life prediction model based on the WPHM to verify the effectiveness of the model. Full article

The use of CNC equipment that integrates several machining operations allows the elimination of downtime resulting from setup changeovers and the clamping of workpieces in several different machine tools. More and more CNC machines and tools that allow the integration of several machining operations are appearing on the market, but there are only a few examples of these and many solutions that allow such integration for more complex operations are still missing. The aforementioned factors motivated the research work described in this paper. The purpose of the present study was to develop an innovative grinding head with different functional features for use in the process of shaped surfaces face grinding, the use of which will enable complete abrasive machining in a single mounting. The conducted tests of the grinding process showed a reduction in the values of the roughness parameters Sa (5.30, 1.12, 0.63 μm), St (31.8, 14.4, 6.72 μm), Sq (6.39, 1.46, 0.81 μm) and Spk (6.16, 0.77, 0.33 μm) and an increase in the value of the parameter Sds (393, 563, 1203 pks/mm²) on the surface after machining in two stages, first for rough grinding and then for finishing relative to the surface after the shaped milling process. Full article

In order to improve the tool life and micro-hole machining quality, the H-shaped chisel edge micro-drill (HCE-MD) was developed in this paper. The HCE-MD was characterized by the inner edge formed through the chisel edge thinning. In the micro-drilling process, the inner edge can perform positive rake cutting, so the machining area of the workpiece extruded by cutting edge with a negative rake angle is reduced. Based on this, the distribution of rake angle near the chisel edge corner is improved. Then, the HCE-MD was fabricated on the six-axis CNC grinding machine. The grinding process parameters of the micro-drill were optimized based on the orthogonal grinding test and grey relational grade theory. The size and shape accuracy of the micro-drill were controlled by the multi-axis linkage grinding method and the movement-axis micro compensation method. Finally, the 0.25 mm HCE-MD was fabricated with the cutting edge radius of 1.94 μm and the flank surface roughness of 0.25 μm. The drilling performance of HCE-MD was evaluated through comparative drilling experiments. The experimental results show that, compared with common micro drill, the HCE-MD produced lower thrust force and better micro-hole roundness accuracy, and reduced the micro-drill wear on the chisel edge and the flank. Full article

Due to the existence of machining and installation errors, axis parallelism error of gear pairs occurs, which causes eccentric load and mesh in-out impact, thus weakening loaded transmission character. To solve this problem, the axis parallelism error of gear pairs was equated with tooth axial inclination error based on the gear-meshing principle. On this basis, we established the tooth modification model with tooth axial inclination error as the variable according to involute helical gear form-grinding process. Then, the degradation of loaded transmission character caused by axis parallelism error of gear pairs was quantitatively analyzed. The gear grinding, gear measuring, and gearbox vibration measuring were, respectively, performed on high-precision CNC horizontal gear form-grinding machine tool L300G, Gleason 350 GMS, and JWY-II multifunctional gearbox loading test bench. The results show that the proposed method can effectively reduce eccentric load and mesh in-out impact and significantly improve loaded transmission character. Therefore, it can provide a theoretical and experimental basis for the research of high-performance gear-grinding technology of gear-grinder machines. Full article

Dimensional error of workpiece is an important index that indicts the grinding accuracy of machine tools. Conventional error compensation strategies focus on modeling one or several error factors for a particular CNC machining type, which are time consuming and costly. Based on data-driven sliding mode terminal iterative learning control, a new dimensional error compensation method is proposed in this paper. The compensation algorithm based on an iterative sliding surface and an objective function is established using the terminal experimental data. A modified NC program is fed to the machine tool to push the workpiece dimension towards desired. The theoretical analysis and experimental results show the proposed compensation method can effectively improve the batch grinding accuracy of the machine tool, which shows good perspective in manufacturing industry. Full article

The grinding force is the most sensitive physical measure of reaction loads in the grinding process. To enhance surface quality and assure high efficiency and stability of the grinding process, it is essential to accomplish adaptive control of the grinding force. This paper suggests a grinding force adaptive control system based on spindle motor power feedback, considering the process–machine interaction. The spindle motor power is utilized as a proxy for the grinding force because of the mapping relationship between the two variables. The machine tool’s feed rate is automatically modified to achieve adaptive control of the grinding force, after assessing the discrepancy between the collected spindle motor power and the preset power. Finally, a cemented carbide tool grinding experiment was performed on a 2MZK7150 CNC tool grinder. During the experiment, the grinding force was precisely controlled between 80 and 100 N, ensuring machining quality and increasing machining efficiency. The experimental results show that the adaptive control system can meet the high-efficiency and high-quality machining requirements of cemented carbide rotary blades. Full article

In smart manufacturing, human-cyber-physical systems host digital twins and IoT-based networks. The networks weave manufacturing enablers such as CNC machine tools, robots, CAD/CAM systems, process planning systems, enterprise resource planning systems, and human resources. The twins work as the brains of the enablers; that is, the twins supply the required knowledge and help enablers solve problems autonomously in real-time. Since surface roughness is a major concern of all manufacturing processes, twins to solve surface roughness-relevant problems are needed. The twins must machine-learn the required knowledge from the relevant datasets available in big data. Therefore, preparing surface roughness-relevant datasets to be included in the human-cyber-physical system-friendly big data is a critical issue. However, preparing such datasets is a challenge due to the lack of a steadfast procedure. This study sheds some light on this issue. A state-of-the-art method is proposed to prepare the said datasets for surface roughness, wherein each dataset consists of four segments: semantic annotation, roughness model, simulation algorithm, and simulation system. These segments provide input information for digital twins’ input, modeling, simulation, and validation modules. The semantic annotation segment boils down to a concept map. A human- and machine-readable concept map is thus developed where the information of other segments (roughness model, simulation algorithm, and simulation system) is integrated. The delay map of surface roughness profile heights plays a pivotal role in the proposed dataset preparation method. The successful preparation of datasets of surface roughness underlying milling, turning, grinding, electric discharge machining, and polishing shows the efficacy of the proposed method. The method will be extended to the manufacturing processes in the next phase of this study. Full article

Magnetic abrasive finishing (MAF) shows a high potential for use on computerized numerical control (CNC) machine tools as a standard tool to polish workpieces directly after the milling process. This paper presents a new MAF tool with a single, large permanent magnet and a novel top cover structure for finishing the plain ferromagnetic workpieces. The top cover structure of the MAF tool, combined with an optimized working gap, ensures the effect of mechanical powder compaction, which leads to a significant increase in process capability and surface roughness reduction. The influence of the process parameters such as feed rate, equivalent cutting speed, working gap (including for three grain sizes) and the gap to the magnet was investigated. In addition, the influence of the initial surface after face milling, end milling, ball end milling and grinding on the surface quality after MAF was investigated. Furthermore, three typical surfaces after milling and MAF were analyzed. By magnetic abrasive finishing, a significant surface quality improvement of the initial milled surfaces to roughness values up to Ra = 0.02 µm and Rz = 0.12 µm in one processing step could be achieved. Full article

In the modern fish processing industry, flat fishes play an important role. They are processed into a final product in the form of a fillet during the skinning operation, which is carried out on machines operating in automated production lines. These machines are usually equipped with a single planar cutting blade or a few of such blades. The high-efficiency skinning and industrial conditions cause rapid wear of the cutting edge of the blade, which is detrimental to the quality of the final product. One of the forms of renewing the cutting ability of these types of tools is the regeneration carried out with the use of precise traverse surface grinding. The results of this process must be carefully verified for determining its correctness and possible optimization of its parameters. The main goal of this article was to characterize the usefulness of a number of observational and measuring methods to evaluate the results of the technical blade regeneration process. In this work, a number of contemporary observation–measurement methods such as optical microscopy (OM), scanning electron microscopy (SEM), energy-dispersive X-ray spectroscopy (EDS), optical profilometry (OP), and angle-resolved scattering (ARS), supported by image processing and analysis techniques, were analyzed. The authors focused on presenting the role of the abovementioned methods in the surface characterization of planar cutting blades made of X39Cr13 chromium martensitic stainless steel before and after the technological operation of flat-fish skinning. Additionally, the surface condition after the regeneration process carried out using the five-axis CNC (computerized numerical control) grinding machine was also assessed. Numerous results of surface observations, elemental composition microanalysis, high-accuracy surface microgeometry measurements, and quantitative and qualitative analysis confirming the possibility of using the proposed methods in the presented applications are presented. Full article
