Memristive elements, known as memristors, memcapacitors and meminductors, have become an important topic of research in the electronics world in recent years. As there is still no efficient way to manufacture two-terminal memristive elements, many researchers have focused their efforts on designing emulator circuits that mimic these devices. In this study, a memcapacitor emulator circuit using Current Derivative Buffered Amplifier (CDBA) is proposed, which has significant advantages such as wide dynamic range, differential structure at the input port, high sloping rate and wide bandwidth. The main advantages of the emulator are that it is floating without grounding constraint, it is electronically adjustable, it has charge-controlled incremental and decremental modes and it has a simpler circuit structure since it does not contain a memristor. To ensure the integrity of the circuit theory, the results of the mathematical model and the simulation of the memcapacitor are given together. In addition, the characteristics of the experimentally investigated memcapacitor emulator are in good agreement with the simulation results. To provide an illustration of the performance of the proposed emulator, firstly the second-order active low-pass filter circuit and subsequently the amoeba learning circuit are selected as the working environment. The results show that the filtering performance of the proposed emulator at a value after the cut-off frequency in the filter circuit is $25\%$ more efficient than a standard capacitor and in terms of power consumption, it consumes $27.93\%$ less power than a standard capacitor. Moreover, the emulator successfully accomplishes the learning and data storage tasks in the amoeba learning circuit. Full article

The acquisition of real-world sonar data necessitates substantial investments of manpower, material resources, and financial capital, rendering it challenging to obtain sufficient authentic samples for sonar-related research tasks. Consequently, sonar image simulation technology has become increasingly vital in the field of sonar data analysis. Traditional sonar simulation methods predominantly focus on low-level physical modeling, which often suffers from limited image controllability and diminished fidelity in multi-category and multi-background scenarios. To address these limitations, this paper proposes a Conditional Dual-Branch Attention Generative Adversarial Network (CDBA-GAN). The framework comprises three key innovations: The conditional information fusion module, dual-branch attention feature fusion mechanism, and cross-layer feature reuse. By integrating encoded conditional information with the original input data of the generative adversarial network, the fusion module enables precise control over the generation of sonar images under specific conditions. A hierarchical attention mechanism is implemented, sequentially performing channel-level and pixel-level attention operations. This establishes distinct weight matrices at both granularities, thereby enhancing the correlation between corresponding elements. The dual-branch attention features are fused via a skip-connection architecture, facilitating efficient feature reuse across network layers. The experimental results demonstrate that the proposed CDBA-GAN generates condition-specific sonar images with a significantly lower Fréchet inception distance (FID) compared to existing methods. Notably, the framework exhibits robust imaging performance under noisy interference and outperforms state-of-the-art models (e.g., DCGAN, WGAN, SAGAN) in fidelity across four categorical conditions, as quantified by FID metrics. Full article

This paper introduces an innovative low-voltage, low-power current differencing buffered amplifier (CDBA). The proposed CDBA utilizes a bulk-driven MOS transistor operating in the subthreshold region, allowing it to function effectively at low supply voltages while minimizing power consumption, making it suitable for sensor and biomedical applications. To demonstrate the performance of the proposed CDBA, it is incorporated into the design of a current-mode, third-order low-pass filter that is specifically tailored for bio-sensing applications. Both the CDBA and the low-pass filter are designed and simulated in Cadence Virtuoso using the TSMC 0.18 µm CMOS process. The CDBA operates at a supply voltage of 0.3 V, consuming 170 nW of power, while the third-order low-pass filter achieves a dynamic range of 57.2 dB with a total harmonic distortion (THD) of 1%. Full article

Current Differencing Buffered Amplifiers (CDBAs) are a critical class of analog circuit components capable of handling both current and voltage signals with minimal power consumption. Due to their low impedance voltage output, they play a significant role in modern electronics for developing high-performance, high-precision analog and mixed-signal circuits. But, designing and characterizing CDBAs pose several challenges, such as ensuring stability at high frequencies, minimizing noise impact for high-precision applications, and enhancing adaptability. Integrating CDBAs with other analog components to create multifunctional integrated circuits opens many opportunities in the analog signal-processing domain. This paper reviews the evolution and applications of CDBAs in analog signal processing. Various implementation schemes, including those using commercial Current Feedback Amplifiers (CFAs) and novel CMOS configurations, are analyzed for their performance metrics such as supply voltage, power dissipation, input/output impedances, and technology node. Future trends and challenges in advancing CDBA technology towards higher integration and lower-voltage operation are discussed, highlighting potential applications in next-generation electronics. Full article

Mechano-luminescent materials that exhibit distinct luminescence responses to force stimuli are urgently anticipated in view of application needs in the fields of sensing, anti-counterfeiting, optoelectronic devices, etc. However, most of the reported materials normally exhibit force-induced changes in luminescent intensity, whereas materials that possess force-induced color-variable luminescence remain rarely reported. Herein, for the first time, a novel mechanical force-induced color-variable luminescence material from carbon dots (CDs) in boric acid (CD@BA) is reported. At low CDs concentration, the luminescence of CD@BA exhibits a grinding-induced color variable from white to blue. This grinding-induced color variable can be switched to yellow-to-white changing by increasing the CDs concentration in BA. The grinding-induced color-variable luminescence originates from dynamic variation in emission ratio of fluorescence and room temperature phosphorescence, due to the influence of oxygen and water vapor in the air. At high CDs concentration, short-wavelength fluorescence undergoes more severe reabsorption compared to room temperature phosphorescence, leading to grinding-induced color-variable switching from white-to-blue to yellow-to-white. Based on the unique properties of CD@BA powder, the applications of recognizing and visualizing fingerprints on the surfaces of various of materials are demonstrated. Full article

This paper traces the history of the evolution of inverse analog filters (IAF) and presents a review of the progress made in this area to date. The paper, thus, presents the current state-of-the art of IAFs by providing an appraisal of a variety of realizations of IAFs using commercially available active building blocks (ABB), such as operational amplifiers (Op-amp), operational transconductance amplifiers (OTA), current conveyors (CC) and current feedback operational amplifiers (CFOA) as well as those realized with newer active building blocks of more recent origin, such as operational transresistance amplifiers (OTRA), current differencing buffered amplifiers (CDBA) and variants of current conveyors which, although not available as off-the-shelf ICs yet, can be implemented as complementary metal–oxide–semiconductors (CMOS) or be realized in discrete form using other commercially available integrated circuits (IC). In the end, some issues related to IAFs have been highlighted which need further investigation. Full article
