The aim of this work is to perform a detailed dilatometric analysis of the decomposition of austenite during the cooling process using experimentally derived continuous cooling transformation (CCT) diagrams for two specific tool steels, X153CrMoV12 Bohdan Bolzano, Bratislava, Slovakia and 100MnCrW4. The dilatometric curves were compared with metallographic evaluations using scanning electron microscopy (SEM). In addition, hardness measurements were performed to obtain additional information about the mechanical properties of the materials. All experimental work was performed using a DIL 805A. The accuracy of the resulting CCT diagrams was verified by comparing them with those calculated with the JMatPro software v12.4. The cooling rates ranged from 20 °C/s to 0.01 °C/s, depending on the specific type of steel tested. The novelty of this research is the combination of experimental and simulation methods to analyze the influence of alloying elements on the kinetics of phase transformations in tool steels. It was found that one of the most significant factors affecting the CCT diagrams is the weight percentage of alloying elements in the steels. These results clearly show that increasing the weight percentage of the content of alloying elements has a significant impact on the accuracy of the simulation results derived from the JMatPro software. Full article

W-Mo-V high-speed steel (HSS) is a high-alloy high-carbon steel with a high content of carbon, tungsten, chromium, molybdenum, and vanadium components. This type of high-speed steel has excellent red hardness, wear resistance, and corrosion resistance. In this study, the alloying element ratios were adjusted based on commercial HSS powders. The resulting chemical composition (wt.%) is C 1.9%, W 5.5%, Mo 5.0%, V 5.5%, Cr 4.5%, Si 0.7%, Mn 0.55%, Nb 0.5%, B 0.2%, N 0.06%, and the rest is Fe. This design is distinguished by the inclusion of a high content of molybdenum, vanadium, and trace boron in high-speed steel. When compared to traditional tungsten-based high-speed steel rolls, the addition of these three types of elements effectively improves the wear resistance and red hardness of high-speed steel, thereby increasing the service life of high-speed steel mill-roll covers. JMatPro (version 7.0) simulation software was used to create the composition of W-Mo-V HSS. The phase composition diagrams at various temperatures were examined, as well as the contents of distinct phases within the organization at various temperatures. The influence of austenite content on the martensitic transformation temperature at different temperatures was estimated. The heat treatment parameters for W-Mo-V HSS were optimized. By studying the phase equilibrium of W-Mo-V high-speed steel at different temperatures and drawing CCT diagrams, the starting temperature for the transformation of pearlite to austenite (A_c1 = 796.91 °C) and the ending temperature for the complete dissolution of secondary carbides into austenite (A_ccm = 819.49 °C) during heating was determined. The changes in carbide content and grain size of W-Mo-V high-speed steel at different tempering temperatures were calculated using JMatPro software. Combined with analysis of A_c1 and A_ccm temperature points, it was found that the optimal annealing temperatures were 817–827 °C, quenching temperatures were 1150–1160 °C, and tempering temperatures were 550–610 °C. The scanning electron microscopy (SEM) examination of the samples obtained with the aforementioned heat treatment parameters revealed that the martensitic substrate and vanadium carbide grains were finely and evenly scattered, consistent with the simulation results. This suggests that the simulation is a useful reference for guiding actual production. Full article

The α variant selection and microstructure evolution in a new metastable β titanium alloy TB17 were studied in depth by DTA, microhardness, XRD, SEM, and EBSD characterization methods. Under the rapid cooling rate conditions (150 °C/min–400 °C/min), only a very small amount of granular α_WM (α Widmanstatten precipitates within the grains) precipitated within the grains. The secondary α phase precipitated in the alloy changed from granular to fine needle-like at moderate cooling rates (15 °C/min–20 °C/min). When continuing to slow down the cooling rates (10 °C/min and 1 °C/min), the α_GB (α precipitates along the β grain boundaries), α_WGB (α Widmanstatten precipitates that developed from β grain boundaries or α_GB) and α_WM grew rapidly. Moreover, the continuous cooling transformation (CCT) diagram illustrated the effect of cooling rate on the β/α phase transition. EBSD analysis revealed that the variants selection of α near the original β grain boundary is mainly divided into three categories. (i) The double-BOR (Burgers orientation relationship) α_WGB colonies within neighboring β grains grow in different directions but have the same crystallographic orientation. (ii) The double-BOR α_WGB colonies within neighboring β grains have different growth directions and different crystallographic orientations. (iii) The double-BOR α_WGB colonies within the same grain have the same growth direction, but different crystallographic directions. And these double-BOR α_WGB colonies correspond to two variants of the given {0001}α//{110}β. Full article

Simultaneous illumination and communication using solid-state lighting devices like white light-emitting diode (LED) light sources is gaining popularity. The white light LED comprises a single-colored yellow phosphor excited by the blue LED chip. Therefore, color-quality determining parameters like color-rendering index (CRI), correlated color temperature (CCT), and CIE 1931 chromaticity coordinates of generic white LED sources are poor. This article presents the development of multi-color phosphors excited by a blue LED to improve light quality and bandwidth. A multi-layer stacking of phosphor layers excited by a blue LED led to the quenching of photoluminescence (PL) and showed limited bandwidth. To solve this problem, a lens-free, electrically powered, broadband white light source is designed by mounting multi-color phosphor LEDs in a co-planar ring-topology. The CRI, CCT, and CIE 1931 chromaticity coordinates of the designed lamp (DL) were found to be 90, 5114 K, and (0.33, 0.33), respectively, which is a good quality lamp for indoor lighting. CRI of DL was found to be 16% better than that of white LED (WL). Assessment of visible light communications (VLC) feasibility using the DL includes time interval error (TIE) of data pattern or jitter analysis, eye diagram, signal-to-noise ratio (SNR), fast Fourier transform (FFT), and power spectral density (PSD). DL transmits binary data stream faster than WL due to a reduction in rise time and total jitter by 31% and 39%, respectively. The autocorrelation function displayed a narrow temporal pulse for DL. The DL is beneficial for providing high-quality illumination indoors while minimizing PL quenching. Additionally, it is suitable for indoor VLC applications. Full article

This paper focuses on the mathematical and numerical modeling of the electric arc + laser beam welding (HLAW) process using an innovative model of the Yb:YAG laser heat source. Laser energy distribution is measured experimentally using a UFF100 analyzer. The results of experimental research, including the beam profile and energetic characteristics of an electric arc, are used in the model. The laser beam description is based on geostatistical kriging interpolation, whereas the electric arc is modeled using Goldak’s distribution. Hybrid heat source models are used in numerical algorithms to analyze physical phenomena occurring in the laser–arc hybrid welding process. Thermal phenomena with fluid flow in the fusion zone (FZ) are described by continuum conservation equations. The kinetics of phase transformations in the solid state are determined using Johnson–Mehl–Avrami (JMA) and Koistinen–Marburger (KM) equations. A continuous cooling transformation (CCT) diagram is determined using interpolation functions and experimental research. An experimental dilatometric analysis for the chosen cooling rates is performed to define the start and final temperatures as well as the start and final times of phase transformations. Computer simulations of butt-welding of S355 steel are executed to describe temperature and melted material velocity profiles. The predicted FZ and heat-affected zone (HAZ) are compared to cross-sections of hybrid welded joints, performed using different laser beam focusing. The obtained results confirm the significant influence of the power distribution of the heat source and the laser beam focusing point on the temperature distribution and the characteristic zones of the joint. Full article

The targeted delivery of a hydrophilic Tripeptide-3 to the skin using microemulsions or nanoemulsions for facial oil reduction was the focus of this study. The impact factors affecting oil/water transparent dispersion formation, such as the surfactant system, HLB value, and co-solvent, were identified through the water titration method and pseudoternary phase diagram plots. The interfacial tension between caprylic/capric triglyceride (CCT oil) and water was significantly reduced by the surfactant/co-surfactant combination (S_mix) of Cremophore^® RH40 and a double-tails co-surfactant, polyglycerol-3-diisostearate, at an HLB of 13 together with a water-to-co-solvent (PG) ratio of 1:1. A two-level full factorial design of experiment (FFD-DoE) emphasized the independent variables of the HLB value, co-solvent, and CCT oil contents affecting the optimal compositions for micro- or nanoemulsion formation. The low-energy spontaneous emulsification of the optimized combination at a low S_mix content (10%) yielded the translucent oil-in-water Tripeptide-3 nanoemulsions with an internal droplet size of 25.7 ± 1.20 nm, a narrow polydispersity index of 0.237 ± 0.129, and 70.6 ± 0.58% transmittance. The in vitro skin permeation study revealed a significantly higher skin penetration and retention of the Tripeptide-3 nanoemulsions compared to the high surfactant microemulsions and coarse emulsions. Skin irritation and oil control efficacy were evaluated in healthy volunteers before and after product application for 28 days. The obtained nanoemulsions not only decreased sebum production but also enhanced skin moisture levels. In conclusion, the meticulously designed nanoemulsions, incorporating suitable excipients, show a promising delivery system for hydrophilic peptides to control sebum overproduction in oily facial skin. Full article

In this work, the effects of jet impact angle and water flow on the heat-transfer coefficient in boron steel probes were analyzed. Angles of 90°, 75° and 60° were used with stirring flows of 33 l·min⁻¹, 25 l·min⁻¹, 13 l·min⁻¹ and 6 l·min⁻¹. The aim consisted of determining the heat-extraction rates by analyzing the correlation programmed in the Ansys Fluent 2020R2 software when different cooling conditions are used, avoiding many experiments, and establishing quenching conditions free of surface defects on the workpiece. This process is currently used in heavy machinery, requiring high hardness and wear resistance. The fluid-dynamic field was validated using a scale physical model using the particle image velocimetry technique, PIV. In contrast, the thermal field was validated with transient state experiments solving the inverse heat conduction problem, IHCP. The results show that for high flows (33 l·min⁻¹), the jets with an angle of 90° impact the entire surface of the piece, but their cooling rate is slower compared to the other angles, being 243.61 K·s⁻¹, and 271.70 K·s⁻¹, 329.56 K·s⁻¹ for 75° and 60°, respectively. However, for low flows (6 l·min⁻¹), the impact velocities are very similar for the three cases, promoting more homogeneous cooling rates of 58.47 K·s⁻¹, 73.58 K·s⁻¹ and 63.98 K s⁻¹ for angles of 90°, 75° and 60°, respectively. Likewise, through the use of CCT diagrams, it was determined that regardless of the cooling rate, the final structure will always be a mixture of martensite–bainite due to the effect of boron as determined experimentally, which implies a more significant proportion of martensite at higher cooling rates. Full article

One of the effects of welding is residual stress. Welding involves complex tests concerning differences in values of the mechanical parameters of its regions as an effect of residual stress. Such multiphysics characteristics of welding pose a challenge in predicting residual stress. In the present study, a thermo-mechanical constitutive model considering phase transformation and transformation plasticity is implemented in the numerical model in ABAQUS user subroutines. In order to consider phase evolution in welding, the metallurgical parameters for Leblond’s phase equation were obtained from the calibration of DH36 steel with a CCT diagram. In addition, the effects of welding speed on thermal profiles and residual stress generation were investigated. Analysis has suggested that the width of the heat-affected zone (HAZ) decreases with an increase in welding speed, and the phase fraction is significantly affected by this kind of parameter. Such phase transformation has led to the generation of a compressive stress in the fusion zone (FZ) and HAZ. The volume difference between coexisting phases produces a compressive stress in cooling, and its magnitude was increased with martensite increasing. Full article

In this work, we have proposed an AI-based model that can simultaneously predict the hardness and phase fraction percentages of micro-alloyed steel with a predefined chemical composition and thermomechanical processing conditions. Specifically, the model uses a feed-forward neural network enhanced by the ensemble method. The model has been trained on experimental data derived from continuous cooling transformation (CCT) diagrams of 39 different steels. The inputs to the model include a cooling profile defined by a set of time-temperature values and the chemical composition of the steel. Sensitivity analysis was performed on the validated model to understand the impact of key input variables, including individual alloys and the thermomechanical processing conditions. This analysis, which measures the variability in output in response to changes in a specific input variable, showed excellent agreement with experimental data and the trends in the literature. Thus, our model not only predicts steel properties under varied cooling conditions but also aligns with existing theoretical knowledge and experimental data. Full article

The article presents a hybrid method for calculating the chemical composition of steel with the required hardness after cooling from the austenitizing temperature. Artificial neural networks (ANNs) and genetic algorithms (GAs) were used to develop the model. Based on 550 diagrams of continuous cooling transformation (CCT) of structural steels available in the literature, a dataset of experimental data was created. Artificial neural networks were used to develop a hardness model describing the relationship between the chemical composition of the steel, the austenitizing temperature, and the hardness of the steel after cooling. A genetic algorithm was used to identify the chemical composition of the steel with the required hardness. The value of the objective function was calculated using the neural network model. The developed method for identifying the chemical composition was implemented in a computer application. Examples of calculations of mass concentrations of steel elements with the required hardness after cooling from the austenitizing temperature are presented. The model proposed in this study can be a valuable tool to support chemical composition design by reducing the number of experiments and minimizing research costs. Full article

Continuous cooling transformation (CCT) diagrams of base metals are common in welding. They can be built using physical or numerical simulations, each with advantages and limitations. However, those are not usual for weld metal, considering its variable composition due to the dilution of the weld into the base metal. Wire Arc Additive Manufacturing (WAAM) is a distinctive case in which the interest in materials comparable with weld composition raises attention to estimating their mechanical properties. Notwithstanding, this concept is still not used in WAAM. Therefore, the aim of this work was to address a methodology to raise MC-CCT (Multiple Cycle Continuous Cooling Transformation) diagrams for WAAM by combining physical and numerical simulations. A high-strength low-alloy steel (HSLA) feedstock (a combination of a wire and a shielding gas) was used as a case study. To keep CCT as representative as possible, the typical multiple thermal cycles for additive manufacturing thin walls were determined and replicated in physical simulations (Gleeble dilatometry). The start and end transformations were determined by the differential linear variation approach for each thermal cycle. Microstructure analyses and hardness were used to characterise the product after the multiple cycles. The same CCT diagram was raised by a commercial numerical simulation package to determine the shape of the transformation curves. A range of austenitic grain sizes was scanned for the curve position matching the experimental results. Combining the experimental data and numerically simulated curves made estimating the final CCT diagram possible. Full article

The microstructure and hardness along the thickness direction of a water-quenched, high-strength thick plate with a thickness of 40 mm were investigated with three specimens from the thick plate: surface, 1/4t, and 1/2t (center) thickness, and the phase transformation behavior of the thick plate according to the cooling rate was analyzed through dilatometric experiments. Finally, the cooling rate for each thickness of the thick plate was estimated by comparing the microstructure and hardness of the thick plate along with the thickness with those of the dilatometric specimens. Martensite microstructure was observed on the surface of the water-quenched thick plate due to the fast cooling rate. On the other hand, an inhomogeneous microstructure was transformed inside the thick plate due to the relatively slow cooling rate and central segregation of Mn. A small fraction of bainite was shown at 1/4t thickness. A banded microstructure with martensite and bainite resulting from Mn segregation was developed at 1/2t; that is, the full martensite microstructure was transformed in the Mn-enriched area even at a slow cooling rate due to high hardenability, but a bainite microstructure was formed in the Mn-depleted area owing to relatively low hardenability. A portion of martensite with fine cementite at the surface and 1/4t was identified as auto-tempered martensite with a Bagaryatskii orientation relationship between the ferrite matrix and cementite. The microstructure and hardness as well as dilatation were investigated at various cooling rates through a dilatometric experiment, and a continuous cooling transformation (CCT) diagram was finally presented for the thick plate. Comparing the microstructure and hardness at the surface, 1/4t, and 1/2t of the thick plate with those of dilatometric specimens cooled at various cooling rates, it was estimated that the surface of the thick plate was cooled at more than 20 °C/s, whereas the 1/4t region was cooled at approximately 5~10 °C/s during water quenching. Despite the difficulty in estimation of the cooling rate of 1/2t due to the banded structure, the cooling rate of 1/2t was estimated between 3 and 5 °C/s based on the results of an Mn-depleted zone. Full article

The paper deals with the dilatometric study of high-alloy martensitic tool steel with the designation M398 (BÖHLER), which is produced by the powder metallurgy process. These materials are used to produce screws for injection molding machines in the plastic industry. Increasing the life cycle of these screws leads to significant economic savings. This contribution focuses on creating the CCT diagram of the investigated powder steel in the range of cooling rates from 100 to 0.01 °C/s. JMatPro^® API v7.0 simulation software was used to compare the experimentally measured CCT diagram. The measured dilatation curves were confronted with a microstructural analysis, which was evaluated using a scanning electron microscope (SEM). The M398 material contains a large number of carbide particles that occur in the form of M₇C₃ and MC and are based on Cr and V. EDS analysis was used to evaluate the distribution of selected chemical elements. A comparison of the surface hardness of all samples in relation to the given cooling rates was also carried out. Subsequently, the nanoindentation properties of the formed individual phases as well as the carbides, where the nanohardness and reduced modulus of elasticity (carbides and matrix) were evaluated. Full article

High-aluminium steels contain a significant amount of aluminium. The reaction between Al in the liquid steel and SiO₂ in lime-silica-based mould powders during the continuous casting process of high Al steel causes chemical compositional changes in the mould powders, subsequently affecting the surface quality of slabs. In order to solve the aforementioned problem, lime-alumina-based mould powders have been developed, which can lead to an increase in the surface quality of cast slabs by inhibiting steel/slag interaction. However, the mould slag tends to crystallise easily, which leads to a deterioration of the mould lubrication. In view of this aspect, it is important to develop and optimize lime-alumina-based mould powders to meet the requirements of continuous casting of high-aluminium steels. In this study, the changes in crystallinity, viscosity and melting temperature of lime-alumina-based mould powders with the effects of increasing the CaO/Al₂O₃ ratio have been observed through STA (Simultaneous Thermal Analysis), HSM (Hot Stage Microscopy), XRD (X-ray Diffraction), IPT (Inclined Plate Test) and rotational viscometer. The crystallisation behaviour of these mould powders was evaluated by generating CCT (continuous cooling transformation) diagrams. Additionally, the changes in steel chemistry have also been analysed using XRF (X-ray fluorescence) and ICP (Inductively Coupled Plasma Mass Spectrometer). The results of these analyses demonstrated that crystallinity of lime-alumina-based mould powder is increased while the initial crystallisation temperature and viscosity are decreased by CaO/Al₂O₃ additions. However, the degree of steel/slag interaction decreases with an increase in Al₂O₃ content. Full article

Understanding the phase transformation and fraction affected by thermal changes is imperative for ensuring the safety of a welded joint. This study proposes a methodology for predicting the phase transformation and fraction of a welded joint using an integrated model. The integrated model includes a heat transfer model and procedures for predicting phase fraction and microhardness. The heat transfer model was developed to simulate the heat transfer in a welded joint and obtain the thermal cycles. The procedure consists of obtaining the peak temperature, austenite fraction, prior austenite grain size (PAGS), and t_8/5 (the cooling time between 800 and 500 °C). A database was constructed based on the continuous cooling transformation (CCT) diagram using PAGS and t_8/5 as the variables. The phase fraction was then predicted by considering the PAGS with t_8/5 from the database. The predicted phase fraction and microhardness were in good agreement with those determined experimentally, demonstrating the reliability of the methodology. This methodology provides a more realistic understanding of phase transformation and facilitates the prediction of the phase fraction and microhardness under various welding conditions that have experimental limitations. Full article
