This research aims to facilitate informed decision-making to enhance building energy simulation, reduce costs, and minimize CO₂ emissions through building insulation enhancements employing BIM-based simulation. Architectural models of an apartment, a prevalent residential structure in Japan, were developed and examined under diverse insulation scenarios utilizing ArchiCAD 28. Five insulation substances were chosen based on existing guidelines to ensure conformity with local standards and were evaluated for their thermal and environmental properties: Cellulose Fiber, Glass Wool, Urethane Foam, Phenolic Board, and Rock Wool for evaluation based on thermal and environmental properties. The simulation parameters were aligned with Japan’s energy efficiency standards and climate conditions. The factors addressed encompass energy performance evaluation, economic viability, and CO₂ emissions. Simulation findings highlight Urethane Foam as the most effective and environmentally friendly building insulation material. This study provides valuable perspectives for property owners, building designers, and contractors, offering a framework for insulation enhancement choices that optimizes sustainable construction, reduces environmental impact, and enhances cost-effectiveness through the implementation of BIM-based simulation. Full article

Conducting accurate and quick energy analyses for retrofitting purposes became crucial for Architecture, Engineering, Construction, and Operations (AECO) markets worldwide. This paper investigates the possibility of determining and implementing an architect-friendly BIM-based energy analysis for Morocco’s Energy Efficiency Retrofitting (EER). For this matter, a socio-technical approach is adopted. The technical part of the study assesses two Building Information Modeling (BIM) tools (ArchiCAD v26 and Revit v23) regarding their Building Energy Modeling (BEM) capabilities for EER. Their evaluation uses a confirmed case of EER located in Marrakech as a baseline to compare the two tools. The social part investigates the AECO market of Marrakech, where the baseline is located, to anticipate the strengths and limits that might influence the implementation of the BIM-based BEM for an EER workflow in architecture studios. The technical part underlines the significant potential of the chosen BIM tools: ArchiCAD is more flexible, customizable, and accurate regarding energy analysis results, while Revit allows for the strong integration of regulations within its process. The social investigation showcases the studied market’s potential for adopting BIM and BEM for EER but highlights the issue of persisting 2D Computer-Aided Design (CAD) workflows. The same social investigation also suggests that combining BIM tools (ArchiCAD and Revit) in the same workflow might benefit the studied market more because of AECO professionals’ diverse needs. These findings constitute a first base for the national implementation of a BIM-based BEM for EER. They also hold the potential to be used in emerging economies with similar AECO markets. Full article

Socialist modernist architecture in the Balkan has left a valuable legacy of remarkable buildings from this century, which brought a mixture of new experiences and local traditions. Unfortunately, after the 1990s, many of these buildings have been neglected, improperly treated, or abandoned. This paper focuses on the iconic socialist modernist office building “Rilindja” in Prishtina, Kosovo, which was built in 1979. In 2010, the building envelope was changed in the name of revitalization, without considering the energy aspect. The study aims to present energy performance analysis through cost-optimal renovation measures of the building envelope while restoring the architectural values before the last renovation. Using Archicad and EcoDesigner STAR, a BIM model was created, and energy analysis was conducted. The findings indicate that eighteen proposed energy efficiency measures can achieve a reduction in energy consumption for heating and cooling of more than 80% over the life cycle period of 20 years. The comparison before and after renovation considering restoring and preserving the inherent values, while integrating energy efficiency measures was necessary, as there is a lack of such studies in the general literature. Finally, the potential of restoring the collective memory through cost-optimal analysis is emphasized as an approach for similar cases. Full article

This research raises questions about the possibilities and options of using the BIM methodology associated with software for the wood design and construction of structure modeling along an asset’s cycle life. Likewise, several academic and research initiatives are reviewed. In this sense, this paper aims to establish an appropriate link between two agendas that the architecture, engineering, and construction (AEC) industry, academia, and governments normally handle separately. By conducting several literature reviews (book, journals, and congresses) and extensive software tests (BIM software: Revit v2023, Archicad v27, Tekla, and wood plug-ins: AGACAD, Archiframe, Timber Framing 2015, WoodStud Frame, etc.), the state-of-the-art was assessed in both fields, and several cases linking BIM and wood are shown in detail and discussed. Various theoretical samples are modelled and shown, and the advantages and disadvantages of each technique and stage are explained. On the other hand, although wood construction has been most common for hundreds of years, this is not the case of BIM software developments associated with this materiality. Furthermore, since the appearance of materials such as steel and reinforced concrete, all software developments have focused on these materials, leaving aside the possibility of developing applications for use in wood projects. According to that previously discussed, it can be concluded that BIM for wood has been used more frequently in academia, that both fields have several common processes, and, in many cases, that only a few BIM-wood tools have been used, thus disregarding the high potential and high level of benefits that result with the application of these methodologies for the complete building life cycle (design, construction, and operation). Full article

The analysis of the carbon footprint of buildings is a key tool for assessing the impact of different buildings on climate change. Several frameworks and methodologies are available to calculate the footprint of buildings, including standards and norms, Life Cycle Assessment (LCA), and dedicated software tools. The use of Building Information Modeling (BIM) programme for these calculations is both scientifically justified and very practical. This scientific publication focuses on the application of a BIM-based research methodology to analyse the carbon footprint of a single-family house. The research process included the following steps: (i) the design of a single-family house with masonry construction using Archicad 26, BIM programme, (ii) simulation of the building energy performance using the EcoDesigner Star plug-in, (iii) LCA using the plug-in for Archicad, (iv) preparation of a second model with timber-frame construction for comparison, and (v) comparative analysis of the single-family house models with masonry construction (building A) and timber-frame (building B). Analysis of the results highlights significant differences in CO₂e emissions between buildings and the varying impact of individual elements on the total CO₂e emissions of the buildings studied. Building A had significantly higher net emissions, amounting to 43,226.94 kg CO₂e, in stark contrast to Building B’s significantly lower 13,522.13 kg CO₂e. This discrepancy was also mirrored in the emission intensity, with Building A emitting at a rate of 281.06 kg CO₂e/m² compared to Building B’s 96.72 kg CO₂e/m². These findings are relevant for future work on sustainable building design and construction aiming to minimise negative environmental impacts. The goal of minimising the cumulative carbon footprint of buildings is critical to achieve the Sustainable Development Goals and combating climate change. Full article

The reliable reconstruction of cultural or historical heritage objects is an urgent problem for humanity. It can be successfully solved using up-to-date 3D modeling tools. The proposed technique allows for modeling virtual environments at an even higher level. This study aimed to develop an approach for designing historical heritage objects with sufficient accuracy using a built environment. The Kilburun Fortress was chosen as the object of study. The modeling procedure includes monitoring the object’s territory, analyzing archival, librarian, and cartographic sources, and further modeling and reproducing the research object in a virtual environment using various software tools. The following stages were implemented during this study: analysis and processing of preliminary data (analysis of plans and schemes, overlapping maps); the scaling of graphical objects for the reliable reproduction of the studied object; the design of a working 3D model using AutoCAD and SketchUp; the rendering and final processing of textures using Quixel; and visualization using Twinmotion. As a result, a model of the historical heritage object was created using 3D means. The model can also be integrated into ArchiCAD and Revit software. Full article

Life cycle assessment (LCA) has become an important part of building design optimization. Design studios need tools that make the LCA of buildings faster and simple, and provide results that allow comparison between variants. The objective of this study was to show the possibility of LCA data integration into the existing building design tool, the DEK Building Library, which is already widely used in the Czech Republic, by connecting it to 1200 items of the largest Czech cost-estimating database, and the application of this connection into building information modeling (BIM) tools. This process also included the large-scale adaptation of 160 relevant LCA data. The main result was obtained using EnviBIM, a freely accessible BIM plugin, as well as a web interface that allows users to receive cradle-to-gate environmental impacts of DEK Building Library elements. Additionally, a semi-automated algorithms system for different groups of building materials and elements named EnviDataGenerator was developed in MS Excel, which enables the consistent linking of LCA data to the cost-estimating database items. This allows EnviBIM extensions and upgrades. The EnviBIM module was validated using case studies of three buildings modeled in ArchiCAD and REVIT. The difference in results compared to the manual calculation was 3.1% to 10.9%, which was considered a success. Full article

An energy-efficient building is not built in a day. It requires effective processes, approaches, and tools, as well as high commitment from all the involved parties. A similar requirement is needed for effective retrofitting practice. Building Information Modelling (BIM) is one of the sensible processes in ensuring either the new building development or retrofitting initiatives arrive at its ultimate objectives, i.e., reduction in energy consumption, energy cost, and removal of harmful emissions. Many studies had proved that a window is one of the building elements that could contribute to establishing an energy-efficient building. Therefore, a 25-floor Wisma R&D, University of Malaya building was modeled using ArchiCAD to analyse the influences of window glazing, opaque materials, and shading elements on overall building energy performances. The accuracy of the model and simulation outcome was initially compared with the energy audit result conducted from March to May 2017. Consequently, this study revealed that the effective combinations of the window parameters had assisted in improving the infiltration rate and heat transfer coefficient which allowed a lower cooling load within 3% to 6%, respectively. After most, minimum savings of 18,133.9 kWh, RM 6618.88, and 1265.16 kg of carbon dioxide (CO₂) were gained through a reduction of cooling load in Wisma R&D based on the window system improvement. This article aims to promote the capability of ArchiCAD as a practical tool for effective retrofitting decision-making. Ultimately, this study revealed the importance of a multivariate framework in building energy conservation and provide an insight into the improvement of the Malaysia Standard MS1525:2019, mainly for high-rise buildings in Malaysia. Full article

Building Information Modelling (BIM) technology has been widely used in the construction industry in recent years. However, to date, it still cannot sufficiently meet the requirements of construction practitioners in terms of the layout design of floor tiles. Recently, the BIM-based Parametric Design (PD) platform has presented considerable potential in automatically generating and optimizing floor tile layout design. In this paper, we propose a workflow to generate and optimize the layout design of floor tiles globally. To develop the workflow, we first formalize the design algorithm of floor tiles according to the trade know-how cutting and planning rules. Then, we combine the design algorithm with an evolutionary algorithm (EA) to generate and optimize the layout design for floor tiles automatically while minimizing material wastage. A prototype system is established in the ArchiCAD (BIM) and Grasshopper (PD platform) software. An apartment room tiling layout is used to demonstrate the feasibility and effectiveness of the proposed approach. Compared with the existing design methods, the proposed approach (1) reduces the material waste rate by 14.58% and 11.46%; and (2) improves the calculation efficiency and reduces the required computation time by 17.3 s to 50.0 s. Moreover, this research improves the existing design algorithm, enabling the BIM- and PD-based approaches to be used reliably in optimizing floor tile planning with arc-shaped boundaries. The outcomes are summarized in order to provide valuable insights in terms of floor tile waste reduction for further sustainable construction practice. Full article

Construction waste (CW) is a prime contributor to the stream of total waste worldwide. One of the biggest challenges of the construction industry is to minimise CW and to develop practices of a more sustainable nature for its management and recycling in order to promote its transition towards a more effective circular economy. The implementation of these practices contributes towards mitigating the scarcity of natural resources and the environmental impact of CW. Thus, a preceding and essential step is the estimation of CW during building design, which will allow the adoption of measures for its early reduction and optimisation. For this purpose, Building Information Modelling (BIM) has become a useful methodology to predict waste during the early stages of design. There remains, however, a lack of instrumental development. Therefore, this study proposes a BIM-based method to estimate CW during building design by integrating a consolidated construction waste quantification model in three different BIM platforms. For its validation, the method is applied to the structural system of a Spanish residential building. The results provide evidence that the proposed method is vendor-neutral and enables the automatic identification and quantification of the waste generated by each building element during the design stage in multiple BIM platforms. Full article

Over the years, building information modelling (BIM) has undergone a significant increase, both in terms of functions and use. This tool can almost completely manage the entire process of design, construction, and management of a building internally. However, it is not able to fully integrate the functions and especially the information needed to conduct a complex energy analysis. Indeed, even if the energy analysis has been integrated into the BIM environment, it still fails to make the most of all the potential offered by building information modelling. The main goals of this study are the analysis of the interaction between BIM and energy simulation, through a review of the main existing commercial tools (available and user-friendly), and the identification and the application of a methodology in a BIM environment by using Graphisoft’s BIM software Archicad and the plug-in for dynamic energy simulation EcoDesigner STAR. The application on a case study gave the possibility to explore the advantages and the limits of these commercial tools and, consequently, to provide some possible improvements. The results of the analysis, satisfactory from a quantitative and qualitative point of view, validated the methodology proposed in this study and highlighted some limitations of the tools used, in particular for the aspects concerning the personalization of heating systems. Full article

The building information modelling (BIM) methodology supports collaborative works, based on the centralization of all information in a federated BIM model and on an efficient level of interoperability between BIM-based platforms. Concerning the structure design, the interoperability capacity of the most used software presents limitations that must be identified and alternative solutions must be proposed. This study analyzes the process of transfer of structure models between modeling and structure analysis tools. Distinct building cases were performed in order to recognize the type of limitations verified in the transfer processes concerning two-way data flow between several software. The study involves the modeling software ArchiCAD 2020, Revit 2020, and AECOsim 2019 and the structure analyzes tools SAP 2020, Robot 2020, and ETABS 22020. The transfer processes are realized in two ways: using the native data format; using a universal standard data transfer, the Industry Foundation Classes (IFC) format. The level of maturity of BIM in structure design is still relatively low, caused essentially by interoperability problems, but despite the limitations detected, this study shows throughout the development of several building case, that the methodology has clear advantages in the development of the structure project. Full article

Building Information Modelling (BIM) is a globally adapted methodology by government organisations and builders who conceive the integration of the organisation, planning, development and the digital construction model into a single project. In the case of a heritage building, the Historic Building Information Modelling (HBIM) approach is able to cover the comprehensive restoration of the building. In contrast to BIM applied to new buildings, HBIM can address different models which represent either periods of historical interpretation, restoration phases or records of heritage assets over time. Great efforts are currently being made to automatically reconstitute the geometry of cultural heritage elements from data acquisition techniques such as Terrestrial Laser Scanning (TLS) or Structure From Motion (SfM) into BIM (Scan-to-BIM). Hence, this work advances on the parametric modelling from remote sensing point cloud data, which is carried out under the Rhino+Grasshopper-ArchiCAD combination. This workflow enables the automatic conversion of TLS and SFM point cloud data into textured 3D meshes and thus BIM objects to be included in the HBIM project. The accuracy assessment of this workflow yields a standard deviation value of 68.28 pixels, which is lower than other author’s precision but suffices for the automatic HBIM of the case study in this research. Full article

This paper proposes an extended comparative evaluation model framework (ECEMF) that highlights two objectives: (1) a specific economic evaluation method for the cost-optimisation of prefabricated lightweight system envelopes to achieve a greater value of the building, and (2) a comparative evaluation model framework usable by different profiles of stakeholders, when adopting the decision on the most optimal envelope type in the early design phase. Based on the proposed framework, the analysis was conducted for the case study building representing a small single-family house located in Slovenia. The methodology applied is based on the life cycle cost (LCC) including construction, operation, maintenance, and refurbishment costs, but excluding dismantling, disposal, and reuse, for the period of 50 years’ lifetime of the building which combines the Building Information Modelling (BIM) with Value for Money (VfM) assessment. To exploit the automated evaluation process in the computing environment, several tools were used, including Archicad for BIM in combination with Legep software for LCC. On one hand, the model confirms the assumption that the optimal value parameters of a building do not only depend on the typical costs related to high-performance buildings. On the other hand, from the stakeholders’ view, the model enables the choice of the optimal solution regarding the envelope type to be made in the early design phase. In this view, the model could function as an important decision tool, with a direct economic impact on the value. Full article

Planning of the built environment requires two-levels of planning process, city/neighborhood-scale and building-scale levels. At the city/neighborhood-scale, Geographic Information System (GIS) is commonly used with CityGML as its open-source 3D format. Meanwhile, for building-scale, Building Information Modelling (BIM) is used, and Industry Foundation Classes (IFC) format is its open-source file format. Both technologies work on different data formats and data exchanges. The research is focusing on ways of exchanging information and bringing together CityGML and IFC. With local context input, the methodology could be considered as a framework to parametrically manage the information related to energy, environment, security, etc. In this project, two use cases were developed, such as visualization for a web application. Autodesk Revit and Graphisoft Archicad were used in developing the building models as a prototype for the transformation testing. The transformation system was developed using Feature Manipulation Engine (FME), by Safe Software. FME allowed us to restructure the data model (IFC) and transformed it to the destination data format (CityGML). The test results showed that from detailed BIM models, CityGML format, as well as a Sketchup file, could be generated. These models can be imported to web visualization applications for urban energy modelling. Full article
