Search Results (14)

In this article, a miniature eight-port multiple-input multiple-output (MIMO) antenna array is proposed for fifth-generation (5G) sub-6 GHz handset applications. The individual antenna element comprises a radiator shaped like the Chinese character “王” (phonetically represented as “Wang”) and three split-ring resonators (SRR) on the metal frame. The size of the individual antenna element is only 6.8 × 7 × 1 mm³ (47.6 mm³). The proposed antenna element has a −10 dB impedance bandwidth of 1.7 GHz (from 3.3 GHz to 5 GHz) that can cover 5G New Radio (NR) sub-6 GHz bands N77 (3.3–4.2 GHz), N78 (3.3–3.8 GHz), and N79 (4.4–5 GHz). The evolution design, the current distribution, the effects of single-handed holding, and the analysis of the parameters are deduced to study the approach used to design the featured antenna. The measured total efficiencies are from 40% to 80%, the isolation is better than 12 dB, the calculated envelope correlation coefficient (ECC) is less than 0.12, and the calculated channel capacity (CC) ranges from 35 to 38 bps/Hz. The presented antenna array is a good alternative to 5G mobile handsets with wideband operation, a metal frame, and minimized spacing. Full article

This paper presents a design and performance analysis of a 10-element 5G massive Multiple Input Multiple Output (m-MIMO) antenna array for sub-6 GHz mobile handsets, specifically for Long Term Evolution (LTE) bands 43 (3600–3800 MHz) and 48/49 (3550–3700 MHz) applications. The proposed antenna array consists of ten closely spaced inverted-F antennas with a compact size of 20 × 9 mm${}^2$ of a single element. The proposed antenna array provides high efficiency and low correlation between the antenna elements, which result in increased data rate and enhanced signal quality. The performance of the antenna array is evaluated in terms of the radiation pattern, diversity gain, efficiency, and correlation coefficient. The simulation and measured results show that the proposed antenna array achieves an approximate peak gain of 2.8 dBi and a total efficiency of 65% at the resonance frequency of 37 GHz and a low correlation coefficient of 0.07 between the adjacent antenna elements. Moreover, the single and two-hand modes are also given in order to highlight the potential of such a structure as a smart mobile terminal. The simulated results are discovered to be in excellent agreement with the measured values. We think this structure has a bright future in the next generation of smart mobile phones based on the performance and the measured findings. Full article

This article reported a compact ultra-thin tightly arranged 4 × 4 multiple-input multiple-output (MIMO) antenna pair (AP) functioning in the fifth-generation (5G) n78 band (3.4–3.6 GHz) for the ultra-thin 5G mobile handset. Two APs were printed on the center of two sideboards. A T-shaped open-ended slot was utilized in the grounding plane to improve the port impedance matching and attenuate the reciprocal magnetic coupling. A minimized total volume of 145 × 75 × 5 mm³ was obtained, and the area of each radiating unit was only 8.5 × 4.2 mm² (0.1λ₀ × 0.05λ₀, λ₀ is the free-space wavelength at the frequency of 3.5 GHz). By placing two radiating elements in an exceeding closed (1 mm or 0.01167λ₀) distance, the designed AP precisely resonated at 3.5 GHz, and an acceptable measured isolation performance superior to 17 dB was attained. A prototype of this presented APs system was printed and tested, and remarkable consistency was observed between the simulated and measured curves. Numerous indicators were computed to assess its MIMO performance, such as Envelope Correlation Efficiency (ECC), Diversity Gain (DG), Total Active Reflection Coefficient (TARC), and Multiplexing Efficiency (ME). Full article

In multipath environments, multiple-input multiple-output (MIMO) terminals typically suffer from non-zero correlations due to limited handset space and power imbalances due to different antenna efficiencies or partial hand blockage. These antenna–channel impairments can lead to significant throughput performance degradation of MIMO terminals. The multiplexing efficiency was proposed to quantitatively assess this performance degradation. Previous work only derived the analytical expression of the throughput-based multiplexing efficiency of two-port MIMO antennas for user equipment (UE). However, the fifth-generation (5G) UE dictates four or more antennas. In this paper, we extend the multiplexing efficiency metric to high-order MIMO UEs. Both correlation-based channel models and geometry-based stochastic channel models were used for validation. Besides dipole antennas, two representative terminal antennas were also employed for simulation verifications in this work. Full article

In this paper, single-element and MIMO microstrip antenna with two pairs of unequal slits is proposed as a circularly polarized antenna with negligible back radiation for 5G mid-band handsets. The unequal pairs of slits are engraved on the antenna patch to guarantee the presence of the circular polarization (CP). The proximity-coupled feeding technique is used to excite the proposed microstrip antenna in order to provide larger antenna −10 dB bandwidth which approaches 10.8% (3.48–3.87 GHz). A novel analysis technique is proposed in this paper that demonstrates the 3D axial ratio pattern in order to generate CP in the broadside direction without affecting the structure of the ground plane which ensures weak back radiation. The 3 dB axial ratio bandwidth (ARBW) is found to be equal to 4.1% extended along the range (3.58–3.73 GHz). To make the design more compatible with the 5G mid-band handsets, the 2 × 2 MIMO structure of the proposed antenna with reduced mutual coupling (less than −20 dB) is also presented in this work. The simulation and measured results are in good agreement, and both verify the CP characteristics and the weak back radiation of the proposed antenna. Full article

This article presents the design of a uni-planar MIMO antenna system for sub-6 GHz 5G-enabled smartphones. The MIMO antenna designed comprises four loop-shaped radiators placed at each corner of the mobile phone board, which follows the principle of pattern diversity. The single-antenna element resonates at 3.5 GHz, its impedance bandwidth is noted to be 1.28 GHz (3–4.28 GHz) for S${}_{11}\le$ −6 dB, and it is equal to 720 MHz (3.18–3.9 GHz) for S${}_{11}\le$ −10 dB. For a single-antenna element, a peak gain of 3.64 dBi is observed with an antenna efficiency of >90%. The isolation of >10 dB between antenna elements is achieved for the MIMO configuration. Furthermore, the MIMO antenna designed provides enough radiation coverage to support different sides of the mobile phone board, which is an important feature for future 5G-enabled handsets. In addition, the impacts of human hands and heads on MIMO antenna performance are investigated, and acceptable performance in the data and conversation modes is observed. Full article

A low-profile Multiple Input Multiple Output (MIMO) antenna showing dual polarization, low mutual coupling, and acceptable diversity gain is presented by this paper. The antenna introduces the requirements of fifth generation (5G) and the satellite communications. A horizontally (4.8–31 GHz) and vertically polarized (7.6–37 GHz) modified antipodal Vivaldi antennas are simulated, fabricated, and integrated, and then their characteristics are examined. An ultra-wideband (UWB) at working bandwidths of 3.7–3.85 GHz and 5–40 GHz are achieved. Low mutual coupling of less than −22 dB is achieved after loading the antenna with cross-curves, staircase meander line, and integration of the metamaterial elements. The antennas are designed on a denim textile substrate with ${\epsilon }_r$ = 1.4 and h = 0.5 mm. A conductive textile called ShieldIt is utilized as conductor with conductivity of 1.8 × 10⁴. After optimizing the proposed UWB-MIMO antenna’s characteristics, it is increased to four elements positioned at the four corners of a denim textile substrate to be employed as a UWB-MIMO antenna for handset communications, 5G, Ka and Ku band, and satellite communications (X-band). The proposed eight port UWB-MIMO antenna has a maximum gain of 10.7 dBi, 98% radiation efficiency, less than 0.01 ECC, and acceptable diversity gain. Afterwards, the eight-ports antenna performance is examined on a simulated real voxel hand and chest. Then, it is evaluated and compared on physical hand and chest of body. Evidently, the simulated and measured results show good agreement between them. The proposed UWB-MIMO antenna offers a compact and flexible design, which is suitably wearable for 5G and satellite communications applications. Full article

In this paper, an intuitive approach to assessing advantages of beamforming in 5G wireless communication is proposed as a novel try and practical demonstration of importance of alignment between the transmitter’s and receiver’s beams working in millimeter-wave frequency bands. Since the diffraction loss of millimeter-wave signals matters seriously in propagation, the effects of the misalignment and alignment between beams need to be checked for, which was conducted with a horn antenna and the 4 × 4 Butler matrix which mimic the relationship of the base station and handset antennas. Designing and using the microstrip-line and the substrate integrated waveguide (SIW) Butler matrices, RF-to-RF wireless connectivity between the horn and the microstrip line beamformer as case 1 and the horn and the SIW beamformer as case 2, concerning the changing angle of the beam from either of the two Butler matrices, was tested, showing over 12 dB enhancement in received power. This direct electromagnetic link test was accompanied by examining 64-QAM constellations for beam-angle changing from −30° to +30° for the two cases, where the error vector magnitude in the QAM-diagram becomes less than 10% by beam-alignment for the changing angle. Full article

The study and exploration of massive multiple-input multiple-output (MMIMO) and millimeter-wave wireless access technology has been spurred by a shortage of bandwidth in the wireless communication sector. Massive MIMO, which combines antennas at the transmitter and receiver, is a key enabler technology for next-generation networks to enable exceptional spectrum and energy efficiency with simple processing techniques. For massive MIMOs, the lower band microwave or millimeter-wave band and the antenna are impeccably combined with RF transceivers. As a result, the 5G wireless communication antenna differs from traditional antennas in many ways. A new concept of the MIMO tri-band hexagonal antenna array is being introduced for next-generation cellular networks. With a total scaling dimension of 150 × 75 mm², the structure consists of multiple hexagonal fractal antenna components at different corners of the patch. The radiating patch resonates at 2.55–2.75, 3.45–3.7, and 5.65–6.05 GHz (FR1 band) for better return loss (S11) of more than 15 dB in all three operating bands. The coplanar waveguide (CPW) feeding technique and defective ground structure in the ground plane have been employed for effective impedance matching. The deviation of the main lobe of the radiation pattern is achieved using a two-element microstrip Taylor antenna array with series feeding, which also boosts the antenna array’s bandwidth and minimizes sidelobe. The proposed antenna is designed, simulated, and tested in far-field radiating conditions and generates tri-band S-parameters with sufficient separation and high-quality double-polarized radiation. The fabrication and testing of MIMO antennas were completed, where the measurement results matched the simulation results. In addition, the 5G smartphone antenna system requires a new, lightweight phased microwave antenna (μ-wave) with wide bandwidth and a fire extender. Because of its decent performance and compact architectures, the proposed smartphone antenna array architecture is a better entrant for upcoming 5G cellular implementations. Full article

In this paper, a new sensor is developed to estimate the dielectric constant of Cyclo Olefin Polymer (COP) film utilizable for 5G mobile phones’ multi-layered back-cover. It is featured by the electrical characterization of the thin layer of the COP film at 28 GHz as the material under test (MUT) directly contacting the planar probe (which is an array of resonating patches) and a new meta-surface as metal patterned on the COP film inserted between the planar probe and the 5G multi-layered back-cover for enhanced physical interpretation of the data by way of impedance matching. In this approach to delving into the material, a thin and small meta-surface film with an area of 25.65 × 21.06 mm² and a thickness of 55 μm is examined for applications to 5G mobile 28 GHz-frequency communication on the basis of the below −10 dB-impedance matching for the 1-by-4 array sensor. Along with this, the real and commercial handset back-cover is brought to the test. The proposed method presents the advantages of geometrical adequacy to the realistic 5G handset antenna configuration, the idea of impedance-matching via meta-materials, and the suitability of characterizing the film-type structure as compared to the open-ended coaxial waveguide, waveguide-to-waveguide and TX horn-to-RX horn free-space test methods. Full article

The increasing popularity of using wireless devices to handle routine tasks has increased the demand for incorporating multiple-input-multiple-output (MIMO) technology to utilize limited bandwidth efficiently. The presence of comparatively large space at the base station (BS) makes it straightforward to exploit the MIMO technology’s useful properties. From a mobile handset point of view, and limited space at the mobile handset, complex procedures are required to increase the number of active antenna elements. In this paper, to address such type of issues, a four-element MIMO dual band, dual diversity, dipole antenna has been proposed for 5G-enabled handsets. The proposed antenna design relies on space diversity as well as pattern diversity to provide an acceptable MIMO performance. The proposed dipole antenna simultaneously operates at 3.6 and 4.7 sub-6 GHz bands. The usefulness of the proposed $4\times 4$ MIMO dipole antenna has been verified by comparing the simulated and measured results using a fabricated version of the proposed antenna. A specific absorption rate (SAR) analysis has been carried out using CST Voxel (a heterogeneous biological human head) model, which shows maximum SAR value for 10 g of head tissue is well below the permitted value of 2.0 W/kg. The total efficiency of each antenna element in this structure is −2.88, −3.12, −1.92 and −2.45 dB at 3.6 GHz, while at 4.7 GHz are −1.61, −2.19, −1.72 and −1.18 dB respectively. The isolation, envelope correlation coefficient (ECC) between the adjacent ports and the loss in capacity is below the standard margin, making the structure appropriate for MIMO applications. The effect of handgrip and the housing box on the total antenna efficiency is analyzed, and only 5% variation is observed, which results from careful placement of antenna elements. Full article

A compact dual-frequency ( $38/60 \mathrm{GHz}$ ) microstrip patch antenna with novel design is proposed for 5G mobile handsets to combine complicated radiation mechanisms for dual-band operation. The proposed antenna is composed of two electromagnetically coupled patches. The first patch is directly fed by a microstrip line and is mainly responsible for radiation in the lower band ( $38 \mathrm{GHz}$ ). The second patch is fed through both capacitive and inductive coupling to the first patch and is mainly responsible for radiation in the upper frequency band ( $60 \mathrm{GHz}$ ). Numerical and experimental results show good performance regarding return loss, bandwidth, radiation patterns, radiation efficiency, and gain. The impedance matching bandwidths achieved in the $38 \mathrm{GHz}$ and $60 \mathrm{GHz}$ bands are about $2 \mathrm{GHz}$ and $3.2 \mathrm{GHz}$ , respectively. The minimum value of the return loss is $-42$ dB for the $38 \mathrm{GHz}$ band and $-47$ for the $60 \mathrm{GHz}$ band. Radiation patterns are omnidirectional with a balloon-like shape for both bands, which makes the proposed single antenna an excellent candidate for a multiple-input multiple-output (MIMO) system constructed from a number of properly allocated elements for 5G mobile communications with excellent diversity schemes. Numerical comparisons show that the proposed antenna is superior to other published designs. Full article

In this study, a new design of a tri-band multiple-input–multiple-output (MIMO) antenna array is proposed for fifth-generation (5G) cellular systems. Its structure is composed of eight identical planar-inverted F antenna (PIFA) elements placed at different edge corners of the handset mainboard with overall dimensions of 150 × 75 mm². The PIFA elements and ground plane of the MIMO antenna system are arranged on the back layer of the platform, which makes the design easy to integrate with the handset circuit. For S₁₁ ≤ −10 dB, the radiation elements of the MIMO design operate at the frequency ranges of 2.5–2.7 GHz, 3.4–3.75 GHz, and 5.6–6 GHz covering the long-term evolution (LTE) 41, 42/43, and 47 operation bands, respectively. The array achieves better than 15 dB return loss results across the three operating bands. The presented antenna array not only exhibits multi-band operation but also generates the polarization diversity characteristic, which makes it suitable for multi-mode operation. The proposed antenna array was simulated and experimentally tested. Fundamental characteristics of the proposed design are investigated. It offers three band S-parameters with acceptable isolation and dual-polarized radiation with quite good efficiency and gain results. Besides this, the total active reflection coefficient (TARC) and envelope correlation coefficient (ECC) results of the PIFAs are very low over the bands. In addition, the radiation characteristics of the MIMO antenna in the presence of the user and handset components are studied. Moreover, a new and compact phased array millimeter-wave (MM-Wave) antenna with broad bandwidth and end-fire radiation is introduced which can be easily integrated into the smartphone antenna system. Due to its good performance and simple structures, the proposed smartphone antenna array design is a good candidate for future multi-mode 5G cellular applications. Full article

In this paper, a 28 GHz fifth-generation (5G) phased array antenna with air-hole slots for beam width enhancement is proposed. The proposed antenna consists of eight dipole radiators on a mobile handset-sized ground with air-hole slots between the two adjacent elements for enhancing the half power beam width (HPBW) in the elevation plane. The dimensions of the proposed antenna are 130 mm × 42 mm × 0.127 mm. The proposed array antenna satisfies a −10 dB reflection coefficient in the frequency range from 27.2 to 29.2 GHz with a peak gain of 10.33 dBi and a side lobe level (SLL) of 13 dB. In addition to its good performance, the proposed antenna has a very wide HPBW (measured) in the elevation plane, up to 219 degree with a scan coverage of ±45 degree in the azimuth plane. The proposed antenna demonstrates excellent hemispheric beam coverage for 5G mobile handset devices and can enable cost-effective mass production. Full article
