Symmetric/Asymmetric Analysis and Design of Microwave Circuits/Antennas

A special issue of Symmetry (ISSN 2073-8994). This special issue belongs to the section "Engineering and Materials".

Deadline for manuscript submissions: 31 May 2025 | Viewed by 414

Special Issue Editor


E-Mail Website
Guest Editor
Key Laboratory of Near-Range RF Sensing ICs & Microsystems, Nanjing University of Science and Technology, Nanjing 210094, China
Interests: antenna theory and design; microwave/millimeter wave devices and circuits; frequency selective structures and LTCC-based millimeter-wave circuits

Special Issue Information

Dear Colleagues,

This Special Issue, entitled “Symmetric/Asymmetric Analysis and Design of Microwave Circuits/Antennas”, aims to explore the significance of symmetric/asymmetric analysis methods and design concepts in advanced multi-function integrated microwave circuits/antennas. Specifically, it delves into novel circuits/antennas integrated with the functionalities of frequency selectivity, power division, phase shifting, balance–unbalance transform, electromagnetic radiation/reception, etc. The contributions will focus on the novel approaches, theoretical frameworks, and practical implementations highlighting the efficiency and advantages of function integrated circuits/antennas in either the symmetric or asymmetric network form. This collection aspires to foster a deeper understanding of function integration concepts, which contribute to high integration, compact size, and low loss circuit/antenna designs in a modern communication system.

Therefore, seeing the potential of symmetric/asymmetric concepts in microwave/millimeter-wave circuit/antenna designs, we would like to present the current advances in this topical field through this Special Issue. Original research articles and reviews are welcome. Research areas related to the topic may include, but are not limited to, the following:

  • Analysis on symmetric/asymmetric microwave network;
  • Broadband, multi-band antenna and circuit;
  • Filtering antenna, power divider, phase shifter;
  • Low RCS antenna;
  • Microwave and millimeter-wave filter;
  • Metamaterials, artificial materials, and frequency selective structures;
  • MIMO, multi-mode, and multi-port antennas;
  • Mutual coupling and decoupling technique;
  • Reconfigurable antennas with multiple functionalities;
  • Reflectionless antenna and filter;
  • Other topics.

Prof. Dr. Jianpeng Wang
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Symmetry is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • antenna
  • function integration
  • microwave component
  • filter
  • power divider
  • phase shifter
  • balun
  • frequency selective surface

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue policies can be found here.

Published Papers (1 paper)

Order results
Result details
Select all
Export citation of selected articles as:

Research

16 pages, 4503 KiB
Article
A Design Approach for Asymmetric Coupled Line In-Phase Power Dividers with Arbitrary Terminal Real Impedances and Arbitrary Power Division Ratio
by Yan Zhang, Bin Xia and Junfa Mao
Symmetry 2025, 17(4), 562; https://doi.org/10.3390/sym17040562 - 8 Apr 2025
Viewed by 224
Abstract
In this paper, we first introduced asymmetric coupled lines (ACLs) into both the transmission path and isolation path in traditional in-phase Gysel power dividers and proposed the single-resistor asymmetric coupled line in-phase Gysel power dividers (ACPDs). Utilizing the decoupled branch-line model of ACLs, [...] Read more.
In this paper, we first introduced asymmetric coupled lines (ACLs) into both the transmission path and isolation path in traditional in-phase Gysel power dividers and proposed the single-resistor asymmetric coupled line in-phase Gysel power dividers (ACPDs). Utilizing the decoupled branch-line model of ACLs, a generalized design approach for ACPDs with arbitrary terminal real impedances and arbitrary power division ratio was innovatively proposed. Design formulas relating terminal real impedances, power division ratio, and image impedances of ACLs, for simultaneously satisfying the perfect port isolation and match conditions, are presented. ACPDs achieved a large in-phase power division ratio of 100:1 (20 dB) and offered significant advantages, including impedance transformation, high design freedom, and miniaturization. To automatically determine accurate initial values of geometric parameters for ACLs, a solution software based on MATLAB-HFSS co-simulation and multi-layer perception neural networks was developed, significantly reducing subsequent optimization iterations. To verify the proposed analysis theory and design approach, three ACPDs with different power division ratios of 1:1 (3 dB), 10:1 (10 dB), and 100:1 (20 dB) were implemented. Comparisons of the measured and simulated results showed great accordance, and the three ACPDs achieved good frequency bandwidth, high isolation, excellent port match, and compact size. Full article
