Article

A 12-Bit 50 MS/s Split-CDAC-Based SAR ADC Integrating Input Programmable Gain Amplifier and Reference Voltage Buffer

by
Zhuofan Xu
1,2,
Biao Hu
1,2,
Tianxiang Wu
1,2,
Yuting Yao
1,2,
Yong Chen
3,
Junyan Ren
1 and
Shunli Ma
1,2,*
1
State-Key Laboratory of ASIC and System, Fudan University, Shanghai 201203, China
2
Zhangjiang Fudan International Innovation Center, Shanghai 200433, China
3
State-Key Laboratory of Analog and Mixed-Signal VLSI and IME/ECE-FST, University of Macau, Macao 999078, China
*
Author to whom correspondence should be addressed.
Electronics 2022, 11(12), 1841; https://doi.org/10.3390/electronics11121841
Submission received: 1 May 2022 / Revised: 2 June 2022 / Accepted: 7 June 2022 / Published: 9 June 2022
(This article belongs to the Section Circuit and Signal Processing)
Browse Figures
Versions Notes

Abstract

This article describes an asynchronous split-CDAC-based SAR ADC with integrated input PGA and an RV-Buffer. The split CDAC structure not only reduces the area of the ADC, but also relieves the driving pressure of the input PGA and RV-Buffer. Using the input PGA instead of the traditional input buffer as the driving circuit of the ADC increases the dynamic input range of the ADC. The proposed on-chip RV-Buffer can provide 1.1 V positive and 0.1 V negative voltage, avoiding the disturbance caused by off-chip reference. This prototype is implemented in a 65 nm CMOS process and occupies an active area of 0.088 mm2. The input PGA can provide 0–18 dB programmable gain with a step of 3 dB. Measurement results show that as the provided gain changes, the ADC’s SNR is best, reaching 50.9 dB, and the SFDR is beat, reaching 62.35 dB at 50 MS/s.
