A Modified Wet Transfer Method for Eliminating Interfacial Impurities in Graphene
Abstract
:1. Introduction
2. Experiments
2.1. Chemical Vapor Deposition of Graphene
2.2. Substrate Treatment
2.3. Raman Spectroscopy
2.4. Device Fabrication
3. Results and Discussions
4. Conclusions
Supplementary Materials
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
