Open AccessArticle
Appl. Sci. 2015, 5(4), 1837-1845;

High Power Diode-Side-Pumped Q-Switched Nd:YAG Solid-State Laser with a Thermoelectric Cooler

Institute of Laser Engineering, Beijing University of Technology, Beijing 100124, China
Author to whom correspondence should be addressed.
Academic Editor: Malte C. Kaluza
Received: 31 July 2015 / Revised: 3 November 2015 / Accepted: 4 November 2015 / Published: 16 December 2015
(This article belongs to the Special Issue Diode-Pumped, Ultra-Short Pulse Lasers)
Full-Text   |   PDF [826 KB, uploaded 16 December 2015]   |


A diode-side-pumped, high-energy, high-beam-quality, pulsed solid-state Nd3+:Y3Al5O12 (Nd:YAG) laser with a thermoelectric cooler (TEC) is investigated in this study. The pump laser was a pulsed laser diode array with maximum peak power of 15 kW. A 350 mJ laser pulse was obtained with a wavelength of 1064 nm, a pulse duration of 10 ns, a total electrical-to-optical efficiency of 7.5%, a relative stability of output energy of 5%, and a beam quality of M2 < 4. View Full-Text
Keywords: diode-side-pumped; high-energy; Q-switched; Nd:YAG laser diode-side-pumped; high-energy; Q-switched; Nd:YAG laser

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Dong, J.; Liu, X.-S.; Peng, C.; Liu, Y.-Q.; Wang, Z.-Y. High Power Diode-Side-Pumped Q-Switched Nd:YAG Solid-State Laser with a Thermoelectric Cooler. Appl. Sci. 2015, 5, 1837-1845.
