Angle-Sensitive Photonic Crystals for Simultaneous Detection and Photocatalytic Degradation of Hazardous Diazo Compounds

1
Department of Applied Chemistry, Osaka Prefecture University, 1-1, Gakuencho, Naka-ku, Sakai, Osaka 599-8531, Japan
2
Department of Physical and Environmental Sciences, University of Toronto at Scarborough, 1265 Military Trail, Toronto, ON M1C 1A4, Canada
*
Author to whom correspondence should be addressed.
These authors contributed equally to this work and shared the first authorship.
Micromachines 2020, 11(1), 93; https://doi.org/10.3390/mi11010093
Received: 21 December 2019 / Revised: 9 January 2020 / Accepted: 11 January 2020 / Published: 15 January 2020
(This article belongs to the Section C:Chemistry)
Congo Red (CR) and Amido Black 10B (AB-10B) are anionic diazo dyes, which are metabolized to produce a bioaccumulative and persistent carcinogen, benzidine. In this regard, an angle sensitive sensor composed of photonic crystal supported photocatalyst was fabricated for the simultaneous detection and photocatalytic degradation of diazo dyes from aqueous solutions. Reflectance spectroscopy was used in the detection of CR and AB-10B, which was based on the emergence of the incident angle dependent reflection peaks from the TiO2 coated two-dimensional photonic crystal (2D-PhC) surfaces and their subsequent quenching due to the presence of dye molecules whose absorbance peak intensity overlapped the reflection peak intensity of TiO2 at the respective angle. Interestingly, ultraviolet (UV) mediated photocatalytic degradation of CR and AB-10B was achieved using the same TiO2 coated 2D-PhC surfaces. 2D-PhC underneath the TiO2 layer was able to confine and localize the light on the TiO2 coated 2D-PhC surface, which enhanced the light absorption by dye molecules on the TiO2 surface and the photocatalytic efficiency in the degradation of CR and AB-10B. Finally, this proof-of-concept study demonstrated the fabrication of copolymer film based photonic crystal supported photocatalytic device, which can be used for developing miniaturized sensors competent in on-field detection and degradation of pollutants.
Keywords: photonic crystals; Congo Red; Amido Black 10B; photocatalytic; reflectance spectroscopy; TiO2; environmental sensor photonic crystals; Congo Red; Amido Black 10B; photocatalytic; reflectance spectroscopy; TiO2; environmental sensor
Show Figures

Graphical abstract

MDPI and ACS Style

Maeno, K.; Patel, B.R.; Endo, T.; Kerman, K. Angle-Sensitive Photonic Crystals for Simultaneous Detection and Photocatalytic Degradation of Hazardous Diazo Compounds. Micromachines 2020, 11, 93.
