Thus, it is crucial to elaborate scenarios, driven by different storylines that target a rather holistic perception than solely absolute numbers [13
]. To do so, this paper examines three different scenarios for Germany’s low-carbon transformation concerning the ratified NDCs. To establish a differentiated impact assessment, those are implemented into the Global Energy System Model (GENeSYS-MOD) v2.0 [14
]. This multi-sectoral energy system model is used to analyze national trajectories for the sectors electricity, heat, and transportation until 2050 by applying a cost-optimization algorithm. Based on its federal system, Germany is divided into 16 sub-regions to indicate bottlenecks and potentials for a sophisticated recommendation for action. Despite a limited transferability to other countries, a close consideration of the German case bears insights on its past and future development and might offer some lessons and best practices for other nations, because of Germany’s fruitful start and the Energiewende’s
success in laying down a base for an decarbonized energy system [8
], its close interdependence with other European nations and a certain maturity of the idea of renewable energy supply [8
]. Section 1.1
gives a brief overview on the status quo of Germany’s climate policy and energy system within its national and international context. Section 2.1
and Section 2.2
introduce three different scenarios and their implementation in GENeSYS-MOD. The model results of the scenarios are displayed and discussed in the following Section 3
to provide holistic recommendations for political action. Section 4
concludes the paper.
1.1. German Climate Policy
Germany takes part in the United Nations Framework Convention on Climate Change (UNFCCC) since its foundation. The first Conference of the Parties (COP) took place in 1992 in Berlin, the capital of Germany. Since then, Germany took part in various multilateral agreements and programs for global climate protection, like the Montreal Protocol to protect the ozone layer [16
] and the Kyoto Protocol [17
]. As part of the European Union (EU), Germany commits itself to a number of further climate protection measures and targets. Since 2005, for example, emissions from the domestic energy industry and heavy industry have been covered by an Emissions Trading System (ETS). This accounts for 45% of European emissions [18
]. A second approach to reducing greenhouse gas (GHG) emissions on a European level is pan-European reduction targets, which should include emissions outside the ETS. These targets are also included in the Paris Agreement and state that by 2020, greenhouse gas (GHG) emissions should be reduced by 10 percent compared to 2020 [19
] and by 30 percent compared to 2030 [20
]. In order to balance the burden between the countries according to their economic performance, the Effort Sharing scheme is implemented. Hence, relatively underdeveloped countries can even increase their emissions by a certain amount, while other countries have to reduce beyond the European target. Germany is to reduce its emissions by 14 percent by 2020 compared to 2005 [19
] but will miss this European target [21
]. Aside the European targets, Germany has set itself own targets for 2030 and 2050, based on the reference year of 1990. These targets are also subject to the Paris Agreement ratified by Germany. The main goal is to provide a reduction of GHG emissions of at least 55% until 2030 and 80–95% in 2050 compared to 1990-levels. Additionally, renewable energy sources are prescribed to account for at least 60% of the energy consumption in 2050, while efficiency rates should increase by 50% [22
]. The final decision to phase out nuclear power by 2022 has already been cushioned by the addition of renewable energy plants. The annual nuclear power production fell from 170 Terawatt Hours (TWh) in 2000 to 76 TWh in 2018 while at the same time renewables rose from 38 TWh to 229 TWh. However, power production with coal decreased only from 291 TWh to 229 TWh in the respective timespan [23
]. Hence, there is a large gap between the own decarbonization targets and the actual implementation so far. In 2018, the German government convened a commission “Growth, Structural Change, and Employment” (“Coal-Commission”) for the purpose of implementing practical measures to concretize the goals set out in the climate protection plan. In January 2019, their final report on the gradual reduction and cessation of coal-fired power generation was published [24
]. This report suggests that by 2022, coal-fired power plant capacities have to be reduced gradually to around 15 Gigawatt (GW) of lignite and 15 GW of hard coal. Phasing out coal is recommended at the latest by 2038 [24
]. In the second half of 2018, a new global movement gained medial presence: Every Friday, schoolchildren, supporters from universities, and the scientific community protest for a more decisive approach of politics in climate questions. The German branch of the “Fridays for Future” movement demands Germany shall have no net emissions of carbon dioxide (CO2
) by 2035 and complete phase-out of coal by 2030. Also, they demand an electricity supply that is entirely renewable by 2035. By the end of 2019, the movement further demands to shut down one-quarter of capacity of coal-fired power plants an end to all subsidies on fossil fuels and a pricing scheme for CO2
that internalizes all external effects and thus they refer to the German Environment Agency which estimates a price of 180€ per ton of CO2
Further insights on the regional differences, stakeholders in Germany, and the division of competences among the ministries can be found in the Appendix A
1.2. Energy System
The German energy system is undergoing fundamental restructuring intending to achieve a renunciation of fossil fuels, a switch to renewable energies, and more efficient use of energy. The driving force behind this transformation is the man-made global climate change through the emission of GHG and the climate protection targets developed in response [26
The current supply structure of the power, heating, and transport sectors, as well as the transmission grid and the final energy demand, serve as a starting point for modeling the future energy system of Germany.
Even though electricity generated by renewable technologies reached a share of approximately 37.8% in 2018, the four conventional sources coal (hard coal and lignite), oil, fossil gas, and nuclear are still dominating [23
]. This translates to 313 million tons of CO2
equivalents released in the atmosphere in the year 2017 [27
]. Lignite and hard coal account for the highest share (35.4%) of electricity produced in Germany in 2018. Gas fired power plants are held as a flexible reserve to cushion the renewables’ volatility and grid compensatory measures. Most of the renewable power generation comes from wind and solar with wind energy already providing 17.2% of the total electricity production [23
]. With the further development of offshore capacities in the Baltic- and North Sea, as well as onshore wind turbines focused in northern Germany, this share will increase. Among more cost-intensive technical requirements [28
], the maximum potential for offshore installations of 85 GW [29
] is lower compared to the potential of onshore installations, which is set at 200 GW [30
]. Photovoltaics (PV) are another important pillar of Germany’s future electricity supply, contributing about 7% of the electricity supply today [23
]. Braun et al. [31
] calculated a potential for open-field PV of 297 GW following the target set in German Renewable Green Energy Act (EEG) 2017 of locating open-field PV plants along traffic routes [32
]. Storing the generated electrical energy will become a challenge concerning the volatility of the feed-in of power into the grid by solar and wind plants. Storage technologies, such as batteries, pumped hydro power plants, or gas- and heat storages can be used to effectively reduce the fluctuating power feed in by renewables. CCS technology will not play a role in the German nor European power sector in the future. It has turned out that the implementation is technologically too demanding, very expensive and not needed [33
Compared to the power sector, the heating sector faces more difficulties to become renewable. In fact, the transition of the heating sector towards less carbon dioxide emissions requires a renewable electricity sector, as electric heating alternatives are only renewable if the electricity used is renewable. The heating sector consists of space and water heating but also implies process heating in the industry. Fossil fuels still play a major role in heat generation, particularly fossil gas. In 2018, 49% of German households were supplied with heat by direct gas heating and 13% by district heating [36
]. In the industry, coal and gas are mainly used for the supply of process heat [37
]. The use of renewable energy sources for heat generation is not yet as established as in the electricity sector, although their share in heating and cooling in Germany rose from 4.4% to 13.9% between 2000 and 2018 [38
]. Also, the application of renewables is mainly used for generating low-temperature heat, lesser for process heat in the industry. The share of renewables is at only 5.3%, while coal and gas remain the dominating energy sources [39
]. Further deployment of renewables could be implemented through electric furnaces and renewable gas, produced via renewable energy inputs. In the low-temperature heating sector, heat pumps, as an electric alternative to fossil boilers, can contribute to the decarbonization. The efficiency of heat pumps is higher for small differences in temperature. Therefore, they are primary only used in the low-temperature heating sector. Contrary, process heat also demands temperatures above 1000 °C. Therefore, renewable gas is the only option to decarbonize specific processes, according to Naegler et al. [40
]. As a result, Biogas and Biomass are getting more relevant but are limited by the existing arable lands and grasslands [41
]. Also, a renewable heating sector will rely on direct electric heat generation (e.g., heat pumps or electric (arc) furnaces) and thereby coupling the sectors electricity and heat. Furthermore, synthetic hydrogen has substantial potential in the heating sector, as well as in the transportation sector. Still, this would lead to a higher total electricity demand because of increased need for hydrogen produced by electrolysis. Consequently, the higher demand for electricity will also possibly generate the need for an expansion of the electricity grid.
Currently, the German electricity distribution networks have a line length of 1.7 million kilometres (km) in total and are operated by approximately 880 Distibution System Operators (DSOs) [42
]. The existing transmission grid has a length of 35,000 km and is operated by four privately organized Transmission System Operators (TSOs) [43
]. The transformation of the energy supply to renewable energies involves a profound change in the German electricity supply structure [44
], which leads to new challenges for the grid infrastructure.
The final energy demand in Germany amounted to 9329 petajoules (PJ) in 2017, in which power and heat applications accounted for 70.5%. The remaining energy demand was caused by the transportation sector [45
]. Even with efficiency improvements and climate goals, the final energy demand in the household sector increased slightly from 2383 to around 2430 PJ in the past 27 years [45
]. Finally, the energy demand in the mobility sector increased by almost 376 PJ from 1990 to 2017 [45
1.3. Literature Review
Since Conference of the Parties (COP) 21 in 2015 at the latest, limiting the effects of climate change and decarbonizing and decentralizing the existing energy systems has become a topic and a task not only for scientists but also for states and subnational state institutions. As the Renewable Energy Policy Network for the 21st Century (Ren21) stated in its annual report of 2018 [46
], 169 countries have already set their own targets for renewable energies. The transformation of energy systems is underway around the world with varying degrees of ambition, as shown, among other things, by the large volumes of investment in renewable energy plants. Nevertheless, the Ren21 report also shows a slightly reduced effort globally: Compared to 2017, global investment has fallen, CO2
emissions increased by 1.7% last year, some countries have retired from their own climate targets, and overall efforts are insufficient to meet the climate targets of the Paris Agreement [46
]. That is why it is important that research continues on a global, supranational, national, and regional level in this area and that studies are being published that demonstrate the relevance of the issue and can put pressure on decision-makers.
There is a variety of studies available that analyze possible pathways for decarbonized energy systems. While some studies are focusing on a global context [47
] or on a European level [49
]. Connolly et al. [53
] used the 2013 version of the EU reference scenario [54
] to calculate a European energy system in 2050 with integrated transportation, heating and cooling and industry sectors, which relies on renewables by 100%. They conclude, that it is possible without using unsustainable amounts of biomass and by additional system costs of 12%. Following the question of technical feasibility and the burden that lies on the power sector and the European transmission grid, Zappa et al. [52
] used various reference scenarios determining future power demands and data from entso-e, to conclude that the installed power generation capacity has to increase from 1 Terawatt (TW) to 1.9 TW in 2050. Around 8.5 Exajoule (EJ) from Biomass will be used in the power sector, compared to Connolly et al. [53
] 13.5 EJ in the whole European energy system. Also using GENeSYS-MOD, Hainsch et al. [49
] model a low carbon energy system for Europe. They conclude that achieving a target where global warming is limited to 1.5 is only feasible under certain conditions while staying below 2.0 will only generate 1.5% additional costs compared to the business as usual case. Using the Dynamic Investment and Dispatch Model for the Future European Electricity Market (dynELMOD), Gerbaulet et al. [50
] calculate that PV throughout Europe, as in Germany, is only used half as much as wind power in 2050. Also, they figure out that by 2050, a 98% decarbonization can be achieved, which goes hand in hand with levelized costs for electricity of around 27–32€ per MWh.
Considering a global level with some regional detail, Ram et al. [48
] conclude that 100% renewable energies are feasible, as well as levelized costs in electricity are falling, but are rising in heat supply. In contrast to Gerbaulet et al. [50
], their calculations suggest that Germany’s renewable energy system will be based primarily on solar energy generation.
Considering the issue of imports and exports, the role of individual countries plays a decisive role. A breakdown for European countries is provided by Child et al. [51
] who use the LUT Energy System Transition model also used by Ram et al. [48
]. They come to the conclusion: power trade within Europe is increasing massively from 63 GW to 262 GW. They calculate that the United Kingdom, Ireland, Norway, Denmark, and the Baltic states will be exporters of electricity, while Germany will import 1% of its requirements.
The same questions arise also in the national context of Germany: numerous studies consider pathways towards a possible decarbonization of the German energy system [11
]. However, the German studies are usually done on a national level and only seldomly in a federal context.
Pregger, Nitsch, and Naegler’s [55
] study compares necessary developments for achieving the aims of the German federal government’s “Energy Concept” under different costs for technologies and resources. To accomplish the lower boundary of 80% emission reductions until 2050, they find that an increase of renewable power generation is needed, accompanied by the need for substantial efficiency gains across the sectors. In their base case scenario, they compute a rather moderate amount of installed renewable capacity of 179 GW in 2050.
Palzer and Henning [56
] take a look at the electricity and heating system and conclude that given significant efficiency gains in the heating sector (40% to 50% of heat demand compared to 2010), both sectors can be decarbonized by 2050– with an installed renewable energy generation capacity of 465 GW. In another study, Henning and Palzer [57
] also include the sectors transportation and industry and conclude that a transformation towards 80% GHG emission reduction is theoretically feasible, although additional costs would be around EUR 30 billion annually, compared to the reference case. Regarding the nearer future, Oei et al. [60
] conclude in their study that Germany will not meet its intermediate targets for 2020 and 2030 if it keeps the current trends (and limited efforts). One main message is the fact that an extensive phase-out of coal-generated electricity until 2030 to meet the targets could be feasible without endangering the security of electricity supply.
While these studies do not put much weight on electricity import and export, Samadi et al. [58
] point out that usual scenarios are relying on high values of net imports of electricity, thus needing fewer storage capacities but increasing technological, financial, and political complexity [58
]. However, Pleßmann et al. [47
] conclude that after modeling the demand for energy storage for a 100% renewable and thus fluctuating electricity supply, the integration of electricity storages will not increase the levelized costs of electricity (LCOE) in comparison to conventional energy sources. The question as to how important energy storage is for a 100% renewable energy system is also extensively discussed in a German context: In a comparing study, Cebulla et al. [61
] found a large variance between the estimated requirements for electric energy storage in an energy system relying heavily on renewables: One cited study estimates a storage capacity of up to 83 TWh in a system that is 100% renewable (or 6.3 TWh in the case of 80% market penetration) [62
]. By 2050, Child et al. [51
] estimate that up to 147 TWh of storage capacity have to be built in Germany to compensate for grid fluctuations which is far higher than Hartmann’s estimate which is even more astonishing, when having in mind, that this study calculated a fully integrated European power sector. Concentranting on Germany, Sinn [11
] calculated a need for electric storages of around 16.3 TWh Schill et al. [12
] however, argue that with the regulation of generation peaks from renewable energy plants, as well as sector coupling, there would be no need for large electricity storage additions. Today, there exist multiple storage technologies and solutions that can play a role in compensating the strong fluctuations in the feed-in of renewable energies. In this context, Zsiborács et al. [63
] argue that European energy storage market developments and regulations which motivate the increased use of stationary energy storage systems are of importance for a successful renewable energy integration. Decentralized power storage systems, for example, can contribute to increasing local self-consumption and thus to relieving the pressure on distribution networks, as decentralized systems become more widespread [64
With focus on the power sector and technical feasibilty within the transmission grids [65
] also modeled the German energy system including demands for the transportation, heating and industry sectors. Different from other approaches, they chose to model in different steps which allowed them not only to have a simple cost optimization but also include some market and grid simulations. In both papers they conclude, that with a sufficient electrification of the non-power sectors an energy system largely decarbonized is feasible and that power to gas will pose as a main driver [65
]. Furthermore, Müller et al. [65
] also looked at cross-border power trade and conclude, that Germany will become a net importer on at the norther borders and a net exporter on all borders, making Germany a net exporterin 2050.
Regarding the electrification of the mobility sector, and the possible effects on the German power sector and grids, some studies have been published in recent years. Hanemann et al. [67
] found out that vehicle-to-grid (V2G) charging mechanisms would be supportive for the stability of German power grids, would help to decrease electricity costs from renewables by increasing rates of utility and that a high CO2
-price would support the two aforementioned points. Furthermore, transnational powertrade could be reduced and the electrification of the transportation sector could go in hand with the decarbonization of the power sector [67
]. More general, Schill and Gerbaulet [68
] point out that not scarcity of energy should be of the policymakers’ concerns but demand peaks. This means that a user-driven charging scheme will endanger the grid stability and support coal fired power plants, as they are used as a back up reserve. Further, price-driven or market-driven charging schemes will only work if an adequate CO2
-price is deployed. Just like V2G, a controlled charging would increase grid stabilities and support higher rates of utilisation of renewables thus, decrease the overall costs for electricity. In contrast to that, Loisel et al. [69
], who examined different grid-to-vehicle and V2G-schemes, point out, that, as of today, battery technology is not mature enough to support such schemes and that in current pricing regimes of the power and mobility sector, electricity simply is worthier in the latter. Hence, a full integration of both sectors, as projected is still a far- away goal.
Considering the issue of imports and exports, the role of individual countries plays a decisive role.A breakdown for European countries is provided by Child et al. [51
] who use the LUT Energy System Transition model also used by Ram et al. [48
]. They come to the conclusion: power trade within Europe is increasing massively from 63 GW to 262 GW. They calculate thatthe United Kingdom, Ireland, Norway, Denmark, and the Baltic states will be exporters of electricity, while Germany will import 1% of its requirements.By 2050, they estimate up to 147 TWh of storage capacity will be built in Germany to compensate for grid fluctuations. Similar considerations are also carried out with the heating sector in connection with the electricity sector. Thus, Bloess [70
] in her investigation of possible electrification mechanisms of space heating has determined that, similar to the mobility sector, flexibility options arise. Flexibilities in turn help the market penetration of renewables. On the other hand, there is great pressure on the electricity sector, with an additional demand for about 200 TWh of electricity by 2030 [70
The high number of studies focusing on different sectors and regions and their interactions in the next decades presents how important this field of research is. Nevertheless, only a few studies try to have a holistic look and to model an energy system as a whole. One of the most recent studies that did that is published by Hansen et al. [59
]. They conclude that even full decarbonization is possible by 2050 utilizing only domestic energy sources. This is achievable by strong sector coupling but at high costs of more than EUR 400 billion per year. Interestingly, decarbonizing the transport sector would make up 55–65% of the total costs. Touching on overall costs of the energy transformation, it becomes apparent that any non-implementation of measures would lead to even higher expenses in the long run. According to Stern [5
], not acting would intensify climate change and lead to severe consequences for human life on this planet such as access to water, food production, health, and the environment. In sum, the costs and risks for not acting will be equivalent to losing at least 5% of global Gross Domestic Product (GDP) per year, respectively 20% if a wider range of risks is taken into account. However, reducing GHG emissions, in contrast, would limit the cost burden substantially to 1% [5
Although a large number of different studies examine the German energy system and its future developments, a quantitative approach at the federal level is not yet comprehensively covered. In particular, data on the heating sector accurate to the federal state, as well as a desirable high level of detail for the location potentials of renewable energies are capable of extension and improvement is missing in these studies.
