Review

Elastography Techniques for the Assessment of Liver Fibrosis in Non-Alcoholic Fatty Liver Disease

by
Yasushi Honda
,
Masato Yoneda
,
Kento Imajo
and
Atsushi Nakajima
*
Department of Gastroenterology and Hepatology, Yokohama City University Graduate School of Medicine, Yokohama 236-0004, Japan
*
Author to whom correspondence should be addressed.
Int. J. Mol. Sci. 2020, 21(11), 4039; https://doi.org/10.3390/ijms21114039
Submission received: 30 April 2020 / Revised: 26 May 2020 / Accepted: 3 June 2020 / Published: 5 June 2020
(This article belongs to the Special Issue Diabetic Liver Disease)
Browse Figures
Review Reports Versions Notes

Abstract

:
Non-alcoholic fatty liver disease (NAFLD) is expected to increase in prevalence because of the ongoing epidemics of obesity and diabetes, and it has become a major cause of chronic liver disease worldwide. Liver fibrosis is associated with long-term outcomes in patients with NAFLD. Liver biopsy is recommended as the gold standard method for the staging of liver fibrosis. However, it has several problems. Therefore, simple and noninvasive methods for the diagnosis and staging of liver fibrosis are urgently needed in place of biopsy. This review discusses recent studies of elastography techniques (vibration-controlled transient elastography, point shear wave elastography, two-dimensional shear wave elastography, and magnetic resonance elastography) that can be used for the assessment of liver fibrosis in patients with NAFLD.

1. Introduction

Non-alcoholic fatty liver disease (NAFLD) has become a major cause of chronic liver disease worldwide. The prevalence of NAFLD is currently estimated to be 25% in the general population [1,2], 90% of people with obesity, and 60% of patients with type 2 diabetes mellitus [3,4,5]. Furthermore, the prevalence of NAFLD is expected to increase because of the epidemics of obesity and diabetes [6]. Liver fibrosis, but not non-alcoholic steatohepatitis, is associated with long-term outcomes in patients with NAFLD [7,8]. Liver fibrosis is categorized into non-fibrosis (stage 0), mild fibrosis (stage 1), significant fibrosis (stage 2), advanced fibrosis (stage 3), and cirrhosis (stage 4) (Figure 1) [9]. Liver biopsy is conventionally recommended as the gold standard method for the diagnosis of NAFLD and the staging of liver fibrosis [10]. However, it has several problems, such as sampling error, inter- and intra-observer variation, a risk of complications, and high cost [11,12]. Therefore, simpler and noninvasive methods for the assessment of liver fibrosis have been explored.
Conventional ultrasonography (US), computed tomography, and magnetic resonance imaging (MRI) are useful for the diagnosis of chronic liver disease and cirrhosis and the detection of hepatocellular carcinoma. However, these imaging methods cannot accurately differentiate the various stages of liver fibrosis. Conversely, elastography techniques using US or MRI are performed to measure liver stiffness, which increases in the presence of fibrosis. Therefore, during the last two decades, elastography techniques have been developed as quantitative noninvasive methods for the assessment of liver fibrosis that can be used in place of liver biopsy. Several US-based elastography techniques have been developed, the most important of which is shear wave elastography, which can be divided into vibration-controlled transient elastography (VCTE), point shear wave elastography (pSWE), and two-dimensional shear wave elastography (2D-SWE). In this review, we discuss recent studies of the use of elastography techniques for the assessment of liver fibrosis in NAFLD. Figure 2 shows illustrations and images of each elastography technique, and Table 1 lists the meta-analyses of studies of elastography techniques for the diagnosis of liver fibrosis in patients with NAFLD that have been conducted to date. Supplementary Table S1 lists 47 studies included in the meta-analyses.

2. Vibration-Controlled Transient Elastography

VCTE was developed in 1992 as the first US-based elastography technique [13] and requires a one-dimensional probe and an ultrasonic transducer. The probe is placed over an intercostal space, and a low-amplitude 50-Hz mechanical pulse is then transmitted from the probe to the liver, inducing the propagation of an elastic shear wave through the tissue. The propagation velocity that is measured by VCTE is positively related to the liver stiffness, within the range of 1.5 to 75 kPa [14]. VCTE assesses a volume of liver around 100 to 200 times the size of a liver biopsy. Three different probes can be used to make measurements under various circumstances: A standard M probe (3.5 MHz) is used for adults, an XL probe (2.5 MHz) is used for overweight patients, and an S probe (5.0 MHz) is used for children. Lower-frequency probes are suitable to reduce wave attenuation in patients who have a high degree of abdominal adiposity or a long distance between the skin and liver surface [15].
Yoneda et al. [16] first reported the usefulness of VCTE for estimating the severity of liver fibrosis in patients with NAFLD in 2007. VCTE performed using the FibroScan (Echosens, Paris, France) became the first Food and Drug Administration-approved US-based elastography technique in 2013. VCTE was also included in the European Association for the Study of the Liver Clinical Practice Guidelines for the assessment of liver fibrosis in patients with chronic hepatitis B and C virus infection [17]. Although VCTE is a blind technique, it is the most commonly used technique for screening, treatment monitoring, and longitudinal follow-up in various chronic liver diseases, and is the best-validated elastography modality worldwide. In patients with NAFLD, repeated measurements of liver stiffness made using VCTE are useful for long-term monitoring and the prediction of liver-related complications and cardiovascular events [18,19]. In addition, repeated measurements of liver stiffness can reduce false-positive diagnosis of advanced fibrosis in patients with NAFLD [20,21].
The benefits of VCTE are its extensive validation, availability, and high patient acceptance. In addition, there is good intra- and inter-observer reproducibility (intra-class correlation coefficient (ICC) = 0.98) in patients with various liver diseases, including NAFLD [22]. However, VCTE has some technical and patient-related limitations: The equipment requires recalibration every 6 to 12 months to ensure technical stability [15], and the failure rate of VCTE using a standard M probe is high (6.7%–29.2%). Common patient-related limitations are obesity, operator inexperience, narrow intercostal spaces, acute inflammation, and ascites [23,24,25,26].
Kwok et al. [27] performed the first systematic review and meta-analysis of studies of VCTE (M-probe). The meta-analysis included 854 patients with NAFLD and showed that the sensitivity and specificity for the diagnosis of stages 2, 3, and 4 fibrosis were 0.79 and 0.75, 0.85 and 0.85, and 0.92 and 0.92, respectively. In the most recent meta-analysis of VCTE (M-probe), which was based on 11 studies and 1753 patients with NAFLD, the area under the receiver operating characteristic curve (AUROC) for the diagnosis of stages 2, 3, and 4 fibrosis was 0.85, 0.92, and 0.94, respectively [28]. The authors concluded that VCTE is useful for the staging of liver fibrosis in patients with NAFLD, particularly for those with advanced fibrosis and cirrhosis. Xiao et al. [29] performed a meta-analysis of the use of the XL probe. The meta-analysis included three studies involving 318 patients with NAFLD and showed that the AUROC for the diagnosis of stages 2, 3, and 4 fibrosis was 0.82, 0.86, and 0.94, respectively.

3. Point Shear Wave Elastography

The pSWE was originally developed by Siemens (Erlangen, Germany). Unlike VCTE, which uses a mechanical impulse, pSWE uses an acoustic radiation force impulse to induce shear waves in liver tissue. The performance of pSWE is assisted by its incorporation into standard B-mode US acquisition. This technique permits an operator to visualize the liver tissue and select a region without blood vessels, rib shadows, or bile ducts. The pSWE produces a single point of energy within the liver and targets a region of interest (ROI) of 5 × 10 mm using B-mode imaging [30]. The measured shear wave speed is expressed in m/s and converted to Young’s modulus in kPa for the estimation of tissue stiffness. The pSWE has shown high levels of repeatability and reproducibility in studies involving same-day comparisons [31]. The other advantages of pSWE include high intra-observer (ICC = 0.89–0.90) and inter-observer (ICC = 0.81–0.85) coefficients, which were calculated in a cohort of patients with various liver diseases including NAFLD [31,32,33]. Although pSWE may also overestimate the severity of liver fibrosis in patients with acute inflammation, it is not limited by the presence of ascites, unlike VCTE. Indeed, the failure rate of pSWE in healthy volunteers is low (1%–2%) [34].
The systematic review and meta-analysis by Liu et al. [35] showed that pSWE had a modest level of accuracy for the detection of stage 2 fibrosis (summary sensitivity, 0.80; summary specificity, 0.85; and AUROC, 0.90). Jiang et al. [28] performed a meta-analysis of studies of pSWE in patients with NAFLD and found that the AUROC for the diagnosis of stages 2, 3, and 4 fibrosis was 0.86, 0.94, and 0.95, respectively. The authors concluded that pSWE is also useful for the staging of liver fibrosis, particularly in patients with advanced fibrosis or cirrhosis. The most recent systematic review and meta-analysis, published in 2020, was based on 13 studies and involved 1147 patients with NAFLD [36]. This meta-analysis showed that the AUROC for the diagnosis of stages 2, 3, and 4 fibrosis was 0.89, 0.94, and 0.94, respectively.

4. Two-Dimensional Shear Wave Elastography

Two-dimensional SWE was first introduced on a diagnostic imaging device called the Aixplorer (SuperSonic Imagine, Aix-en-Provence, France) [37]. It also uses acoustic radiation force impulse and is now available on US scanners produced by most major manufacturers. Two-dimensional SWE involves the focusing of acoustic energy to multiple sites in the liver and generates real-time and 2D quantitative maps of liver tissue elasticity using standard B-mode US imaging over a significantly larger area of tissue (35 × 25 mm) than VCTE and pSWE [38,39,40]. Stiffer tissues appear red and softer tissues appear blue on the display [37,40]. The mean shear wave speed (m/s) is derived from multiple measurements obtained from tissue within the ROI, which can be adjusted in terms of size and location. The measured shear wave speed can be algebraically converted to Young’s modulus (kPa). The advantages of 2D-SWE, as well as pSWE, are its rapidity, patient acceptance, and high intra-observer (ICC = 0.93–0.95) and inter-observer (ICC = 0.88) coefficients [41]. In addition, the operator can explore a large field of view by choosing an ROI. However, it is necessary to standardize the selection of an appropriate ROI. The sampling time associated with 2D-SWE may be longer than those associated with VCTE or pSWE because larger tissue volumes are assessed. In one study, the estimated failure rate of 2D-SWE was about 5% in 79 patients (25 healthy patients, 26 with various liver diseases) [42]. To date, no meta-analyses of studies of 2D-SWE in patients with NAFLD have been conducted. Therefore, the diagnostic accuracy of 2D-SWE in patients with NAFLD requires further investigation.

5. Magnetic Resonance Elastography

Magnetic resonance elastography (MRE) was developed at the Mayo Clinic in 1995 [43], introduced into clinical practice in 2007, and approved by the Food and Drug Administration in 2009. It is an MRI-based technique for the quantitative imaging of tissue stiffness and is currently the most accurate noninvasive imaging method for the diagnosis of liver fibrosis [44,45,46,47]. Today, MRE is available on MR scanners made by three of the principal manufacturers (General Electric, Milwaukee, WI, USA; Philips Medical Systems, Best, Netherlands; and Siemens Healthineers, Erlangen, Germany) at 1.5 T and 3 T field strengths.
Quantitative stiffness images (elastograms) of the liver can be rapidly obtained during breath-holding and can, therefore, be readily included in conventional liver MRI protocols [48]. The liver volume that is measurable using MRE is typically ≥250 mL and up to one-third of the liver volume [45,49,50]. A more advanced version of three-dimensional MRE can evaluate the entire liver volume and was used in a recent prospective study [51]. Therefore, MRE can be used to assess the entire liver with a high success rate [52]. Furthermore, unlike US-based techniques, the success of MRE is operator-independent [47] and is minimally affected by obesity, ascites, and bowel interposition between the liver and abdominal wall [44]. MRE is also highly repeatable, and there is high inter-observer and intra-observer reproducibility among the scanner models [53,54,55,56]. The estimated failure rate of MRE is about 5% in patients with various liver diseases [57], and substantial iron deposition in the liver is the most common cause of failure. However, patients who are claustrophobic and have undergone implantation of MR-incompatible devices cannot tolerate MR examinations. Motion artifacts such as cardiac impulses are another cause of failure because MRE is a motion-sensitive technique. MRE should be conducted after ≥4 h of fasting because liver stiffness measurements may increase due to postprandial portal blood flow [58].
A systematic review and analysis of pooled individual participant data by Singh et al. [59] showed that the optimal cut-off MRE value for the diagnosis of stages 1, 2, 3, and 4 fibrosis in patients with NAFLD was 2.88, 3.54, 3.77, and 4.09 kPa, respectively. The authors also calculated the AUROC for the diagnosis of each of these stages (0.86, 0.87, 0.90, and 0.91, respectively). In the most recent meta-analysis by Xiao et al. [29] of five studies involving 628 patients with NAFLD, the AUROC for the diagnosis of stages 2, 3, and 4 fibrosis using MRE was 0.88, 0.93, and 0.92, respectively. The authors concluded that MRE may have the highest diagnostic accuracy for the staging of liver fibrosis.

6. Comparison of Elastography Techniques in Patients with Non-Alcoholic Fatty Liver Disease

Table 2 outlines the advantages and limitations of the above-described elastography techniques. While US-based elastography techniques are relatively inexpensive and simple, they are limited by a high technical failure rate in patients with obesity [24,60]. In addition, these techniques evaluate only a limited volume of the liver, and the results may be influenced by inflammation, cholestasis, and hepatic congestion [61]. The results of liver stiffness by MRE may also be influenced by cholestasis and hepatic congestion [62]. Jiang et al. [28] compared the technical failure ratios of pSWE and VCTE in patients with NAFLD in a meta-analysis and found that the proportion of failed measurements was >10-fold greater when VCTE (M-probe) was used (VCTE: 11.3% (187/1649) and pSWE: 0.8% (6/733)). Several studies have shown that the success ratio of VCTE is much lower when it is performed on patients with a high body mass index of >25 kg/m2 [63,64]. However, obesity seems to have less influence on pSWE. Nevertheless, the accuracy of pSWE is affected by the presence of severe steatosis [65,66]. Cassinotto et al. [39] reported that liver stiffness measurements made using pSWE are unreliable in 18.2% of patients with NAFLD. As with VCTE and pSWE, technical failures of 2D-SWE occur in patients with obesity and in those with a thick subcutaneous fat layer [39], and most patients with NAFLD are obese and have thick subcutaneous fat layers. To circumvent this problem, the XL probe was developed for use in overweight patients. A recent prospective study showed no significant difference in diagnostic accuracy between M and XL probes using probe-specific cut-off values [67]. If the choice of the M probe or the XL probe is made using the automatic probe recommendation tool of the VCTE device, the applicability of VCTE increases to 97% in patients with NAFLD [68,69]. However, there has been insufficient validation of the use of the XL probe. Although MRE is expensive and not widely available, its use for the measurement of liver stiffness is not associated with similar confounders. A systematic review and analysis of pooled individual participant data by Singh et al. [59] showed that the diagnostic performance of MRE is robust, stable, and independent of sex, obesity, and inflammation. Imajo et al. [70] found that although the costs associated with MRE are higher than those associated with VCTE, MRE has the advantage of yielding data for the entire liver, which is useful for screening for other diseases, including hepatocellular carcinoma.
MRE has many advantages over US-based elastography techniques for the evaluation of liver fibrosis. In 2017, Xiao et al. [29] conducted a systematic review and meta-analysis of 64 articles involving 13,046 patients with NAFLD to compare the diagnostic performance of noninvasive indexes (aspartate aminotransferase-to-platelet ratio index, fibrosis-4 index, BARD score, NAFLD fibrosis score, VCTE (M- and XL-probe), SWE, and MRE for the prediction of significant fibrosis, advanced fibrosis, and cirrhosis. The authors found that MRE offered the best diagnostic performance for the staging of liver fibrosis. Other studies have also demonstrated that MRE is superior to VCTE and noninvasive indexes for the diagnosis of liver fibrosis in patients with NAFLD [51,71,72,73]. Because MRE has the highest accuracy for the diagnosis of liver fibrosis, it is being increasingly regarded as a promising surrogate measurement for the monitoring of disease progression and therapeutic endpoints [74]. The most recent prospective cohort study by Ajmera et al. [75] investigated the clinical utility of an increase of MRE in predicting fibrosis progression in patients with NAFLD with paired biopsies and paired MRE measurements. The authors reported that a 15% increase in MRE was associated with histologic fibrosis progression.

7. Conclusions

Although each elastography technique has its advantages and limitations, VCTE and MRE are considered the methods of choice. According to the clinical practice guidelines published by the European Association for the Study of the Liver, VCTE is an acceptable noninvasive procedure for the identification of patients at low risk of advanced fibrosis/cirrhosis [76]. In addition, according to practice guidance published by the American Association for the Study of Liver Diseases, VCTE and MRE are clinically useful tools for the identification of advanced fibrosis in patients with NAFLD [77]. However, pSWE and 2D-SWE are not recommended in the current guidelines for NAFLD. One reason is that there are no data for follow-up using pSWE and 2D-SWE in patients with NAFLD. In addition, VCTE and MRE have the advantage of being used to evaluate not only liver fibrosis but also liver steatosis. The controlled attenuation parameter, which is based on the properties of the ultrasonic signals acquired using VCTE, is a novel means of grading steatosis by measuring the degree of ultrasound attenuation by hepatic steatosis [78]. The FibroScan-AST (FAST) score, which combines the liver stiffness measurement and the controlled attenuation parameter measured by VCTE and aspartate aminotransferase, was recently proposed [79]. This score can identify patients with non-alcoholic steatohepatitis (NAFLD activity score of ≥4 and fibrosis stage ≥2) and has been validated in large global cohorts. Furthermore, the proton density fat fraction is an MRI-based method of quantitatively assessing hepatic steatosis and is available as an option on MRI scanners made by several manufacturers [80,81].
Elastography techniques are recent developments and have not been widely validated in NAFLD. In particular, few patients have participated in studies of the use of the XL probe and 2D-SWE for the prediction of fibrosis. In addition, there is no consensus regarding the use of these elastography techniques in clinical practice in place of liver biopsy. Nevertheless, VCTE and MRE appear to be best suited for the evaluation of liver fibrosis in patients with NAFLD. In fact, several clinical algorithms for the diagnosis and monitoring of patients with NAFLD using VCTE and MRE have been proposed [82,83,84]. In addition, the combination of VCTE and the fibrosis-4 index or the NAFLD fibrosis score has been proposed to assess liver fibrosis [85,86,87]. Additional prospective randomized controlled trials are needed to compare the diagnostic and prognostic accuracy and the cost-effectiveness of these elastography techniques.

Supplementary Materials

The following are available online at https://www.mdpi.com/1422-0067/21/11/4039/s1, Table S1: Characteristics of 47 studies included in previously published meta-analyses.

Author Contributions

Writing—original draft preparation, Y.H., M.Y., K.I., and A.N.; writing—review and editing, Y.H., M.Y., K.I., and A.N. All authors have read and agreed to the published version of the manuscript.

Funding

This work received no external funding.

Acknowledgments

We thank Mark Cleasby, and Angela Morben, DVM, ELS, from Edanz Group (www.edanzediting.com/ac), for editing a draft of this manuscript.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Younossi, Z.M.; Keonig, A.B.; Abdelatif, D.; Fazel, Y.; Henry, L.; Wymer, M. Global epidemiology of nonalcoholic fatty liver disease—Meta-analytic assessment of prevalence, incidence, and outcomes. Hepatology 2016, 64, 73–84. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  2. Li, J.; Zou, B.; Yeo, Y.H.; Feng, Y.; Xie, X.; Lee, D.H.; Fujii, H.; Wu, Y.; Kam, L.Y.; Ji, F.; et al. Prevalence, incidence, and outcome of non-alcoholic fatty liver disease in Asia, 1999–2019: A systematic review and meta-analysis. Lancet Gastroenterol. Hepatol. 2019, 4, 389–398. [Google Scholar] [CrossRef]
  3. Machado, M.P.; Marques-Vidal, P.; Cortez-Pinto, H. Hepatic histology in obese patients undergoing bariatric surgery. J. Hepatol. 2006, 45, 600–606. [Google Scholar] [CrossRef] [PubMed]
  4. Milic, S.; Lulic, D.; Stimac, D. Non-alcoholic fatty liver disease and obesity: Biochemical, metabolic and clinical presentations. World J. Gastroenterol. 2014, 20, 9330–9337. [Google Scholar] [CrossRef]
  5. Dai, W.; Ye, L.; Wen, S.W.; Deng, J.; Wu, X.; Lai, Z. Prevalence of nonalcoholic fatty liver disease in patients with type 2 diabetes mellitus: A meta-analysis. Medicine 2017, 96, e8179. [Google Scholar] [CrossRef]
  6. Estes, C.; Anstee, Q.M.; Arias-Loste, M.T.; Bantel, H.; Bellentani, S.; Caballeria, J.; Colombo, M.; Craxi, A.; Crespo, J.; Day, C.P.; et al. Modeling NAFLD disease burden in China, France, Germany, Italy, Japan, Spain, United Kingdom, and United States for the period 2016–2030. J. Hepatol. 2018, 69, 896–904. [Google Scholar] [CrossRef]
  7. Angulo, P.; Kleiner, D.E.; Dam-Larsen, S.; Adams, L.A.; Bjornsson, E.S.; Charatcharoenwitthaya, P.; Mills, P.R.; Keach, J.C.; Lafferty, H.D.; Stahler, A.; et al. Liver fibrosis, but no other histologic features, is associated with long-term outcomes of patients with nonalcoholic fatty liver disease. Gastroenterology 2015, 149, 389–397.e10. [Google Scholar] [CrossRef] [Green Version]
  8. Hagström, H.; Nasr, P.; Ekstedt, M.; Hammar, U.; Stål, P.; Hultcrantz, R.; Kechagias, S. Fibrosis stage but not NASH predicts mortality and time to development of severe liver disease in biopsy-proven NAFLD. J. Hepatol. 2017, 67, 1265–1273. [Google Scholar] [CrossRef]
  9. Brunt, E.M.; Janney, C.G.; Di Bisceglie, A.M.; Neuschwander-Tetri, B.A.; Bacon, B.R. Nonalcoholic steatohepatitis: A proposal for grading and staging the histological lesions. Am. J. Gastroenterol. 1999, 94, 2467–2474. [Google Scholar] [CrossRef]
  10. Angulo, P. Nonalcoholic fatty liver disease. N. Eng. J. Med. 2002, 346, 1221–1231. [Google Scholar] [CrossRef] [Green Version]
  11. Bedossa, P.; Carrat, F. Liver biopsy: The best, not the gold standard. J. Hepatol. 2009, 50, 1–3. [Google Scholar] [CrossRef] [Green Version]
  12. Sumida, Y.; Nakajima, A.; Itoh, Y. Limitations of liver biopsy and non-invasive diagnostic tests for the diagnosis of nonalcoholic fatty liver disease/nonalcoholic steatohepatitis. World J. Gastroenterol. 2014, 20, 475–485. [Google Scholar] [CrossRef]
  13. Talwalkar, J.A. Elastography for detecting hepatic fibrosis: Options and considerations. Gastroenterology 2008, 135, 299–302. [Google Scholar] [CrossRef] [Green Version]
  14. Sandrin, L.; Tanter, M.; Gennisson, J.L.; Catheline, S.; Fink, M. Shear elasticity probe for soft tissues with 1-D transient elastography. IEEE Trans. Ultrason. Ferroelectr. Freq. Control 2002, 49, 436–446. [Google Scholar] [CrossRef]
  15. Ferraioli, G.; Wong, V.W.; Castera, L.; Berzigotti, A.; Sporea, I.; Dietrich, C.F.; Choi, B.I.; Wilson, S.R.; Kudo, M.; Barr, R.G. Liver ultrasound elastography: An update to the world federation for ultrasound in medicine and biology guidelines and recommendations. Ultrasound Med. Biol. 2018, 44, 2419–2440. [Google Scholar] [CrossRef] [Green Version]
  16. Yoneda, M.; Fujita, K.; Inamori, M.; Nakajima, A.; Yoneda, M.; Tamano, M.; Hiraishi, H. Transient elastography in patients with non-alcoholic fatty liver disease (NAFLD). Gut 2007, 56, 1330–1331. [Google Scholar] [CrossRef]
  17. European Association for Study of Liver. EASL Clinical practice guidelines: Management of hepatitis C virus infection. J. Hepatol. 2014, 60, 392–420. [Google Scholar] [CrossRef] [PubMed]
  18. Kamarajah, S.K.; Chan, W.K.; Nik Mustapha, N.R.; Mahadeva, S. Repeated liver stiffness measurement compared with paired liver biopsy in patients with non-alcoholic fatty liver disease. Hepatol. Int. 2018, 12, 44–55. [Google Scholar] [CrossRef]
  19. Nogami, A.; Yoneda, M.; Kobayashi, T.; Kessoku, T.; Honda, Y.; Ogawa, Y.; Suzuki, K.; Tomeno, W.; Imajo, K.; Kirikoshi, H.; et al. Assessment of 10-year changes in liver stiffness using vibration-controlled transient elastography in non-alcoholic fatty liver disease. Hepatol. Res. 2019, 49, 872–880. [Google Scholar] [CrossRef]
  20. Chow, J.C.; Wong, G.L.; Chan, A.W.; Shu, S.S.; Chan, C.K.; Leung, J.K.; Choi, P.C.; Chim, A.M.; Chan, H.L.; Wong, V.W. Repeating measurements by transient elastography in non-alcoholic fatty liver disease patients with high liver stiffness. J. Gastroenterol. Hepatol. 2019, 34, 241–248. [Google Scholar] [CrossRef] [Green Version]
  21. Chuah, K.H.; Lai, L.L.; Vethakkan, S.R.; Nik Mustapha, N.R.; Mahadeva, S.; Chan, W.K. Liver stiffness measurement in non-alcoholic fatty liver disease: Two is better than one. J. Gastroenterol. Hepatol. 2020. [Google Scholar] [CrossRef] [PubMed]
  22. Fraquelli, M.; Rigamonti, C.; Casazza, G.; Conte, D.; Donato, M.F.; Ronchi, G.; Colombo, M. Reproducibility of transient elastography in the evaluation of liver fibrosis in patients with chronic liver disease. Gut 2007, 56, 968–973. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  23. de Ledinghen, V.; Vergniol, J. Transient elastography (FibroScan). Gastroenterol. Clin. Biol. 2008, 32, 58–67. [Google Scholar] [CrossRef]
  24. Castera, L.; Foucher, J.; Bernard, P.H.; Carvalho, F.; Allaix, D.; Merrouche, W.; Couzigou, P.; de Ledinghen, V. Pitfalls of liver stiffness measurement: A 5-year prospective study of 13,369 examinations. Hepatology 2010, 51, 828–835. [Google Scholar] [CrossRef]
  25. Sirli, R.; Sporea, I.; Bota, S.; Jurchis, A. Factors influencing reliability of liver stiffness measurements using transient elastography (M-probe)-monocentric experience. Eur. J. Radiol. 2013, 82, e313–e316. [Google Scholar] [CrossRef]
  26. Wong, V.W.; Vergniol, J.; Wong, G.L.; Foucher, J.; Chan, H.L.; Le Bail, B.; Choi, P.C.; Kowo, M.; Chan, A.W.; Merrouche, W.; et al. Diagnosis of fibrosis and cirrhosis using liver stiffness measurement in nonalcoholic fatty liver disease. Hepatology 2010, 51, 454–462. [Google Scholar] [CrossRef]
  27. Kwok, R.; Tse, Y.K.; Wong, G.L.; Ha, Y.; Lee, A.U.; Ngu, M.C.; Chan, H.L.; Wong, V.W. Systematic review with meta-analysis: Non-invasive assessment of non-alcoholic fatty liver disease--the role of transient elastography and plasma cytokeratin-18 fragments. Aliment. Pharmacol. Ther. 2014, 39, 254–269. [Google Scholar] [CrossRef]
  28. Jiang, W.; Huang, S.; Teng, H.; Wang, P.; Wu, M.; Zhou, X.; Ran, H. Diagnostic accuracy of point shear wave elastography and transient elastography for staging hepatic fibrosis in patients with non-alcoholic fatty liver disease: A meta-analysis. BMJ Open 2018, 8, e021787. [Google Scholar] [CrossRef] [Green Version]
  29. Xiao, G.; Zhu, S.; Xiao, X.; Yan, L.; Yang, J.; Wu, G. Comparison of laboratory tests, ultrasound, or magnetic resonance elastography to detect fibrosis in patients with nonalcoholic fatty liver disease: A meta-analysis. Hepatology 2017, 66, 1486–1501. [Google Scholar] [CrossRef]
  30. De Robertis, R.; D’Onofrio, M.; Demozzi, E.; Crosara, S.; Canestrini, S.; Pozzi Mucelli, R. Noninvasive diagnosis of cirrhosis: A review of different imaging modalities. World J. Gastroenterol. 2014, 20, 7231–7241. [Google Scholar] [CrossRef]
  31. Han, A.; Labyed, Y.; Sy, E.Z.; Boehringer, A.S.; Andre, M.P.; Erdman, J.W., Jr.; Loomba, R.; Sirlin, C.B.; O’Brien, W.D., Jr. Inter-sonographer reproducibility of quantitative ultrasound outcomes and shear wave speed measured in the right lobe of the liver in adults with known or suspected non-alcoholic fatty liver disease. Eur. Radiol. 2018, 28, 4992–5000. [Google Scholar] [CrossRef]
  32. Bota, S.; Sporea, I.; Sirli, R.; Popescu, A.; Danila, M.; Costachescu, D. Intra- and interoperator reproducibility of acoustic radiation force impulse (ARFI) elastography—Preliminary results. Ultrasound Med. Biol. 2012, 38, 1103–1108. [Google Scholar] [CrossRef] [PubMed]
  33. Balakrishnan, M.; Souza, F.; Munoz, C.; Augustin, S.; Loo, N.; Deng, Y.; Ciarleglio, M.; Garcia-Tsao, G. Liver and spleen stiffness measurements by point shear wave elastography via acoustic radiation force impulse: Intraobserver and interobserver variability and predictors of variability in a US population. J. Ultrasound Med. 2016, 35, 2373–2380. [Google Scholar] [CrossRef]
  34. Ferraioli, G.; Tinelli, C.; Lissandrin, R.; Zicchetti, M.; Bernuzzi, S.; Salvaneschi, L.; Filice, C. Ultrasound point shear wave elastography assessment of liver and spleen stiffness: Effect of training on repeatability of measurements. Eur. Radiol. 2014, 24, 1283–1289. [Google Scholar] [CrossRef]
  35. Liu, H.; Fu, J.; Hong, R.; Liu, L.; Li, F. Acoustic radiation force impulse elastography for the non-invasive evaluation of hepatic fibrosis in non-alcoholic fatty liver disease patients: A systematic review & meta-analysis. PLoS ONE 2015, 10, e0127782. [Google Scholar] [CrossRef] [Green Version]
  36. Lin, Y.; Fu, J.; Hong, R.; Liu, L.; Li, F. The diagnostic accuracy of liver fibrosis in non-viral liver diseases using acoustic radiation force impulse elastography: A systematic review and meta-analysis. PLoS ONE 2020, 15, e0227358. [Google Scholar] [CrossRef] [Green Version]
  37. Bercoff, J.; Tanter, M.; Fink, M. Supersonic shear imaging: A new technique for soft tissue elasticity mapping. IEEE Trans. Ultrason. Ferroelectr. Freq. Control 2004, 51, 396–409. [Google Scholar] [CrossRef]
  38. Bavu, E.; Gennisson, J.L.; Couade, M.; Bercoff, J.; Mallet, V.; Fink, M.; Badel, A.; Vallet-Pichard, A.; Nalpas, B.; Tanter, M.; et al. Noninvasive in vivo liver fibrosis evaluation using supersonic shear imaging: A clinical study on 113 hepatitis C virus patients. Ultrasound Med. Biol. 2011, 37, 1361–1373. [Google Scholar] [CrossRef]
  39. Cassinotto, C.; Boursier, J.; de Ledinghen, V.; Lebigot, J.; Lapuyade, B.; Cales, P.; Hiriart, J.B.; Michalak, S.; Bail, B.L.; Cartier, V.; et al. Liver stiffness in nonalcoholic fatty liver disease: A comparison of supersonic shear imaging, FibroScan, and ARFI with liver biopsy. Hepatology 2016, 63, 1817–1827. [Google Scholar] [CrossRef]
  40. Sporea, I.; Bota, S.; Jurchis, A.; Sirli, R.; Gradinaru-Tascau, O.; Popescu, A.; Ratiu, I.; Szilaski, M. Acoustic radiation force impulse and supersonic shear imaging versus transient elastography for liver fibrosis assessment. Ultrasound Med. Biol. 2013, 39, 1933–1941. [Google Scholar] [CrossRef] [Green Version]
  41. Ferraioli, G.; Tinelli, C.; Zicchetti, M.; Above, E.; Poma, G.; Di Gregorio, M.; Filice, C. Reproducibility of real-time shear wave elastography in the evaluation of liver elasticity. Eur. J. Radiol. 2012, 81, 3102–3106. [Google Scholar] [CrossRef]
  42. Woo, H.; Lee, J.Y.; Yoon, J.H.; Kim, W.; Cho, B.; Choi, B.I. Comparison of the reliability of acoustic radiation force impulse imaging and supersonic shear imaging in measurement of liver stiffness. Radiology 2015, 277, 881–886. [Google Scholar] [CrossRef] [PubMed]
  43. Muthupillai, R.; Lomas, D.J.; Rossman, P.J.; Greenleaf, J.F.; Manduca, A.; Ehman, R.L. Magnetic resonance elastography by direct visualization of propagating acoustic strain waves. Science 1995, 269, 1854–1857. [Google Scholar] [CrossRef]
  44. Venkatesh, S.K.; Yin, M.; Ehman, R.L. Magnetic resonance elastography of liver: Technique, analysis, and clinical applications. J. Magn. Reson. Imaging 2013, 37, 544–555. [Google Scholar] [CrossRef] [Green Version]
  45. Barr, R.G.; Ferraioli, G.; Palmeri, M.L.; Goodman, Z.D.; Garcia-Tsao, G.; Rubin, J.; Garra, B.; Myers, R.P.; Wilson, S.R.; Rubens, D.; et al. Elastography assessment of liver fibrosis: Society of radiologists in ultrasound consensus conference statement. Radiology 2015, 276, 845–861. [Google Scholar] [CrossRef] [Green Version]
  46. Srinivasa Babu, A.; Wells, M.L.; Teytelboym, O.M.; Mackey, J.E.; Miller, F.H.; Yeh, B.M.; Ehman, R.L.; Venkatesh, S.K. Elastography in chronic liver disease: Modalities, techniques, limitations, and future directions. Radiographics 2016, 36, 1987–2006. [Google Scholar] [CrossRef] [PubMed]
  47. Venkatesh, S.K.; Talwalkar, J.A. When and how to use magnetic resonance elastography for patients with liver disease in clinical practice. Am. J. Gastroenterol. 2018, 113, 923–926. [Google Scholar] [CrossRef]
  48. Carrion, J.A.; Navasa, M.; Forns, X. MR elastography to assess liver fibrosis. Radiology 2008, 247, 591. [Google Scholar] [CrossRef]
  49. Barr, R.G. Elastography in clinical practice. Radiol. Clin. N. Am. 2014, 52, 1145–1162. [Google Scholar] [CrossRef]
  50. Tan, C.H.; Venkatesh, S.K. Magnetic resonance elastography and other magnetic resonance imaging techniques in chronic liver disease: Current status and future directions. Gut Liver 2016, 10, 672–686. [Google Scholar] [CrossRef] [Green Version]
  51. Loomba, R.; Cui, J.; Wolfson, T.; Haufe, W.; Hooker, J.; Szeverenyi, N.; Ang, B.; Bhatt, A.; Wang, K.; Aryafar, H.; et al. Novel 3D magnetic resonance elastography for the noninvasive diagnosis of advanced fibrosis in NAFLD: A prospective study. Am. J. Gastroenterol. 2016, 111, 986–994. [Google Scholar] [CrossRef] [Green Version]
  52. Yin, M.; Talwalkar, J.A.; Glaser, K.J.; Manduca, A.; Grimm, R.C.; Rossman, P.; Fidler, J.L.; Ehman, R.L. Assessment of hepatic fibrosis with magnetic resonance elastography. Clin. Gastroenterol. Hepatol. 2007, 5, 1207–1213.e2. [Google Scholar] [CrossRef] [Green Version]
  53. Hines, C.D.; Bley, T.A.; Lindstrom, M.J.; Reeder, S.B. Repeatability of magnetic resonance elastography for quantification of hepatic stiffness. J. Magn. Reson. Imaging 2010, 31, 725–731. [Google Scholar] [CrossRef] [Green Version]
  54. Shire, N.J.; Yin, M.; Chen, J.; Railkar, R.A.; Fox-Bosetti, S.; Johnson, S.M.; Beals, C.R.; Dardzinski, B.J.; Sanderson, S.O.; Talwalkar, J.A.; et al. Test-retest repeatability of MR elastography for noninvasive liver fibrosis assessment in hepatitis C. J. Magn. Reson. Imaging 2011, 34, 947–955. [Google Scholar] [CrossRef] [Green Version]
  55. Trout, A.T.; Serai, S.; Mahley, A.D.; Wang, H.; Zhang, Y.; Zhang, B.; Dillman, J.R. Liver stiffness measurements with MR elastography: Agreement and repeatability across imaging systems, field strengths, and pulse sequences. Radiology 2016, 281, 793–804. [Google Scholar] [CrossRef]
  56. Yasar, T.K.; Wagner, M.; Bane, O.; Besa, C.; Babb, J.S.; Kannengiesser, S.; Fung, M.; Ehman, R.L.; Taouli, B. Interplatform reproducibility of liver and spleen stiffness measured with MR elastography. J. Magn. Reson. Imaging 2016, 43, 1064–1072. [Google Scholar] [CrossRef] [Green Version]
  57. Singh, S.; Venkatesh, S.K.; Loomba, R.; Wang, Z.; Sirlin, C.; Chen, J.; Yin, M.; Miller, F.H.; Low, R.N.; Hassanein, T.; et al. Diagnostic performance of magnetic resonance elastography in staging liver fibrosis: A systematic review and meta-analysis of individual participant data. Clin. Gastroenterol. Hepatol. 2015, 13, 440–451.e6. [Google Scholar] [CrossRef] [Green Version]
  58. Yin, M.; Talwalkar, J.A.; Glaser, K.J.; Venkatesh, S.K.; Chen, J.; Manduca, A.; Ehman, R.L. Dynamic postprandial hepatic stiffness augmentation assessed with MR elastography in patients with chronic liver disease. AJR Am. J. Roentgenol. 2011, 197, 64–70. [Google Scholar] [CrossRef] [Green Version]
  59. Singh, S.; Venkatesh, S.K.; Loomba, R.; Wang, Z.; Sirlin, C.; Chen, J.; Yin, M.; Miller, F.H.; Low, R.N.; Hassanein, T.; et al. Magnetic resonance elastography for staging liver fibrosis in non-alcoholic fatty liver disease: A diagnostic accuracy systematic review and individual participant data pooled analysis. Eur. Radiol. 2016, 26, 1431–1440. [Google Scholar] [CrossRef]
  60. Bota, S.; Sporea, I.; Sirli, R.; Popescu, A.; Danila, M.; Jurchis, A.; Gradinaru-Tascau, O. Factors associated with the impossibility to obtain reliable liver stiffness measurements by means of acoustic radiation force impulse (ARFI) elastography—Analysis of a cohort of 1,031 subjects. Eur. J. Radiol. 2014, 83, 268–272. [Google Scholar] [CrossRef]
  61. Castera, L. Noninvasive methods to assess liver disease in patients with hepatitis B or C. Gastroenterology 2012, 142, 1293–1302.e4. [Google Scholar] [CrossRef] [Green Version]
  62. Venkatesh, S.K.; Wells, M.L.; Miller, F.H.; Jhaveri, K.S.; Silva, A.C.; Taouli, B.; Ehman, R.L. Magnetic resonance elastography: Beyond liver fibrosis-a case-based pictorial review. Abdom. Radiol. 2018, 43, 1590–1611. [Google Scholar] [CrossRef] [PubMed]
  63. Wong, G.L.; Wong, V.W.; Chim, A.M.; Yiu, K.K.; Chu, S.H.; Li, M.K.; Chan, H.L. Factors associated with unreliable liver stiffness measurement and its failure with transient elastography in the Chinese population. J. Gastroenterol. Hepatol. 2011, 26, 300–305. [Google Scholar] [CrossRef]
  64. Myers, R.P.; Pomier-Layrargues, G.; Kirsch, R.; Pollett, A.; Duarte-Rojo, A.; Wong, D.; Beaton, M.; Levstik, M.; Crotty, P.; Elkashab, M. Feasibility and diagnostic performance of the FibroScan XL probe for liver stiffness measurement in overweight and obese patients. Hepatology 2012, 55, 199–208. [Google Scholar] [CrossRef]
  65. Guo, Y.; Lin, H.; Zhang, X.; Wen, H.; Chen, S.; Chen, X. The influence of hepatic steatosis on the evaluation of fibrosis with non-alcoholic fatty liver disease by acoustic radiation force impulse. In Proceedings of the 2017 39th Annual International Conference of the IEEE Engineering in Medicine and Biology Society (EMBC), Seogwipo, Korea, 11–15 July 2017; pp. 2988–2991. [Google Scholar] [CrossRef]
  66. Joo, S.K.; Kim, W.; Kim, D.; Kim, J.H.; Oh, S.; Lee, K.L.; Chang, M.S.; Jung, Y.J.; So, Y.H.; Lee, M.S.; et al. Steatosis severity affects the diagnostic performances of noninvasive fibrosis tests in nonalcoholic fatty liver disease. Liver Int. 2018, 38, 331–341. [Google Scholar] [CrossRef]
  67. Oeda, S.; Takahashi, H.; Imajo, K.; Seko, Y.; Ogawa, Y.; Moriguchi, M.; Yoneda, M.; Anzai, K.; Aishima, S.; Kage, M.; et al. Accuracy of liver stiffness measurement and controlled attenuation parameter using FibroScan((R)) M/XL probes to diagnose liver fibrosis and steatosis in patients with nonalcoholic fatty liver disease: A multicenter prospective study. J. Gastroenterol. 2020, 55, 428–440. [Google Scholar] [CrossRef]
  68. Vuppalanchi, R.; Siddiqui, M.S.; Van Natta, M.L.; Hallinan, E.; Brandman, D.; Kowdley, K.; Neuschwander-Tetri, B.A.; Loomba, R.; Dasarathy, S.; Abdelmalek, M.; et al. Performance characteristics of vibration-controlled transient elastography for evaluation of nonalcoholic fatty liver disease. Hepatology 2018, 67, 134–144. [Google Scholar] [CrossRef]
  69. Eddowes, P.J.; Sasso, M.; Allison, M.; Tsochatzis, E.; Anstee, Q.M.; Sheridan, D.; Guha, I.N.; Cobbold, J.F.; Deeks, J.J.; Paradis, V.; et al. Accuracy of FibroScan controlled attenuation parameter and liver stiffness measurement in assessing steatosis and fibrosis in patients with nonalcoholic fatty liver disease. Gastroenterology 2019, 156, 1717–1730. [Google Scholar] [CrossRef] [Green Version]
  70. Imajo, K.; Kessoku, T.; Honda, Y.; Tomeno, W.; Ogawa, Y.; Mawatari, H.; Fujita, K.; Yoneda, M.; Taguri, M.; Hyogo, H.; et al. Magnetic resonance imaging more accurately classifies steatosis and fibrosis in patients with nonalcoholic fatty liver disease than transient elastography. Gastroenterology 2016, 150, 626–637.e7. [Google Scholar] [CrossRef] [Green Version]
  71. Cui, J.; Ang, B.; Haufe, W.; Hernandez, C.; Verna, E.C.; Sirlin, C.B.; Loomba, R. Comparative diagnostic accuracy of magnetic resonance elastography vs. eight clinical prediction rules for non-invasive diagnosis of advanced fibrosis in biopsy-proven non-alcoholic fatty liver disease: A prospective study. Aliment. Pharmacol. Ther. 2015, 41, 1271–1280. [Google Scholar] [CrossRef] [Green Version]
  72. Cui, J.; Heba, E.; Hernandez, C.; Haufe, W.; Hooker, J.; Andre, M.P.; Valasek, M.A.; Aryafar, H.; Sirlin, C.B.; Loomba, R. Magnetic resonance elastography is superior to acoustic radiation force impulse for the Diagnosis of fibrosis in patients with biopsy-proven nonalcoholic fatty liver disease: A prospective study. Hepatology 2016, 63, 453–461. [Google Scholar] [CrossRef] [PubMed]
  73. Park, C.C.; Nguyen, P.; Hernandez, C.; Bettencourt, R.; Ramirez, K.; Fortney, L.; Hooker, J.; Sy, E.; Savides, M.T.; Alquiraish, M.H.; et al. Magnetic resonance elastography vs. transient elastography in detection of fibrosis and noninvasive measurement of steatosis in patients with biopsy-proven nonalcoholic fatty liver disease. Gastroenterology 2017, 152, 598–607.e2. [Google Scholar] [CrossRef] [Green Version]
  74. Dulai, P.S.; Sirlin, C.B.; Loomba, R. MRI and MRE for non-invasive quantitative assessment of hepatic steatosis and fibrosis in NAFLD and NASH: Clinical trials to clinical practice. J. Hepatol. 2016, 65, 1006–1016. [Google Scholar] [CrossRef]
  75. Ajmera, V.H.; Liu, A.; Singh, S.; Yachoa, G.; Ramey, M.; Bhargava, M.; Zamani, A.; Lopez, S.; Mangla, N.; Bettencourt, R.; et al. Clinical utility of an increase in magnetic resonance elastography in predicting fibrosis progression in nonalcoholic fatty liver disease. Hepatology 2020, 71, 849–860. [Google Scholar] [CrossRef]
  76. European Association for the Study of the Liver (EASL); European Association for the Study of Diabetes (EASD); European Association for the Study of Obesity (EASO). EASL-EASD-EASO clinical practice guidelines for the management of non-alcoholic fatty liver disease. J. Hepatol. 2016, 64, 1388–1402. [Google Scholar] [CrossRef]
  77. Chalasani, N.; Younossi, Z.; Lavine, J.E.; Charlton, M.; Cusi, K.; Rinella, M.; Harrison, S.A.; Brunt, E.M.; Sanyal, A.J. The diagnosis and management of nonalcoholic fatty liver disease: Practice guidance from the American Association for the Study of Liver Diseases. Hepatology 2018, 67, 328–357. [Google Scholar] [CrossRef]
  78. Sasso, M.; Beaugrand, M.; de Ledinghen, V.; Douvin, C.; Marcellin, P.; Poupon, R.; Sandrin, L.; Miette, V. Controlled attenuation parameter (CAP): A novel VCTE™ guided ultrasonic attenuation measurement for the evaluation of hepatic steatosis: Preliminary study and validation in a cohort of patients with chronic liver disease from various causes. Ultrasound Med. Biol. 2010, 36, 1825–1835. [Google Scholar] [CrossRef]
  79. Newsome, P.N.; Sasso, M.; Deeks, J.J.; Paredes, A.; Boursier, J.; Chan, W.K.; Yilmaz, Y.; Czernichow, S.; Zheng, M.H.; Wong, V.W.; et al. FibroScan-AST (FAST) score for the non-invasive identification of patients with non-alcoholic steatohepatitis with significant activity and fibrosis: A prospective derivation and global validation study. Lancet Gastroenterol. Hepatol. 2020, 5, 362–373. [Google Scholar] [CrossRef] [Green Version]
  80. Reeder, S.B.; Robson, P.M.; Yu, H.; Shimakawa, A.; Hines, C. DG.; McKenzie, C.A.; Brittain, J.H. Quantification of hepatic steatosis with MRI: The effects of accurate fat spectral modeling. J. Magn. Reson. Imaging 2009, 29, 1332–1339. [Google Scholar] [CrossRef] [Green Version]
  81. Permutt, Z.; Le, T.-A.; Peterson, M.R.; Seki, E.; Brenner, D.A.; Sirlin, C.; Loomba, R. Correlation between liver histology and novel magnetic resonance imaging in adult patients with non-alcoholic fatty liver disease—MRI accurately quantifies hepatic steatosis in NAFLD. Aliment. Pharmacol. Ther. 2012, 36, 22–29. [Google Scholar] [CrossRef] [Green Version]
  82. Yoneda, M.; Imajo, K.; Nakajima, A. Non-invasive diagnosis of nonalcoholic fatty liver disease. Am. J. Gastroenterol. 2018, 113, 1409–1411. [Google Scholar] [CrossRef]
  83. Castera, L.; Friedrich-Rust, M.; Loomba, R. Noninvasive assessment of liver disease in patients with nonalcoholic fatty liver disease. Gastroenterology 2019, 156, 1264–1281.e4. [Google Scholar] [CrossRef] [Green Version]
  84. Chan, W.K.; Treeprasertsuk, S.; Goh, G.B.; Fan, J.G.; Song, M.J.; Charatcharoenwitthaya, P.; Duseja, A.; Dan, Y.Y.; Imajo, K.; Nakajima, A.; et al. Optimizing use of nonalcoholic fatty liver disease fibrosis score, fibrosis-4 score, and liver stiffness measurement to identify patients with advanced fibrosis. Clin. Gastroenterol. Hepatol. 2019, 17, 2570–2580.e37. [Google Scholar] [CrossRef] [Green Version]
  85. Chan, W.K.; Nik Mustapha, N.R.; Mahadeva, S. A novel 2-step approach combining the NAFLD fibrosis score and liver stiffness measurement for predicting advanced fibrosis. Hepatol. Int. 2015, 9, 594–602. [Google Scholar] [CrossRef]
  86. Petta, S.; Vanni, E.; Bugianesi, E.; Di Marco, V.; Cammà, C.; Cabibi, D.; Mezzabotta, L.; Craxì, A. The combination of liver stiffness measurement and NAFLD fibrosis score improves the noninvasive diagnostic accuracy for severe liver fibrosis in patients with nonalcoholic fatty liver disease. Liver International 2015, 35, 1566–1573. [Google Scholar] [CrossRef] [Green Version]
  87. Petta, S.; Wong, V.W.-S.; Cammà, C.; Hiriart, J.-B.; Wong, G.L.-H.; Vergniol, J.; Chan, A.W.-H.; Di Marco, V.; Merrouche, W.; Chan, H.L.-Y.; et al. Serial combination of non-invasive tools improves the diagnostic accuracy of severe liver fibrosis in patients with NAFLD. Aliment. Pharmacol. Ther. 2017, 46, 617–627. [Google Scholar] [CrossRef] [Green Version]
Ijms 21 04039 g001 550
Figure 1. Liver fibrosis score in non-alcoholic fatty liver disease (Masson trichrome staining). Stage 1: Pericellular and perisinusoidal fibrosis in zone 3. Stage 2: Pericellular and perisinusoidal fibrosis with periportal fibrosis. Stage 3: Bridging fibrosis. Stage 4: Cirrhosis.
Figure 1. Liver fibrosis score in non-alcoholic fatty liver disease (Masson trichrome staining). Stage 1: Pericellular and perisinusoidal fibrosis in zone 3. Stage 2: Pericellular and perisinusoidal fibrosis with periportal fibrosis. Stage 3: Bridging fibrosis. Stage 4: Cirrhosis.
Ijms 21 04039 g001
Ijms 21 04039 g002 550
Figure 2. Illustrations and images of each elastography technique. (a) Vibration-controlled transient elastography transmits a mechanical pulse from the probe to the liver. (b) Point shear wave elastography and (c) two-dimensional shear wave elastography use acoustic radiation force impulse (green dots) to induce shear waves in liver tissue. (d) Magnetic resonance elastography uses a driver system to generate and transmit longitudinal waves into the liver. The green-yellow wave lines (a, b, c) show shear waves, and the curved lines (d) show vibrations in the liver. The yellow rectangles indicate the interrogated liver volume.
Figure 2. Illustrations and images of each elastography technique. (a) Vibration-controlled transient elastography transmits a mechanical pulse from the probe to the liver. (b) Point shear wave elastography and (c) two-dimensional shear wave elastography use acoustic radiation force impulse (green dots) to induce shear waves in liver tissue. (d) Magnetic resonance elastography uses a driver system to generate and transmit longitudinal waves into the liver. The green-yellow wave lines (a, b, c) show shear waves, and the curved lines (d) show vibrations in the liver. The yellow rectangles indicate the interrogated liver volume.
Ijms 21 04039 g002
Table
Table 1. Meta-analyses of elastography techniques for the diagnosis of liver fibrosis in patients with non-alcoholic fatty liver disease.
Table 1. Meta-analyses of elastography techniques for the diagnosis of liver fibrosis in patients with non-alcoholic fatty liver disease.
TechniqueAuthorYearReference No.No. of PatientsNo. of Studies
VCTE M probeKwok et al.2014268548Fibrosis StageRange
Cut-off (kPa)SensitivitySpecificityAUROC
≥26.65–7.70.67–0.940.61–0.840.79–0.87
≥38.0–10.40.65–1.000.75–0.970.76–0.98
≥410.3–17.50.78–1.000.82–0.980.91–0.99
Fibrosis StageSummary
SensitivitySpecificity
≥2 0.790.75
≥30.850.85
≥40.920.92
Xiao et al.201728249516Fibrosis StageRange
Cut-off (kPa)SensitivitySpecificity
≥25.80.90–0.940.42–0.80
6.65–70.58–1.000.45–0.84
7.25–110.53–0.840.70–0.93
≥36.95–7.250.67–0.700.65–0.68
7.6–80.65–1.000.66–0.90
8.7–90.76–0.880.63–0.88
9.6–11.40.69–1.000.84–0.97
≥47.9–8.40.93–1.000.76–0.79
10.3–11.30.78–1.000.82–0.90
11.5–11.950.69–0.900.85–0.91
13.4–22.30.41–1.000.76–0.98
Fibrosis StageSummary
AUROC (95% CI)
≥2 0.83 (0.79–0.86)
≥30.87 (0.83–0.90)
≥40.92 (0.90–0.94)
Jiang et al.201827175311Fibrosis StageRange
Cut-off (kPa)SensitivitySpecificityAUROC
≥26.7–11.00.60–0.940.61–1.000.79–0.88
≥38.0–12.50.57–1.000.76–0.970.76–0.99
≥410.4–17.50.65–1.000.76–0.980.87–0.99
Fibrosis StageSummary
Sensitivity (95% CI)Specificity (95% CI)AUROC (95% CI)
≥2 0.77 (0.70–0.84)0.80 (0.74–0.84)0.85 (0.82–0.88)
≥30.79 (0.69–0.87)0.89 (0.84–0.92)0.92 (0.89–0.94)
≥40.90 (0.73–0.97)0.91 (0.87–0.94)0.94 (0.93–0.97)
VCTE XL probeXiao et al.2017283183Fibrosis StageRange
Cut-off (kPa)SensitivitySpecificity
≥24.8–8.20.57–0.920.37–0.90
≥35.7–9.30.57–0.910.54–0.90
≥47.2–160.71–1.000.70–0.91
Fibrosis StageSummary
AUROC (95% CI)
≥2 0.82 (0.75–0.89)
≥30.86 (0.78–0.94)
≥40.94 (0.88–0.99)
pSWELiu et al.2015347237Fibrosis StageRange
Cut-off (m/s)SensitivitySpecificity
≥21.165–1.790.71–0.900.67–0.90
≥31.45–2.200.75–1.000.68–0.95
≥41.61–2.900.74–1.000.67–0.96
Fibrosis StageSummary
Sensitivity (95% CI)Specificity (95% CI)AUROC (95% CI)
≥2 0.80 (0.76–0.84)0.85 (0.81–0.89)0.90
Jiang et al.2018279829Fibrosis StageRange
Cut-off (m/s)SensitivitySpecificityAUROC
≥21.16–1.320.56–0.850.78–0.910.71–0.94
≥31.34–1.770.59–1.000.74–0.960.76–0.99
≥41.40–2.480.44–1.000.74–1.000.84–0.98
Fibrosis StageSummary
Sensitivity (95% CI)Specificity (95% CI)AUROC (95% CI)
≥2 0.70 (0.59–0.79)0.84 (0.79–0.88)0.86 (0.83–0.89)
≥30.89 (0.73–0.96)0.88 (0.82–0.92)0.94 (0.91–0.95)
≥40.89 (0.60–0.98)0.91 (0.82–0.95)0.95 (0.93–0.97)
Lin et al.202035114713Fibrosis StageSummary
Cut-off (m/s)Sensitivity (95% CI)Specificity (95% CI)AUROC (95% CI)
≥21.30.850.830.89 (0.85–0.91)
≥32.060.90.90.94 (0.91–0.96)
≥41.890.90.950.94 (0.92–0.95)
MRESingh et al.2016582329Fibrosis StageSummary
Cut-off (kPa)Sensitivity (95% CI)Specificity (95% CI)AUROC (95% CI)
≥12.880.75 (0.68–0.87)0.77 (0.65–0.88)0.86 (0.82–0.90)
≥23.540.79 (0.76–0.90)0.81 (0.72–0.91)0.87 (0.82–0.93)
≥33.770.83 (0.53–0.90)0.86 (0.81–0.96)0.90 (0.84–0.94)
≥44.090.88 (0.82–1.00)0.87 (0.77–0.97)0.91 (0.76–0.95)
Xiao et al.2017286285Fibrosis StageRange
Cut-off (kPa)SensitivitySpecificity
≥23.4–3.6265.7–97.385.0–95.7
≥33.62–4.874.5–92.286.9–93.3
≥44.15–6.780.0–90.991.4–94.5
Fibrosis StageSummary
AUROC (95% CI)
≥2 0.88 (0.83–0.92)
≥30.93 (0.90–0.97)
≥40.92 (0.80–1.00)
For the diagnosis of mild fibrosis (stage 1), significant fibrosis (stage 2), advanced fibrosis (stage 3), and cirrhosis (stage 4), histopathology was used as the reference standard. VCTE, vibration-controlled transient elastography; pSWE, point shear wave elastography; MRE, magnetic resonance elastography; AUROC, area under the receiver operating characteristic curve; CI, confidence interval.
Table
Table 2. Advantages and limitations of elastography techniques.
Table 2. Advantages and limitations of elastography techniques.
US-BasedMR-Based
VCTE pSWE2D-SWEMRE
M ProbeXL Probe
ConfounderObesity ObesityObesity
InflammationInflammationInflammationInflammation
AscitesAscites
Iron Overload
Cholestasis, Hepatic Congestion
Sampling Volume of LiverLittleLarge
Technical Failure6.7–29.2%~2%~5%~5%
CostLowLowModerateModerateHigh
AvailabilityGoodLimited
HCC ScreeningBlind techniqueUS ExamUS ExamMRI Exam
Evaluation of Liver Fat AccumulationCAP--PDFF
Guideline RecommendationAASLD, EASL--AASLD
US, ultrasonography; MR, magnetic resonance; VCTE, vibration-controlled transient elastography; pSWE, point shear wave elastography; 2D-SWE, two-dimensional shear wave elastography; MRE, magnetic resonance elastography; HCC, hepatocellular carcinoma; MRI, magnetic resonance imaging; CAP, controlled attenuation parameter; PDFF, proton density fat fraction; AASLD, American Association for the Study of Liver Diseases; EASL, European Association for the Study of the Liver.

Share and Cite

MDPI and ACS Style

Honda, Y.; Yoneda, M.; Imajo, K.; Nakajima, A. Elastography Techniques for the Assessment of Liver Fibrosis in Non-Alcoholic Fatty Liver Disease. Int. J. Mol. Sci. 2020, 21, 4039. https://doi.org/10.3390/ijms21114039

AMA Style

Honda Y, Yoneda M, Imajo K, Nakajima A. Elastography Techniques for the Assessment of Liver Fibrosis in Non-Alcoholic Fatty Liver Disease. International Journal of Molecular Sciences. 2020; 21(11):4039. https://doi.org/10.3390/ijms21114039

Chicago/Turabian Style

Honda, Yasushi, Masato Yoneda, Kento Imajo, and Atsushi Nakajima. 2020. "Elastography Techniques for the Assessment of Liver Fibrosis in Non-Alcoholic Fatty Liver Disease" International Journal of Molecular Sciences 21, no. 11: 4039. https://doi.org/10.3390/ijms21114039

APA Style

Honda, Y., Yoneda, M., Imajo, K., & Nakajima, A. (2020). Elastography Techniques for the Assessment of Liver Fibrosis in Non-Alcoholic Fatty Liver Disease. International Journal of Molecular Sciences, 21(11), 4039. https://doi.org/10.3390/ijms21114039

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
