2.1. Color Measurement
The burgers prepared on the soy protein base were subjected to instrumental color analysis (
Table 1). During storage, an increase in the brightness (L*) parameter was observed compared to day one in all groups except for the control group and the G1 group with cardamon. No significant differences were observed between the samples prepared with lower granularity proteins until day fourteen, where the highest brightness (46.59) was observed in the samples with carrot powder. In contrast, the lowest brightness was recorded for the samples with pomegranate powder (42.43). The opposite situation was observed for samples with higher granulation protein, where differences (
p ≤ 0.05) between groups were only observed on days 1 and 7. The burgers analyzed by Botella-Martínez et al. [
35] were prepared using liquid beetroot juice. The present study used powdered beetroot juice dissolved in water during sample preparation. The L* parameter in the study by Botella-Martínez et al. [
35] ranged from 33.03 to 34.87, a slightly lower value than in the present study, which could be due to the different proportion of the coloring substance in the recipes used. Furthermore, in the present study, carob powder was also used in the burger recipe, which has a darker color and may have contributed to lower brightness of the samples. This combination of at least two coloring ingredients was identified in a study by Ryu et al. [
26] as the most effective to achieve the appropriate color in meat analogues. In the study by Ryu et al. [
26], beetroot juice and cocoa were used, while in the present study, it was beetroot juice and carob. The brightening of the color of the burgers during storage was related to the use of beetroot juice as one of the color-giving ingredients. This finding is consistent with the results of Kayın et al. [
36], who reported a significant increase in the value of the L* parameter during storage of beetroot juice.
Considering the parameter a* (−a* green, +a* red) and the parameter b* (−b* blue, +b* yellow), no significant differences were observed between samples with granulation 1 on day 1 and samples with granulation 2 on day 14 (
p > 0.05). The samples with pomegranate powder had the highest value of the a* parameter on day 1 (8.80) for granulation1. On day seven, the highest values of this parameter were characterized by samples with carrot powder (8.25) for granulation1 and samples belonging to the control group (10.47) for granulation2. Among samples with lower granulation, the highest b* values were recorded on days 7 and 14 for samples with carrot powder (D7 = 20.39; D14 = 20.43). Among the samples with higher granulation protein, the highest values of the b* parameter were observed on day one for the samples with cardamom powder (18.35) and on day seven for the control group (20.22). The protein granulation and the storage of the burgers did not clearly and significantly affect the a* and b* values in most of the tested samples. The a* value in the tested burgers was comparable to the values obtained by Botella-Martínez et al. [
35] for samples with commercial beetroot juice (7.88 and 7.92). For the b* parameter, the results obtained by Botella-Martínez et al. [
35] showed a significant difference (8.14–9.72), possibly due to the seasonings used and the color of the textured soy protein. The results of the study by Vu et al. [
37] which included instrumental color analysis of commercial plant-based burgers from Impossible Foods (Redwood City, CA, USA) after baking, indicate comparable values for the L* and a* parameters. Regarding the b* parameter, this study obtained significantly higher results, which may be due to differences in the ingredient lists. The Impossible Burger contains different spices and is also enriched with vitamins.
2.2. Texture Measurement and Weight Loss [%]
The instrumental analysis of the texture parameters (
Table 2 and
Table 3) showed that higher granulation of the textured plant protein results in greater springiness in the tested plant-based burgers. Statistically significant differences (
p ≤ 0.05) were observed for samples with pomegranate powder on days 1 and 14, for the control group on day 14, and for all tested groups on day 7. Storage of the burgers led to an increase in springiness between days 1 and 7, followed by a decrease in the value in this parameter between days 7 and 14, which was observed in most of the tested samples, particularly for granulation two.
On day 1, no statistically significant (
p > 0.05) differences were observed between groups (control, cardamom, pomegranate, juniper, carrot) and granulations (G1, G2) in terms of the cohesiveness of the burger samples (0.12–0.18). On Day 7, higher springiness was recorded for the higher granulation protein-based samples, except for the juniper powder group. Similar to springiness, most burger samples showed an initial increase in cohesiveness on day 7, followed by a decrease on day 14. However, no statistically significant changes (
p > 0.05) were observed during storage in samples with G1 protein from the control, cardamom-containing and carrot-containing groups. In a study by Botella-Martínez et al. [
35], texture parameters were analyzed in plant burgers prepared with textured soy protein, where significantly lower springiness values (0.10–0.12) were observed compared to the present study, while higher cohesiveness values (0.44–0.53) were recorded in their samples. The differences in these parameters may be primarily due to the formulation composition (despite the similar proportion of textured soy protein—21 and 22%) and the functional properties of the ingredients themselves. In a study by Peñaranda & Garrido [
38], the cohesiveness of the tested soy burgers was also significantly higher (0.34–0.38). However, the study used a different thickener (methylcellulose) and a higher content of textured protein.
On the three test days, samples prepared using textured plant protein of higher granulation had a statistically significantly higher value for the hardness parameter than samples based on lower granulation. On day 1, no statistical differences (p > 0.05) were observed within the G1 granulation samples concerning the hardness of the burgers (50.08–54.51 N). On the following day (D7), only the control group (114.92 N) was distinguished from the other samples by a higher hardness (p ≤ 0.05). A slightly higher variation in hardness was observed among the samples with G2 granulation protein. The samples from the control group had the highest value for this parameter on day 1 (93.85). In all tested groups, regardless of the protein granulation used, storage for 7 days resulted in a statistically significant (p ≤ 0.05) increase in the hardness of the burgers. Further storage led to continued increases in hardness in most of the groups, resulting in nearly a twofold increase in this parameter due to water loss.
The soy burgers tested by Botella-Martínez et al. [
35] had hardness levels of 22.38–33.30 N, significantly lower than the samples tested in this study. The difference could primarily be attributed to the significantly lower fiber content and the method and duration of heat treatment. In the present study, 2.60% fiber was used, while in the study by Botella-Martínez et al. [
35], the proportion of fiber was 1.27%. The burger recipe in this study also included 1.7% potato starch and 4.5% soy protein, which may have contributed to the increased hardness of the burgers. In the study by Jung et al. [
39], the hardness values (51.07–91.07 N) were similar to those obtained in the present study, depending on the heat treatment time and temperature. In contrast, the hardness of the burgers in the study by Peñaranda & Garrido [
38] was significantly higher, (195.87–247.94 N), probably due to the recipe’s high protein and methylcellulose content. An interesting study was conducted by Lee et al. [
27], in which the textural properties of cooked commercial beef burgers and two plant-based burgers—one from the USA and one from South Korea—were examined and compared. About the results of the study by Lee et al. [
27], the texture parameter results obtained in this study were significantly higher than those of commercial burgers from the USA (200% for G1 and 400% G2) and South Korea (125% for G1, 200% for G2). Burgers with larger protein granulation had a hardness similar to that of commercial beef burgers. At the same time, the burgers prepared in this study had approximately 4 times lower elasticity and cohesiveness values than both commercial beef and plant-based burgers. This indicates the need to modify the burger recipe in future studies, particularly regarding texturizing agents.
The weight losses (
Table 4) due to the heat treatment of the burgers that were observed for each group were not statistically significantly different (
p > 0.05). Nevertheless, using two granulations of textured soy protein in the plant-based burgers revealed that the higher granulation resulted in greater weight loss in each test group. However, the weight loss difference was statistically significant for the control group and the group containing carrot powder (
p ≤ 0.05). Weight loss during heat treatment ranged from 11.62 to 12.58% for granulation 1 and 12.77 to 14.09% for granulation 2. Vu et al. [
40] reported a higher weight loss (approximately 15%) of soy burgers (Impossible Foods Burger Patties) during baking for 12 min. Also, in the study by Botella-Martínez et al. [
35], despite a shorter cooking time, weight loss of 14–17% was observed, which was higher than the present study. This is likely due to differences in formulation and the properties of the selected ingredients, such as fiber, protein powder, textured plant protein, and thickeners.
Differences observed in texture parameters and weight loss between samples can be explained by structural and hydration-related mechanisms associated with particle size in extruded plant protein. Particle size determines the specific surface area available for water absorption and protein interactions. Smaller particles have a higher surface area-to-volume ratio, which promotes more uniform hydration and thus reduces the hardness parameter. In contrast, larger textured protein particles behave more like separate structural units deposited in the matrix [
28]. During mechanical testing, these particles can increase physical resistance and, consequently, the hardness parameter. Comparable mechanisms were described by Zhang et al. [
41], who showed that increasing the size of TVP particles significantly increased the cutting work, probably due to the mechanical resistance of individual particles. However, the effect of particle size on cooking loss is limited and less consistent, as indicated by Zhang et al. [
41], suggesting that raw material properties and hydration level play a more important role than particle size alone.
Storage-related changes in texture can be explained by water redistribution and reorganization of the protein matrix [
42]. During refrigerated storage, partial migration of water may occur from the interior of hydrated particles toward the surrounding continuous phase. At the same time, limited surface evaporation and progressive binding of water by hydrocolloids or other water-binding components in the composition can reduce the amount of free water. This change can lead to increased hardness over time.
The effects of dried plant powders on a product formulation’s physical parameters can be explained by several interacting mechanisms. Firstly, the presence of dietary fiber and non-starch polysaccharides in plant powders can increase water-binding capacity and modify the product’s textural properties. Secondly, finely ground plant particles can fill gaps in the protein matrix, altering the microstructure and potentially changing the texture parameters. Protein–polyphenol and protein–polysaccharide interactions during storage may further modify matrix compactness and water immobilization. Nevertheless, these mechanisms are complex and challenging to analyze in a formulation as intricate as the one studied in this research, due to the numerous interactions between raw materials and variations in the chemical composition of plant powders, as well as potential storage-related factors such as heterogeneous moisture loss and microbiological activity that may additionally influence structural stability over time.
2.3. Determination of Phenolic Compounds
The prepared soy burgers were analyzed for their polyphenol and flavonoid content (
Table 4). The samples with the addition of pomegranate powder (735.44–839.14 mg) exhibited the highest polyphenol content, regardless of the testing day or the granulation of the textured protein. The only exception was on day fourteen, when the highest polyphenol levels were recorded in the samples containing cardamom fruit powder (741.23 mg) in the higher protein granulation group. Among all samples, on each test day, in both protein granulations, the samples belonging to the control group had the lowest polyphenol content (257.31–284.90 mg). Refrigerated storage of the prepared burgers did not have a statistically significant effect (
p > 0.05) on polyphenol content in most of the samples tested. There was a reduction in polyphenol content in the first 7 days of storage of samples belonging to the control group with smaller granulation and samples with carrot powder and larger granulation. Furthermore, no statistically significant differences (
p > 0.05) were observed between samples from the same group, tested on the same day, but containing proteins with different granulations.
Similar to the polyphenol content, the highest flavonoid levels were recorded in the samples with pomegranate powder on each test day, regardless of granulation, ranging from 317.39 to 335.36 mg. In contrast, the lowest flavonoid content was recorded in the control group (193.10–214.79 mg). Of the samples formulated with dried plant material, those containing dried carrots exhibited the lowest flavonoid content (238.13–253.8). There were no statistical differences (p > 0.05) between the results for the samples in the group containing cardamom and juniper powder. During storage, there was a statistically significant decrease (p ≤ 0.05) in flavonoid content between 7 and 14 days only in samples from the control group (granulation 1 and granulation 2). The degree of granulation had no statistically significant effect on the flavonoid content of the soy burgers.
2.4. DPPH Radical Scavenging Activity
A plant-based meat analogue based on textured soy protein was analyzed for antioxidant capacity (
Table 5). The highest antioxidant capacity was in samples with cardamom fruit powder and pomegranate powder, which did not show statistically significant differences (
p > 0.05). The lowest values were recorded for the control group samples throughout the study, regardless of the protein granulation used (40.68–47.83%). As with flavonoids, the lowest antioxidant activity values among samples containing plant powders were observed in the carrot powder group (55.48–61.11%). Most of the test groups exhibited the highest DPPH radical scavenging capacity on day one; the exceptions were the groups containing cardamom and pomegranate powder. During storage, a significant decrease (
p ≤ 0.05) in antioxidant capacity was observed in samples from the control group and those containing carrot powder in the lower granulation protein-based burgers.
Several studies have explored the use of plant ingredients in meat analogues and meat products: [
40,
43,
44,
45,
46,
47]. In the present study, ingredients known for their health-promoting compounds, such as polyphenols and flavonoids, were included in the plant burger recipe: cardamom fruit [
48], juniper fruit [
49], pomegranate fruit [
50], carrot root [
51]. Therefore, the results are consistent with the existing scientific literature, which demonstrates that adding plant ingredients containing polyphenols and flavonoids to formulations results in their presence in the finished product, while also influencing its antioxidant capacity.
The observed decrease in antioxidant capacity during refrigerated storage can be explained by the development of lipid oxidation and the degradation of phenolic compounds in plant powders. Phenolic compounds act as radical scavengers, donating hydrogen atoms or electrons, thereby interrupting the crucial phases of lipid oxidation. Over time, these compounds are gradually depleted, which explains the decrease in measured antioxidant activity.
Interactions between proteins and polyphenols may partially protect bioactive compounds by limiting their mobility and reducing oxygen availability. Furthermore, the presence of dietary fiber and polysaccharides in plant powders may change water retention and contribute to texture hardening. This can indirectly slow the diffusion of oxygen, thereby mitigating oxidative reactions. As a result, samples containing plant powders showed slower decrease in antioxidant capacity than the control preparation.
2.5. Lipid Oxidation Analysis (TBARS)
The samples stored for 7 and 14 days were subjected to lipid oxidation analysis (
Table 5). On each test day, the MDA content was highest in samples belonging to the control group (0.40–1.02 mg). Among the samples with dried plants, the highest content of this compound was present in burgers with carrot powder (0.35–0.81 mg). On day 1, samples containing dried pomegranate, juniper, or cardamom did not show statistically significant differences (
p > 0.05) (G1 = 0.24–0.28 mg; G2 = 0.21–0.25 mg). On day 7, the lowest values were recorded for samples with cardamom and pomegranate, which were statistically significantly different (
p ≤ 0.05) from samples with juniper. In contrast, pomegranate powder samples showed lower values on day 14 (G1 = 0.42 mg, G2 = 0.39 mg Throughout the storage period, the MDA content increased significantly (
p ≤ 0.05) in all samples, reaching its peak on day 14.). The exceptions were samples with pomegranate and lower granulation protein and juniper and higher granulation protein, where the MDA content did not increase from day 7, and samples with pomegranate and higher granulation protein, where the change occurred only between days 7 and 14. The granulation of the textured protein did not significantly affect lipid oxidation (
p > 0.05) in most of the samples, except in the control group on day 14, where the MDA content was significantly higher in G1 granulation samples.
Ariz et al. [
52] demonstrated that a heat-treated plant-based (pea) protein burger had an MDA content of 0.42 ppm, which is comparable to the results obtained in the present study for the control group on day one. This finding aligns with research on the potential of plant-based ingredients in meat products and meat analogues to reduce lipid oxidation. The incorporation of plant-based ingredients has been shown to reduce lipid oxidation during storage and thermal processing of products [
53,
54].
2.6. Semi-Consumer Analysis of Plant-Based Burgers
The plant-based burger samples were subjected to a semi-consumer analysis. The results of the evaluation of selected sensory attributes such as color, smell, taste, texture, and overall acceptability are presented in
Table 6. Burgers containing pomegranate powder received the highest scores for color, aroma, taste, and overall acceptability, regardless of the granulation tested. In terms of texture, samples with carrot powder and juniper received the highest ratings in granulation 1, while in granulation 2, the control group burgers were rated as having the best texture by the evaluators. The samples with cardamom and juniper, and the control group, received the lowest ratings for all parameters.
The semi-consumer evaluation showed differences in the acceptance of the tested plant-based burger variants depending on the plant powder additive used. Differences in perception of texture and color largely corresponded to the results of the instrumental TPA analysis and color parameter measurements (L*, a*, b*). In the color assessment, the variants with the highest L* values in burgers with granulation 1 were perceived as more attractive. At the same time, significantly lower L* values in samples with protein granulation 2 resulted in a lower color rating. The addition of powders rich in natural colorants (e.g., carotenoids in carrots) increased the a* or b* parameter values, resulting in a warmer product shade and, in some cases, an improvement in visual assessment. Samples with the lowest a* parameter values were rated worst for color and overall acceptability. The texture assessment results also corresponded to the semi-consumer assessment results. Samples with higher hardness in instrumental analysis received higher scores in the texture and overall acceptability assessment. Samples with the lowest hardness were rated significantly lower.
