In this paper, we introduce a health parameter and estimation algorithm to assess the severity of stator turn-to-turn/inter-turn short-circuit (TTSC) faults in wound-rotor synchronous generators (WRSG). Our methodology establishes criteria for evaluating the severity of stator TTSC faults in WRSG and provides a specific solution for estimating both the severity of these faults and the resultant power loss. Our assessment methodology directly reflects the intrinsic impact of stator TTSC faults on the WRSG, offering enhanced efficiency, accuracy, and resilience to interference compared with traditional methods in estimating and gauging the TTSC severity. First, we demonstrate that it is impossible to determine the two fault parameters of the WRSG stator TTSC faults solely based on the voltage and current measurements. Subsequently, we introduce a novel health parameter for the WRSG stator TTSC faults and show that for a given generator and load, the dynamics of voltage and current during these faults as well as the resulting power loss are determined by this health parameter. We then detail the characteristics of the proposed health parameter and criteria for evaluating the severity of the WRSG stator TTSC faults. Furthermore, we present an estimation algorithm that is capable of accurately estimating the health parameter and power loss, demonstrating its minimal estimation error. Finally, we provide a comprehensive set of simulation results, including Monte Carlo results, to validate our proposed methodology and illustrate that our approach offers significant improvements in terms of the efficiency, accuracy, and robustness of the WRSG stator TTSC fault detection and isolation (FDI) over conventional methods. Full article

The conversion of air currents through wind turbine technology stands as one of the most significant and effective means of generating green electricity. Wind turbines featuring a horizontal axis exhibit the greatest installed capacity. The study establishes a mathematical model for large wind turbines, categorized by megawatt output, utilizing measured data for key parameters, including wind speed, power output from the generator, and rotational speed. The analysis of the system’s behavior on startup—the cut-in wind speed, is conducted by transitioning the electric generator into motor mode. A mathematical model has been established for the dual-powered motor configuration, wherein both the stator and rotor are connected to a common frequency network, facilitating a shift to synchronous motor functionality. The equation that describes the kinetic moment highlights the importance of attaining optimal velocity, while simultaneously accounting for variations in the load angle. These fluctuations are observable in both the power output and the electrical currents. The simulations that have been processed are derived from experimental data, specifically inputs obtained from a 1.5 MW wind turbine located in the Oravita region of southwestern Romania. The paper thus outlines essential elements concerning the functionality of high-power wind turbines that utilize wound rotor induction generators, aiming to guarantee optimal performance from the moment the wind speed reaches the cut-in threshold. Full article

Wound rotor synchronous condensers (WRSCs) are DC-excited rotor machines that utilize rotor winding instead of permanent magnets. Their voltage regulator controls the rotor field to generate or absorb reactive power, thereby regulating grid voltage or improving power factor. A key characteristic of a WRSC is the compounding curve, which shows the required rotor current under specific stator current and voltage conditions. This paper presents an approach for quickly calculating the electromagnetic parameters of a WRSC using a mathematical method. After determining magnetic flux density, induced voltage, and inductance through analytical methods, the Park and Clarke transformations are applied to derive the dq-frame quantities, enabling prediction of active and reactive powers and compounding curve characteristics. The 60 Hz model was evaluated through comparison with finite element method (FEM) simulations. Results of flux density, induced voltage, and the compounding curve under varying rotor and stator current conditions showed that the proposed method achieved comparable performance to FEM simulation while reducing computational time by half. Full article

Utilizing non-overlap windings has emerged as a favourable choice for minimizing electrical machine manufacturing costs, among other benefits. Nevertheless, it is widely acknowledged that these windings exhibit a notable level of harmonic contents in the resultant magnetomotive force, which can detrimentally impact machine performance, particularly in terms of torque ripple. In the context of wind energy conversion, maintaining low torque ripple is an essential and demanding prerequisite. Medium-speed wind generators present a good trade-off between high energy yield and low gearbox ratios. So far, medium-speed non-overlap winding wound-rotor synchronous generator (WRSG) technologies have been limited to 10/12 and the less common 16/18 pole/slot combinations. In this study, the analysis of a high-pole number combination (24/27 pole/slots) non-overlap WRSG is carried out to theoretically and comparatively predict the electromagnetic and radial force mechanical stress performance analysis with the 16/18 machine with a phase-shifted non-overlap winding (PSW), at 5 MW power level. The study, which is founded on the finite element analysis (FEA) technique, shows that the 24/27 machine exhibits comparable average torque and torque ripple, lower core losses and significantly reduced radial forces compared to the 16/18 PSW-WRSG. However, the 16/18 PSW-WRSG has a 50% reduction in the radial forces compared to the conventional 16/18 non-overlap winding. Experimental vibration analysis of a 3 kW 16/18 WRSG test machine confirms the radial force and vibration reduction in the phase-shifted winding. Full article

This paper investigates the use of fractional-slot concentrated windings (FSCWs) in large-scale (MW level) offshore wind generators. It focuses specifically on a power rating of 3 MW and uses an existing direct-drive synchronous PM machine (DD-SPM) with 480s/160p and dual three-phase integer-slot winding (ISW) as a baseline. A multiple of the common 12s/10p FSCW machine is used that matches the electrical frequency of the ISW machine, yielding a 192s/160p dual three-phase machine. The hybrid star–delta connection has grown increasingly popular owing to its unique harmonic cancellation properties, which can help reduce rotor and PM eddy current losses in FSCW machines. In this paper, two dual three-phase star–delta-wound machines are scaled to 3 MW and included in the investigation. Specifically, a 384s/160p dual three-phase and dual star–delta winding machine, which is a multiplication of the 24s/10p machine, and a 192s/176p dual three-phase and dual star–delta winding machine, which is a multiplication of the 24s/22p machine, are used. These machines are investigated using finite element analysis (FEA) and compared on the basis of their air-gap flux density harmonics, open-circuit electro-motive force (EMF), torque performance, and losses and power. It is found that the proposed 384s/160p dual star–delta winding machine has the best electromagnetic performance of all, with a stator power that is 1.2% greater than that of the baseline ISW machine. However, this machine has a coil pitch of 2 and so loses the manufacturing and fault-tolerant advantage of having concentrated windings. If concentrated windings are desired, then the proposed 192s/176p dual star–delta winding machine is the best choice, with the stator power only 2.6% less than that of the baseline ISW machine, but unfortunately still has significant rotor and PM eddy current losses. Full article

The nonlinear modeling and analyzing of wound-rotor synchronous starter/generators (WRSSGs) plays a vital role in the analysis and monitoring of aircraft power systems. Moreover, they are of great significance with regard to the establishment of a future aircraft smart grid. However, owing to its nonlinear, high-dimensional, and strong coupling characteristics, this modeling has always remained in the frequency domain stage and the progress of more intuitive time domain modeling has been slow. This paper presents a nonlinear model of a WRSSG in a generating state. When the WRSSG is in power generation mode, most cases indicate that the aircraft is in flight mode. The establishment of the nonlinear model of the system in the power generation state is of great significance for the research of the health management and state monitoring of the aircraft power system and can improve the safety and reliability of the aircraft during flight. The model uses FE analysis and neural network to solve the nonlinear problem of the motor in the system and uses the improved variable parameter average model to solve the nonlinear problem of the rotating rectifier. According to the principle of signal transmission, a time domain model for the whole system is developed. Finally, the model is compiled by the RT-LAB real-time simulator. The nonlinear model performs well when compared with FE analysis results and tested against the MIL-STD-704F standard. The proposed nonlinear model and analysis results can be used for the condition monitoring and fault diagnosis of aircraft power systems. The hardware-in-the-loop test platform based on an accurate nonlinear model is a feasible means to study the failure of expensive equipment, and it can aid the study of irreversible failures of equipment at a low cost. Full article

Traditional diesel generators on a merchant ship, composed of a wound rotor synchronous generator and a four-stroke diesel engine, supply electrical power for various loads. Recently, shaft generators for merchant ships have been increasingly replacing diesel generators to reduce CO₂ emissions through fuel efficiency improvement. In particular, permanent magnet synchronous generators have replaced induction generators due to their high-efficiency characteristics at light loads. The surface-mounted permanent magnet rotor can be a suitable topology owing to the relatively short constant power range. This generator can also operate as a motor according to the propulsion mode, so minimizing the harmonics of the induced voltage with the torque pulsation being essential. This paper proposes an alternative surface permanent magnet topology. Three magnets comprise one pole, with one bread-loaf magnet and two rectangular magnets. It helps to simplify the magnetization and assembly of the rotor because of the flat bottom shape of the magnet. Due to the low remanence of two rectangular magnets at the pole edge, this rotor structure effectively makes the air-gap magnetic flux density sinusoidal with production costs reduced. The step-skew suppresses higher-order harmonics. The total harmonic distortion comparison of the two-dimensional finite element analysis and the no-load test result shows under 6% difference from the interior permanent magnet prototype machine. A comparison of harmonic characteristics with other rotors shows that the proposed modular pole has sufficient competitiveness compared to the tapered bread-loaf type. It can be applied as a substitute for the tapered bread-loaf magnet in direct-drive ship propulsion systems and is expected to shorten the manufacturing process and time. Full article

This study analyzes the material deformation of electrical steel with aging and its effects on the electromagnetic and thermal characteristics of a Brushless Wound-Field Synchronous Generator (BL-WFSG). First, in order to confirm the material deformation of electrical steel applied to the BL-WFSG, magnetic property tests are performed on the core sheets of the old and new generators. Those two generators are made of the same material, so there was no difference except for their usage time. Based on the results of the magnetic property tests, an electromagnetic field analysis is performed on the old and new generators, and analysis results are compared in order to confirm the effects of material deformation on the electromagnetic characteristics of BL-WFSG. Then, a thermal analysis is performed on the old and new generators using losses calculated by electromagnetic field analysis as heat sources, and analysis results are compared in order to confirm the effects of material deformation on the thermal characteristics of BL-WFSG. Finally, an additional electromagnetic analysis is performed on both the old and new generators, using the exact winding resistances that were calculated in the thermal analysis for each respective generator in order to calculate and compare the efficiency of the old and new generators. Through this process, the authors confirmed the effects of material deformation of the rotor and stator cores due to aging on the electromagnetic and thermal characteristics of the BL-WFSG. Full article

In the search for efficient non-permanent magnet variable-speed wind generator solutions, this paper proposes a maximum power point tracking (MPPT) current-control method for a wound rotor synchronous wind generator. The focus is on direct-drive, medium-speed wind generators. In the proposed method, the currents of the wound rotor synchronous generator (WRSG) are optimally adjusted according to the generator speed to ensure maximum power generation from the wind turbine without needing information on wind speed. The design, modeling, and simulation of the MPPT current controllers are done in Matlab/Simulink with the WRSG in the synchronous reference frame. The controller is put to the test using different wind speed profiles between cut-in and rated speeds. The simulation results indicate that the proposed current control method is simple, effective, and robust, suggesting its practical implementation. To validate the simulation results, experimental work on a 4.2 kW WRSG prototype system is presented to demonstrate the stability and robustness of the MPPT current control method in operating the turbine at or near the maximum power point. Full article

This paper presents a new online method based on low frequency signal injection to estimate the stator resistance of a Wound Rotor Synchronous Machine (WRSM). The proposed estimator provides a parameter-free method for estimating the stator resistance, in which there is no need to know the values of the parameters of the machine model, such as the stator and rotor inductances or the rotor flux linkage. In this method, a low frequency sinusoidal current is injected in the d axis of the stator current to produce a sinusoidal flux in the stator. In this paper, it is shown that the phase difference between the generated sinusoidal flux and the injected sinusoidal current is related to the stator resistance mismatch. Using this phase difference, the stator resistance is estimated. To validate the proposed model-free estimator, simulations were performed with Matlab Simulink and the results were compared with the extended Kalman filter observer. Finally, experimental tests, under different conditions, were performed to estimate the stator resistance of a WRSM. Full article

This paper presents a topology for the brushless operation of a wound-rotor synchronous machine based on the subharmonic excitation technique by using two sets of multi-pole windings on the armature as well as on the rotor. The armature windings consist of a four-pole three-phase main winding and a two-pole single-phase additional winding, responsible for the generation of fundamental and subharmonic components of magnetomotive force (MMF), respectively. The rotor contains four-pole field winding and two-pole excitation winding. From the generated air gap MMF, the additional winding is responsible for induction in excitation winding, which feeds DC to the field winding through a rotating rectifier without the need of brushes. Then, the interaction of the magnetic field from the main and the field windings produces torque. The proposed topology is analyzed using 2D finite element analysis (FEM). From the analysis, the generation of the subharmonic component of MMF is verified, which helps in achieving the brushless operation of the wound-rotor synchronous machine. Furthermore, the performance of the proposed brushless multi-pole topology is compared with the existing dual three-phase winding multi-pole topology in terms of current due to induction, output torque, torque ripples, and efficiency. Full article

In recent years, electric vehicles have developed rapidly. However, many electric cars are equipped with permanent magnet synchronous motors. Permanent magnet synchronous motors have several disadvantages: For example, permanent magnets tend to demagnetize at high temperatures. Electrically excited synchronous motors have several excellent properties. First, they are cheaper because the stator and rotor of the motor only need to be wound, which is more affordable than permanent magnets for speed regulation. When the armature current reaches the maximum value, the excitation current can also be adjusted for speed regulation, which makes the speed regulation more flexible. In the case of a short circuit, the corresponding direct-axis current is smaller than the quadrature-axis current, so the fault tolerance is better. Since the traditional electric excitation motor has brushes and slips rings, sparks will be generated during commutation. Therefore, a new excitation method is adopted to make non-contact motor excitation, and the motor operation is safer and more environmentally friendly. At the same time, to ensure that the output power of the non-contact electric excitation motor remains stable, a step-down circuit and power-type fast discrete terminal sliding mode control are added after the full-bridge rectifier circuit to make the excitation current and voltage output of the motor more stable. That is, the output power reaches a steady production. In this paper, an improved sliding mode control algorithm is used to stabilize the output voltage of the non-contact excitation motor, which can still ensure the stable output of the voltage when the equivalent load changes. It is confirmed that the non-contact excitation motor can be applied to various complex situations, and the proposed algorithm is simulated and experimentally verified to verify the accuracy of the proposed algorithm. Full article

This paper proposes a new scheme for a brushless wound rotor synchronous machine (WRSM) by generating an additional, two-pole component of magneto-motive force (MMF) with a series-connected additional three-phase winding with the armature three-phase winding. Unlike existing brushless excitation schemes, which use the inverter to inject harmonic currents in the stator windings, the proposed scheme uses series-connected additional winding on the stator with the armature winding in a two-pole configuration. Consequently, as the current flows in the armature winding, it creates a fundamental rotating air gap flux to interact with the field flux. At the same time, additional rotating flux is created from the additional three-phase winding, which cannot synchronize with the field winding. This additional flux can cause the induction of a voltage in a winding with exactly the same number of poles. For this purpose, a harmonic winding is installed in the rotor along with the field winding connected through a diode bridge rectifier, in order to feed the direct current (DC) to the field winding for rotor excitation without an input current from the brush-slip-ring assembly. The 2D finite-element analysis (FEA) was performed to validate the brushless operation of the proposed machine system. Full article

This paper presents a nonlinear magnetic equivalent circuit method and an electromagnetic characteristic analysis and verification of a wound rotor synchronous generator (WRSG). The reluctance generated by the stator, rotor, and air gap is subdivided to form a reluctance construction. A nonlinear magnetic equivalent circuit (MEC) for the WRSG is constructed and solved by an iteration method. Moreover, to calculate the inductance of the generator, the reluctance circuit of the $d-q$axis is constructed, and the inductance of the generator is obtained using the initial relative permeability of the material. Using the electromagnetic parameters obtained via the MEC method, the power generation characteristics of the generator are predicted. The results of this MEC method are also verified by comparing them with the finite element analysis (FEA) results and experimental results. Full article

This paper presents a new high-efficient three-phase brushless wound rotor synchronous machine (BL-WRSM) based on a sub-harmonic field excitation technique. In the proposed machine topology, the stator is equipped with two different three-phase windings: (1) main armature winding, and (2) additional armature winding. The main armature winding is based on a 4-pole winding configuration, whereas the additional armature winding is based on a 2-pole winding configuration. Both windings are supplied current from two different inverters, i.e., inverter-1, inverter-2, and simultaneously. Inverter-1 provides the regular input current to the main armature winding, whereas inverter-2 provides a three-phase current of low magnitude to the 2-pole additional armature winding. This generates an additional sub-harmonic component of MMF in the airgap beside the fundamental MMF. On the other side, the rotor is equipped with (1) harmonic, and (2) field windings. These windings are electrically coupled via a rectifier. The fundamental component of MMF produces the main rotating magnetic field, whereas the sub-harmonic MMF gets induced in the harmonic winding to produce harmonic current. This current is rectified to give DC to the rotor field winding to attain brushless operation. To authenticate the operation and analyze its performance, the proposed BL-WRSM topology is supported using 2-D finite element analysis (FEA) in JMAG-Designer. Later on, the performance of the proposed brushless topology is compared with the customary BL-WRSM topology to verify its high efficiency, high output torque, low torque ripple, and low unbalanced radial force on the rotor. Full article
