Search Results (90)

In order to break through the difficulties with a very-low-frequency (VLF) miniaturized antenna with small power capacity and low radiation efficiency, this paper proposes a high-radiation-field-strength magnetic loop antenna based on a nanocrystalline alloy magnetic core. A high-permeability nanocrystalline toroidal core (μ_r = 50,000, B_s = 1.2 T) is used to optimize the thickness-to-diameter ratio (t = 0.08) and increase the effective permeability to 11,000. The Leeds wires, characterized by their substantial carrying capacity, are manufactured through a toroidal winding process. This method results in a 68% reduction in leakage compared to traditional radial winding techniques and enhances magnetic induction strength by a factor of 1.5. Additionally, this approach effectively minimizes losses, thereby facilitating support for kilowatt-level power inputs. A cascaded LC resonant network (resonant capacitance 2.3 μF) and ferrite balun transformer (power capacity 3.37 kW) realize a 20-times amplification of the input current. A series connection of a high-voltage isolation capacitor blocks DC bias noise, guaranteeing the stable transmission of 1200 W power, which is 6 times higher than the power capacity of traditional ring antenna. At 7.8 kHz frequency, the magnetic field strength at 120 m reaches 47.32 dBμA/m, and, if 0.16 pT is used as the threshold, the communication distance can reach 1446 m, which is significantly better than the traditional solution. This design marks the first instance of achieving kilowatt-class VLF effective radiation in a compact 51 cm-diameter magnetic loop antenna, offering a highly efficient solution for applications such as mine communication and geological exploration. Full article

The last few years have seen the introduction of new technologies in beekeeping, including RFID. Using readers and miniaturized tags, RFID systems work in the UHF frequency band, allowing reading distances to reach tens of centimeters. This work analyzes the propagation inside a full beehive, composed of 10 frames supported by a wooden structure. Each frame contains a layer of beeswax supported by metallic wires. The methodology employed involves measuring Received Signal Strength Indicator (RSSI) values and simulating the environment using CST Studio. The results show that tags located along the frame’s wires have more coverage than tags in the center positions, revealing coupling of the microtag antenna with the wire. Furthermore, obtaining coverage through simulations represents a more restrictive approach than through measurements. Frame selectivity is also observed, as most of the coverage is found within the three frames closest to the reader antenna. This result shows that RFID systems can find application in the identification and location of the queen bee in a hive. Full article

Wireless passive temperature sensors are essential in environments where wired connections are impractical, such as rotating machinery and harsh conditions. A key advantage of these sensors is their ability to operate without a local power source. This study employs the antenna backscattering method, which relies on the wireless interaction between the interrogator antenna and the sensor antenna’s resonant frequency, implemented in the far-field region to support long communication distances. To evaluate the impact of antenna shape on sensor performance, three microstrip patch antenna shapes—rectangular, circular, and equilateral triangular—were designed to operate in the fundamental mode at 2.4 GHz. These designs were simulated using HFSS in Ansys Electromagnetic Suite^® 2023 R1 (Ansys Inc., Canonsburg, PA, USA), fabricated on alumina substrates, and assessed for performance metrics, including communication distance and sensitivity. Results indicated that the equilateral triangular patch outperformed the others, achieving a maximum communication distance of 16.5 cm, a sensitivity of 0.129 MHz/°C over a temperature range of 25 °C to 500 °C, and a simulated gain of 5.84 dBi. These findings underscore the importance of antenna shape selection and optimization for robust, wireless temperature sensing in demanding environments. Full article

Communication with the underwater vehicles during their tasks is one of the most important issues. The need for real-time data transfer raises the necessity of developing communication systems. Conventional underwater communication systems, such as acoustic systems, cannot satisfy applications that need a high transmission data rate. In this study, we investigate the radio frequency communication system in seawater, which is crucial for real-time data transfer with underwater vehicles. The experiments were in a water tank full of seawater and a real environment in the ocean. Three types of antennae were used: loop antenna, wire antenna, and helical antenna. An Autonomous Underwater Vehicle (AUV) is used as a transmitter to measure the transmission rate as a function of distance. The helical antenna showed better performance regarding the coverage area. Furthermore, the AUV could move freely within the helical and capture live video streaming successfully. This investigation underscores the potential of radio frequency communication systems for enhancing underwater vehicle operations, offering promising avenues for future research and practical implementation. Full article

In order to ensure the safety and preserve the value of historical buildings, inclination is an essential parameter during the continuous structural health monitoring process. However, the wire and price of a traditional sensor limit application. This paper proposes a low-cost inclination sensor based on a patch antenna with a reconfigurable water load. Only the water directly on the antenna is considered effective. The different volume of the effective water load, which is determined by the inclination of the attached surface, will affect the effective permittivity of the dielectric plate of the patch antenna, further causing a variation in the resonant frequency. Therefore, the proposed antenna sensor can monitor the inclination of the attached surface by interrogating the resonant frequency. The working mechanism is first clarified by theoretically investigating the relationship between the dielectric properties and the inclination of the covering medium. The antenna sensor is then simulated using High-Frequency Structure Simulator ver.15 (HFSS 15), which helps to determine geometric parameters and confirm accuracy and sensitivity. An experiment has been conducted based on the design verified in the simulation. The inclination detection shows a correlation coefficient of 0.9771 with a sensitivity of 7.92 MHz/°, indicating a potential for real application. Full article

This paper presents the latest developments regarding the single-feed Quality Wideband Linear (QWL) wire array antenna, known for its broadband and high-gain electromagnetic characteristics and robust design. A systematic review of recent advances in relation to the QWL antenna is provided, covering its driven element, director, reflector, low common-mode current interference connector, and array series-feed configuration. For the first time, an analytical expression and a quick design formula for the input impedance of the QWL antenna’s driven element, the linear Wideband High-gain Electromagnetic Structure (WHEMS) antenna, are presented. Theoretical analysis demonstrates the potential for broadband performance using the WHEMS antenna. The rugged design of the QWL array antenna offers engineering advantages such as simple feeding, low wind resistance, a lightweight construction, low cost, and structural robustness. The QWL antenna has already found applications in various industrial sectors, with potential for broader use in the future, contributing to further advancements in antenna technology. Full article

Proper prediction of the temperature variation in a metallic wire mesh for spaceborne large deployable reflector antennas is essential for evaluating the dimensional stability of the antenna under extreme on-orbit thermal environments. However, predicting the temperature of a mesh is difficult because of its complex yarn configuration. To analyze the thermal behavior of the spaceborne mesh antenna reflector, the thermal optical characteristics with various knitting methods of the metallic mesh were obtained experimentally in this study. Subsequently, to analyze the thermal sensitivity of the reflector based on its optical properties, an on-orbit thermal analysis of the mesh reflector was performed based on measurements of the mesh specimen. We also investigated the influence of deployable solar panels on the thermal gradient of the reflector. Full article

This paper describes the design and experimental verification of a 6 m parabolic deployable mesh reflector antenna mechanism based on a superelastic shape memory alloy. This antenna mainly consists of a deployable primary reflector with a superelastic shape memory alloy-based hinge mechanism and a fixed-type secondary reflector mast, where a rotary-type holding and release mechanism and deployment speed control system are installed. The main feature of this antenna is the application of a superelastic shape memory alloy to the mechanism, which has the advantages of plastic deformation resistance, high damping, and fatigue resistance. A shape memory alloy is applied to the hinge mechanism of each primary reflector rib and to the rotary-type holding and release mechanism as a deployment mechanism. In addition, a superelastic shape memory alloy wire is applied to the antenna in the circumferential direction to maintain the curvature of the primary reflector. The effectiveness of the proposed mechanism design was verified through repeated deployment tests on models of the superelastic shape memory alloy-based hinge mechanism and the antenna system. Full article

Achieving negative surgical margins, defined as no tumor found on the edges of the resected tissue, during lumpectomy for breast cancer is critical for mitigating the risk of local recurrence. To identify nonpalpable tumors that cannot be felt, pre-operative placements of wire and wire-free localization devices are typically employed. Wire-free localization approaches have significant practical advantages over wired techniques. In this study, we introduce an innovative localization system comprising a light-emitting diode (LED)-based implantable device and handheld system. The device, which is needle injectable and wire free, utilizes multiple wirelessly powered LEDs to provide direct visual guidance for lumpectomy. Two distinct colors, red and blue, provide a clear indication of tissue depth: blue light is absorbed strongly in tissue, visible within a close range of <1 cm, while red light remains visible through several centimeters of tissue. The LEDs, integrated with an impedance-matching circuit and receiver coil, are encapsulated in biocompatible epoxy for injection with a 12 G needle. Our findings demonstrate that the implant exhibits clearly perceivable depth-dependent color changes and remains visible through >2 cm of ex vivo chicken breast and bovine muscle tissue using less than 4 W of transmitted power from a handheld antenna. These miniaturized needle-injectable localization devices show promise for improving surgical guidance of nonpalpable breast tumors. Full article

Integration of Radio Frequency Identification (RFID) technology with conductive textiles has greatly expanded the possibilities for creating smart devices that fit perfectly into the concept of the Internet of Things. The use of e-textiles for antenna manufacturing has enabled the development of a textronic RFID tag. Integration of such tags into products with often non-flat surfaces may result in exposure to changes in antenna geometry caused by bending. As a result, the antenna parameters may change, resulting in disruption of the entire tag operation. The authors, through simulation and experimental studies, analyzed the effects of bending the antennas of RFID tags operating in the HF (High Frequency) band. Full article

The simulation of microwave absorption and external thermal flow is an essential aspect of the vacuum thermal testing process for Synthetic Aperture Radar (SAR) antenna. This paper proposes a novel integrated method for simulating microwave absorption and external thermal flow, specifically designed for vacuum thermal testing. The method employs a non-woven fabric square pyramid assembly as the primary structure to establish a low electromagnetic scattering environment. External heat flow simulation is achieved by arranging carbon fiber heating wires between square cones. Through numerical analysis and experimental tests, the influence of the position of the carbon fiber heating wire on the uniformity of heat flow and reflectivity was revealed. A prototype system is developed based on these findings. The external thermal flow is adjustable in the range of 80–550 W/m², with a uniformity better than 5%. The reflectivity in the L to X microwave frequency band is basically better than −25 dB, and in local frequency bands, it is better than −30 dB. The system has been successfully applied in SAR antenna component and satellite vacuum thermal tests, meeting all ground simulation test requirements and exhibiting significant potential for widespread application. Full article

This paper addresses the increasing demand for computing power and the challenges associated with adding more core units to a computer processor. It explores the utilization of System-on-Chip (SoC) technology, which integrates Terahertz (THz) wave communication capabilities for intra- and inter-chip communication, using the concept of Wireless Network-on-Chips (WNoCs). Various types of network topologies are discussed, along with the disadvantages of wired networks. We explore the idea of applying wireless connections among cores and across the chip. Additionally, we describe the WNoC architecture, the flip-chip package, and the THz antenna. Electromagnetic fields are analyzed using a full-wave simulation software, Ansys High Frequency Structure Simulator (HFSS). The simulation is conducted with dipole and zigzag antennas communicating within the chip at resonant frequencies of 446 GHz and 462.5 GHz, with transmission coefficients of around −28 dB and −33 to −41 dB, respectively. Transmission coefficient characterization, path loss analysis, a study of electric field distribution, and a basic link budget for transmission are provided. Furthermore, the feasibility of calculated transmission power is validated in cases of high insertion loss, ensuring that the achieved energy expenditure is less than 1 pJ/bit. Finally, employing a similar setup, we study intra-chip communication using the same antennas. Simulation results indicate that the zigzag antenna exhibits a higher electric field magnitude compared with the dipole antenna across the simulated chip structure. We conclude that transmission occurs through reflection from the ground plane of a printed circuit board (PCB), as evidenced by the electric field distribution. Full article

Partial discharge (PD) is the dominant insulating defect in Gas-Insulated Switchgear (GIS). The existing detection methods are mainly divided into built-in wire-connected disk antennas with destructive drilling and external ultra-high frequency antennas with poor anti-interference ability. This research introduces a passive wireless PD sensor implanted inside GIS on the observation window. The sensor is implemented by a sheeting branch-inductor with multiple resonances which is able to enhance detection sensitivity. A coaxially aligned readout circuit, positioned outside the GIS, interrogates the PD sensor to wirelessly obtain the PD signal. The proposed sensing scheme improves signal-to-noise ratio and ensures minimal disruption to the electric field distribution inside GIS. An experimental setup was established in a controlled laboratory environment to benchmark the multi-resonant sensor against the commercial UHF sensor. A 2.5-times enhancement of signal strength was observed. Since our sensor was implanted inside the GIS, a high signal-to-noise ratio (68.82 dB) was obtained. Moreover, we constructed a wireless calibration test to investigate the accuracy of the proposed sensor. The precision of the signal test was as high as 0.72 pC. The pulse phase distribution information was collected to demonstrate a phase-resolved partial discharge (PRPD) pattern. The experiment results validate the effectiveness of the proposed method and demonstrate excellent performance in PD detection. Full article

The dimensional accuracy and microstructure affect the service performance of parts fabricated by wire arc additive manufacturing (WAAM). Regulating the geometry and microstructure of such parts presents a challenge. The coupling method of an artificial neural network and finite element (FE) is proposed in this research for this purpose. Back-propagating neural networks (BPNN) based on optimization algorithms were established to predict the bead width (BW) and height (BH) of the deposited layers. Then, the bead geometry was modeled based on the predicted dimension, and 3D FE heat transfer simulation was performed to investigate the evolution of temperature and microstructure. The results showed that the errors in BW and BH were less than 6%, and the beetle antenna search BPNN model had the highest prediction accuracy compared to the other models. The simulated melt pool error was less than 5% with the experimental results. The decrease in the ratio of the temperature gradient and solidification rate induced the transition of solidified grains from cellular crystals to columnar dendrites and then to equiaxed dendrites. Accelerating the cooling rate increased the primary dendrite arm spacing and δ-ferrite content. These results indicate that the coupling model provides a pathway for regulating the dimensions and microstructures of manufactured parts. Full article

In this study, we developed a novel wireless, passive pressure-sensing method functional at cryogenic temperatures (−196 °C). The currently used pressure sensors are inconvenient and complicated in cryogenic environments for their weak low-temperature tolerances and long wires for power supply and data transmission. We propose a novel pressure-sensing method for cryogenic applications by only using low-temperature-tolerant passive devices. By innovatively integrating a magnetoresistor (MR) on a backscattering antenna, the pressure inside a cryogenic environment is transferred to a wirelessly obtainable return loss. Wireless passive measurement is thus achieved using a backscattering method. In the measurement, the pressure causes a relative displacement between the MR and a magnet. The MR’s resistance changes with the varied magnetic field, thus modulating the antenna’s return loss. The experimental results indicate that our fabricated sensor successfully identified different pressures, with high sensitivities of 4.3 dB/MPa at room temperature (24 °C) and 1.3 dB/MPa at cryogenic temperature (−196 °C). Additionally, our method allows for simultaneous wireless readings of multi sensors via a single reading device by separating the frequency band of each sensor. Our method performs low-cost, simple, robust, passive, and wireless pressure measurement at −196 °C; thus, it is desirable for cryogenic applications. Full article
