Search Results (46)

Thermocouples can be combined into thermopiles to sense heat differences or achieve localized heating and cooling. However, integrating them into textiles using yarns is not straightforward, and chemical methods face challenges like complex processing, poor scalability, and voltage non-uniformity. This study employs conventional weaving to fabricate textile-based thermocouples and thermopiles for wearable sensing and potential cooling applications, with a focus on protective clothing. Using stainless steel and nickel-coated carbon yarns, we demonstrate a more stable thermocouple than those made with chemical or welded methods, with minimal fabric damage. Four conductive yarns, stainless steel, carbon fiber (CF), and nickel-coated carbon fiber (NiFC), were woven and laser-cut to form thermocouples using three different binding types to connect them. Inox1–NiFC was the most efficient thermocouple, achieving the highest Seebeck coefficient of 21.87 µV/K with Binding 3. Binding 3 also reduced contact resistance by 66% across all configurations. Slightly lower but comparable performance was seen with Inox1–NiFC/Binding 2 (21.83 µV/K) and Inox2–NiFC/Binding 1 (15.79 µV/K). In contrast, FC-based thermocouples showed significantly lower Seebeck values: 5.67 µV/K (Inox2–FC/Binding 2), 5.43 µV/K (Inox1–FC/Binding 3), and 5.06 µV/K (Inox2–FC/Binding 1). A woven thermopile with three junctions made with the optimal binding and thermocouple combination generated an average of 55.54 µV/K and about 500 µV at small temperature differences (4–5 °C), with a linear voltage response suitable for sensing. While thermal sensing proved effective, Peltier cooling needs further optimization. This method offers a stable, low-cost, and scalable platform for textile-integrated thermoelectric systems, with strong potential for use in uniforms and other protective garments. Full article

This paper delves incto the tungsten inert gas (TIG) welding process, renowned for its efficacy in creating robust metal joints and widely employed in diverse industries for fusing similar or dissimilar materials. The focus of this study is the welding of mild steel with stainless steel, showcasing the method’s ability to amalgamate exceptionally sturdy metals and alloys. The resultant welded joints exhibit a meticulously refined microstructure and an impressive strength-to-weight ratio. The primary aim is to scrutinize TIG-welded joints, specifically those connecting mild steel with stainless steel, to elucidate their metallurgical and mechanical attributes. Notably, joints formed between distinct materials, such as mild steel and stainless steel, manifest commendable mechanical and metallurgical properties. This paper extensively investigates the metallurgical microstructures and tensile characteristics of both comparable and dissimilar metal junctions, contributing valuable insights to the field. Full article

The two-tank molten salt thermal storage system is the most common storage solution in concentrated solar power (CSP) plants. Solar salt (60% NaNO₃ + 40% KNO₃) is the most widely used energy storage material in solar thermal plants. In solar tower technology, where the molten salts must operate at temperatures ranging from 290 °C to 565 °C, several issues related to tank failures have emerged in recent years, with some of these failures attributed to the welding process. The welding process of joints in 316L stainless steel (ASS) probes exposed to a moving flow of a binary mixture containing 60% NaNO₃ and 40% KNO₃ (solar salt) is analysed. The results were evaluated using scanning electron microscopy (SEM) at 120, 500, 1000, 1500, and 2300 h of exposure. It was identified that arc mechanical oscillations significantly improve the microstructural properties and geometrical characteristics of welded joints, reducing structural defects and improving corrosion resistance. The technique promotes uniform thermal distribution, refined dendrite morphology, and homogeneous alloying element distribution, resulting in lower mass loss in high-temperature molten salt environments. Additionally, oscillation welding optimises the bead geometry, with reduced wetting angles and controlled penetration, making it ideal for high-precision industrial applications and extreme environments, such as molten salt thermal storage systems. Full article

C-type thermocouples are widely used to measure rich combustions; however, the measured temperature, i.e., the thermocouple junction temperature, is not equal to the gas temperature. The junction temperature results from the junction energy balance, including radiation with environments, conduction with thermocouple wires, and convection with gas. A correction based on the junction energy conservation can derive the gas temperature from the measured temperature. Two C-type thermocouples are used to measure the core region of the standard flames with known gas velocity, composition, and temperature. By matching the CFD-simulated junction temperature with the measured temperature, the emissivity of the thermocouples is obtained. In the temperature range of 1190–1542 K, the emissivity of both thermocouples is close to 0.4. Since the junctions of the C-type thermocouple are large, the area ratios of the wire cross-section to the junction surface are small, and the wire conduction effect is minimal. CFD simulations show that the junction temperatures only decrease by 3.9 K and 8.1 K without wire conduction when the 0.5 mm and 1.0 mm thermocouples measure the Hencken flame with the temperature of 2023.5 K. With the CFD simulation of the measurement of the diffusion region of the Hencken flame, where a strong gas temperature gradient exists, the junction contacting status is judged for the 0.5 mm thermocouple. The simulated temperature of the welding point is consistent with the measured temperature, indicating no wire contact inside the junction. Full article

The welded pipeline structure of aircraft fuel is a complex and diverse entity, significantly influenced by fluid–solid coupling. The refined aviation fuel-welded pipeline model plays a pivotal role in the investigation of its fluid–solid coupling mechanical properties. However, the mechanical analyses of pipelines with welded structures frequently simplify or ignore the influence of the weld zone (WZ). Consequently, these analyses fail to reveal the complex interactions between different weld zones in detail. In this study, a comprehensive and precise fuel-welded pipeline refinement model is developed through the acquisition of microstructural dimensions and mechanical parameters of the weld zone via metallographic inspection and microtensile testing. Additionally, the influence of clamps and brackets under airborne conditions is fully considered. Furthermore, the numerical simulation results are compared and verified using modal and random vibration tests. This paper addresses the impact of diverse fluid characteristics on the velocity field, pressure field, and stress in disparate areas, and it also conducts an investigation into the random vibration characteristics of the pipeline. The results demonstrate that the fluid pressure and velocity exert a considerable influence on the fluid flow state and structural stress distribution within the pipeline. An increase in flow velocity and alteration to the pipeline geometry will result in a change to the local velocity distribution, which in turn affects the distribution of the fluid pressure field. The highest stresses are observed in the weld zone, particularly at the junction between the weld zone and the heat-affected zone (HAZ). In contrast, the stresses in the bend region exhibit a corrugated distribution in both the axial and circumferential directions. An increase in fluid pressure has a significant impact on the natural frequency of the pipeline. This study enhances our comprehension of the mechanical properties of aircraft fuel lines with fluid–solid coupling and provides a foundation and guidance for the optimal design of fuel-welded lines. Full article

Steel traditional Chinese buildings (STCBs) are constructed using modern materials, replicating the esthetics of ancient Chinese buildings, but their irregular joints differ significantly from those in conventional steel structures. To investigate the influence of beam section shape and axial compression ratio on the failure mode and shear resistance of all-welded irregular joints (WIJs) in STCBs, the size proportion relationships in the traditional Chinese modular construction system for such joints in existing practical projects are analyzed. Four exterior joint specimens were designed and fabricated for pseudo-static loading tests. The failure mode, hysteresis curve, and skeleton curve of the specimens were obtained. The test results indicate that the failure mode of the specimens involves shear deformation in the lower core area, with final failure due to crack formation in the weld at the junction between the column wall and the beam flange. As the axial compression ratio increases, the bearing capacity of the joint decreases. Based on the test results, the numerical model was established by using finite element software Abaqus2016, and parameter analysis was performed by varying the axial compression ratio of the column. After analyzing the force transfer mechanism of the core area in the WIJs of STCBs, a simplified calculation formula for the shear bearing capacity of the core area was derived based on the proportional relationship outlined in the construction manual from the Song Dynasty. The calculated results show good agreement with the experimental results, providing a basis for the structural design of WIJs in STCBs. Full article

As a critical component of rocket systems, the grid fin is widely applied in the aerospace industry. Compared to traditional manufacturing methods and other additive manufacturing (AM) techniques, wire arc additive manufacturing (WAAM) is more advantageous in its time and cost efficiency, especially when it is utilized in the large-scale production of components. Given the significant effect of the welding strategies on the quality of manufactured parts, we investigated two distinct WAAM printing orientations, horizontal, or lie (L), and perpendicular, or stand (S), using a small-scale model. The feasibility of these two printing approaches was evaluated by analyzing the surface quality, microstructure, and mechanical properties at the junctions of the grid fin. Furthermore, a finite element analysis (FEA) was adopted to simulate and analyze the main factors, including the temperature distribution, deformation, and stress profiles at the welding joints, in both AM strategies. The integrated approach adopted in this study provides important insights for optimizing the application of WAAM in grid fin manufacturing. In summary, our results indicate that while the L mode is easily manufacturable and exhibits stable properties, the S mode holds significant market potential if its welding parameters are optimized. Full article

The microstructure and residual mechanical properties of several groups of T92/Super304H dissimilar steel welded joints (hereinafter referred to as welded joints) in service for 70,000~85,000 h were analyzed. The results show that the early service history of the welded joint results in the polygonization of the martensite lath and the coarsening of the precipitated phase on the side of T92 steel. In the further creep process, the cavities nucleate along the precipitated phase interface and the triple junction grain boundary. Under the same load, the creep life of the joint decreases rapidly with the increase in service time and, finally, type IV cracking occurs. Type IV cracking needs to meet two conditions: 1. a large degree of precipitated phase coarsening and cavity nucleation in the fine grain heat-affected zone (FGHAZ) and 2. a much lower loading stress than the yield strength. Full article

A solid-state repair technique based on surface friction welding is investigated in depth to achieve excellent mechanical properties of damaged 7A52 aluminum alloy. The results show that the yield strength and tensile strength along the repair direction are 436 MPa and 502 MPa, respectively, at a rotational speed of 1400 rpm and a travel speed of 300 mm/min, which are about 157.9% and 129.7% of those before the defects were repaired, respectively, while the elongation is 17.2% compared to the base material. Perpendicular to the repair direction, the yield strength and tensile strength are 254 MPa and 432 MPa, which are 111.4% and 129.7% of those before the defects were repaired, respectively, while the elongation is 11.8% compared to the base material. The mechanical properties of the repaired areas are still improved compared to those of the defect-free sheets. On the one hand, this is attributed to the dynamic recrystallization of the nugget zone due to the thermo-mechanical coupling, resulting in the formation of a fine, equiaxed grain structure; on the other hand, the precipitated Mg₂Si phase, which is incoherent within the base material, transforms into the Al₁₂(Fe, Mn)₃Si phase, as well as the precipitation of the Al₆Mn phase and η′ phase, resulting in the enhancement of the properties. The material fracture at the junction of the nugget zone and the heat-affected zone occurs after repair, which is attributed to the significant difference in the texture of the nugget zone and the heat-affected zone, as well as to the stress concentration at the junction. Full article

The study of materials for space exploration is one of the most interesting targets of international space agencies. An essential tool for realizing light junctions is epoxy adhesive (EA), which provides an elastic and robust material with a complex mesh of polymeric chains and crosslinks. In this work, a study of the structural and chemical modification of a commercial two-part flexible EA (3M™ Scotch-Weld™ EC-2216 B/A Gray), induced by ⁶⁰Co gamma radiation, is presented. Combining different spectroscopic techniques, such as the spectroscopic Fourier transform infrared spectroscopy (FTIR), the THz time-domain spectroscopy (TDS), and the electron paramagnetic resonance (EPR), a characterization of the EA response in different regions of the electromagnetic spectrum is performed, providing valuable information about the structural and chemical properties of the polymers before and after irradiation. A simultaneous dissociation of polymeric chain and crosslinking formation is observed.The polymer is not subject to structural modification at an absorbed dose of 10 kGy, in which only transient free radicals are observed. Differently, between 100 and 500 kGy, a gradual chemical degradation of the samples is observed together with a broad and long-living EPR signal appearance. This study also provides a microscopic characterization of the material useful for the mechanism evaluation of system degradation. Full article

In this study, an upper sheet of an A6061 aluminum alloy and a lower sheet of Q235 steel were welded by resistance element welding with a steel rivet. The temperature field during welding was calculated using ABAQUS numerical simulation software, and the interfacial microstructure was observed. A nugget was formed between the rivet shank and the lower sheet. With increases in welding current and welding time, the tensile shear load of the joint increased first and then decreased slightly. When the welding current was 14 kA and the welding time was 300 ms, the tensile shear load of the joint reached a maximum of 7.93 kN. The smaller the distance from the position to the lower sheet along the interface between the rivet shank and upper sheet, the longer the high-temperature duration and the higher the peak temperature during welding. At the junction of the rivet shank, upper sheet, and lower sheet in the joint, the high-temperature duration was the longest, at about 392 ms, and the peak temperature was the highest, at about 1237 °C. The results show that the smaller the distance from the position to the lower sheet along the interface between the rivet shank and the upper sheet in the joint, the thicker the reaction layer generated there, and that the thickness of the reaction layer was about 2.0 μm at the junction of the rivet shank, upper sheet, and lower sheet in the joint. Full article

Q690 steel is widely used as building steel due to its excellent performance. In this paper, the microstructure evolution of the heat-affected zone of Q690 steel under simulated high heat input welding conditions was investigated. The results show that under the heat input of 150–300 kJ/cm, the microstructures of the heat-affected zone are lath bainite and granular bainite. The content of lath bainite gradually decreased with the increase in heat input, while the content of granular bainite steadily increased. The proportion of large-angle grain boundaries decreased from 51.1% to 40.3%. Overall, the average size of original austenite increased, and the precipitates changed from Ti (C, N) to Cr carbides. During the cooling process, the nucleation position of bainitic ferrite was from high to low according to the nucleation temperature, and in order of inclusions at grain boundaries, triple junctions, intragranular inclusions, bainitic ferrite/austenite phase boundaries, twin boundaries, grain boundaries, and intragranular inclusions at the bainitic ferrite/austenite phase interface. The growth rate of bainitic ferrite nucleated at the phase interface, grain boundary, and other plane defects was faster, while it was slow at the inclusions. Moreover, it was noted that the Mg-Al-Ti-O composite inclusions promote the nucleation of lath bainitic ferrite, while the Al-Ca-O inclusions do not facilitate the nucleation of bainitic ferrite. Full article

The need to modify removable partial dentures equipped with a metal framework in order to add other prosthetic teeth to replace natural teeth lost by the patient could lead to laboratory procedures so complex as to require the creation of new prostheses with a heavy economic burden. The creation of preformed metal pins to be welded using the economical TIG cold welding method could represent a valid alternative solution with the aim of modifying the prostheses using a reinforced resin capable of adequately resisting masticatory loads. This study evaluates and compares the mechanical robustness and the clinical reliability of these modified prostheses in cases of junctions of one or two contiguous prosthetic teeth. The 6-month follow-up demonstrated the total validity of the method via the absence of significant breakages or detachments in all of the patients analyzed; on the other hand, the prostheses modified using the traditional method and used as controls showed a high incidence of fractures. Full article

To enhance the conductivity of a silver nanowire (Ag NW) network, a facile solvent welding method was developed. Soaking a Ag NW network in ethylene glycol (EG) or alcohol for less than 15 min decreased the resistance about 70%. Further combined solvent processing via a plasmonic welding approach decreased the resistance about 85%. This was achieved by simply exposing the EG-soaked Ag NW network to a low-power blue light (60 mW/cm²). Research results suggest that poly(vinylpyrrolidone) (PVP) dissolution by solvent brings nanowires into closer contact, and this reduced gap distance between nanowires enhances the plasmonic welding effect, hence further decreasing resistance. Aside from this dual combination of methods, a triple combination with Joule heating welding induced by applying a current to the Ag NW network decreased the resistance about 96%. Although conductivity was significantly enhanced, our results showed that the melting at Ag NW junctions was relatively negligible, which indicates that the enhancement in conductivity could be attributed to the removal of PVP layers. Moreover, the approaches were quite gentle so any potential damage to Ag NWs or polymer substrates by overheating (e.g., excessive Joule heating) was avoided entirely, making the approaches suitable for application in devices using heat-sensitive materials. Full article

Micro-injection molding (µIM) is a widespread process for the production of plastic parts with at least one dimension, or feature, in the microscale (conventionally below 500 µm). Despite injection molding being recognized as a robust process for obtaining parts with high geometry accuracy, one last occurrence remains a challenge in micro-injection molding, especially when junctions are present on the parts: the so-called weld lines. As weld lines are crucial in determining mechanical part performances, it is mandatory to clarify weld line position and characteristics, especially at the industrial scale during mold design, to limit failure causes. Many works deal with weld lines and their dependence on processing parameters for conventional injection molding, but only a few works focus on the weld line in µIM. This work examines the influence of mold temperature on the weld line position and strength by both experimental and simulation approaches in µIM. At mold temperatures below 100 °C, only short shots were obtained in the chosen cavity. At increased mold temperatures, weld lines show up to a 40% decrease in the whole length, and the overall tensile modulus doubles. This finding can be attributed to the reduction of the orientation at the weld line location favored by high mold temperatures. Moldflow simulations consistently reproduce the main features of the process, weld line position and length. The discrepancy between experimental and simulated results was attributed to the fact that crystallization in flow conditions was not accounted for in the model. Full article
