Search Results (40)

Control valves in nuclear systems operate under high-pressure differentials generating intense transient fluid forces that induce destructive structural vibrations, risking resonance and the valve stem fracture. In this study, computational fluid dynamics (CFD) was employed to characterize the internal flow dynamics of the valve, supported by experiment validation of the fluid model. To account for nonlinear structural effects such as contact and damping, a coupled fluid–structure interaction approach incorporating nonlinear perturbation analysis was applied to evaluate the dynamic response of the valve core assembly under fluid excitation. The results indicate that flow separation, re-circulation, and vortex shedding within the throttling region are primary contributors to structural vibrations. A comparative analysis of stability coefficients, modal damping ratios, and logarithmic decrements under different valve openings revealed that the valve core assembly remains relatively stable overall. However, critical stability risks were identified in the lower-order modal frequency range at 50% and 70% openings. Notably, at a 70% opening, the first-order modal frequency of the valve core assembly closely aligns with the frequency of fluid excitation, indicating a potential for critical resonance. This research provides important insights for evaluating and enhancing the vibration stability and operational safety of control valves under complex flow conditions. Full article

Predicting the roll damping coefficient of a ship is a crucial factor in determining the dynamic stability of the vessel. However, a nonlinear analysis that considers the viscosity of the fluid is required to accurately estimate the roll damping coefficient. This study numerically analyzed the hydrodynamic coefficients related to the roll motion of ships, focusing on the eddy-making damping coefficient. A series of forced vibration tests were conducted on a two-dimensional triangular cylinder floating on the water surface. The overset method and the volume-of-fluid method were applied, and the governing equations were solved using the open-source software OpenFOAM v2106. Uncertainties in the grid size and time intervals were identified through the International Towing Tank Conference (ITTC) procedure, and the obtained hydrodynamic coefficients were compared with available experimental data and potential flow results. Additionally, eddy-making damping was extracted from the shed vortex for various excitation frequencies and amplitudes. The study found that the uncertainty in the roll damping coefficient was less than 8%, with eddy-making damping being the dominant factor influencing the results. Numerical results showed a good agreement with experimental data, with an average deviation of 4.4%, highlighting the importance of considering nonlinear effects at higher excitation amplitudes. Comparison with experimental data and empirical formulas revealed that the nonlinearity due to the excitation amplitude must be considered in empirical formulations. Full article

This study conducted numerical simulations of three-dimensional vortex-induced vibrations (VIV) on cylindrical bodies with various surface protrusion coverage rates, systematically investigating the impact of coverage and protrusion height on the vibrational response of flexible cylinders. The fluid forces on the surface of the riser were resolved using the finite volume method, while the structural forces were solved with the finite element method. A strongly coupled approach was employed for iterative updates between the flow field and structural field data, achieving a bidirectional flow–structure coupling simulation of VIV in a marine environment. The study further explored the performance of surface protrusions in suppressing VIV and considered protrusion heights of 0.1 times the cylinder diameter (0.1D) under coverage rates (CR) of 0%, 10%, 20%, 30%, and 40%, as well as seven different protrusion heights of 0.05D, 0.1D, and 0.15D at a 20% coverage rate. The mechanism of VIV suppression by surface protrusions was identified as altering the separation point of the shear layer and the frequency of vortex shedding through the vortices formed between the surface protrusions. It was found that a 20% coverage rate with a protrusion height of 0.01D (CR20) effectively suppressed the VIV of the cylinder, showing the best performance in VIV suppression, with an efficiency of 30.04%. These results provide a theoretical basis for designing more efficient VIV suppression devices and contribute to enhancing the resistance of marine structures against vortex-induced vibrations. Full article

Due to the effects of swing motion, the performances and internal flow characteristics of marine centrifugal pump undergo some unsteady variations in the marine environment. The hydraulic test system with six degree of freedom parallel motion platform is established to study the pump performance characteristics at the different heel angles of steady roll position and pitch position. The pump head gradually decreases as heel angle increases. The pump head has decreased by 7% to reach the minimum at the 15° heel angle of roll position. At the same heel angle, the head at the roll position is lower than that at the pitch position under the rated flow condition. The fluid in the impeller passage is subjected to the additional inertial force of roll motion or pitch motion under unsteady swing motion, inducing some flow bias phenomena in the velocity field. The unsteady development of flow velocity induces the intense vortex motion, and the shedding and dissipation of interblade vortices are affected. The periodic flow-induced pulsation characteristics obviously appear in the impeller passage. The pulsation periodicity and pressure amplitude are influenced due to the swing motion. The pitch motion induces the greater hydraulic excitation and fluid-induced vibration amplitude. In addition to the pressure pulsation at the low frequencies, the pulsation amplitude at 20 times the shaft frequency is evident under pitch motion. Full article

The low specific speed centrifugal pump plays a crucial role in industrial applications, and ensuring its efficient and stable operation is extremely important for the safety of the whole system. The pump must operate with an extremely high head, an extremely low flow rate, and a very fast speed. The internal flow structure is complex and there is a strong interaction between dynamic and static components; consequently, the hydraulic excitation force produced becomes a significant factor that triggers abnormal vibrations in the pump. Therefore, this study focuses on a low specific speed centrifugal pump and uses a single-stage model pump to conduct PIV and pressure pulsation tests. The findings reveal that the PIV tests successfully captured the typical jet-wake structure at the outlet of the impeller, as well as the flow separation structure at the leading edge of the guide vanes and the suction surface. On the left side of the discharge pipe, large-scale flow separation and reverse flow happen as a result of the flow-through effect, producing a strong vortex zone. The flow field on the left side of the pressure chamber is relatively uniform, and the low-speed region on the suction surface of the guide vanes is reduced due to the reverse flow. The results of the pressure pulsation test showed that the energy of pressure pulsation in the flow passage of the guide vane occurs at the f_BPF and its harmonics, and the interaction between the rotor and stator is significant. Under the same operating condition, the RMS value distribution and amplitude at f_BPF of each measurement point are asymmetric in the circumferential direction. The amplitude of f_BPF near the discharge pipe is lower, while the RMS value is higher. A complex flow structure is shown by the larger amplitude and RMS value of the f_BPF on the left side of the pressure chamber. With the flow rate increasing, the energy at f_BPF of each measurement point increases first and then decreases, while the RMS value decreases, indicating a more uniform flow field inside the pump. Full article

Pipeline maintenance technology based on pipeline intelligent plugging robot (PIPR) has become an effective method for failure accident prevention of high-pressure subsea oil and gas pipelines. However, during the plugging operation, the vortexes and pressure fluctuation are presented under turbulent flow field excitation, which may lead to vortex-induced vibration and failure of the plugging operation. Therefore, in order to ensure the reliability of pipeline plugging, the vibration characteristics are analyzed using numerical simulation, providing guidance on the structural optimization of PIPR’s end face. Firstly, the flow field characteristics under different PIPR’s end faces are investigated. Secondly, an experimental scheme is designed based on Latin Hypercube Sampling Design (LHSD) optimized by greedy strategy. A mathematical model of the end face’s parameters and pressure gradient is established using a back propagation (BP) neural network. Then, an improved whale optimization algorithm (IWOA) is proposed to optimize the end face’s parameters to minimize the pressure gradient of the flow field. Finally, the experimental study is performed to observe the turbulent flow field and pressure fluctuation to validate the optimization results. The results demonstrate that the PIPR’s end face has a great influence on the vortex-induced vibration response. After structural optimization, the average pressure gradient of the optimal PIPR’s end face has decreased by 84.69% and 54.55% before and after the plugging process, compared to the original end face. This study can provide a reference for pipeline plugging operations, which is significant for preventing pipeline failure accidents. Full article

The vortex-induced vibrations of two side-by-side flexible cylinders in a uniform flow were studied using a three-dimensional direct numerical simulation at Reynolds number Re = 350 with an aspect ratio of 100, and a center-to-center spacing ratio of 2.5. A mixture of standing-traveling wave pattern was induced in the in-line (IL) vibration, while the cross-flow (CF) vibration displayed a standing-wave characteristic. The ninth vibration mode prominently occurred in both IL and CF directions, along with competition between multiple modes. Proximity effects from the neighboring cylinder caused the primary frequency to be consistent between IL and CF vibrations for each cylinder, deviating from the IL to CF ratio of 2:1 in isolated cylinder conditions. Repulsive mean lift coefficients were observed in both stationary and vibrating conditions for the two cylinders due to asymmetrical vortex shedding in this small gap. Comparatively, lift and drag coefficients were notably increased in the vibrating condition, albeit with a lower vortex shedding frequency. Positive energy transfer was predominantly excited along the span via vortex shedding from the cylinder itself and the neighboring one, leading to increasing lower-mode vibration amplitudes. The flip-flopping (FF) wake pattern was excited in the stationary and vibrating cylinders, causing spanwise vortex dislocations and wake transition over time, with the FF pattern being more regular in the stationary cylinder case. Full article

This study proposes a computational fluid dynamics and computational structure dynamics (CFD/CSD) coupled method for calculating the buffet response of a variant tail wing. The large-scale separated flow in the buffet is simulated by the detached vortex approach, vibration deformation of the tail wing is solved by the dynamic mesh generation technique, and structural modeling is based on the mode method. The aerodynamic elastic coupling is calculated through the cyclic iteration of aerodynamics and the structural solution in the time domain. We verify the correctness of the proposed method through a typical delta wing calculation case, further simulate the buffet response of a variant tail wing in maneuver state, and finally realize buffet mitigation using an active excitation method. Overall, this study can provide an important reference for the design of variant-tailed aircraft. Full article

This study investigates the vertical-type submerged floating tunnel with anchor cables. Based on the characteristics of the anchor cables, the anchor cables are simplified as a nonlinear beam model with hinged ends. Disregarding the axial displacement of the tunnel body, the loads will cause displacements in the x and z directions of the tunnel body. The vibrations of the anchor cables are decomposed into three directions, and the parameter excitation at the connection point between the anchor cables and the tunnel body is taken into account. The equations of motion for the three degrees of freedom of the anchor cables are established using Hamilton’s principle, and then the three equations are solved using the Galerkin method and the fourth-order Runge–Kutta method. The basic characteristics of an internal wave stratified flow acting on the anchor cables are considered, as well as the influence of the incident angle of the ocean currents on the three degrees of freedom of the anchor cables. The results indicate that (1) stratified flow weakens the first- and third-order vortex-induced vibrations of the anchor cables while enhancing the second-order vortex-induced vibrations. When considering the parameter excitation of the anchor cables, the first- and third-order vibrations are weakened, while the second-order vibration remains significant; (2) the first-order vibration of the anchor cables reaches its maximum value when the transverse oscillation frequency of the tunnel body is twice its natural frequency, and the second-order vibration of the anchor cables reaches its maximum value when the transverse oscillation frequency of the tunnel body is twice its natural frequency; (3) the downstream vibration of the anchor cables increases with the increase in the incident angle of the ocean currents, the cross-flow vibration of the anchor cables decreases with the increase in the incident angle of the ocean currents, and the axial vibration of the anchor cables reaches its maximum value when the incident angle of the ocean currents is 60 degrees; (4) stratified flow weakens the lock-in phenomenon of the anchor cables, and the influence of the 1/2 stratified flow on the vibrations of the anchor cables is greater than the influence of the 1/2 stratified flow. Full article

To investigate the vortex-induced vibration (VIV) characteristics of two rectangular cylinders with a width-to-depth ratio of 5:1 in a tandem arrangement, sectional model wind tunnel tests that measure vibration responses and pressure distributions simultaneously were adopted. The ratio of the spacing between the cylinders to its width is 1.2. The analyses were performed considering VIV responses as well as the distribution characteristics of mean and rms pressure coefficients. Additionally, the time-frequency domain statistical parameters like correlation and contribution coefficients, phase lags between distributed and general vortex excited forces (VEFs), and amplitudes of VEF coefficients at predominant frequencies were calculated to analyze the physical VIV mechanism of two 5:1 rectangular cylinders in tandem. This study indicates that the influence of incidence angles on the dynamic responses is notable; the contribution of the distributed VEFs acting on the trailing surface of the upstream cylinder and the leading surface of the downstream one is significant to VIVs of the cylinders from wind pressure distribution characteristics and correlation analyses. Full article

Pitch motion is the key factor affecting the performance characteristics of centrifugal pumps on board ships and exacerbates hydraulic excitation to induce the unsteady vibration of pump units. A hydraulic test platform with swing motion is established to explore the effects of pitch motion on a pump’s performance characteristics. An obvious hump zone exists in the head characteristic curve in the low-flow-rate condition due to the pitch motion. The pump head in the shut-off condition has a significant decrease due to the pitch motion, compared to the static state. The head decrease gradually increases as the maximum pitch angle increases or the pitch period shortens. Specifically, the head in the rated flow condition decreases by 6.3 % to reach a minimum at the maximum pitch angle of 20 degrees in a period of 5 s. Based on a multiple-reference coordinate system, a large eddy simulation with a shear-modified eddy viscosity model is employed to simulate inner flow characteristics under the influence of pitch motion. A distinct vortex flow appears near the blade suction surface and becomes increasingly turbulent as the pitch period shortens. The pitch motion intensifies the unsteady stretching and deformation of vortices. The periodic variations in fluid-induced pressure over time present parabolic features, and the amplitude in the frequency domain reaches its maximum value within a pitch period of 5 s. Full article

Low-frequency pressure fluctuations are common in open-jet wind tunnels, affecting test accuracy and posing safety risks to the wind tunnels. These oscillations can be caused by different mechanisms in different wind tunnels, and it is often necessary to identify the specific mechanism responsible for the oscillation and develop appropriate control methods. This paper presents a comprehensive review of the current state of research on low-frequency pressure fluctuations in subsonic open-jet wind tunnels, with a particular emphasis on their generation mechanisms and control strategies. The primary source of excitation is attributed to the edgetone feedback formed by the impingement of the jet on the collector. The sound wavelength corresponding to the edgetone frequency is close to that of the plenum scale, facilitating resonance with both plenum-associated vibration modes and specific-order standing wave modes within the circuit loop, resulting in significant low-frequency pulsations. Passive control methods such as nozzle vortex generators and collector breathing gaps have been extensively employed due to their cost-effectiveness and efficiency. The concluding section highlights some unresolved issues that require further investigation in this field. Full article

The exhaust chimney of third-generation nuclear power units is a typical attached high-rise riser structure. In this paper, the simplified mechanical model and dynamic model of China’s third-generation nuclear power Hualong-1 VNA system, including multiple nonlinear factors, are established for the first time. The DTM (differential transformation method) was first applied to solve the natural vibration characteristics of a multi-point constrained variable cross-section riser structure, and the effects of variable cross-section, variable mass, variable axial force, and different elastic constraint parameters on the natural vibration characteristics of the system were studied. The dynamic behavior of the VNA system under the combined action of internal flow velocity, vortex excitation, and foundation excitation was studied. The results show that the outer diameter function of the VNA system pipeline should be designed as a quadratic function or a near quadratic multi-segment constant value function. The “limiting” effect of constraining large stiffness can force low-order vibration modes with high constraint stiffness to jump to high-order vibration modes with low constraint stiffness. The elastic constraint arrangement scheme with near center symmetry can make the system vibration mode present a half stable and half-curved form. A new optimization design scheme has been proposed regarding the layout and stiffness parameters of the VNA system guide bracket. This can enable the VNA system pipeline to avoid severe oscillations near the response extreme values caused by multiple frequency excitations of seismic loads under design and accident conditions and ensure the service life of the equipment. Full article

To investigate the wind-induced response and equivalent wind load of a super-tall building, an aeroelastic model of the building was designed to measure aerodynamic interference in wind tunnel tests. Experiments on pressure and vibration measurements were conducted in both uniform and turbulent wind fields, and the displacement response and surface wind pressure at different locations of the model were recorded. The displacement time-history response spectrum and aerodynamic spectrum in both fields were compared and analyzed. The research showed that the mean displacement responses of the model in the across-wind and along-wind directions gradually increased with velocity under different wind attack angles. The mean displacement response of torsion moment in a uniform wind field changed very little, and the mean and fluctuating wind pressures in each layer were significantly stratified, making it is easy to generate a coupled vortex-induced resonance. On the other hand, the mean displacement response of torsion moment in a turbulent field increased with wind velocity. Strong turbulence made the fluctuating wind pressure at the top and bottom of the model slightly more significant than in a uniform field. The resistance of super-tall buildings came from turbulence excitation in the along-wind direction and the self-excited resistance generated by the across-wind direction. The test methods and main research conclusions may provide a reference for glass curtain walls and the structural wind-resistant design of super-tall buildings. Full article

A harbor seal’s whisker is able to sense the trailing vortices of marine organisms due to its unique three-dimensional wavy shape, which suppresses the vibrations caused by its own vortex-shedding, while exciting large-amplitude and synchronized vibrations in a wake flow. This provides insight into the development of whisker-inspired sensors, which have broad applications in the fields of ocean exploration and marine surveys. However, the harbor seal’s whisker may lose its vibration suppression ability when the angle of attack (AoA) of the incoming flow is large. In order to explore the flow-induced vibration (FIV) features of a harbor seal’s whisker at various angles of attack ($\theta =0$–${90}^{\circ }$), this study experimentally investigates the effect of AoA on the vibration response of a whisker model in a wide range of reduced velocities ($U_r$ = 3–32.2) and the Reynolds number, Re = 400–7000, in a circulating water flume. Meanwhile, for the sake of comparison, the FIV response of an elliptical cylinder with the same equivalent diameters is also presented. The results indicate that an increase in AoA enhances the vibration amplitude and expands the lock-in range for both the whisker model and the elliptical cylinder. The whisker model effectively suppresses vibration responses at $\theta =0^{\circ }$ due to its unique three-dimensional wavy shape. However, when $\theta \ge {30}^{\circ }$, the wavy surface structure gradually loses its suppression ability, resulting in large-amplitude vibration responses similar to those of the elliptical cylinder. For $\theta$ = 30${}^{\circ }$ and 45${}^{\circ }$, the vibration responses of the whisker model and the elliptical cylinder undergo three vibration regimes, i.e., vortex-induced vibration, transition response, and turbulent-induced vibration, with the increasing $U_r$. However, at $\theta$ = 60${}^{\circ }$ and 90${}^{\circ }$, the vortex-shedding gradually controls the FIV response, and only the vortex-induced vibration is observed. Full article
