In large-scale water conservancy and hydropower projects, complex rock structures are considered to be the main factor controlling the stability of hydraulic structures. The classification of rock mass structure plays an important role in the safety of all kinds of large buildings, especially underground engineering buildings. As a quantitative classification index of rock mass, the rock block index is very common in the classification of borehole and dam foundation rock mass structures. However, there are few studies on the classification of underground engineering rock masses. Moreover, their classification criteria have disadvantages in spatial dimension. Therefore, this paper takes the long exploratory cave CPD1 in the water transmission and power generation system of the Qingtian pumped storage power station in Zhejiang Province as the research object and launches a study on the structural classification of the rock mass of a flat cave based on the 3D rock block index. According to the group distribution of joints, the sections are statistically homogeneous. Additionally, the Monte Carlo method is used to carry out random simulations to generate a three-dimensional joint network model. The virtual survey lines are arranged along the center of the shape of the three different orthogonal planes of the 3D joint network model to represent the boreholes, and the RBI values of the virtual survey lines on each orthogonal plane are counted to classify the rock mass structure of the flat cave in a refined manner using the rock block index of the rock mass in 3D. The above method realizes the application of the 3D rock block index in underground engineering and overcomes the limitations of traditional rock mass classification methods in terms of classification index and dimension. The results show that: (1) Three-dimensional joint network simulations built on statistical and probabilistic foundations can visualize the structure of the rock mass and more accurately reflect the structural characteristics of the actual rock mass. (2) Based on the 3D rock block index, the rock mass structure of the long-tunnel CPD1 is classified, from that of a continuous structure to a blocky structure, corresponding to the integrity of the rock mass from complete to relatively complete. The classification results are consistent with the evaluation results of horizontal tunnel seismic wave geophysical exploration. (3) Based on the 3D joint network model, it is reasonable and feasible to use the 3D rock block index as a quantitative evaluation index to determine the structure type of flat cave rock masses. The above method is helpful and significant in the classification of underground engineering rock mass structures. Full article

Rock Quality Designation (RQD) is among the widely used measures of the quality of rock masses and can be derived through Monte Carlo stochastic process-based fracture network simulations. However, repeated simulations can yield variable RQD results. Here, we introduce a four-step approach that incorporates class ratio analysis to estimate the representative RQD, which includes (1) extracting the mean and confidence interval of the RQD sample, in terms of the Confidence Neutrosophic Number Cubic Value (CNNCV), (2) employing class ratio analysis to determine the thresholds of the number of virtual boreholes and that of the number of models for a given size D, beyond which the CNNCV remains substantially unchanged, (3) accepting the CNNCV at the thresholds of the number of models as the representative RQD for the model of size D (RQD(D)) and (4) determining the representative RQD (rRQD), defined as the specific value which, once D exceeds, the RQD(D) does not change significantly. The introduced approach is illustrated with a case study of an open-pit slope in China, and it was tested for its performance. The RQD calculation results of the proposed method and the traditional single-model approach exhibit differences, which diminish with increasing model sizes. At the 95% confidence level, the stable size of the RQD determined by the proposed method is 13 m, compared to 25 m for the single-model approach. This method enhances the accuracy of representative elementary volume predictions by accounting for the diversity in the simulation results of RQDs for the same size. Overall, the introduced approach offers a reliable method for obtaining RQD estimates. Full article

Effective response strategies to earthquake disasters are crucial for disaster management in smart cities. However, in regions where earthquakes do not occur frequently, model construction may be difficult due to a lack of training data. To address this issue, there is a need for technology that can generate earthquake scenarios for response training at any location. We proposed a model for generating earthquake scenarios using an auxiliary classifier Generative Adversarial Network (AC-GAN)-based data synthesis. The proposed ACGAN model generates various earthquake scenarios by incorporating an auxiliary classifier learning process into the discriminator of GAN. Our results at borehole sensors showed that the seismic data generated by the proposed model had similar characteristics to actual data. To further validate our results, we compared the generated IM (such as PGA, PGV, and SA) with Ground Motion Prediction Equations (GMPE). Furthermore, we evaluated the potential of using the generated scenarios for earthquake early warning training. The proposed model and algorithm have significant potential in advancing seismic analysis and detection management systems, and also contribute to disaster management. Full article

The design process of a borehole heat exchanger (BHE) requires knowledge of building thermal loads, the expected heat pump’s COP and the ground’s thermophysical properties. The thermal response test (TRT) is a common experimental technique for estimating the ground’s thermal conductivity and borehole thermal resistance. In classic TRT, a constant heat transfer rate is provided above ground to the carrier fluid that circulates continuously inside a pilot BHE. The average fluid temperature is measured, and from its time-dependent evolution, it is possible to infer both the thermal resistance of the BHE and the thermal conductivity of the ground. The present paper investigates the possibility of a new approach for TRT with the continuous injection of heat directly into the BHE’s grouting by means of electrical resistance imparted along the entire BHE’s length, while local (along the depth) temperature measurements are acquired. This DTRT (distributed TRT) approach has seldom been applied and, in most applications, circulating hot fluid and optical fibers are used to infer depth-related temperatures. The distributed measurements allow the detection of thermal ground anomalies along the heat exchanger and even the presence of aquifer layers. The present paper investigates the new EDDTRT (electric depth-distributed TRT, under patenting) approach based on traditional instruments (e.g., RTD) or one-wire digital sensors. The accuracy of the proposed method is numerically assessed by Comsol Multiphysics simulations. The analysis of the data obtained from the “virtual” EDDTRT confirms the possibility of estimating within 10% accuracy both thermal ground and grout conductivities. Full article

The stability of a rock slope is strongly influenced by the pattern of groundwater flow through the fracture system, which may lead to an increase in the water pressure in partly open joints and the consequent decrease in the rock wall strength. The comprehension of the fracture pattern is a challenging but vital aspect in engineering geology since the fractures’ spatial distribution, connectivity, and aperture guide both the water movement and flow quantity within the rock volume. In the literature, the most accepted methods to hydraulically characterise fractured rocks in situ are the single borehole packer test, the high-resolution flow meters for fractures, and the artificial tracer tests performed in boreholes. However, due to the high cost a borehole requires and the general absence of wells along coastal cliffs, these methods may not be appropriate in rockfall-prone areas. In this study, an unsaturated rocky cliff, strongly affected by rockfalls, was investigated by combining kinematic analysis, Discrete Fracture Network (DFN) modelling, and artificial tracer tests. The DFN model and potential rock block failure mechanisms were derived from high-resolution 3D virtual outcrop models via the Structure from Motion (SfM) photogrammetry technique. An artificial tracer was injected using a double ring infiltrometer atop the recharge zone of the slope to determine the infiltration rate and validate the DFN results. The DFN and tracer test methods are frequently used at different spatial scales and for different disciplines. However, the integration of digital photogrammetry, DFN, and tracer tests may represent a new step in rockfall and landslide studies. This approach made possible the identification of groundwater flow patterns within the fracture system and revealed about a 10-day tracer transit time from the injection area and the monitored slope, with similar conductivity values gathered from both the DFN and tracer test. Planar and wedge failures with volumes ranging from 0.1 and 1 m³ are the most probable failure mechanisms in the areas. The results were consistent with the delay between the intense rainfall and the slope failures previously documented in the study area and with their mechanisms. Full article

The evaluation of localized soil-liquefaction potential is based primarily on the individual evaluation of the liquefaction potential in each borehole, followed by calculating the liquefaction-potential index between boreholes through Kriging interpolation, and then plotting the liquefaction-potential map. However, misjudgments in design, construction, and operation may occur due to the complexity and uncertainty of actual geologic structures. In this study, the coupled Markov chain (CMC) method was used to create and analyze stratigraphic profiles and to grid the stratum between each borehole so that the stratum consisted of several virtual boreholes. The soil-layer parameters were established using homogenous and random field models, and the subsequent liquefaction-potential-evaluation results were compared with those derived using the Kriging method. The findings revealed that within the drilling data range in this study, the accuracy of the CMC model in generating stratigraphic profiles was greater than that of the Kriging method. Additionally, if the CMC method incorporated with random field parameters were to be used in engineering practice, we recommend that after calculating the curve of the mean, the COV should be set to 0.25 as a conservative estimation of the liquefaction-potential interval that considers the evaluation results of the Kriging method. Full article

The objective of this study is to assess the suitability of the analytical infinite moving line source (MLS) model in determining the temperature of vertical grouted borehole heat exchangers (BHEs) for steady-state conditions when horizontal groundwater advection is present. Therefore, a numerical model of a grouted borehole is used as a virtual reality for further analysis. As a result of the first analysis, it has been discovered that established analytical methods to determine the borehole thermal resistance as a mean value over the borehole radius can also be applied to BHEs with groundwater advection. Furthermore, the deviation between a finite MLS and the infinite MLS is found to be only less than 5% for BHEs of a depth of 30 m or more, and Péclet numbers greater than 0.05. Finally, the accuracy of the temperature change calculated with the infinite MLS model at the radius of the borehole wall compared to the temperature change at a numerically simulated grouted borehole is addressed. A discrepancy of the g-functions resulting in a poor dimensioning of BHEs by the infinite MLS model is revealed, which is ascribed to the impermeable grouting material of the numerical model. A correction function has been developed and applied to the infinite MLS model for steady-state conditions to overcome this discrepancy and to avoid poor dimensioning of BHEs. Full article

The Groningen gas field in the Netherlands is an ideal test bed for in-situ reservoir monitoring techniques because of the availability of both active and passive in-reservoir seismic data. In this study, we use deconvolution interferometry to estimate the reflection and transmission response using active and passive borehole data within the reservoir at ∼3-km depth and separate up- and downgoing P- and S-wave fields by f-k filtering. We validate the results using synthetic data of a 1D elastic model built from sonic logs recorded in the well. The estimated full-waveform reflection response for a virtual source at the top geophone is consistent with the synthetic response. For the virtual source at the bottom geophone, the reflection response appears to be phase delayed, though its arrivals are consistent with the local subsurface geology. Similarly, the first-order estimated local transmission response successfully approximates that of the P-wave velocity in the reservoir. The study shows that reliable subsurface information can be obtained from borehole interferometry without detailed knowledge of the medium parameters. In addition, the method could be used for passive reservoir monitoring to detect velocity, attenuation, and/or interface time-lapse variations. Full article

Beavers have lived in the territory of Poland since the beginning of the Holocene, as testified by bone remains found in archaeological sites of different ages. The area inhabited by these animals has experienced continuing transformations of terrain relief, geological structure, hydrology and plant cover. In Poland, beavers are partially protected and their population has spread in virtually every part of the country (except in the highest mountain ranges). The authors of this paper wish to present the results of field works carried out since 2006 in the Tuchola Forest (Polish Plain). This paper aims to identify the potential sediments of relict beaver ponds and their sedimentological features. The studies are also backed up with a description of radiocarbon dating of samples. The results indicate that beavers used to live in the Tuchola Forest in the Middle Ages, as shown by the radiocarbon dates and sequences of mineral–organic deposits found in exposures and geological boreholes. The spatial distribution of organic and mineral deposits in wider sections of river valleys can be explained by the avulsion of the riverbed downstream of the pond and by the distribution of ponds in the Gołyjonka valley. The discovery of relict beaver pond sediments suggests that the activity of these mammals in the Middle Ages played a major part in shaping the landscape of the valley. The results of studies clearly indicate that analyses of the valley sediment facies of small watercourses should take into account the role beavers played in the past in shaping the landscape of the analysed valley. This highlights the insufficiency of studies concerning the activity of beavers in river valleys. Full article

Structure-from-motion (SfM) photogrammetry enables the cost-effective digital characterisation of seismic- to sub-decimetre-scale geoscientific samples. The technique is commonly used for the characterisation of outcrops, fracture mapping, and increasingly so for the quantification of deformation during geotechnical stress tests. We here apply SfM photogrammetry using off-the-shelf components and software, to generate 25 digital drill core models of drill cores. The selected samples originate from the Longyearbyen CO₂ Lab project’s borehole DH4, covering the lowermost cap rock and uppermost reservoir sequences proposed for CO₂ sequestration onshore Svalbard. We have come up with a procedure that enables the determination of bulk volumes and densities with precisions and accuracies similar to those of such conventional methods as the immersion in fluid method. We use 3D printed replicas to qualitatively assure the volumes, and show that, with a mean deviation (based on eight samples) of 0.059% compared to proven geotechnical methods, the photogrammetric output is found to be equivalent. We furthermore splice together broken and fragmented core pieces to reconstruct larger core intervals. We unwrap these to generate and characterise 2D orthographic projections of the core edge using analytical workflows developed for the structure-sedimentological characterisation of virtual outcrop models. Drill core orthoprojections can be treated as directly correlatable to optical borehole-wall imagery data, enabling a direct and cost-effective elucidation of in situ drill core orientation and depth, as long as any form of borehole imagery is available. Digital drill core models are thus complementary to existing physical and photographic sample archives, and we foresee that the presented workflow can be adopted for the digitisation and digital storage of other types of geological samples, including degradable and dangerous ice and sediment cores and samples. Full article

Geological exploration plays a fundamental and crucial role in geological engineering. The most frequently used method is to obtain borehole videos using an axial view borehole camera system (AVBCS) in a pre-drilled borehole. This approach to surveying the internal structure of a borehole is based on the video playback and video screenshot analysis. One of the drawbacks of AVBCS is that it provides only a qualitative description of borehole information with a forward-looking borehole video, but quantitative analysis of the borehole data, such as the width and dip angle of fracture, are unavailable. In this paper, we proposed a new approach to create a whole borehole-wall cylindrical panorama from the borehole video acquired by AVBCS, which provides a possibility for further analysis of borehole information. Firstly, based on the Otsu and region labeling algorithms, a borehole center location algorithm is proposed to extract the borehole center of each video image automatically. Afterwards, based on coordinate mapping (CM), a virtual coordinate graph (VCG) is designed in the unwrapping process of the front view borehole-wall image sequence, generating the corresponding unfolded image sequence and reducing the computational cost. Subsequently, based on the sum of absolute difference (SAD), a projection transformation SAD (PTSAD), which considers the gray level similarity of candidate images, is proposed to achieve the matching of the unfolded image sequence. Finally, an image filtering module is introduced to filter the invalid frames and the remaining frames are stitched into a complete cylindrical panorama. Experiments on two real-world borehole videos demonstrate that the proposed method can generate panoramic borehole-wall unfolded images from videos with satisfying visual effect for follow up geological condition analysis. From the resulting image, borehole information, including the rock mechanical properties, distribution and width of fracture, fault distribution and seam thickness, can be further obtained and analyzed. Full article

Modeling ore body in 3D is the basis of digital intelligent mining. However, most existing three-dimensional mining software uses the contour approach that requires too much man–machine interaction and difficult partial updating. Moreover, accounting for uncertainty and low geometric quality picking is very difficult in the direct contour approach. Therefore, an implicit modeling approach to automatically build the three-dimensional model for ore body by means of spatial interpolation directly based on the geological borehole data with Hermite radial basis function (HRBF) algorithm as the core is proposed. Furthermore, in order to solve the problems of weak continuity of models due to the long-distance original boreholes as well as the boundary-point normal solution error, the densification of original borehole data with the virtual borehole as well as the calculation of point-cloud normal direction based on the adjacent hole-drilling method is proposed. The verification of two mine engineering projects and comparison with the explicit modeling results show that this approach could realize the automatic building of three-dimensional models for the ore body with high geometric quality, timely update and accurate results. Full article

A new first break picking for three-component (3C) vertical seismic profiling (VSP) data is proposed to improve the estimation accuracy of first arrivals, which adopts gesture detection calibration and polarization analysis based on the eigenvalue of the covariance matrix. This study aims at addressing the problem that calibration is required for VSP data using the azimuth and dip angle of geophones, due to the direction of geophones being random when applied in a borehole, which will further lead to the first break picking possibly being unreliable. Initially, a gesture-measuring module is integrated in the seismometer to rapidly obtain high-precision gesture data (including azimuth and dip angle information). Using re-rotating and re-projecting using earlier gesture data, the seismic dataset of each component will be calibrated to the direction that is consistent with the vibrator shot orientation. It will promote the reliability of the original data when making each component waveform calibrated to the same virtual reference component, and the corresponding first break will also be properly adjusted. After achieving 3C data calibration, an automatic first break picking algorithm based on the autoregressive-Akaike information criterion (AR-AIC) is adopted to evaluate the first break. Furthermore, in order to enhance the accuracy of the first break picking, the polarization attributes of 3C VSP recordings is applied to constrain the scanning segment of AR-AIC picker, which uses the maximum eigenvalue calculation of the covariance matrix. The contrast results between pre-calibration and post-calibration using field data show that it can further improve the quality of the 3C VSP waveform, which is favorable to subsequent picking. Compared to the obtained short-term average to long-term average (STA/LTA) and the AR-AIC algorithm, the proposed method, combined with polarization analysis, can significantly reduce the picking error. Applications of actual field experiments have also confirmed that the proposed method may be more suitable for the first break picking of 3C VSP. Test using synthesized 3C seismic data with low SNR indicates that the first break is picked with an error between 0.75 ms and 1.5 ms. Accordingly, the proposed method can reduce the picking error for 3C VSP data. Full article

The burial of coffins may pose an environmental and health hazard since the metals that are used in coffin-making may corrode or degrade into harmful toxins. These may leach into the surrounding soils and groundwater. Very little research has been conducted world-wide on the mineral contamination potential of cemeteries, and virtually none in South Africa. The aim of the study is to determine whether burial practices affect the mineral content of soils in cemeteries. This was done by comparing the mineral concentrations of soils within the Zandfontein Cemetery in Tshwane (Gauteng, South Africa) to those off-site as well as those in zones with high burial loads with those zones with fewer burials. Twenty three soil samples were collected from various sites on- and off-site and analyzed for 31 minerals using ICP-AES. It was found that mineral concentrations of soils within the Zandfontein Cemetery were considerably higher than those off-site. Soil samples in multiple burials blocks also have elevated metal concentrations. These excess metals are probably of anthropogenic origin associated with burial practices and could pose an environmental and human health hazard. Strict monitoring of water quality in boreholes in the vicinity of the cemetery is recommended. Full article
