The hydrodynamics of a river confluence generate significant vertical, lateral, and stream-wise gradients in the context of velocity, thereby forming a highly complex three-dimensional flow structure, including the development of large-scale turbulence structures. The above features affect the ecologically important underlying hyporheic zone, where surface and subsurface waters interact, and hence affect biological activity and result in highly varied habitats for organisms as well as the whole river environment. The influence of challenging conditions for in situ monitoring of hyporheic exchange—such as non-sinusoidal temperature signals, uncertainty in thermal parameters, and unsteady flows—have led to the development of hyporheic exchange detection methods that are based on the phase and amplitude changes in transient thermal signals. The use of heat as a tracer can require complex steps, including the isolation of the diurnal component of the temperature signal from other signals as well as stochastic variation. The focus of this study was to investigate a field campaign carried out between the Ninemile Creek and its tributary confluence, located in Marcellus, NY. Temperature data of the shallowest saturated sediment layers were measured from April to May 2019. Flux estimations were calculated using VFLUX 2, a MatLab based code, which performed data filtering and DHR (Dynamic Harmonic Regression). The patterns and rates of vertical flux exchange were then analyzed, and sampling of the temporal thermal profiles was performed. Furthermore, multiple analytical solutions of the one-dimensional heat transport model were analyzed and discussed in order to obtain the confluence hydrodynamic effect as well as the variations in the vertical flux estimation. This was achieved by utilizing different sensor pairs and porous medium characteristics, such as thermal diffusivity and conductivity. The predicted flow field shows that confluence topography—which includes the turbulent kinetic energy downstream of the junction, shear layer formations, bed stratigraphy and water table gradients—affects the magnitude and patterns of hyporheic exchange. The results of this study could help to advance the calibration of one-dimensional heat transport models in order to better understand the key hydrological, hydraulic, and ecological issues associated with river confluence. Full article

The hyporheic zone (HZ) plays an important role in the river ecosystem, and hyporheic exchange and solute transport in the HZ are important ecological functions. However, the relationship between the design parameters of river structure and solute transport is still poorly understood. In this study, we combined flume experiments and numerical simulations to systematically evaluate how in-stream structures impact the solute transport depth (D_P), hyporheic vertical exchange flux (Q), and solute flux (Qs). The results showed that the in-stream structure had a significant influence on solute transport in the HZ and could obviously increase the intensity of hyporheic exchange and promote solute transport. Model results indicated that D_P, Q, and Qs increased with the ratio of ground height to underground height of structure (H/D) and structure number (N), while Q, D_P, and Qs increased with the structural spacing (S) to begin with; then, Q remained constant, and D_P and Qs decreased as S continued to increase. This study deepened our understanding of the influence of in-stream structural design parameters on HZ solute transport, which is helpful to provide a theoretical basis for ecological restoration projects in the river HZ. Full article

Identifying and quantifying exchange flux across sediment-water interface is crucial when considering water and nutrient contributions to a eutrophic lake. In this study, observed temporal temperature distributions in shallow sediment of Lake Taihu (Eastern China) based on three-depth sensors at 14 sites throughout 2016 were used to assess temporal water exchange patterns. Results show that temporal temperature in shallow sediments differed with sampling sites and depths and the temperature amplitudes also clearly shrunk as the offshore distance increasing. Exchange fluxes estimated using the VFLUX 2 model based on temperature amplitude show that alternating-direction temporal flow exists in the eastern zone of Lake Taihu with averages of −13.0, −0.6, and 3.4 mm day⁻¹ (negative represents discharging into the lake) at three nearshore sites (0.5, 2.0, and 6.0 km away from the shoreline, respectively). Whereas downwelling flow occurred throughout almost the entire year with averages of 37.7, 23.5, and 6.6 mm day⁻¹ at the three southern nearshore sites, respectively. However, upwelling flow occurred throughout almost the entire year and varied widely in the western zone with averages of −74.8, 45.9, and −27.0 mm day^–1 and in the northern zone with averages of −76.2, −55.3, and −51.1 mm day⁻¹. The estimated fluxes in the central zone were relatively low and varied slightly during the entire year (−15.1 to 22.5 mm day⁻¹ with an average of −0.7 mm day⁻¹). Compared with the sub sensor pair (at 5 and 10 cm), the estimated hyporheic fluxes based on the top sensor pair (at 0 and 5 cm) varied within wider ranges and exhibited relatively larger values. Effects of upwelling flow at the western and northern zones need to be paid attention to on nearshore water quality particularly during winter and spring seasons. Estimated flow patterns at the four zones summarily reflect the seasonal water interaction near the sediment surface of Lake Taihu and are beneficial to improve its comprehensive management. Thermal dispersivity usually used for estimating the thermal diffusivity is more sensitive for upward hyporheic flux estimating even if with a low flux. Temperature amplitude ratio method can be used to estimate the exchange flux and suitable for low flux conditions (either upwelling or downwelling). A better evaluation of the exchange flux near inclined nearshore zones might need an optimized installation of temperature sensors along with the potential flow path and/or a vertical two-dimensional model in the future. Full article

The bioturbation activity of macroinvertebrates can affect the level of water exchange across the sediment–water interface. The impact of tubificid worm with different densities on the vertical water exchange at the sediment–water interface was investigated based on laboratory flume experiments. Vertical water fluxes, as well as physiochemical parameters, were measured at seven-day intervals, and the maximum penetration depths were obtained by dye injection before and after the tubificid bioturbation experiment, respectively. The bioturbation effects can be summarized in two aspects: (1) when the density was less than (or equal to) 20 individual/10 cm², the volume of vertical water exchange positively correlated with the tubificid bioturbation. Once the density exceeded (or equaled) 25 individual/10 cm², the vertical water flux decreased with increasing tubificid bioturbation. After 14 to 21 days, a negative correlation was identified between the bioturbation and the vertical water flux under all biological densities. (2) The maximum depth that the surface water can penetrate the sediment increased with increasing tubificid density. These results revealed that the vertical water was closely related to the biological density. The study has certain reference significance to understanding the spatiotemporal heterogeneity of hyporheic water exchange on a local scale. Full article

This paper introduces and tests the Sediment Bed Borehole Advection Method (SBBAM), a low cost, point-measurement technique which utilizes a push-point probe to quantify the vertical direction and magnitude of Darcy flux at the surface water—groundwater sediment interface. The Darcy flux measurements are derived from the residence-time analysis of tracer arrival calculated from measured tracer concentration time-series data. The technique was evaluated in the laboratory using a sediment bed simulator tank at eight flow rates (1–90 cm/day). Triplicate test runs for each flow rate returned average errors between 4–20 percent; r² = 0.9977. Full article

Modelling of water flow in the hyporheic zone and calculations of water exchange between groundwater and surface waters are important issues in modern environmental research. The article presents the Analytical Hyporheic Flux approach (AHF) permitting calculation of the amount of water exchange in the hyporheic zone, including vertical water seepage through the streambed and horizontal seepage through river banks. The outcome of the model, namely water fluxes, is compared with the corresponding results from the numerical model SEEP2D and simple Darcy-type model. The errors of the AHF model, in a range of 11–16%, depend on the aspect ratio of water depth to river width, and the direction of the river–aquifer water exchange, i.e., drainage or infiltration. The AHF model errors are significantly lower compared to the often-used model based on vertical water seepage through the streambed described by Darcy’s law. Full article

To assist river restoration efforts we need to slow the rate of river degradation. This study provides a detailed explanation of the hydraulic complexity loss when a meandering river is straightened in order to motivate the protection of river channel curvature. We used computational fluid dynamics (CFD) modeling to document the difference in flow dynamics in nine simulations with channel curvature (C) degrading from a well-established tight meander bend (C = 0.77) to a straight channel without curvature (C = 0). To control for covariates and slow the rate of loss to hydraulic complexity, each of the nine-channel realizations had equivalent bedform topography. The analyzed hydraulic variables included the flow surface elevation, streamwise and transverse unit discharge, flow velocity at streamwise, transverse, and vertical directions, bed shear stress, stream function, and the vertical hyporheic flux rates at the channel bed. The loss of hydraulic complexity occurred gradually when initially straightening the channel from C = 0.77 to C = 0.33 (i.e., the radius of the channel is three-times the channel width), and additional straightening incurred rapid losses to hydraulic complexity. Other studies have shown hydraulic complexity provides important riverine habitat and is positively correlated with biodiversity. This study demonstrates how hydraulic complexity can be gradually and then rapidly lost when unwinding a river, and hopefully will serve as a cautionary tale. Full article

This study characterized vertical one-dimensional (1-D) flux rates in the top 150 cm of the streambed and explored the relationship between stage and 1-D vertical flux rates in a low-gradient stream. Six multi-level samplers were installed along a 25 m stretch of the thalweg spaced at 5 m intervals. Each sampler recorded temperature at five separate depths (30, 60, 90, and 150 cm) from February 2009 to March 2010. Temperature and stage data were collected at 15 min intervals. For the midpoint between sensors, 1-D flux rates were calculated using the 1-D conduction-advection-dispersion equation utilized in the VFLUX MATLAB program. The dominant flux direction at a depth of 15 cm was downward (negative), while the average flux directions at depths of 45, 75, and 120 cm were upward (positive). Variable flux directions above 15 cm indicated hyporheic exchange with background upwelling groundwater between 15 to 120 cm. Flux rates approach zero in the summer, representing limited hyporheic exchange. Relationships between stage and flux at the near-surface streambed (15 cm) were weak, but statistically significant, with Spearman’s rank correlations for all six multi-level samplers ranging from −0.032 to 0.369 with an average of 0.085. Full article

Confluences are nodes in riverine networks characterized by complex three-dimensional changes in flow hydrodynamics and riverbed morphology, and are valued for important ecological functions. This physical complexity is often investigated within the water column or riverbed, while few studies have focused on hyporheic fluxes, which is the mixing of surface water and groundwater across the riverbed. This study aims to understand how hyporheic flux across the riverbed is organized by confluence physical drivers. Field investigations were carried out at a low gradient, headwater confluence between Baltimore Brook and Cold Brook in Marcellus, New York, USA. The study measured channel bathymetry, hydraulic permeability, and vertical temperature profiles, as indicators of the hyporheic exchange due to temperature gradients. Confluence geometry, hydrodynamics, and morphodynamics were found to significantly affect hyporheic exchange rate and patterns. Local scale bed morphology, such as the confluence scour hole and minor topographic irregularities, influenced the distribution of bed pressure head and the related patterns of downwelling/upwelling. Furthermore, classical back-to-back bend planform and the related secondary circulation probably affected hyporheic exchange patterns around the confluence shear layer. Finally, even variations in the hydrological conditions played a role on hyporheic fluxes modifying confluence planform, and, in turn, flow circulation patterns. Full article

Stream restoration designed specifically to enhance hyporheic processes has seldom been contemplated. To gain experience with hyporheic restoration, an engineered streambed was built using a gravel mixture formulated to mimic natural streambed composition, filling an over-excavated channel to a minimum depth of 90 cm. Specially designed plunge-pool structures, built with subsurface gravel extending down to 2.4 m, promoted greatly enhanced hyporheic circulation, path length, and residence time. Hyporheic process enhancement was verified using intra-gravel temperature mapping to document the distribution and strength of upwelling and downwelling zones, computation of vertical water flux using diurnal streambed temperature patterns, estimation of hyporheic zone cross section using sodium chloride tracer studies, and repeat measurements of streambed sand content to document evolution of the engineered streambed over time. Results showed that vertical water flux in the vicinity of plunge-pool structures was quite large, averaging 89 times the pre-construction rate, and 17 times larger than maximum rates measured in a pristine stream in Idaho. Upwelling and downwelling strengths in the constructed channel were larger and more spatially diverse than in the control. Streambed sand content showed a variety of response over time, indicating that rapid return to an embedded, impermeable state is not occurring. Full article

As a typical water exchange of surface water and groundwater, hyporheic flow widely exists in streambeds and is significantly affected by the characteristics of sediment and surface water. In this study, a low-permeability clay lens was chosen to investigate the influence of the streambed heterogeneity on the hyporheic flow at a river section of the Xin’an River in Anhui Province, China. A 2D sand tank was constructed to simulate the natural streambed including a clay lens under different velocity of surface water velocity. Heat tracing was used in this study. In particular, six analytical solutions based on the amplitude ratio and phase shift of temperatures were applied to calculate the vertical hyporheic flux. The results of the six methods ranged from −102.4 to 137.5 m/day and showed significant spatial differences. In view of the robustness of the calculations and the rationality of the results, the amplitude ratio method was much better than the phase shift method. The existence of the clay lens had a significant influence on the hyporheic flow. Results shows that the vertical hyporheic flux in the model containing a clay lens was lower than that for the blank control, and the discrepancy of the hyporheic flow field on both sides of the lens was obvious. Several abnormal flow velocity zones appeared around the clay lens where the local hyporheic flow was suppressed or generally enhanced. The hyporheic flow fields at three test points had mild changes when the lens was placed in a shallow layer of the model, indicating that the surface water velocity only affect the hyporheic flow slightly. With the increasing depth of the clay lens, the patterns of the hyporheic flow fields at all test points were very close to those of the hyporheic flow field without a clay lens, indicating that the influence of surface water velocity on hyporheic flow appeared gradually. A probable maximum depth of the clay lens was 30 to 40 cm, which approached the bottom of the model and a clay lens buried lower than this maximum would not affect the hyporheic flow any more. Influenced by the clay lens, hyporheic flow was hindered or enhanced in different regions of streambed, which was also depended on the depth of lens and surface water velocity. Introducing a two-dimensional sand tank model in a field test is an attempt to simulate a natural streambed and may positively influence research on hyporheic flow. Full article

Hydrologic exchange is a crucial component of the water cycle. The strength of the exchange directly affects the biogeochemical and ecological processes that occur in the hyporheic zone and aquifer from micro to reach scales. Hydrologic exchange fluxes (HEFs) can be quantified using many field measurement approaches, however, in a relatively large river (scale > 10³ m), these approaches are limited by site accessibility, the difficulty of performing representative sampling, and the complexity of geomorphologic features and subsurface properties. In rivers regulated by hydroelectric dams, quantifying HEF rates becomes more challenging because of frequent hydropeaking events, featuring hourly to daily variations in flow and river stages created by dam operations. In this study, we developed and validated a new approach based on field measurements to estimate shallow water HEF rates across the river bed along the shoreline of the Columbia River, USA. Vertical thermal profiles measured by self-recording thermistors were combined with time series of hydraulic gradients derived from river stages and inland water levels to estimate the HEF rates. The results suggest that the HEF rates had high spatial and temporal heterogeneities over the riverbed, with predicted flux rates varied from +1 × 10⁻⁶ m s⁻¹ to −1.5 × 10⁻⁶ m s⁻¹ under different flow conditions. Full article

The hyporheic zone regulates physicochemical processes in surface-groundwater systems and can be an important source of heavy metals in fluvial systems. This study assesses the pore water concentrations and diffusive fluxes of heavy metals with respect to the vertical water exchange flux (VWEF) and sediment grain size. Water and sediment samples were collected on August 2016 from upstream Site 1 and downstream Site 2 along the Juehe River in Shaanxi Province, China. Streambed vertical hydraulic conductivity (Kv) and the VWEF were estimated via the standpipe permeameter test method and Darcy’s law. The heavy metal concentrations in the pore water were measured and the diffusive fluxes were calculated using Fick’s first law. The VWEF patterns were dominated by upward flow, and Site 1 featured higher values of Kv and VWEF. Higher Cu and Zn concentrations occurred near the channel centre with coarse sand and gravel and greater upward VWEFs because coarser sediment and greater upward VWEFs cause stronger metal desorption capacity. Additionally, Cu and Zn at the two sites generally diffused from pore water to surface water, potentially due to the upward VWEF. The VWEF and sediment grain size are likely crucial factors influencing the heavy metal concentrations and diffusive fluxes. Full article

Channel bends are one of the most important characteristic features of natural streams. These bends often create the conditions for a hyporheic zone, which has been recognized as a critical component of stream ecosystems. The streambed vertical hydraulic conductivity (K_v), vertical hydraulic gradient (VHG) and Darcian flux (DF) in the hyporheic zone were estimated at 61 locations along a channel bend of the Beiluo River during July 2015 and January 2016. All the streambed attributes showed great spatial variability along the channel bend. Both upward fluxes and downward fluxes occurred during the two test periods, most of studied stream sections were controlled by downwelling, indicating stream water discharge into the subsurface. The average downward flux was higher at the downstream side than at the upstream side of the channel bend, especially in July 2015. The distribution of streambed sediment grain size has a significant influence on the variability of K_v; high percentages of silt and clay sediments generally lead to low K_v values. Higher K_v at the depositional left bank at the upstream site shifted toward the erosional right bank at the downstream site, with K_v values positively correlated with the water depth. This study suggested that the variabilities of K_v and VHG were influenced by the stream geomorphology and that the distribution of K_v was inversely related, to a certain extent, to the distribution of VHG across the channel bend. K_v and VHG were found to have opposite effects on the DF, and the close relationship between K_v and DF indicated that the water fluxes were mainly controlled by K_v. Full article
