Search Results (58)

Hydrogen Internal Combustion Engines (H₂ICEs) offer significant potential in reducing the CO₂ emissions of the heavy-duty transport sector in the pursuit of the European Green Deal targets. However, the challenges associated with hydrogen energy density require advanced technologies for fuel efficiency enhancement. Hybrid powertrains, equipped with innovative energy recovery systems, allow optimizing the engine working point while recovering otherwise wasted energy. In particular, Turbocompound (TCo) systems allow recovering the energy content in the exhaust gases, improving the overall efficiency of the powertrain. Optimizing both engine operation and TCo recovery presents a significant challenge, as it requires balancing the dynamic interaction between the engine’s combustion process and TCo (which increases backpressure). This paper presents a novel approach aimed at optimizing the performance of a hybrid hydrogen-fueled internal combustion engine by integrating a TCo system. The TCo allows extracting a 9 kW extra power peak with respect to the baseline configuration. The performance assessment of the optimized working point for series hybrid powertrains underscores the capability of the strategy to reduce hydrogen consumption up to 6.8%. Full article

A reduction in emissions in transportation is paramount to achieve full compliance with the European Union’s 2050 targets. In this framework, a great boost to the carbon dioxide (CO₂) emission of internal combustion engines fueled by petroleum-derived fuels can be obtained through the adoption of biomass-derived fuels that can be employed in conventional series production engine vehicles. This paper presents the results of an experimental activity on a two-cylinder turbocharged common rail diesel engine, whose main application is for urban mobility, fueled with renewable fuels: Neste MY Renewable Diesel and Eni HVOlution. Aimed at analyzing the potential employment of renewable fuels as drop-in alternative fuels, the engine performance and emissions were investigated under fixed settings of the injection parameters, in the complete range of the engine speed, at the full pedal position. The comparison with the data from tests in which the engine was fueled with fossil diesel highlighted minimal differences in the performance outcomes, while significant differences were observed in the emissions results. In more detail, there were reduced carbon monoxide (CO) emissions (HVO produced using Ecofining™ technology retained better behavior in relation to HVO produced using the NEXBTL™ technology), advantages in hydrocarbon (HC) and nitrogen oxide (NOx) emissions (HVO from NESTE Oil performed better than HVO from ENI), a decrease in the particle mass and number emissions (HVO from Ecofining™ technology was characterized by a lower particle number and court mean diameter in relation to HVO from the NEXBTL™ technology). The results highlight that an optimization of the engine settings based on the specific properties of each fuel could allow us to take full advantage of these fuels in reducing the environmental impact of cars. Full article

The methods of increasing the efficiency of internal combustion engines through heat utilization are examined. A proposed classification of heat utilization systems for mobile energy vehicles is presented. External utilization harnesses the heat generated by a diesel engine to fulfill the needs of consumers not directly related to the engine, such as interior heating and air conditioning systems. Internal recycling focuses on enhancing the power, environmental performance, and economic performance of an engine and its related systems. Various heat utilization schemes are compared. For the economic conditions of the European Union (EU), a turbocompounding diesel engine is acceptable if its agricultural tractor rated power is more than 275 kW and its combine harvester rated power is more than 310 kW. Steam injection into the combustion chamber is utilized to improve the technical and economic performance of gas turbine engines. This technology is also produced in Ukraine and is proposed for use in internal combustion engines. It is suggested to inject water vapor into a turbocharger turbine. This approach reduces the number of components in the heat recovery system, thereby lowering its cost. A recycling chiller can be employed to cool the air after it passes through the air cleaner, enhance the efficiency of the air cooler, and improve the performance of the thermoelectric generators. This device is particularly effective at relatively high air temperatures and can be recommended for agricultural machinery that operates in such conditions, such as combines. With the application of this new technology, it is possible to increase the power of diesel engines by 15…20% and reduce fuel consumption by up to 14%. Further research will focus on substantiating the parameters of recycling systems for different classes of vehicles. Developing a methodology to justify the effective application of heat utilization systems in agricultural mobile energy vehicles is advisable. Full article

This article studies the transformation and assembly process of the Volkswagen (VW) Crafter from conventional to hybrid vehicle of the department of vehicles engineering, University of Debrecen, and uses a computer-aided simulation (CAS) to design the vehicle based on the real measurement data (hardware-in-the-loop, HIL method) obtained from an online CAN bus data measurement platform using MATLAB/Simulink/Simscape and LabVIEW software. The conventional vehicle powered by a 6-speed manual transmission and a 4-stroke, 2.0 Turbocharged Direct Injection Common Rail (TDI CR) Diesel engine and the transformed hybrid electrified powertrain are designed to compare performance. A novel methodology is introduced using Netcan plus 110 devices for the CAN bus analysis of the vehicle’s hybrid version. The acquired raw CAN data is analyzed using LabVIEW and decoded with the help of the database (DBC) file into physical values. A classical proportional integral derivative (PID) controller is utilized in the hybrid powertrain system to manage the vehicle consumption and CO₂ emissions. However, the intricate nonlinearities and other external environments could make its performance unsatisfactory. This study develops the energy management strategies (EMSs) on the basis of enhanced proportional integral derivative-based genetic algorithm (GA-PID), and compares with proportional integral-based particle swarm optimization (PSO-PI) and fractional order proportional integral derivative (FOPID) controllers, regulating the vehicle speed, allocating optimal torque and speed to the motor and engine and reducing the fuel and energy consumption and the CO₂ emissions. The integral time absolute error (ITAE) is proposed as a fitness function for the optimization. The GA-PID demonstrates superior performance, achieving energy efficiency of 90%, extending the battery pack range from 128.75 km to 185.3281 km and reducing the emissions to 74.79 gCO₂/km. It outperforms the PSO-PI and FOPID strategies by consuming less battery and motor energy and achieving higher system efficiency. Full article

This study presents the findings of a comprehensive SWOT analysis on the integration of hybrid electric turbochargers (HETs) in mass-produced road vehicles. Through a synthesis of multiple research findings, this study compared the performance of HETs on thermal engines versus traditional turbochargers and HETs on thermal engines versus HETs on hybrid engines. The analysis highlights key strengths, weaknesses, opportunities, and threats associated with the adoption of HET technology in the automotive industry. The results of the SWOT analysis provide valuable insights for both manufacturers and consumers regarding the feasibility and benefits of adopting HET technology in modern vehicles. By elucidating the fundamental mechanics of turbochargers and demonstrating the potential of hybrid electric turbocharging, this study contributes to a deeper understanding of the role of HETs in shaping the future of automotive engineering. In conclusion, this study underscores the potential of HETs to substantially mitigate the environmental impact of the transportation sector by reducing emissions and conserving energy. The novelty of this study is reflected in its comprehensive synthesis of multiple research findings, offering insights into the feasibility and benefits of adopting HET technology in modern vehicles, thereby contributing to a deeper understanding of the role of HETs in shaping the future of automotive engineering and highlighting their continued significance, as evidenced by the systematic SWOT analysis presented. Their ability to optimize fuel efficiency and power output, coupled with the feasibility of downsized engines, positions HETs as an attractive option for sustainable mobility solutions. Further research is warranted to comprehensively understand the environmental and economic implications of widespread HET adoption. Full article

The application of hydrogen in heavy-duty vehicles or trains has been suggested as a promising solution to decarbonize the transportation sector. In this study, a one-dimensional engine modeling is employed to evaluate the potential of hydrogen as a fuel for railway applications. A turbocharged diesel engine is simulated as the baseline unit, and the results are validated with experimental data. The same engine is converted to become compatible with hydrogen through some modifications in the turbocharger group and the injection and ignition systems to preserve the performance of the baseline configuration. The findings show that the engine traction power is reduced from 600 to 400 kW, indicating an inferior performance for the hydrogen-fueled engine. The energy consumption of the hydrogen-fueled engine on a real train mission profile is almost two times the diesel version. However, our Life Cycle Assessment analysis with a Well-to-Wheel system boundary shows a 56% reduction in equivalent CO₂ emissions for the engine fueled with photovoltaic-based green hydrogen. Substituting diesel with low-carbon hydrogen can decrease the train’s carbon footprint from 4.27 to even less than 2 kg CO₂ eq./km, suggesting that moderately modified engines are a promising solution for decarbonizing non-feasibly electrified railway sections. Full article

Efficient and low-polluting mobility is a major demand in all countries. Hybrid electric vehicles have already shown to be suitable to respond to this need, being a reliable alternative to conventional cars, at least in urban environments. Nevertheless, such vehicles present a yet unexplored potential. In this paper, we will investigate how the powertrain efficiency may possibly benefit, in an integrated drivetrain for a hybrid electric vehicle, based on a turbocharged gasoline engine, of an innovative supercharging system. The compressor and turbine will be mechanically decoupled so as to independently optimize their operation, avoiding turbo lag and maximizing energy recovery by completely eliminating the waste-gate valve. This, in turns, requires changing the turbine so as to have a flattest possible efficiency/load curve. Therefore, an ad-hoc designed turbine will be implemented in the decoupled configuration, to be used to drive an electrical generator and produce electrical energy for charging the battery. This study presents a preliminary assessment of the potential of a turbo-compounded system for a 1L turbocharged gasoline engine for a small city car. To this aim, a one-dimensional dynamic model of the engine has been built in GT-Suite and has been calibrated and validated by means of experimental data obtained on a dynamometer, both in steady state and dynamic conditions. In particular, the model has been calibrated by means of experimental data obtained in stationary conditions and its robustness has then been verified through experimental data obtained under transient conditions. The model also includes data retrieved from the characterization of the existing turbine and compressor, while a new performance map for the turbine has been designed to better exploit the potential of the components’ decoupling. Results include the estimation of energy recovery potential of such a solution. Under the implementation of a straightforward control strategy, which runs both compressor and turbine at the same speed, the system is able to achieve a 60.57% increase in energy recovered from the exhaust gasses in the turbine. Afterwards, an attempt was made to limit the minimum turbine speed to 45000 rpm and simultaneously decrease the instantaneous speed by 3000 rpm compared to the compressor, attaining a further increase of 1.7% in the energy recovered by the turbine. Full article

As environmental regulations on automotive exhaust gas are gradually strengthened to cope with climate change, internal combustion engines, including those in hybrid electric vehicles, are continuously being downsized. Supercharging technologies are essential to compensate for the reduced engine power. One of the supercharging technologies, the turbocharger, has a response delay in the low-speed region, which is known as turbo lag. Various technologies have emerged to reduce turbo lag. Recently, electric supercharging technologies capable of reducing turbo lag using high-speed motors have been developed and commercialized. However, they are difficult to obtain for high-speed motors because of the cost of load performance test equipment. For this reason, many previous studies have compared analysis and experiment results under no-load conditions, or they have estimated performance in the high-speed region from results at low speed with light loads. This makes it difficult to know exactly how the performance of the motor is affected under loads applied to an actual system. In this study, performance test evaluation was conducted using a high-speed torque sensor, eddy current brake, and inertial dynamometer. Input/output power and efficiency were calculated using the measured voltage, current and output side torque and speed, and the results were compared. Full article

Hydrogen is an effective route for achieving zero carbon dioxide emissions, with a contained cost compared to electric powertrains. When considering the conversion of spark ignition (SI) engines to H₂ fueling, relatively minor changes are required in terms of added components. This study looks at the possibility of converting a small-size passenger car powered by a turbocharged SI unit. The initial evaluation of range and peak power showed that overall, the concept is feasible and directly comparable to the electric version of the vehicle in terms of powertrain performance. Injection phasing effects and cylinder imbalance were found to be potential issues. Therefore, the present work applied an 0D/1D simulation for investigating the effects of hydrogen fueling with respect to the likelihood of backfire. A range of engine speeds and load settings were scrutinized for evaluating the possibility of achieving the minimal risk of abnormal combustion due to pre-ignition. Ensuring the correct flow was predicted to be essential, especially at high loads and engine speeds. Fuel delivery phasing with respect to valve intake and closing events was also found to be a major factor that influenced not only backfire occurrence but conversion efficiency as well. Interactions with the electronic control unit were also evaluated, and additional requirements compared to standard conversion kits for LPG or CNG fueling were identified. Full article

The proposed changes to the legislation on diesel cars require intensification of work on the possibilities of reducing emissions of harmful substances into the atmosphere by these vehicles. The subject of experimental research included in the manuscript was the Skoda Octavia with a 1.9 TDI (turbocharged direct injection) compression ignition engine (type 1Z). Light absorption measurements of smokiness of the exhaust gases emitted after combustion of various biofuels (conventional diesel, pure hydrotreated vegetable oil, hydrotreated vegetable oil, biobutanol) and their blends with fossil diesel fuel were studied. The measured light absorption coefficient is the reciprocal of the thickness of the layer, after passing through which the light has a ten times lower intensity. Its unit is the reciprocal of the meter (1/m or m⁻¹). The results obtained by means of a standard smokiness meter indicate that the use of biofuels or their blends, in general, reduces smoke formation. Full article

Electrification is considered an optimal long-term solution for the decarbonization of the transport sector. However, in the medium period, propulsion systems will continue to dominate urban mobility, thus requiring the shift from fossil fuels toward low carbon fuels. In this regard, the request from the EU to achieve carbon neutrality by 2050 is encouraging the use of innovative fuels and powertrains. Alcohols such as ethanol and methanol are particularly suitable for spark ignition engines. This paper investigates the effect of ethanol/methanol blends on the performance and emissions of a turbocharged direct injection spark ignition engine running on the worldwide harmonized light vehicles test cycle. Three blends were considered, consisting of 10% v/v ethanol (E10), 25% v/v ethanol (E25) and 5% v/v ethanol with 15% v/v methanol (E5M15). Gaseous and particle emissions were measured at the exhaust. The main novelty of the study regards the investigation of the behavior of alcohol blends, especially those based on methanol, in transient conditions. It was found that CO, THC and NO_x emissions decrease with the increase in alcohol content in the blend, with different contributions in the different phases of the cycle. Particle emissions decrease for E10 and even more so for E25. When methanol is added to the blend, particle emissions increase with respect to E25 and they are characterized by a larger diameter. Full article

The efficiency of hybrid electric vehicles may be substantially increased if the energy of exhaust gases, which do not complete the expansion inside the cylinder of the internal combustion engine, is efficiently recovered using a properly designed turbo-generator and employed for vehicle propulsion. Previous studies, carried out by the same authors of this work, showed a potential hybrid vehicle fuel efficiency increment up to 15% employing a 20 kW turbine on a 100 HP-rated power thermal unit. The innovative thermal unit proposed here is composed of a supercharged engine endowed with a properly designed turbo-generator, which comprises two fundamental elements: an exhaust gas turbine expressly designed and optimized for the application, and a suitable electric generator necessary to convert the recovered energy into electric energy, which can be stored in the on-board energy storage system of the vehicle. In this two-part work, the realistic efficiency of the innovative thermal unit for hybrid vehicles is evaluated and compared to a traditional turbocharged engine. In Part 1, the authors presented a model for the prediction of the efficiency of a dedicated radial turbine, based on a simple but effective mean-line approach; the same paper also reports a design algorithm, which, thanks to some assumptions and approximations, allows fast determination of the right turbine geometry for a given design operating condition. It is worth pointing out that, being optimized for quasi-steady power production, the exhaust gas turbine here considered is quite different from the ones commonly employed for turbocharging applications; for this reason, and in consideration of the required power size, such a turbine is not available on the market, nor has its development been previously carried out in the scientific literature. In this paper, Part 2, a radial turbine geometry is defined for the thermal unit previously calculated, employing the design algorithm described in Part 1; the realistic energetic advantages that could be achieved by the implementation of the turbo-generator on a hybrid propulsion system are evaluated through the performance prediction model under different operating conditions of the thermal unit. As an overall result, it was estimated that, compared to a reference traditional turbocharged engine, the turbo-compound system could gain vehicle efficiency improvement between 3.1% and 17.9%, according to the output power delivered, with an average efficiency increment of 10.9% evaluated on the whole operating range. Full article

The efficiency of Hybrid Electric Vehicles (HEVs) may be substantially increased if the energy of the exhaust gases, which do not complete the expansion inside the cylinder of the internal combustion engine, is efficiently recovered by means of a properly designed turbogenerator and employed for vehicle propulsion; previous studies, carried out by the same authors of this work, showed a potential hybrid vehicle fuel efficiency increment up to 15% by employing a 20 kW turbine on a 100 HP rated power thermal unit. The innovative thermal unit here proposed is composed of a supercharged engine endowed with a properly designed turbogenerator, which comprises two fundamental elements: an exhaust gas turbine expressly designed and optimized for the application, and a suitable electric generator necessary to convert the recovered energy into electric energy, which can be stored in the on-board energy storage system of the vehicle. In these two parts, the realistic efficiency of the innovative thermal unit for hybrid vehicle is evaluated and compared to a traditional turbocharged engine. In Part 1, the authors present a model for the prediction of the efficiency of a dedicated radial turbine, based on a simple but effective mean-line approach; the same paper also reports a design algorithm, which, owing to some assumptions and approximations, allows a fast determination of the proper turbine geometry for a given design operating condition. It is worth pointing out that, being optimized for quasi-steady power production, the exhaust gas turbine considered is quite different from the ones commonly employed for turbocharging application; for this reason, and in consideration of the required power size, such a turbine is not available on the market, nor has its development been previously carried out in the scientific literature. In the Part 2 paper, a radial turbine geometry is defined for the thermal unit previously calculated, employing the design algorithm described in Part 1; the realistic energetic advantage that could be achieved by the implementation of the turbogenerator on a hybrid propulsion system is evaluated through the performance prediction model under the different operating conditions of the thermal unit. As an overall result, it was estimated that, compared to a reference traditional turbocharged engine, the turbocompound system could gain vehicle efficiency improvement between 3.1% and 17.9%, depending on the output power level, while an average efficiency increment of 10.9% was determined for the whole operating range. Full article

The turbocharger, a key component in a vehicle’s powertrain, results in insufficient accuracy if it does not fully consider the unsteady flow effects of the intake and exhaust systems. Based on the difference between the turbocharger’s actual operating performance with unsteady flow and the corresponding steady flow performance, unsteady flow correction concepts and correction methods for the compressor and turbine were put forward, and the correction of the internal joint operation curve was investigated. The results show that when unsteady correction coefficients were added to both ends of the turbocharger and the optimized structure was used at both ends, the original turbocharger’s surge margin was reduced by 4.6% to 11.8%, and that of the optimized turbocharger was reduced by 15.2% to 21.9% in the medium–low-speed range. Meanwhile, the unsteady flow energy utilization coefficient of the optimized turbocharger was more than 14.5% higher than that of the original turbocharger in the medium–low speed range, and the energy utilization advantage was obvious. It indicated that the optimized turbocharger was working earlier, and the engine’s medium–low-speed admission performance has been obviously improved. Therefore, compared with the steady curve, the corrected unsteady curve was closer to the actual engine performance. Full article

An energy management control strategy based on the instantaneous optimization method of equivalent consumption minimization strategy (ECMS) under motor power compensation for mild hybrid vehicles is proposed in this study to improve fuel economy and ensure the dynamic performance of cars. A mild hybrid platform is built, and the future supplementary model of electric energy and the future consumption model of electric energy are established according to different power flow directions. It determines the equivalent fuel consumption rate of powertrain as the objective function by defining the equivalent factor and corresponding derivation, carries out optimization calculation, and obtains the energy distribution relationship between the engine and the motor. The motor power compensation strategy based on the control strategy is adopted to solve the effect of turbocharged engines’ transient response on vehicle dynamics and fuel economy. The actual results showed that vehicle power and fuel economy can be improved under the control strategy and compensation strategy design. Meanwhile, different motors allow the compensating coefficient to have different power-boosting and fuel economy effects. Full article
