Unmanned Surface Vehicle (USV) offers a cost-effective platform for high-resolution marine magnetic surveys using shipborne fluxgate magnetometers. However, platform-induced magnetic interference and electromagnetic interference (EMI) can degrade data quality, even with paramagnetic hulls. This study evaluates fluxgate magnetometer data acquired from a paramagnetic-hulled USV. Noise characterization identified EMI and maneuver-induced high-frequency noise, the latter of which was effectively reduced through low-pass filtering. We compared four different correction approaches addressing both vessel attitude and magnetization. The results demonstrate that the paramagnetic hull significantly reduces magnetic interference and shortens the duration of viscous magnetization (VM) effects caused by eddy currents in the platform, compared to conventional ferromagnetic vessels. Nonetheless, residual magnetization from onboard ferromagnetic components still requires correction. A method utilizing all nine components of the susceptibility tensor demonstrated improved accuracy and stability. Despite corrections, low-frequency VM-related noise during azimuth changes and a consistent absolute offset (~200 nT) remain when compared to towed scalar magnetometer data. These findings validate the use of paramagnetic USV for vector magnetic surveys, highlighting their benefit in VM mitigation while emphasizing the need for further development in VM correction and offset correction to achieve high-precision measurements. Full article

We have developed a miniaturized magnetic sensor based on diamond nitrogen-vacancy (NV) centers, combined with a two-dimensional scanning setup that enables imaging magnetic samples with millimeter-scale resolution. Using the lock-in detection scheme, we tracked changes in the NV’s spin resonances induced by the magnetic field from target samples. As a proof-of-principle demonstration of magnetic imaging, we used a toy diorama with hidden magnets to simulate scenarios such as the remote detection of landmines on a battlefield or locating concealed objects at a construction site, focusing on image analysis rather than addressing sensitivity for practical applications. The obtained magnetic images reveal that they can be influenced and distorted by the choice of frequency point used in the lock-in detection, as well as the magnitude of the sample’s magnetic field. Through magnetic simulations, we found good agreement between the measured and simulated images. Additionally, we propose a method based on NV vector magnetometry to compensate for the non-zero tilt angles of a target, enabling the accurate localization of its position. This work introduces a novel imaging method using a scanning miniaturized magnetometer to detect hidden magnetic objects, with potential applications in military and industrial sectors. Full article

Atomic magnetometers are highly sensitive instruments widely used for measurements of weak magnetic field. Extracting vector information while maintaining high-precision scalar detection has become the trend in atomic magnetometer development. We introduce a vector atomic magnetometer containing a 5 mm-thick microfabricated vapor cell operating in free-induction-decay mode. By employing orthogonal modulation techniques, the system achieves high-precision in-plane vector magnetic field measurements. The high-precision vector magnetic field measurements are demonstrated in the x–z plane. The sensitivity of the total field detection in the miniaturized atomic magnetometer is 30 pT·Hz^−1/2 @11 µT. The average angular error of the decoupled measurement is as low as 4.7 mrad @7.6 µT for vector magnetic fields, providing a new approach for vector magnetic field measurement in miniaturized atomic magnetometers. Full article

In the past few decades, there has been a notable technological advancement in geophysical sensors. In the case of magnetometry, several sensors were used, having the common feature of being miniaturized and lightweight, thus idoneous to be carried by UAVs in drone-borne magnetometric surveys. A common feature is that their sensitivity ranges from 0.1 to about 200 nT, thus not comparable to that of optically pumped, standard fluxgate or even proton magnetometers. However, their low cost, volume and weight remain very interesting features of these sensors. In fact, such sensors have the common feature of being very inexpensive, so new ways of making surveys using many of these sensors could be devised, in addition to the possibility, even with limited resources, of creating gradiometers by combining two or more of them. In this paper, we explore the range of applicability of small tri-axial magnetometers commonly used for attitude determination in several devices. We compare the results of surveys performed with standard professional geophysical instruments with those obtained using these sensors and find that in the presence of strongly magnetized sources, they succeeded in identifying the main anomalies. Full article

This paper reports the successful application of a self-developed, miniaturized, low-power nano-star tracker for precise attitude measurement of a 5-m-long satellite extension boom. Such extension booms are widely used in space science missions to extend and support payloads like magnetometers. The nano-star tracker, based on a CMOS image sensor, weighs 150 g (including the baffle), has a total power consumption of approximately 0.85 W, and achieves a pointing accuracy of about 5 arcseconds. It is paired with a low-cost, commercial lens and utilizes automated calibration techniques for measurement correction of the collected data. This system has been successfully applied to the precise attitude measurement of the 5-m magnetometer boom on the Chinese Advanced Space Technology Demonstration Satellite (SATech-01). Analysis of the in-orbit measurement data shows that within shadowed regions, the extension boom remains stable relative to the satellite, with a standard deviation of 30′′ (1σ). The average Euler angles for the “X-Y-Z” rotation sequence from the extension boom to the satellite are [−89.49°, 0.08°, 90.11°]. In the transition zone from shadow to sunlight, influenced by vibrations and thermal factors during satellite attitude adjustments, the maximum angular fluctuation of the extension boom relative to the satellite is approximately ±2°. These data and the accuracy of the measurements can effectively correct magnetic field vector measurements. Full article

Falls represent a significant risk factor, necessitating accurate classification methods. This study aims to identify the optimal placement of wearable sensors—specifically accelerometers, gyroscopes, and magnetometers—for effective fall-direction classification. Although previous research identified optimal sensor locations for distinguishing falls from non-falls, limited attention has been given to the classification of fall direction across different body regions. This study assesses inertial measurement unit (IMU) sensors placed at 12 distinct body locations to determine the most effective positions for capturing fall-related data. The research was conducted in three phases: first, comparing classifiers across all sensor locations to identify the most effective; second, evaluating performance differences between sensors placed on the left and right sides of the body; and third, exploring the efficacy of combining sensors from the upper and lower body regions. Statistical analyses of the results for the most effective classifier model demonstrate that the support vector machine (SVM) is more effective than other classifiers across all sensor locations, with statistically significant differences in performance. At the same time, the comparison between the left and right sensor locations shows no significant performance differences within the same anatomical areas. Regarding optimal sensor placement, the findings indicate that sensors positioned on the pelvis and upper legs in the lower body, as well as on the shoulder and head in the upper body, were the most effective results for accurate fall-direction classification. The study concludes that the optimal sensor configuration for fall-direction classification involves strategically combining sensors placed on the pelvis, upper legs, and lower legs. Full article

In practical application, existing two-point magnetic gradient tensor (MGT) localization methods have a maximum detection distance of only 2.5 m, and the magnetic moment vectors of measured targets are all unknown. In order to realize remote, real-time localization, a new two-point magnetic localization method based on self-developed, ultra-sensitive superconducting quantum interference device (SQUID) magnetometers and MGT invariants is proposed. Both the magnetic moment vector and the relative position vector can be directly calculated based on the linear positioning model, and a quasi-Newton optimization algorithm is adopted to further improve the interference suppression capability. The simulation results show that the detection distance of the proposed method can reach 500 m when the superconducting MGT measurement system is used. Compared with Nara’s single-point tensor (NSPT) method and Xu’s two-point tensor (XTPT) method, the proposed method produces the smallest relative localization error (i.e., significantly less than 1% in the non-positioning blind area) without sacrificing real-time characteristics. The causes of and solutions to the positioning blind area are also analyzed. The equivalent experiments, which were conducted with a detection distance of 10 m, validate the effectiveness of the localization method, yielding a minimum relative localization error of 4.5229%. Full article

This study presents an unmanned aerial vehicle (UAV)-borne vector magnetometer (MAG) system and proposes a new data-processing technique for modeling the residual magnetic anomalies of three types of landmines: the metallic antitank M15, the metallic antipersonnel M16, and the minimum-metal antitank M19. The burial depth and magnetic moment of these landmines were estimated using the measured and simulated residual magnetic anomalies based on the proposed UAV-borne vector MAG model. Initial in-flight validation showed a strong correlation between the residual magnetic anomaly maps obtained from measurements and simulations. To verify the detection capability in real-world conditions, the UAV-borne MAG system was tested at the Korean Combat Training Center. Both simulations and experiments demonstrated the effectiveness of the proposed data-processing method and UAV-borne MAG model in accurately modeling the residual magnetic anomalies of landmines with metallic components. This approach will facilitate the automated detection of M15, M16, and M19 landmines with high detection rates and enable accurate classification. Full article

Magnetoencephalography (MEG) non-invasively provides important information about human brain electrophysiology. The growing use of optically pumped magnetometers (OPM) for MEG, as opposed to fixed arrays of cryogenic sensors, has opened the door for innovation in system design and use cases. For example, cryogenic MEG systems are housed in large, shielded rooms to provide sufficient space for the system dewar. Here, we investigate the performance of OPM recordings inside of a cylindrical shield with a 1 × 2 m² footprint. The efficacy of shielding was measured in terms of field attenuation and isotropy, and the value of post hoc noise reduction algorithms was also investigated. Localization accuracy was quantified for 104 OPM sensors mounted on a fixed helmet array based on simulations and recordings from a bespoke current dipole phantom. Passive shielding attenuated the vector field magnitude to 50.0 nT at direct current (DC), to 16.7 pT/√Hz at power line, and to 71 fT/√Hz (median) in the 10–200 Hz range. Post hoc noise reduction provided an additional 5–15 dB attenuation. Substantial field isotropy remained in the volume encompassing the sensor array. The consistency of the isotropy over months suggests that a field nulling solution could be readily applied. A current dipole phantom generating source activity at an appropriate magnitude for the human brain generated field fluctuations on the order of 0.5–1 pT. Phantom signals were localized with 3 mm localization accuracy, and no significant bias in localization was observed, which is in line with performance for cryogenic and OPM MEG systems. This validation of the performance of a small footprint MEG system opens the door for lower-cost MEG installations in terms of raw materials and facility space, as well as mobile imaging systems (e.g., truck-based). Such implementations are relevant for global adoption of MEG outside of highly resourced research and clinical institutions. Full article

A typical magnetometer-based measurement-while-drilling (MWD) system determines the azimuth of the bottom hole assembly during the drilling process by employing triaxial accelerometers and magnetometers. The geomagnetic azimuth solution is susceptible to magnetic interference, especially strong magnetic interference and so a rotary norm constraint filtering (RNCF) method for azimuth estimation, designed to support a gyroscope-aided magnetometer-based MWD system, is proposed. First, a new magnetic dynamical system, one whose output is observed by the magnetometers triad, is designed based on the Coriolis equation of the desired geomagnetic vector. Second, given that the norm of the non-interfered geomagnetic vector can be approximated as a constant during a short-term drilling process, a norm constraint procedure is introduced to the Kalman filter. This is achieved by the normalization of the geomagnetic part of the state vector of the dynamical system and is undertaken in order to obtain a precise geomagnetic component. Simulation and actual drilling experiments show that the proposed RNCF method can effectively improve the azimuth measurement precision with 98.5% over the typical geomagnetic solution and 37.1% over the KF in a RMSE sense when being strong magnetic interference environment. Full article

This research proposes a magnetic field sensor with spatial orientation ability. Through the assistance of a magnetic flux concentrator, out-of-plane magnetic flux can be concentrated and guided into the planar magnetic cores of a fluxgate sensor. A printed circuit board is used to construct the basic planar structure, on which the proposed three-dimensional magnetic flux concentrator and magnetic cores are assembled. This reduces the alignment error of the coils and improves the reliability of the sensor. Three-axis sensing is achieved by using the second harmonic signals from selected sensing coil pairs. The magnetometer exhibits a linear range to 130 μT. At an excitation frequency of 50 kHz, the measured sensitivities are 257.1, 468.8, and 258.8 V/T for the X-, Y-, and Z-axis sensing modes, respectively. This sensor utilizes only one sensing mechanism for the vector field, making it suitable for IoT applications, especially for assessing mechanical posture or position. Full article

Studying the spatial response of a single-axis magnetometer could be the key parameter to optimize the ultimate performances of magnetic heads of detection. Indeed, the problem of non-orthogonality, misalignment, and 3D spatial response could be improved based on the knowledge of the 3D sensor spatial response. In that way, we have investigated the latter for our giant magneto-impedance (GMI) magnetometer, as a far-field pattern, by using a three-axis Helmholtz coil system. Firstly, we calibrate our device and secondly, we apply a specific 3D magnetic field to obtain this pattern. The latter helps to observe the directional or angular dependence of the sensor sensitivity versus the applied magnetic field, as we exemplified. The results confirm the excellent directivity of our off-diagonal GMI magnetometer. The evaluation of the associated error compared to an ideal vector magnetometer is also given and discussed. Full article

To overcome the shortcoming wherein the accuracy of subsea cable detection can be affected by the determination of the bias vector, scale factors, and non-orthogonality corrections of the vector magnetometer, a real-time attitude-independent route tracking method for subsea power cables is investigated theoretically and experimentally by means of scalar magnetic field checking. The measurement of the magnetic field B_c produced by the current in a cable is made immune to the influence of the platform attitude by extracting the component of B_c along the geomagnetic field using a high-bandwidth self-oscillating optically pumped magnetometer. The self-oscillating frequency is proved to be independent of the attitude of the magnetometer with the theoretical model. Experiments are carried out to test the attitude-independent performance, and the effectiveness of route tracking is verified by the results of the sea experiment. The proposed method will effectively improve the ability to locate subsea cables under high sea conditions. Full article

The paper presents a method for estimating the inertia tensor components of a spacecraft that has expired its active life using measurement data of the Earth’s magnetic field induction vector components. The implementation of this estimation method is supposed to be carried out when cleaning up space debris in the form of a clapped-out spacecraft with the help of a space tug. It is assumed that a three-component magnetometer and a transmitting device are attached on space debris. The parameters for the rotational motion of space debris are estimated using this measuring system. Then, the known controlled action from the space tug is transferred to the space debris. Next, measurements for the rotational motion parameters are carried out once again. Based on the available measurement data and parameters of the controlled action, the space debris inertia tensor components are estimated. It is assumed that the measurements of the Earth’s magnetic field induction vector components are made in a coordinate system whose axes are parallel to the corresponding axes of the main body axis system. Such an estimation makes it possible to effectively solve the problem of cleaning up space debris by calculating the costs of the space tug working body and the parameters of the space debris removal orbit. Examples of numerical simulation using the measurement data of the Earth’s magnetic field induction vector components on the Aist-2D small spacecraft are given. Thus, the purpose of this work is to evaluate the components of the space debris inertia tensor through measurements of the Earth’s magnetic field taken using magnetometer sensors. The results of the work can be used in the development and implementation of missions to clean up space debris in the form of clapped-out spacecraft. Full article

As micro-electro-mechanical systems (MEMS) technology continues its rapid ascent, a growing array of smart devices are integrating lightweight, compact, and cost-efficient magnetometers and inertial sensors, paving the way for advanced human motion analysis. However, sensors housed within smartphones frequently grapple with the detrimental effects of magnetic interference on heading estimation, resulting in diminished accuracy. To counteract this challenge, this study introduces a method that synergistically employs convolutional neural networks (CNNs) and support vector machines (SVMs) for adept interference detection. Utilizing a CNN, we automatically extract profound features from single-step pedestrian motion data that are then channeled into an SVM for interference detection. Based on these insights, we formulate heading estimation strategies aptly suited for scenarios both devoid of and subjected to magnetic interference. Empirical assessments underscore our method’s prowess, boasting an impressive interference detection accuracy of 99.38%. In indoor environments influenced by such magnetic disturbances, evaluations conducted along square and equilateral triangle trajectories revealed single-step heading absolute error averages of 2.1891° and 1.5805°, with positioning errors averaging 0.7565 m and 0.3856 m, respectively. These results lucidly attest to the robustness of our proposed approach in enhancing indoor pedestrian positioning accuracy in the face of magnetic interferences. Full article
