Search Results (71)

The object of this study is welded joints of AISI 321 and Ti-6Al-4V, obtained by diffusion welding on developed conical surfaces. The problem of creating bimetallic joints of AISI 321 and Ti-6Al-4V with developed conical contact surfaces, using diffusion welding through an intermediate Electrolytic Tough Pitch Copper (Cu-ETP) copper layer, was solved. The joints were studied using micro-X-ray spectral analysis, microstructural analysis, and mechanical tests. High mutual diffusion of copper and titanium, along with increased concentrations of Cr and V in copper, was detected. The shear strength of the obtained welded joints is 250 MPa and 235 MPa at 30 min and 15 min, respectively, which is higher than the copper layer’s strength (180 MPa). The obtained results are explained by the dislocation diffusion mechanism in the volume of grains and beyond, due to thermal deformations during welding. Under operating conditions of internal pressure and cryogenic temperatures, the strength of the connection is ensured by the entire two-layer structure, and tightness is ensured by a vacuum-tight diffusion connection. The obtained strength of the connection (250 MPa) is sufficient under the specified operating conditions. Analysis of existing solutions in the literature review indicates that industrial application of technology for manufacturing bimetallic adapters from AISI 321 stainless steel and Ti-6Al-4V titanium alloy is limited to butt joints with small geometric dimensions. Studies of the transition zone structure and diffusion processes in bimetallic joints with developed conical contact surfaces enabled determination of factors affecting joint structure and diffusion coefficients. The obtained bimetallic adapters, made of Ti-6Al-4V titanium alloy and AISI 321 stainless steel, can be used to connect titanium high-pressure vessels with stainless steel pipelines. Full article

Plasma, an ionized gas composed of charged particles, has shown therapeutic potential in enhancing biological processes such as wound healing and tissue integration. Implants, such as silicone and human acellular dermal matrix (hADM), are commonly used in reconstructive surgery, but improving their biocompatibility and integration remains a challenge. This study investigated the effects of vacuum plasma treatment on silicone and hADM implants using an in vivo rat model. Plasma-treated and untreated implants were inserted subcutaneously, and tissue samples were collected at 1, 4, and 8 weeks post-implantation. Histological and immunohistochemical analyses were performed to assess inflammation, cellular infiltration, collagen formation (neocollagenesis), and angiogenesis. Results showed that plasma-treated silicone and hADM implants had significantly reduced capsule thickness at weeks 4 and 8 compared to untreated controls, indicating a lower chronic inflammatory response. Plasma treatment also promoted greater fibroblast infiltration and enhanced neocollagenesis within the hADM implants. Furthermore, immunohistochemical staining revealed a notable increase in blood vessel formation around and within the plasma-treated hADM implants, suggesting improved vascularization. In conclusion, vacuum plasma treatment enhances the biocompatibility and tissue integration of implants by reducing inflammation and promoting cellular and vascular responses, offering promising potential for improving outcomes in reconstructive surgery. Full article

Fuel cells, propulsion systems, and reaction control systems (RCSs) are just a few of the space applications that depend on pressure vessels (PVs) to safely hold high-pressure fluids while enduring extreme environmental conditions both during launch and in orbit. Under these challenging circumstances, PVs must be lightweight while retaining structural integrity in order to increase the efficiency and lower the launch costs. PVs have significant challenges in space conditions, such as extreme vibrations during launch, the complete vacuum of space, and sudden temperature changes based on their location within the satellite and orbit types. Determining the operational temperature limits and endurance of PVs in space applications requires assessing the combined effects of these factors. As the main propellant for satellites and rockets, hydrogen has great promise for use in future space missions. This study aimed to assess the structural integrity and determine the thermal operating limits of different types of hydrogen pressure vessels using finite element analysis (FEA) with Ansys 2019 R3 Workbench. The impact of extreme space conditions on the performances of various kinds of hydrogen pressure vessels was analyzed numerically in this work. This study determined the safe operating temperature ranges for Type 4, Type 3, and Type 1 PVs at an operating hydrogen storage pressure of 35 MPa in an absolute vacuum. Additionally, the dynamic performance was assessed through modal and random vibration analyses. Various aspects of Ansys Workbench were explored, including the influence of the mesh element size, composite modeling methods, and their combined impact on the result accuracy. In terms of the survival temperature limits, the Type 4 PVs, which consisted of a Nylon 6 liner and a carbon fiber-reinforced epoxy (CFRE) prepreg composite shell, offered the optimal balance between the weight (56.2 kg) and a relatively narrow operating temperature range of 10–100 °C. The Type 3 PVs, which featured an Aluminum 6061-T6 liner, provided a broader operational temperature range of 0–145 °C but at a higher weight of 63.7 kg. Meanwhile, the Type 1 PVs demonstrated a superior cryogenic performance, with an operating range of −55–54 °C, though they were nearly twice as heavy as the Type 4 PVs, with a weight of 106 kg. The absolute vacuum environment had a negligible effect on the mechanical performance of all the PVs. Additionally, all the analyzed PV types maintained structural integrity and safety under launch-induced vibration loads. This study provided critical insights for selecting the most suitable pressure vessel type for space applications by considering operational temperature constraints and weight limitations, thereby ensuring an optimal mechanical–thermal performance and structural efficiency. Full article

With the increasing severity of climate change, Carbon Capture, Utilization, and Storage (CCUS) technology has become essential for reducing atmospheric CO₂. Marine carbon sequestration, which stores CO₂ in seabed geological structures, offers advantages such as large storage capacity and high stability. Cryogenic hoses are critical for the ship-to-ship transfer of liquid CO₂ from transportation vessels to offshore carbon sequestration platforms, but their design methods and mechanical analysis remain inadequately understood. This study reviews existing cryogenic hose designs, including reinforced corrugated hoses, vacuum-insulated hoses, and composite hoses, to assess their suitability for liquid CO₂ transfer. Based on CO₂’s physicochemical properties, a conceptual composite hose structure is proposed, featuring a double-spring-supported internal composite hose, thermal insulation layer, and outer sheath. Practical recommendations for material selection, corrosion prevention, and monitoring strategies are provided to improve flexibility, pressure resistance, and thermal insulation, enabling reliable long-distance tandem transfer. A mechanical analysis framework is developed to evaluate structural performance under conditions including mechanical loads, thermal stress, and dynamic responses. This manuscript includes an introduction to the background, the methodology for data collection, a review of existing designs, an analysis of CO₂ characteristics, the proposed design methods, the mechanical analysis framework, a discussion of challenges, and the conclusions. Full article

As environmental pollution has become a global concern, regulations on carbon emissions from maritime activities are being implemented, and interest in using renewable energy as fuel for ships is growing. Hydrogen, which does not release carbon dioxide and has a high energy density, can potentially replace fossil fuels as a renewable energy source. Notably, storage of hydrogen in a liquid state is considered the most efficient. In this study, a 0.7 m³ liquid hydrogen fuel tank suitable for small vessels was designed, and a structural analysis was conducted to assess its structural integrity. The extremely low liquefaction temperature of hydrogen at −253 °C and the need for spatial efficiency in liquid hydrogen fuel tanks make vacuum insulation essential to minimize the heat transfer due to convection. A composite insulation system of sprayed-on foam insulation (SOFI) and multilayer insulation (MLI) was applied in the vacuum annular space between the inner and outer shells, and a tube-shaped supporter made of a G-11 cryogenic (CR) material with low thermal conductivity and high strength was employed. The material selected for the inner and outer layers of the tank was STS 316L, which exhibits sufficient ductility and strength at cryogenic temperatures and has low sensitivity to hydrogen embrittlement. The insulation performance was quantitatively assessed by calculating the boil-off rate (BOR) of the designed fuel tank. Structural integrity evaluations were conducted for nine load cases using heat transfer and structural analyses in accordance with the IGF code. Full article

This paper introduces a self-consistent field-null optimization algorithm of a poloidal magnetic field that precisely accounts for the influence of vacuum vessel eddy currents. Building on existing poloidal field (PF) coil currents, the algorithm can refine these waveforms to achieve various target field-null configurations. Firstly, based on the TokSys toolbox, a response model, including the PF coils and vacuum vessel circuits for the HL-3 tokamak, is developed under the MATLAB^® and Simulink^™ framework. The resistivity parameters of the model are calibrated using experimental data obtained from single-coil discharge tests. Subsequently, an iterative method was employed to simultaneously solve the dynamic field-null optimization problem within a specified spatial region and precisely account for the effect of passive eddy currents. Typically, $\left|B_{\perp }\right|\le 1 G$ within a large area can be obtained with this iterative scheme, which can be stably sustained for over 15 milliseconds to ensure the robustness of breakdown. Finally, a low-pass filtered PID controller is applied to the model to achieve precise control of the PF coils currents, confirming the feasibility of implementing the proposed algorithm in real experiments. Full article

The existing vacuum fish pump is too large and difficult to move, which is difficult to apply to small fishing vessels. However, the development of a small vacuum fish pump is not a single scaling of the existing vacuum fish pump but requires the support of relevant experiments and simulation theories. In this study, a vacuum fish pump suitable for small fishing vessels was developed. Firstly, a numerical model of the internal flow field during the vacuum fish pump’s working process was established using computational fluid dynamics (CFDs) and verified its effectiveness by physical experiments. It is found that the VOF model can well predict the variation of the volume fraction of the liquid phase in the whole calculation area with time during the suction or drainage process of the vacuum fish pump. Then, the internal flow field characteristics of the fish pump under different working conditions were simulated, and the rationality of the design of the fish pump was evaluated according to the numerical results. Finally, a separate physical experiment was carried out on grass carp, carp, crucian carp, silver carp, and bighead carp, respectively, and the capture efficiency and corresponding fish damage rate for different fish were analyzed. The experimental and numerical results show that the vacuum suction fish pump can achieve efficient and automatic suction and transport of live fish. Full article

Heavy crude oil processing presents significant challenges owing to its complex composition and requirement for processing conditions, which increase the process safety risk in crude processing units, such as fixed equipment, for instance pressure vessels and pipes. The aim of this work is to evaluate the influence of heavy crude oils named A and B and the effect of sulfur-rich compounds and organic acids on the performance at high temperatures of three metallic alloys (5Cr-1/2Mo/ASTM A335GP5, X6CrNiMoTi17122/AISI-SAE 316Ti and Ni66.5Cu31.5/Monel 400) and propose an alternative to be used in pressure vessels and piping in refineries. This work was based on the need to understand the corrosivity of two heavy crude oils (A and B) from eastern Colombia in three materials, evaluated at three temperatures (200 °C, 250 °C and 300 °C) under the same conditions of pressure (200 psi) and rotation velocity (600 rpm) in a dynamic autoclave to simulate atmospheric conditions and conditions in vacuum refinery towers. An understanding of how these factors interact with the fundamental principles of corrosion kinetics is essential for developing an effective corrosion mitigation strategy. The results were interesting for applications requiring high corrosion resistance. X6CrNiMoTi17122/AISI-SAE 316Ti is a solid candidate for this application, with corrosion rates of 0.2 to 0.87 mpy. Ni66.5Cu31.5/Monel 400 exhibited significant corrosion rates up to 74.89 mpy, especially at higher temperatures (300 °C). 5Cr-1/2Mo/ASTM A335GP5 showed a generally moderate corrosion rate (2.04–5.57 mpy) in the evaluated temperature range. Full article

Rupture discs, also known as bursting discs, are indispensable components in fluid-operated systems providing effective protection against hazardous over-pressure or partial vacuum. They belong to a special class of safety devices and are found in a variety of technical applications including pressure vessels, piping systems, reactors and boilers. In all application scenarios, rupture discs act as sacrificial parts that have to fail precisely at a predetermined differential pressure, opening a relief flow path for the working fluid. The membrane employed within rupture discs is usually made out of specific metal alloys or different material layers depending on the particular application. However, for many manufacturers of rupture discs, the production process is characterized by a lack of systematic procedures, relying instead on trial and error as well as empirical values. By means of thorough finite-element-based modeling and simulation of the bulge-forming process of rupture discs, including an elastic–plastic material law, large deformation, as well as contact mechanics, it is possible to accurately predict the resulting stress–strain behavior. All simulation results are rigorously validated through corresponding experiments conducted during the bulge-forming process. Therefore, this contribution provides a reliable basis for the parameter set-up during the manufacturing process of rupture discs. Full article

Highly intense bunches of protons and ions with energies of several MeV/u can be generated with ultra-short laser pulses focused on solid targets. In the most common interaction regime, target normal sheath acceleration, the spectra of these particles are spread over a wide range following a Maxwellian distribution. We report on the design and testing of a magnetic chicane for the selection of protons within a limited energy window. This consisted of two successive, anti-parallel dipole fields generated by cost-effective permanent C-magnets with customized configuration and longitudinal positions. The chicane was implemented into the target vessel of a petawatt laser facility with constraints on the direction of the incoming laser beam and guidance of the outgoing particles through a vacuum port. The separation of protons and carbon ions within distinct energy intervals was demonstrated and compared to a ray tracing code. Measurements with radiochromic film stacks indicated the selection of protons within [2.4, 6.9] MeV, [5.0, 8.4] MeV, or ≥6.9 MeV depending on the lateral dispersion. A narrow peak at 4.8 MeV was observed with a time-of-flight detector. Full article

The purpose of this research is to solve the complex long-distance and high-lift water supply engineering accident water hammer protection problem. Taking the Zhaojinzhuang water supply project as an example, based on the method of characteristics (MOC), the water hammer of the pumping station under the combined action of a water hammer relief valve, hydraulic-control butterfly valve, air vessel, air valve, and other water hammer protection measures is numerically simulated and calculated, and the effectiveness of the range method is analyzed, to ensure a waterproof hammer in pump stop accidents. The results show that the main factors affecting the effect of water hammer protection under the two-stage valve-closing parameters of the hydraulic-control butterfly valve are the fast-closing angle and the slow-closing time. The arrangement of the air vessel behind the pump can effectively increase the minimum water hammer pressure in the climbing section, and with the increase of the volume of the air vessel, the pump reverse speed and the maximum positive pressure increase slightly, but the overall water hammer protection effect is better. With the increase of the moment of inertia of the motor, the maximum positive pressure and minimum negative pressure of the pipeline still do not meet the requirements of the specification, and the modification cost is relatively large. The combination of the one-stage hydraulic-control butterfly valve, the air valve, the air vessel, and the water hammer relief valve can effectively reduce the volume of the air vessel. Under the optimal method, the maximum positive pressure head is 236.61 m, and the minimum negative pressure head is −3.18 m. Compared with the original method, the maximum positive pressure head is increased by 1.18%, the minimum negative pressure head is reduced by 95.78%, the maximum reverse speed of the pump is reduced by 100%, and the maximum reverse flow of the pump is reduced by 70.27%, meeting the requirements of water hammer protection. This is a safe and economical protection method. Full article

Background: Negative pressure wound therapy (NPWT) is an intensely investigated topic, but its mechanism of action accounts for one of the least understood ones in the area of wound healing. Apart from a misleading nomenclature, by far the most used diagnostic tool to investigate NPWT, the laser Doppler, also has its weaknesses regarding the detection of changes in blood flow and velocity. The aim of the present study is to explain laser Doppler readings within the context of NPWT influence. Methods: The cutaneous microcirculation beneath an NPWT system of 10 healthy volunteers was assessed using two different laser Dopplers (O2C/Rad-97^®). This was combined with an in vitro experiment simulating the compressing and displacing forces of NPWT on the arterial and venous system. Results: Using the O2C, a baseline value of 194 and 70 arbitrary units was measured for the flow and relative hemoglobin, respectively. There was an increase in flow to 230 arbitrary units (p = 0.09) when the NPWT device was switched on. No change was seen in the relative hemoglobin (p = 0.77). With the Rad-97^®, a baseline of 92.91% and 0.17% was measured for the saturation and perfusion index, respectively. No significant change in saturation was noted during the NPWT treatment phase, but the perfusion index increased to 0.32% (p = 0.04). Applying NPWT compared to the arteriovenous-vessel model resulted in a 28 mm and 10 mm increase in the venous and arterial water column, respectively. Conclusions: We suspect the vacuum-mediated positive pressure of the NPWT results in a differential displacement of the venous and arterial blood column, with stronger displacement of the venous side. This ratio may explain the increased perfusion index of the laser Doppler. Our in vitro setup supports this finding as compressive forces on the bottom of two water columns within a manometer with different resistances results in unequal displacement. Full article

Vacuum degassing of seeds is a basic preliminary stage of the treatment process to improve the viability of seeds of various crops. In this work, the degassing process of corn seeds was experimentally and numerically analyzed by removing air or other gases from around the seeds, specifically from the seed coating, in a rough vacuum chamber. Two complementary variants were employed to understand and optimize this process to improve the quality and germination rate of the seeds. The average germination percentage on the first day was about 98%, and the germination speed of 5.0 days. Several experiments were conducted with well-established durations of 10 min and masses of 5 kg and masses of corn seeds at different temperatures to observe and record the behavior of the system, facilitating the modeling of the degasification process in the vacuum compartment. Modeling the degasification operation in the vacuum chamber allowed for determining the pressure profiles on the vacuum chamber and its lid. Numerical simulations were either conducted using a simulation program developed in the Visual Basic Applications (VBA) language for Microsoft Excel to model the degassing process in the vacuum chamber or with the assistance of specialized software (transient structural analysis and simulation program in the ANSYS Workbench environment). Statistical analysis of the correlation between experimental and estimated pressure values revealed that both the proposed mathematical model and the solution method are well-chosen, with differences expressed through the absolute error (EA) being very small, only 1.425 mbar. Structural dynamic analysis carried through the Finite Element Method (FEM) highlights that the chosen materials for manufacturing the vacuum chamber vessel (316 stainless steel—yield strength 225 MPa and tangent modulus 2091 MPa) or the chamber lid (transparent acrylic plastic—yield strength 62.35 MPa and shear modulus 1445.3 MPa) are durable and capable of withstanding the desired pressure and temperature demands in the seed treatment process. Additionally, through structural dynamic analysis, it was possible to study the deformation of system components, providing a detailed perspective on their structural distribution. Thus, the paper aims to improve the quality and survival/germination rate of corn seeds as an important step to improve corn yield through simulations and analyses (numerical and experimental) of the vacuum corn seed degassing system. The degassing process of the vacuum chamber was simulated with a simulation program developed for Microsoft Excel for Microsoft 365 MSO (Version 2401 Build 16.0.17231.20236) 64-bit in the VBA language and software (transient structural dynamic analysis in the ANSYS environment through FEM). Vacuum degassing of corn seeds involves the removal of air or other gases around the seeds or products, which is crucial in various fields such as the food, pharmaceutical, or space technology industries. Full article

The blue honeysuckle berry is a fruit known as a rich source of many bioactive substances with proven health-promoting effects. Due to its sour taste with a noticeable hint of bitterness, fruits of this plant are rarely consumed and the consumer prefers the processed form. The purpose of this study was to evaluate the effect of the cooking method on the biological quality of honeysuckle berry confiture. The selected recipe was used to make confiture in a vacuum evaporator using lowered pressure and in a thermomix vessel under atmospheric pressure. Then, the content of the chosen compounds and antioxidant activity of the two types of confitures were compared. The confitures were analyzed right after production and through 180 days of refrigerated storage. The pH, TA and TSS parameters remained unchanged regardless of the production process and storage time. Ascorbic acid, polyphenol and anthocyanin concentrations were greater in the confiture from vacuum cooking. Also, the same confiture showed a lower rate of degradation of bioactive substances during storage. The antioxidant activity of the two types of confiture was significantly different shortly after production, but equal at the end of 180-day storage. HMF content was four times higher in confitures cooked under atmospheric pressure than under vacuum. The confiture made from the honeysuckle berry was very rich in bioactive compounds, especially polyphenols. Vacuum cooking proved to be the best method for confiture production as a result of lower temperatures used and less aeration of the mass. Full article

With the development of the pressure vessel industry, high-energy wire welding has a great future. However, this means higher demands on the weldability of pressure vessel steels. Controlling inclusions via oxidative metallurgy is a reliable method of improving the weldability of pressure vessel steels. Hence, in this paper, experimental steels with different Mg element mass fractions were prepared using vacuum metallurgy. Simulated welding for high-heat input welding was carried out using the Gleeble-2000 welding thermal simulation test machine. The inclusions in the welding heat-affected zone (HAZ) in the experimental steels were observed using an optical microscope (OM) and scanning electron microscope (SEM). The compositions of the inclusions were analyzed using an energy-dispersive spectrometer (EDS). The research results indicated that the addition of Mg could increase the number density of the inclusions in the welding HAZ. With the addition of Mg from 0 to 5 wt.%, the total number density of the inclusions increased from 133 to 687 pieces/mm^2, and the number density of the inclusions with a size of 0–5 μm² increased from 122 to 579 pieces/mm². The inclusions in the experimental steel welding HAZ with Mg elements were mainly elliptical composite inclusions composed of (Mg-Zr-O) + MnS. Moreover, MnS precipitated on the surface of the Mg-containing inclusions in the welding HAZ. Intragranular acicular ferrite (IAF) nucleation was primarily induced via the minimum lattice mismatch mechanism, supplemented with stress-strain energy and inert interface energy mechanisms. Full article
