Search Results (21)

China generates substantial construction and demolition (C&D) waste, owing to rapid urbanization. However, the resource utilization rate of C&D waste remains low. This work is devoted to promoting the application of C&D waste in reinforced soil structures. In this research, the physical and mechanical properties of C&D waste recycled aggregate, biaxial geogrids and triaxial geogrids were first clarified. Then, a series of pullout tests were carried out based on the large-size pullout test setup. With the help of macroscopic indicators, including pullout resistance, horizontal displacement and interface friction coefficient, the effects of normal stress, pullout rate and reinforcement type on the characteristics of the reinforcement–C&D waste recycled aggregate interface were clarified. The test results show that normal stress has the greatest influence on pullout resistance. The pullout rate has the lowest effect on pullout resistance. In addition, the interface effect between the triaxial geogrid and the C&D waste recycled aggregate is more significant than that in biaxial geogrid–C&D waste recycled aggregate. The interface friction angle of triaxial geogrids is 18.1% higher than that of biaxial geogrids (11.6° vs. 9.82°), correlating with an enhanced particle interlocking mechanism. Full article

Expansive soils have significant characteristics of expansion by water absorption, contraction by water loss. Under the freeze–thaw (F-T) cycles, the engineering diseases are more significant, and the serious geotechnical engineering incidents are induced extremely easily. The aim is to investigate the mechanical response characteristics of geogrid-reinforced expansive soils (GRES) under F-T cycles. Based on a series of large-scale temperature-controlled triaxial tests, influencing factors were considered, such as the number of F-T cycles, the geogrid layers, and the confining pressure. The results showed that: (1) Friction between the expansive soil and geogrid and the geogrid’s embedded locking effect indirectly provided additional pressure, limited shear deformation. With the increase in reinforced layers, the stress–strain curve changed from a strain-softening to a strain-hardening type. (2) Elastic modulus, cohesion, and friction angle decreased significantly with increasing number of F-T cycles, whereas dynamic equilibrium was reached after six F-T cycles. (3) The three-layer reinforced specimens showed the best performance of F-T resistance, compared to the plain soil, the elastic modulus reduction amount decreases from 35.7% to 18.3%, cohesion from 24.5% to 14.3%, and friction angle from 7.6% to 4.5%. (4) A modified Duncan–Zhang model with the confining pressure, the F-T cycles, and the geogrid layers was proposed; the predicted values agreed with the measured values by more than 90%, which can be used as a prediction formula for the stress–strain characteristics of GRES under freeze–thaw cycling conditions. The research results can provide important theoretical support for the practical engineering design of GRES in cold regions. Full article

The utilization of ecological and cost-effective construction materials has emerged as a critical necessity in contemporary circumstances. It is essential to investigate the use of repair mortar as opposed to epoxy, which offers adhesion to concrete, to guarantee structural integrity under dynamic stresses. In this study, we performed an experimental and computational analysis of the load-bearing capacity of repair mortar to evaluate the adhesion between reinforced concrete structural elements and a geogrid. We performed triaxial bending, compression, splitting, shear bond strength, angle, and adhesion tests on specimens, which were constructed from repair mortar. We constructed 10 × 10 × 50 cm unreinforced beam specimens and 15 × 25 × 200 cm reinforced concrete beams and wrapped the geogrid in the stress zones of the beams by bonding it with repair mortar. We then performed four-point flexural tests on the geogrid specimens wrapped with repair mortar in the tensile zones of these beams. The mechanical properties obtained from these experiments allowed us to create a numerical model. For the first time in the literature, this study investigated the effectiveness of repair mortar compared with epoxy, as well as the innovative use of repair mortar to improve adhesion between the concrete surface and the geogrid. In the literature, reinforcement materials encasing concrete structural elements have utilized epoxy; however, an example of the application of a geogrid wrapped around structural elements with repair mortar has not been previously published. It was concluded that epoxy, effective in adhering to building materials for reinforcement, can bond with structural elements reinforced with a geogrid using repair mortar and may serve as an alternative to epoxy. Full article

Calcareous sand has been widely used as a construction material for offshore projects; however, the problem of foundation settlement caused by particle crushing cannot be ignored. Although many methods for reinforcing calcareous sands have been proposed, they are difficult to apply on-site. In this study, a permeable polyurethane polymer adhesive (PPA) was used to reinforce calcareous sands, and its mechanical properties after reinforcement were investigated through compression creep, direct shear, and triaxial shear tests. The reinforcement mechanism was analyzed using optical microscopy, CT tomography, and mercury intrusion porosimetry. The experimental results indicate that there is a critical time during the compression creep process. Once the critical time is surpassed, creep accelerates again, causing failure of the traditional Burgers and Murayama models. The direct shear strength of the fiber- and geogrid-reinforced calcareous sand reinforced by PPA was approximately nine times greater than that without PPA. The influence of normal stress was not significant when the moisture content was less than 10%, but when the moisture content was more than 10%, the shear strength increased with an increase in vertical normal stress. Strain-softening features can be observed in triaxial shear tests under conditions of low confining pressure, and the relationship between the deviatoric stress and strain can be described using the Duncan–Chang model before softening occurs. The moisture content also has a significant influence on the peak strength and cohesive force but has little influence on the internal friction angle and Poisson’s ratio. This influence is caused by the different PPA structures among the particles. The higher the moisture content, the greater the number of pores left after grouting PPA. Full article

Indoor triaxial tests on geogrid-reinforced clay elucidate the macroscopic changes in soil strength indices post-reinforcement, yet the underlying mechanisms of strength enhancement require further investigation. By conducting indoor triaxial tests and establishing a corresponding discrete element numerical model, we can delve into the fine-scale mechanisms of geogrid-reinforced soil. This includes analyzing changes in fine-scale parameters such as porosity, the coordination number, and contact stress between soil particles. The findings suggest that an increase in the number of geogrid reinforcement layers leads to a more pronounced improvement in peak strength and cohesion, albeit with minimal impact on the internal friction angle of the specimens. Furthermore, analysis of the triaxial test curves of reinforced soils indicates that the stress–strain relationship adheres to the Duncan–Chang model. Parameters derived from this model have been validated against experimental data, confirming their accuracy. The discrete element model was used to analyze the variations in fine-scale parameters such as porosity and coordination number. It revealed that reinforcement reduces the fluctuation amplitude of porosity and significantly increases the number of particle contacts, resulting in a denser soil structure. Further analysis of the change in contact stress between particles in the discrete element model revealed that the contact force between particles increased significantly after reinforcement and that the reinforcement played a role in restraining the soil particles and dispersing the reinforcement stress, which explains the increase in the strength of the mesh-reinforced clays from another perspective. This further elucidates the strength enhancement mechanism in geogrid-reinforced clay, offering a new perspective on the mechanical behavior and strength development of such materials. Full article

This paper introduces a novel approach to measure deformations in geomaterials using the recently developed ‘Smart Pebble’ sensors. Smart Pebbles were included in triaxial test specimens of unbound aggregates stabilized with geogrids. The sensors are equipped with an aggregate particle/position tracking algorithm that can manage uncertainty arising due to signal noise and random walk effects. Two Smart Pebbles were placed in each test specimen, one at specimen’s mid-height, where a geogrid was installed in the mechanically stabilized specimen, and one towards the top of the specimen. Even with simple raw data processing, the trends on linear vertical acceleration indicated the ability of Smart Pebbles to assess the geomaterial configuration and applied stress states. Employing a Kalman filter-based algorithm, the Smart Pebble position coordinates were tracked during testing. The specimen’s resilient deformations were simultaneously recorded. bender element shear wave transducer pairs were also installed on the specimens to further validate the Smart Pebble small-strain responses. The results indicate a close agreement between the BE sensors and Smart Pebbles estimates towards local stiffness enhancement quantification in the geogrid specimen. The study findings confirm the viability of using the Smart Pebbles in describing the resilient behavior of an aggregate material under repeated loading. Full article

This paper integrates and extends an earlier article presented at the 20th International Conference on Soil Mechanics and Geotechnical Engineering. The generation of a stiffened zone in the proximity of a geogrid is one of the primary mechanisms of mechanical stabilization of pavement unbound aggregate layers using geogrids. This paper focuses on the quantification of the stiffened zone through a local stiffness assessment using bender element (BE) sensors. Unbound aggregate base layers were constructed in a large-scale laboratory testbed. Geogrid-stabilized layers had geogrids with different-sized triangular apertures contributing to the geogrid-stiffened zone. Shear wave velocities were measured at three different heights using BE sensors, and the vertical stiffness profiles of the mechanically stabilized aggregate layers were evaluated. In addition, the conversion method between small-strain stiffness and large-strain stiffness was established from the repeated load triaxial tests with BE pairs to transform the vertical stiffness profile into that of the resilient modulus. Furthermore, dynamic cone penetration (DCP) and light-weight deflectometer (LWD) tests were performed at multiple locations into the stabilized and unstabilized unbound aggregates. From the large-scale experimental study, the local stiffness improvement owing to the geogrid enhancement was up to 16.2% in the vicinity of the geogrid location, and the extent of the local stiffened zone evaluated through various test methods was between 15.2 cm (6 in.) and 25.4 cm (10 in.) above the geogrid. Full article

Geosynthetics play a pivotal role in modern infrastructure projects, with geogrids serving as a common choice for enhancing bearing capacity and reducing soil settlement in road construction. This study investigates the influence of density and uniformity coefficients on geogrid-reinforced sandy and gravelly soils through a series of consolidated drained triaxial tests. The research covers six distinct soil types from Lithuania, each characterized by particle size distribution analysis and classified using various standards. A polyester biaxial geogrid is employed, and test specimens are prepared with and without geogrid reinforcement. Triaxial compression tests are performed at different cell pressures, mirroring real-world conditions in road construction. The results highlight the critical role of cell pressure in the reinforcement effect, with higher pressures reducing the geogrid’s influence. The study also emphasizes the importance of soil type, as gravel soils consistently exhibit higher deviatoric stress than sandy soils. Notably, the geogrid enhances cohesion but reduces the angle of internal friction in most cases. Overall, this research provides valuable insights into the intricate interplay between soil properties, geogrid reinforcement, and cell pressure, shedding light on the mechanical behavior of geosynthetic-reinforced soils in road construction applications. Full article

Node thickening is a way to strengthen the nodes of a geogrid. Increasing the node thickness in conventional biaxial geogrids enhances the interface frictional strength parameters and improves its three-dimensional reinforcement effect. Based on the triaxial tests of aeolian sand, single-rib strip tests of geogrids, and pull-out tests of geogrid in aeolian sand, a three-dimensional discrete element pull-out model for geogrids with strengthened nodes was developed to investigate the mechanical performance of an aeolian sand–geogrid interface. The influences of increasing node thickness, the number of strengthened nodes, and the spacing between adjacent nodes on the mechanical performance of the geogrid–soil interface were extensively studied used the proposed model. The results demonstrated that strengthened nodes effectively optimize the reinforcing performance of the geogrid. Among the three node-thickening methods, that in which both the upper and lower sides of nodes are thickened showed the most significant improvement in ultimate pull-out resistance and interface friction angle. Moreover, when using the same node-thickening method, the ultimate pull-out resistance increase shows a linear relationship with the node thickness increase and the strengthened node quantity. In comparison with the conventional geogrid, the strengthened nodes in a geogrid lead to a wider shear band and a stronger ability to restrain soil displacement. When multiple strengthened nodes are simultaneously applied, there is a collective effect that is primarily influenced by the spacing between adjacent nodes. The results provide a valuable reference for optimizing the performance of geogrids and determining the spacing for geogrid installation. Full article

In order to solve the problem of low transverse tensile strength of triaxial geogrid, a kind of performance-optimized multi-axial geogrid (POMG) that can bear larger transverse loads was designed. Firstly, the forming equipment and process of POMG are designed. Secondly, through the test of formability and mechanical properties, the POMG with good formability and mechanical properties is obtained, and the average tensile strength of POMG with circular and semicircular holes is the highest, reaching more than 16 KN/m. Finally, the feasibility of the process is further verified by numerical simulation, and the shape distribution and stress-strain law of POMG during the forming process are obtained, which provides further guidance for the actual production. Full article

In this paper, the tensile behavior of industrial polypropylene triaxial geogrid with different pre-punched hole diameters was studied by experiment and numerical analysis. The industrial polypropylene sheets with different diameters of circular holes were stretched at elevated temperature and then the tensile properties of triaxial geogrids at room temperature were evaluated. It was found that the pre-punched hole diameter of triaxial geogrid had a very close relationship with the mechanical properties. With the increase of the pre-punched hole diameter, the tensile strength of triaxial geogrid shows a trend of first increasing and then decreasing. Combined with numerical simulation, the optimal pre-punched hole diameter can be accurately obtained, and the distribution law of the width, thickness, stress, and strain of triaxial geogrid can be obtained. Under the condition of a stretching ratio of 3 and node spacing of 3 mm, it was found that the mechanical properties of industrial polypropylene triaxial geogrid was the best when the pre-punched hole diameter was 2.6 mm. Full article

In view of the dynamic response of geogrid-reinforced gravel under high-speed train load, this paper explores the dynamic characteristics of geogrid-reinforced gravel under semi-sine wave cyclic loading. A number of large scale cyclic triaxial tests were performed on saturated gravelly soil reinforced with geogrid to study the influence of the number of reinforcement layers and loading frequencies on the dynamic responses of reinforced gravelly sand subgrade for high speed rail track. The variation of cumulative axial and volumetric strains, excess pore pressure and resilient modulus with number of loading cycles, loading frequency, and reinforcement arrangement are analyzed. The test results reveal that the cumulative axial strain decreases as the number of reinforcement layers increases, but increases with loading frequency. The resilience modulus increases with the number of reinforcement layers, but decreases as the loading frequency increases. The addition of geogrid can reduce the excess pore water pressure of the sample, but it can slightly enhance the rubber mold embedding effect of the sand sample. As the loading frequency increases, the rubber mold embedding effect gradually weakens. Full article

This paper presents an experimental study on the anisotropic shear strength behavior of soil–geogrid interfaces. A new type of interface shear test device was developed, and a series of soil–geogrid interface shear tests were conducted for three different biaxial geogrids and three different triaxial geogrids under the shear directions of 0°, 45° and 90°. Clean fine sand, coarse sand, and gravel were selected as the testing materials to investigate the influence of particle size. The experimental results for the interface shear strength behavior, and the influences of shear direction and particle size are presented and discussed. The results indicate that the interface shear strength under the same normal stress varies with shear direction for all the biaxial and triaxial geogrids investigated, which shows anisotropic shear strength behavior of soil–geogrid interfaces. The soil–biaxial geogrid interfaces show stronger anisotropy than that of the soil–triaxial geogrid interfaces under different shear directions. Particle size has a great influence on the anisotropy shear strength behavior of soil–geogrid interfaces. Full article

Compared with the commonest geosynthetics-reinforced soil structures, layered geogrids–sand–clay reinforced (LGSCR) structures (School of Architecture and Civil Engineering, Shenyang University of Technology, Shenyang 110870, China) can replace granular materials with clay as the primary backfill material. Up until now, the performance of LGSCR structures under triaxial compression has been unclear. In this paper, the discrete element method was used to simulate the triaxial compression test on the LGSCR samples. Based on the particle flow software PFC^3D, three types of cluster particle-simulated sand and the reinforced joints of the geogrid were constructed by secondary development. The effects of the geogrid embedment in sand layers, the number and thickness of sand layers in relation to the deviatoric stress, and the axial strain and the shear strength index of the LGSCR samples were analyzed. The results showed that laying the sand layers in the samples can improve their post-peak strain-softening characteristics and increase their peak strengths under a high confining pressure. A geogrid embedment in sand layers can further enhance the ductility and peak strength of the samples, and in terms of the shear strength index, there is a 41.6% to 54.8% increase in the apparent cohesion of the samples. Full article

The key to modeling the interlocking of geogrid-reinforced ballast is considering both the continuous deformation characteristics of the geogrid and the discontinuity of the ballast particles. For this purpose, pullout tests using biaxial and triaxial geogrids were simulated using the coupled discrete element method (DEM) and finite difference method (FDM). In this coupled model, two real-shaped geogrid models with square and triangular apertures were established using the solid element in FLAC3D. Meanwhile, simplified shaped clumps were used to represent the ballast using PFC3D. The calibration test simulation showed that the accurately formed geogrid model can reproduce the deformation and strength characteristics of a geogrid. The pullout simulation results show that the DEM-FDM method can well predict the relationship between pullout force and displacement, which is more accurate than the DEM method. For ballast particles of 40 mm in size, both the experiment and simulation results showed that the triaxial geogrid of 75 mm is better than the 65-mm biaxial geogrid. In addition, the DEM-FDM method can study the interaction mechanism between the particles and the geogrid from a microscopic view, and also reveal the similar deformation behavior of the geogrid in the pullout process. Therefore, the DEM-FDM coupled method can not only investigate the interlocking mechanism between the ballast and particles but can also provide a great method for evaluating the performance of different types of geogrids. Full article
