Conventional trenchless pipeline rehabilitation technologies are primarily designed for circular pipelines, with limited applicability to box culvert structures. Even when adapted, these methods often lead to significant reductions in the effective cross-sectional area and fail to enhance the structural load-bearing capacity due to geometric incompatibilities. To overcome these limitations, this study proposes a novel construction approach that employs prefabricated high-strength thin concrete segment liners for the reinforcement of underground box culverts. The feasibility of this method was validated through full-scale (1:1) experimental construction in a purpose-built test culvert, demonstrating rapid and efficient installation. A static stacking load test was subsequently conducted on the reinforced upper section of the culvert. Results indicate that the proposed reinforcement method effectively restores structural integrity and satisfies load-bearing and serviceability requirements, even after removal of the original roof slab. Additionally, a finite element analysis was performed to simulate the stacking load test conditions. The simulation revealed that variations in the mechanical properties of the grout between the existing structure and the new lining had minimal impact on the internal force distribution and deformation behavior of the prefabricated segments. The top segment consistently exhibited semi-rigid fixation behavior. This study offers a promising strategy for the rehabilitation of urban underground box culverts, achieving structural performance recovery while minimizing traffic disruption and enhancing construction efficiency. Full article

The spray-applied pipe lining (SAPL) method, extensively employed in the trenchless rehabilitation of reinforced concrete pipes (RCPs) due to its operational versatility, remains constrained by an incomplete understanding of the failure behavior of rehabilitated pipelines, thereby impeding optimal design strategies. This study proposes an analytical approach to evaluate the structural performance of pipes with fiber-reinforced mortar lining, with a particular focus on interface failure and its consequences. Two RCPs with an inner diameter of 1000 mm, repaired with 34 mm and 45 mm centrifugally sprayed fiber-reinforced mortar liners, were subjected to three-edge-bearing (TEB) tests. The elastic limit loads of the two pipes were 57% and 39% of their pre-rehabilitation conditions, while the ultimate loads were 45% and 69%. A thicker liner exhibits a greater susceptibility to interface failure, leading to wider cracks around the elastic stage during loading. Once the interface failure occurs, load redistribution allows the liner to resist further cracking and sustain higher capacity, demonstrating enhanced bearing performance. Critical factors influencing the failure process were analyzed to inform design optimization, revealing that improving the interface takes precedence, followed by thickness design. Full article

Cured-in-place pipe (CIPP) technology is a trenchless rehabilitation method for damaged pipelines in which a resin-saturated liner (often a fiber-reinforced type) is inserted into a host pipe and cured in situ, typically using a UV light beam or steam. This study investigates the influence of selected photoreactive diluents on the photopolymerization process of a styrene-free vinyl ester resin designed for the CIPP applications by evaluating the rheological properties, photopolymerization kinetics (photo-DSC), thermal characteristics (DSC), crosslinking density (gel content), and mechanical properties of thick (15 mm) UV-cured layers. The tested diluents included monofunctional (i.e., methyl methacrylate and vinyl neodecanoate), difunctional (1,6-hexanediol diacrylate, aliphatic urethane acrylates, and an epoxy acrylate), and trifunctional monomers (trimethylolpropane triacrylate, pentaerythritol triacrylate, and trimethylolpropane ethoxylate triacrylate). The key findings demonstrate that the addition of pentaerythritol triacrylate (the most attractive diluent) increases the flexural strength (+6%) and deflection at strength (+28%) at the unchanged flexural modulus value (ca. 2.1 GPa). The difunctional epoxy acrylate caused an even greater increase in the deflection (+52%, at a 5% increase in the flexural strength). Full article

Sanitary sewer pipelines frequently experience blockages, structural failures, and overflows, underscoring the dire state of U.S. wastewater infrastructure, which has been rated a D-, while America’s overall infrastructure scores only slightly better at C-. Traditional open-trench excavation methods or excavation technology (ET) for replacing deteriorated pipes are notoriously expensive and disruptive, requiring extensive processes like route planning, surveying, engineering, trench excavation, pipe installation, backfilling, and ground restoration. In contrast, trenchless technologies (TT) provide a less invasive and more cost-effective alternative. Among these, cured-in-place pipe technology (CIPPT), which involves inserting resin-impregnated fabric into damaged pipelines, is widely recognized for its efficiency. However, a comprehensive life cycle cost analysis (LCCA) directly comparing ET and TT, accounting for the net present value (NPV) across installation, maintenance, and rehabilitation costs, remains unexplored. This study aims to establish an LCCA framework for both CIPPT and ET, specifically for sanitary sewer pipes ranging from 8 to 42 inches in diameter. The framework incorporates construction, environmental, and social costs, providing a holistic evaluation. The key costs for ET involve pipe materials and subsurface investigations, whereas TT’s costs center around engineering and design. Social impacts, such as road and pavement damage, disruption to adjacent utilities, and noise, are pivotal, alongside environmental factors like material use, transportation, project duration, and equipment emissions. This comprehensive framework empowers decision makers to holistically assess economic and environmental impacts, enabling informed choices for sustainable sewer infrastructure renewal. Full article

The wastewater conveyance systems in the United States are facing severe structural challenges, with the nation’s overall wastewater infrastructure receiving a critically low grade of D- from the American Society of Civil Engineers (ASCE). Innovative trenchless technologies, such as Cured-in-Place Pipe Renewal Technology (CIPPRT), offer a cost-efficient substitute for traditional open-cut construction methods (OCCM). However, the possibility of a comprehensive life-cycle cost analysis (LCCA) comparing these methods remains unexplored. LCCA examines the comprehensive financial impact, encompassing installation, operation, maintenance, rehabilitation, and replacement expenses, using net present value (NPV) over a set duration. The objective of this study is to systematically review the existing literature to explore advancements in calculating the LCCA for CIPPRT and compare the latter approach to OCCM. A rigorous PRISMA-guided methodology applied to academic databases identified 845 publications (1995–2024), with 83 documents being selected after stringent screening. The findings reveal limited use of artificial intelligence (AI) or machine learning (ML) in predicting CIPPRT costs. A bibliometric analysis using VOSviewer visualizes the results. The study underscores the potential of intelligent, data-driven approaches, such as spreadsheet models and AI, to enhance decision-making in selecting rehabilitation methods tailored to project conditions. These advancements promise more sustainable and cost-effective management of sanitary sewer systems, offering vital insights for decision-makers in addressing critical infrastructure challenges. Full article

Polyurethane grouting trenchless technology has been widely applied to the rehabilitation of concealed defects in engineering structures. The interfacial properties between polyurethane and engineering structures are key factors determining the stability of the composite structure. In practical applications, the interface shapes of different engineering structures vary significantly, and the influence of the interface shape on interfacial properties should not be overlooked. This study focuses on engineering structures with curved interfaces, such as pile foundations, pipelines, and tunnels. Direct shear tests were conducted on polyurethane and concrete composite specimens with curved interfaces. A comparative analysis of the shear behavior between curved and planar composite specimens was performed, and the influence of arc diameter and polyurethane density on the shear behavior of curved and planar composite specimens was investigated. Additionally, SEM (Scanning Electron Microscopy) was used to conduct a microscopic examination of the interfaces with different polyurethane densities after failure, and the microscopic shear mechanisms between polyurethane and concrete materials were explored. The results revealed that the shear behavior of curved specimens was significantly higher than that of planar specimens. The shear strengths of curved specimens with diameters of 400 mm, 500 mm, and 700 mm were approximately 1.50, 1.39, and 1.10 times those of planar specimens, respectively. With increasing polyurethane density, the variation trend of shear strength in curved specimens was similar to that of planar specimens. However, significant differences were observed in the shear modulus, peak displacement, and shear residual strength between curved and planar specimens as the polyurethane density varied. Different diameter curved interface specimens exhibited a similar trend of shear strength variation with polyurethane density, gradually decreasing as the curvature diameter increased, and ultimately approaching that of planar specimens. Full article

The aging pipeline infrastructure around the world necessitates immediate rehabilitation. Internal replacement pipe (IRP) is a trenchless system offering a versatile and cost-effective solution across a variety of industries, including oil, natural gas, water, and wastewater. As a structural pipeline repair system, IRPs are subject to lateral deformation because of surface traffic loading. The present study evaluates the impact of adhesion between the host pipe and the IRP, with a focus on assessing the debonding effect on the behavior of the repair system under lateral deformation and bending. This was achieved using a comprehensive approach, including experimental, numerical, and analytical techniques. Varying levels of adhesive strength resulting from different methods of surface preparation were considered. The effectiveness of the IRP system on both discontinuous host pipes with various crack widths and continuous host pipes was also investigated. The results demonstrate that adhesive strength exerts a significant influence on the repair system, especially in the case of narrow circumferential cracks, while its impact on the continuous system is minimal. For optimal performance, it is essential to choose adhesives that possess sufficient shear strength while also accounting for the required debonding length. This approach ensures that minor discontinuities are effectively controlled, thereby enhancing the system′s fatigue life. The reliable determination of the maximum allowable shear strength for the adhesive or the debonding length can ensure that it does not negatively affect fatigue life. The findings presented in this study offer new insights into the development of trenchless repair techniques that can enhance system performance and extend service life. Full article

Sewage and water networks are crucial infrastructures of modern urban society. The uninterrupted functionality of these networks is paramount, necessitating regular maintenance and rehabilitation. In densely populated urban areas, trenchless methods, particularly those employing cured-in-place pipe technology, have emerged as the most cost-efficient approach for network rehabilitation. Common diagnostic methods for assessing pipe conditions, whether original or retrofitted with-cured-in-place pipes, typically include camera examination or laser scans, and are limited in material characterization. This study introduces three innovative methods for characterizing critical aspects of pipe conditions. The impact-echo method, ground-penetrating radar, and impedance spectroscopy address the challenges posed by polymer liners and offer enhanced accuracy in defect detection. These methods enable the characterization of delamination, identification of caverns behind cured-in-place pipes, and evaluation of overall pipe health. A machine learning algorithm using deep learning on images acquired from impact-echo signals using continuous wavelet transformation is presented to characterize defects. The aim is to compare traditional machine learning and deep learning methods to characterize selected pipe defects. The measurement conducted with ground-penetrating radar is depicted, employing a heuristic algorithm to estimate caverns behind the tested polymer composites. This study also presents results obtained through impedance spectroscopy, employed to characterize the delamination of polymer liners caused by uneven curing. A comparative analysis of these methods is conducted, assessing the accuracy by comparing the known positions of defects with their predicted characteristics based on laboratory measurements. Full article

The formed-in-place pipe (FIPP) is a trenchless technology used for pipeline rehabilitation. It is a folded PVC pipe that expands through thermoforming to fit tightly inside the host pipe. However, the deficiencies during the construction of FIPP liners such as insufficient inflation, pipe misalignment and initial deformation will lead to elliptical deformation of the FIPP liner, which affects the load-bearing performance of the liner and makes it susceptible to buckling failure. In this paper, the buckling behavior of loosely fitted FIPP liners under uniform external pressure was investigated by the external pressure resistance test and finite element model. The pre- and post-buckling equilibrium paths verified the finite element model. The results indicated that the value of the dimension ratio will significantly reduce the critical buckling pressure. With the increasing value of liner major axis ratio to host pipe, the reduction effect on the critical buckling pressure caused by the increase in the ovality will diminish. Different values of liner major axis ratio to host pipe and ovality changed the range of the detached portion, which affected the critical buckling pressure. The parametric studies modified the design model from ASTM F1216, which was established to predict the critical buckling pressure of a loosely fitted FIPP liner and reduced the average difference rate from 23.43% to 5.52%. Full article

Concrete structures cannot efficiently perform their functions over time due to chemical and physical external effects. Thus, enhancing the relationship between repair and aged structures, and also improving the durability properties of concrete is crucial in terms of sustainability. However, high costs, negative environmental effects, and incompatibility problems occur in repair/retrofit applications. Furthermore, three-quarters of the failures in the repaired/retrofitted structures are caused by a lack of repair durability. The need for repair in pavement/bridge decks is also frequently encountered, and early-age performance problems with repair materials cause pavement/bridge decks to be unavailable for certain periods of time. Engineered Cementitious Composite (ECC) can be effectively used as repair/retrofit and pavement/bridge deck material. It also has a minimal need for repair/retrofit thanks to its high durability properties. This article presents state-of-the-art research regarding the application of ECC as a repair/retrofit and pavement/bridge deck material. Studies in the literature show that the repair/retrofit properties of ECC outperform conventional concrete and steel fiber-reinforced concrete. ECC can be a solution to high early strength and drying shrinkage problems frequently encountered in the use of repair materials. It could also be used for different repair applications such as cast, sprayed, and trenchless rehabilitation. Moreover, ECC might fulfill specific requirements for pavement, pavement overlay, tunnel pavement, airfield pavement, and bridge deck. These superior performances are attributed to ECC’s kink-crack trapping mechanism, uniquely large inelastic strain capacity, strain hardening, high tensile strain capacity, and multiple microcracking and ductile behaviors, especially bonding behavior and self-healing. Full article

Cured-in-place pipe (CIPP) is one of the most popular in situ rehabilitation techniques to repair sewer and water pipes. While there are multiple approaches to curing CIPP, steam-curing of styrene-based resins has been found to be associated with air-borne chemical emissions. Health officials, utilities and industry representatives have recognized the need to know more about these emissions, especially styrene. Such concern has led to multiple studies investigating the concentrations of volatile organic compounds on CIPP installation sites. This study expands upon previous effort by modeling worst-case, steam-cured CIPP emissions over a 5-year weather record. The effort also includes calibration of the model to emissions averages over the work day rather than instantaneous field measurements. Dispersion modelling software, AERMOD, was utilized to model the styrene component of CIPP emissions on two CIPP installation sites in the US. Based on the analysis results, it was found that the styrene emitted from stacks dissipates rapidly with styrene concentrations only exceeding minimum health and safety threshold levels at distances close to the stack (2 m or less). The values predicted by the model analysis are comparable with the field measured styrene concentrations from other studies. Current safety guidelines in the US recommend a 4.6-m (15-ft) safety perimeter for stack emission points. The results of this study indicate that significant and lasting health impacts are unlikely outside recommended safety perimeter. The results also validate the importance of enforcing recommended safety guidance on steam-cured CIPP sites. Full article

For buried municipal tunnels—such as cable tunnels and utility tunnels with structural defects—due to the sheltering of the internal pipelines, shelves, and other auxiliary facilities, traditional trenchless rehabilitating methods are not applicable since an intact ring is needed for spraying and lining. In these tunnels, only the exposed area at the crown of the ring can be partly rehabilitated. In this paper, three-edge bearing tests (TEBTs) for partially rehabilitated reinforced concrete (RC) pipe sections are carried out to simulate the case of a municipal tunnel and the effects of different repair materials (cement mortar and epoxy resin) and different dimensional parameters of the liner (lining thickness, lining range) on the partial rehabilitation effect of defective RC pipes are studied. The deforming compatibility of the liner–pipe interface is discussed, and the flexural rigidity of the partially rehabilitated section is calculated. The results show that the load-carrying capacities of partial rehabilitated RC pipes are effectively improved. Full article

Trenchless rehabilitation lining can be divided into flexible solid wall lining structures, rigid lining structures and rigid–flexible composite lining structures. This paper reviews the research status of the design theory of trenchless rehabilitation lining pipes, analyzes the theory of rigid–flexible composite lining structures, and points out that the value of the factor determined from non-grouting angle K₁ is not clear in the design formula of the rigid–flexible composite lining structure mentioned in the ASTM ‘Standard Practice for Installation of Machine Spiral Wound Poly (Vinyl Chloride) (PVC) Liner Pipe for Rehabilitation of Existing Sewers and Conduits (ASTM F 1741)’. The value of K₁ was obtained by the numerical analysis method with MATLAB software. Through the analysis of the variation trend of the K₁ value, it is concluded that the design formula in the ASTM standard is only applicable to the case of incomplete grouting filling between the original pipe and the lining pipe, and is not applicable to the composite lining pipe with complete grouting filling. Finally, the explicit formula of the non-grouting angle is obtained by fitting, which is more convenient to use. Full article

Cured-in-place pipe (CIPP), as a kind of trenchless sewer rehabilitation technology, is a method to repair sewer pipe using unsaturated polyester resin. This study develops a CIPP liner using hot water or steam curing as well as glass fiber, in contrast to traditional methods, which use nonwoven fabric. Composite material samples were fabricated by combining liner materials using various methods, and the structural characteristics of the liners were compared and analyzed through short- and long-term flexural strength tests. A long-term test was conducted for 10,000 h, and the results revealed 13.3 times higher flexural strength and 8 times higher flexural modulus than the American Society for Testing Materials minimum criteria for CIPP short-term properties. The maximum creep retention factor was 0.64, thereby reducing the design thickness of the CIPP by up to 54%. The structural characteristics also improved when glass fibers were mixed with traditional CIPP liner, making it possible to reduce the thickness by 30%. Glass fibers result in high structural strength when combined with unsaturated polyester resin. Structural strength increased, even when glass fibers were mixed with traditional CIPP liner. The main contribution of this research is the development of a high strength CIPP liner and improvement of the structural properties of CIPP lining without using the specially formulated resin or lining materials. Full article

Most urban areas in the world have water infrastructure systems, including the buried sewer and water pipelines, which are assessed as in need of extensive rehabilitation. Deterioration by many other factors affects structural integrity. Trenchless technologies such as Cured-in-Place Pipe (CIPP) are now applied in numerous projects while minimizing disturbance in an urban environment. The main purpose of this study is to develop a high strength CIPP material using various composite materials (e.g., glass fiber, carbon fiber, polyester felt, unsaturated polyester resin, and others). Composite samples were made of the materials and tested using three-point bend apparatus to find mechanical properties, which include the flexural modulus, strength, and deflection. A composite combination with glass fibers with thin felt layers shows the best results in mechanical properties. Flexural modulus is a key factor for CIPP liner thickness design. Glass fiber composite yields between four and nine times higher values than the minimum value specified in the American Society for Testing and Materials (ASTM) F1216. This study provides a fundamental baseline for high strength CIPP liners that are capable of using conventional curing technologies. Full article
