Search Results (16)

The upright state of pot seedlings in the process of rice mechanized throwing operations has an important influence on the growth rate and yield of rice, and pot seedling uprightness is affected by the influence of soil backfilling during trenching. Due to the complexity of the furrow opener–soil–pot seedling interaction mechanism in the rice pot seedling planting process, the soil backfilling process is difficult to observe. In order to improve the uprightness of pot seedling planting, this paper constructs a soil model and a soil–pot seedling model step by step, based on the discrete element method (DEM), as well as a coupled model of the pot seedling planting system to study the process of furrow opener–soil–pot seedling planting, the reliability of which is then verified. The results showed that the simulation results of the constructed soil model and soil–pot seedling model deviated from the actual calibration results by <6%, and the model could accurately simulate the pot seedling throwing process. The simulation analysis of the trenching process revealed that the soil backfilling process during trenching showed a three-stage evolution pattern of “backfilling-covering-stabilizing”; in addition, the forward speed of the machine was 0.8 m/s, and the falling speed of the seedling discharge cylinder was 3.5 m/s, which made it possible for the model to simulate the pot seedling throwing process accurately. In addition, when the pot seedling with a forward speed of 0.8 m/s and a drop speed of 3.5 m/s fell into the trench after 0.15 s of trenching, its lateral and longitudinal uprightness were 67.0 ± 1.2° and 65.2 ± 1.5°, respectively. After optimization of the structure of the trenchers, the width, depth, and length of the main body were 40 mm, 37.87 mm, and 32.32 mm, respectively, and the lateral and longitudinal uprightness of the pot seedlings increased to 70.0 ± 1.0° and 69.4 ± 0.8, respectively. The coupled model bench validation test showed that its reliability error was <5%. The coupled model provides technical support for the design and parameter optimization of rice planting equipment. Full article

Seafloor topography data are fundamental for marine resource development, oceanographic research, and maritime rights protection. However, approximately 75% of the ocean remains unsurveyed for bathymetry. Sole reliance on shipborne measurements is insufficient for constructing a global bathymetric model within a short timeframe; consequently, satellite altimetry-based inversion techniques are essential for filling data gaps. Recent advancements have improved the variety and quality of satellite altimetry gravity data. To leverage the complementary advantages of multiparameter gravity data, we propose a 1D convolutional neural network based on a convolutional attention module, termed the Attention Channel 1D Convolutional Network (AC1D). Results of a case study of the Mariana Trench indicated that the AC1D grid predictions exhibited improved agreement with single-beam depth checkpoints, with standard deviation reductions of 6.32%, 20.79%, and 36.77% and root mean square error reductions of 7.11%, 22.82%, and 50.99% compared with those of parallel linked backpropagation, the gravity–geological method, and a convolutional neural network, respectively. The AC1D grid demonstrated enhanced stability in multibeam bathymetric validation metrics and exhibited better consistency with multibeam bathymetry data and the GEBCO2023 grid. Power spectral density analysis revealed that AC1D effectively captured rich topographic signals when predicting terrain features with wavelengths below 6.33 km. Full article

Sand waves are large-scale bed forms commonly occurring on the continental shelf seabed and can result in free spans of submarine pipelines, which may have an influence on the stability of the pipelines. Existing span rectification procedures have primarily focused on local rectification methods for free spans caused by local scour or individual spans resulting from seabed unevenness. This paper aims to present a span rectification design applicable to the pipeline crossing sand wave region, and to offer practical guidance on sand wave intervention strategies. A large-scale approach is necessary for the rectification of multiple spans across the field, which may involve the use of either a mass flow excavator (MFE) or a remotely operated vehicle (ROV) jetting tool. A comparative analysis of the estimated durations for post-lay trenching using the MFE and ROV jetting tools is also provided. In instances where the large-scale method fails to achieve span lengths suitable for long-term operation, a localized approach is necessary to address individual spans. The desired trench depth can be attained through a combination of pre-lay and/or post-lay trenching techniques. The analysis of on-bottom roughness and free span has demonstrated that, given the natural seabed profile without trenching, there are no spans surpassing the ultimate limit state (ULS) or fatigue limit state (FLS) criteria for the temporary installation scenario. Consequently, pre-lay rectification is not necessary. However, the analysis indicates that post-lay rectification is essential to meet ULS and FLS criteria under operating conditions. All spans that exceed the ULS and FLS criteria can be effectively rectified by trenching to a depth of 1 m. Full article

Existing support systems for thermal pipeline trenches often fail to meet the specific needs of narrow strips, tight timelines, and short construction periods in urban environments. This study introduces a novel recyclable, non-embedded support system composed of corrugated steel plates, retractable horizontal braces, angle steel, and high-strength bolts designed to address these challenges. The system’s effectiveness was validated through prototype testing and optimized using Abaqus finite element simulations. The research hypothesizes that this new support structure will enhance construction efficiency, reduce installation costs, and provide adaptable and sustainable solutions in urban trench applications. Prototype tests demonstrated that the proposed support had maintained safety and stability in trenches of 2 m and 3 m depth under a 58 kPa load and rainfall, as well as the 4 m deep trenches under asymmetric loading of 80 kPa. Optimization of the proposed system included installing two screw jacks on each horizontal brace and adjusting the corrugated plates, resulting in reduced weight, improved node strength, and enhanced screw jack adjustability. Numerical simulations confirmed the optimized system’s reliability in trenches up to 3 m deep, with caution required for deeper applications to avoid structural failure. The proposed support system offers notable advantages over traditional methods by improving construction efficiency, flexibility, and adaptability while also reducing costs, ensuring safety, and promoting environmental sustainability. Its modular design allows for rapid installation and disassembly, making it suitable for projects with strict deadlines and diverse construction conditions. The findings uphold the initial hypotheses and demonstrate the system’s practicality in urban trench projects. Full article

Sowing depth significantly affects the germination of rapeseed, and different soil moisture conditions require corresponding sowing depths. However, most current trenching devices do not account for soil moisture content, and commonly used hydraulic or constant-force trenching equipment also exhibits deficiencies in stability and consistency. To address these challenges, this study developed an automatic depth adjustment control system based on soil moisture content. A soil moisture detection device and an innovative sliding mechanism that maintained the soil moisture sensor in a relatively stationary position relative to the soil during seeder movement were introduced. An automatic sowing depth adjustment device was designed to modulate the sowing depth. A control strategy that incorporated the Kalman filtering algorithm and linear deceleration equations was conducted. At an observation noise covariance matrix (Q/R) of 0.001, a deceleration range of 40 mm and a minimum speed of 10, the control system exhibited minimal overshoot (approximately 4%) and steady-state error (approximately 3.2 mm). It effectively adjusted the trenching depth while operating at speeds ranging from 2 to 3.6 km/h, successfully adapting to variations in soil topography. The system performance tests revealed that the control system adjustment time (t_s) was 534 ms and the steady-state error remained within 1 mm. Under three different soil moisture content conditions, the sowing depth qualification rate and stability coefficients consistently surpassed 90% and 80%, respectively. This research offers a sowing depth adjustment control system based on soil moisture content, contributing to more precise depth regulation for rapeseed sowing. Full article

In slopes where high pore water pressure exists, deep counterfort drains (also called drainage trenches or trench drains) represent one of the most effective methods for improving stability or mitigating landslide risks. In the cases of deep or very deep slip surfaces, this method represents the only possible intervention. Trench drains can be realized by using panels or secant piles filled with coarse granular material or permeable concrete. If the trenches are adequately “socket” into the stable ground (for example sufficiently below the sliding surface of a landslide or below the critical slip surface of marginally stable slopes) and the filling material has sufficient shear strength and stiffness, like porous concrete, there is a further increase in shear strength due to the “shear keys” effect. The increase in shear strength is due both to the intrinsic resistance of the concrete on the sliding surface and the resistance at the concrete–soil interface (on the lateral surface of the trench). The latter can be very significant in relation to the thickness of the sliding mass, the “socket depth”, and the spacing between the trenches. The increase in shear strength linked to the “shear keys effect” depends on the state of the porous concrete–soil interface. For silty–clayey base soils, it is very significant and is of the same order of magnitude as the increase in shear resistance linked to the permanent reduction on the slip surface in pore water pressure (draining effect). This paper presents the results of an experimental investigation on the shear strength at the porous interface of concrete and fine-grained soils and demonstrates the high significance and effectiveness of the “shear keys” effect. Full article

The trencher design of the pre-cut transverse sugarcane planter is the basis for realizing deep planting and shallow burial. Aimed at the problems of insufficient seeding space provided by furrows and high resistance to trenching, a structural configuration of a combined trencher suitable for transverse cane planting agronomy was proposed to improve the stability, simplicity, and efficiency of trenching. The collaborative operations of components such as the soil lifting of the leak-proof plow, the soil fragmentation and throwing of the double-disc rotary tiller, the rebound of the fender, the lateral diversion of the furrowing plow, and the motion control of the double rocker arms were comprehensively utilized. The trenching principle of using double-sided guards to block soil backfilling to form a seeding space was applied, as well as pre-side diversion to reduce the forward resistance of plow surfaces. The simulation of the trenching process showed that the combined trencher was available in terms of soil particle transfer and dynamic space-forming capabilities, and the stress distribution of the advancing plow surface was analyzed. Moreover, based on the minimum resistance characteristics, the optimal spacing between the rotary tiller and the furrowing plow and the blade arrangement mode were configured, and the structural parameters of the furrowing plow were optimized to include a soil penetration angle of 20°, an oblique cutting angle of 75°, and a curvature radius of 280 mm. Field experiments have proven that the soil entry movement trajectory, the length and width of the accessible seed placement space, and the average planting depth of cane seeds could all achieve respective design anticipations of the combined trencher. The measured trenching resistance was 7609.7 N, with an error of 22.2% from the predicted value under the same configuration. Full article

This research initiative, developed in response to the need for enhanced mechanization efficiency within solar greenhouses, particularly under yellow sand cultivation conditions, introduces an integrated ditching and film-covering machine. A novel spiral staggered throw-cut combined ditching knife was specifically engineered and optimized to meet the exacting agronomic requirements of embedded substrate cultivation. Extensive analyses of soil interactions and the formulation of dynamic equations for soil particles facilitated the determination of key operational parameters: a tangent height of 650 mm for the ditching knife, a soil-throwing width of 300 mm, a piece width of 120 mm, and an inclination angle of 30°. Performance simulations of the ditching knife, conducted using the discrete element method (DEM), revealed superior soil disturbance control and improved soil return compared to conventional designs. Critical operational variables such as forward speed, knife shaft speed, and ditching depth were rigorously tested, with trench depth quality and power consumption as primary evaluation metrics. The results demonstrated that knife shaft speed profoundly influences performance, with optimal operating parameters established through detailed field testing: a speed of 0.5 m/s, a blade shaft speed of 200 rpm, and a ditching depth of 300 mm. Under these optimized conditions, the machine achieved power consumption of 0.668 kW, trench depth stability of 86.7%, a surface width of 413 mm, a bottom width of 304 mm, and an average ditching depth of 310 mm, achieving a qualification rate of 87.1%. The post-ditching soil crushing rate was 92.4%. Both simulation and field evaluations validated that the innovative ditching knife markedly enhances ditching and soil-throwing quality in sandy soil, fulfills agronomic requirements for tomato sowing, and provides an essential reference for the mechanized planting of crops in the yellow sand matrix cultivation mode of solar greenhouses. Full article

The stability and deformation during trenching of ultra-deep diaphragm walls have a greater impact on the construction of diaphragm walls. The conventional limit equilibrium method, known as the vertical slices method, assumes homogeneity within the rock and soil mass, making it challenging to account for their stratification. Based on the limit equilibrium method, the horizontal strip method takes into account the stratification of the foundation soil. Based on the actual project, considering the different mud unit weights and heights, the horizontal strip method was used to analyze the stability of the groove trench and analyze the deformation law of the groove trench by the finite element method. The results indicate the following: The horizontal strip method can effectively assess the influence law of mud weight and height on the safety coefficient of groove trench stabilization. The higher the unit weight and level of slurry, the greater the wall safety coefficient. Moreover, the mud unit weight obtained by the horizontal strip method is about 12.70~12.64 kN/m³, which is close to the actual maximum mud weight of 12.5 kN/m³. The estimated mud unit weight aligns more closely with actual conditions. Additionally, through finite element analysis, the deformation law of the groove trench of ultra-deep diaphragm walls has been analyzed and summarized. The soil around the groove trench does not move inward, which shows three different deformation modes with different depths. Full article

This paper addresses challenges in the application of existing colters in Chinese ecological tea plantations due to abundant straw roots and insufficient tillage depth. Aligned with the agronomic requirements of hilly eco-tea plantations, our study optimizes the structural advantages of the joint use of rotary tillage blades and double-disc colters to design an efficient trenching device. Our investigation explores the motion characteristics of a double-disc colter during deep trenching operations, in conjunction with rotary tillage blades. Employing discrete element method (DEM) simulations, this paper aims to minimize the working resistance and enhance the tillage depth stability. Single-factor experiments are conducted to determine the impact of key structural parameters on the tillage depth stability and working resistance. The optimal parameters are determined as a relative height of 80 mm to 120 mm, a 280 mm to 320 mm diameter for the double-disc colter, and a 10° to 14° angle between the two discs. The central composite design method is used to optimize the structural parameters of the double-disc colter. The results indicate that when the relative height is 82 mm, the diameter of the double-disc colter is 297 mm, and the angle between the two discs is 14°, the tillage depth stability performance reaches 91.64%. With a working resistance of merely 93.93 N, the trenching device achieves optimal operational performance under these conditions. Field validation testing shows a tillage depth stability coefficient of 92.37% and a working resistance of 104.2 N. These values deviate by 0.73% and 10.93%, respectively, from the simulation results, confirming the reliability of the simulation model. A field validation test further confirms that the operational performance of the colter aligns with the agronomic requirements of ecological tea plantations, offering valuable insights for research on trenching devices in such environments. Full article

In the realm of high-speed precision broadcasting, the existing seeder opener proves inadequate for the speed of the seeding operation. We focus on the duckbill opener and employ the quadratic regression orthogonal rotation combination test design method to optimize the structural parameters of the opener. Throughout the experiment, the primary performance metrics encompassed the opener’s working resistance and the side dumping distance. The selected experimental factors comprised the penetration angle, the angle of soil entry gap, the shovel body width, and the shovel length. The optimal arrangement of structural parameters has been determined: a penetration angle, a soil entry gap angle, a shovel body width of 21 mm, and a shovel length of 142 mm. These parameters contribute to increased velocity, reduced operational resistance, and minimal soil disturbance. Under this combination, the relative deviations between the recorded measurements and the theoretical outcomes for working resistance and the side dumping distance stand at 4.24% and 1.06%, respectively; these confirm the credibility of the optimization results. We performed adaptability testing and conducted a comparative analysis under various operational conditions to assess the innovative opener’s ability to reduce force, minimize soil disruption, and maintain depth stability. The findings are as follows: At a depth of 5 cm and velocities ranging from 6 km/h to 8 km/h, an average working resistance reduction of 19.73%, a 5.64% decrease in the side dumping distance, and an average depth stability of 89.5% were observed. When operated at a speed of 7 km/h with a depth ranging from 3 cm to 5 cm, an average reduction of 19.66% in operational resistance, a 2.59% decrease in the side dumping distance, and an average depth stability of 91.1% were recorded. These results illustrate the innovative opener’s capacity to significantly reduce working resistance and side dumping distance while satisfying the depth stability requisites. Full article

The damage to pipeline infrastructures caused by reactive soils has been a critical challenge for asset owners. Sustainable backfilling materials have recently gained interest to stabilize highly reactive zones as a pre-emptive approach towards sustainability. In this study, two adjacent sections of a sewer pipeline trench in Melbourne, Australia were backfilled with two blends of 100% recycled aggregates. The sites were monitored for ground deformations during October 2020–February 2022 (17 months) using surveying techniques. Interferometric synthetic aperture radar (InSAR) techniques and algorithms were also employed to estimate the ground movements of the sites and surrounding regions. The cross-validation of deformation results achieved from both techniques enabled an in-depth analysis of the effectiveness of the recycled aggregates to address reactive soil issues in urban developments. Observational deformation data and their spatiotemporal variation in the field were satisfactorily captured by the InSAR techniques: differential InSAR (DInSAR), persistent scatterer interferometry (PSI), and small baseline subset (SBAS). The SBAS estimations were found to be the closest to field measurements, primarily due to the analysis of zones without well-defined geometries. This study’s contribution to existing knowledge defines the spatiotemporal influence of sustainable backfill in areas with reactive soil through field data and satellite imaging. The relationship between InSAR techniques and actual field behavior of sustainable backfill can be a baseline for the growing construction that may be challenging to perform field monitoring due to resource constraints. Full article

Codonopsis pilosula is cultivated mainly in sandy soils, especially in the Dingxi area of the Gansu province, northwest China. They are mainly planted in hilly areas, where large machines cannot reach easily. Codonopsis pilosula transplanting has been adopted with a conventional flat planting way, film mulching and seedling outcrops. While its planting requires opening a shallow ditch, short operation cycle, considerable labor intensity and is in large demand, a simulation analysis was performed according to specific tillage resistance, helpful in the optimization design in later stages and the improvement of a domestic ditching plow’s performance. This paper studies the simulation performance of an adjustable trench plough and analyzes the orthogonal test and Design-Expert response surface of the data. EDEM simulation software was used to analyze the traction resistance of the furrow ditching mechanism in the ditching process. The results show that the traction resistance increased from 1751.31 N to 2197.31 N as the simulation working speed increased from 0.9 m/s to 1.5 m/s, 1.25 times higher than the former. It indicates that speed had significant effects on traction resistance. With the increase in working speed, the furrow traction resistance and specific consumed power were increased considerably. Using the stability coefficient of the ditching depth and consistency coefficient of ditching bottom width as test indices, speed and angle of furrowing as impact factors, Box–Behnken orthogonal experiment design method, and establishing test indices and test factors, the regression model between the analysis of the influence of the test index, comprehensive agronomic requirements and MATLAB factor optimization of the experiment, the optimized operation parameter combination was obtained: the forward speed was 0.9 m/s, the angle of ditching was 35° and the stability coefficient of the ditching depth and consistency coefficient of ditch bottom width were 97.57% and 98.03%, respectively. The data after the simulation comparison test can provide a design reference for the domestic small trench operation. Full article

Electroosmotic flow (EOF) is fluid flow induced by an applied electric field, which has been widely employed in various micro-/nanofluidic applications. Past investigations have revealed that the presence of nanostructures in microchannel reduces EOF. Hitherto, the angle-dependent behavior of nanoline structures on EOF has not yet been studied in detail and its understanding is lacking. Numerical analyses of the effect of nanoline orientation angle θ on EOF to reveal the associated mechanisms were conducted in this investigation. When θ increases from 5° to 90° (from parallel to perpendicular to the flow direction), the average EOF velocity decreases exponentially due to the increase in distortion of the applied electric field distribution at the structured surface, as a result of the increased apparent nanolines per unit microchannel length. With increasing nanoline width W, the decrease of average EOF velocity is fairly linear, attributed to the simultaneous narrowing of nanoline ridge (high local fluid velocity region). While increasing nanoline depth D results in a monotonic decrease of the average EOF velocity. This reduction stabilizes for aspect ratio D/W > 0.5 as the electric field distribution distortion within the nanoline trench remains nearly constant. This investigation reveals that the effects on EOF of nanolines, and by extrapolation for any nanostructures, may be directly attributed to their effects on the distortion of the applied electric field distribution within a microchannel. Full article

For those slopes where the piezometric regime acts as internal landslide predisposing factor, drainage may represent a more effective mitigation measure than other structural interventions. However, drainage trenches have been generally considered as mitigation measure solely for shallow landslides. More recently, instead, some authors show that the variation in piezometric conditions at large depth is not negligible when medium depth drainage trenches are involved. The paper presents the results of finite element analyses of the transient seepage induced by the installation of systems of drainage trenches of different geometric parameters, and the effect of the drainage system on the stability factor of the slip surface, through 2D limit equilibrium analyses. The pilot region is the Daunia Apennines, where field studies have led to recognize for most of the landslides a “bowl-shaped” slip surface; the results accounting for the Fontana Monte slope at Volturino (Italy), selected as prototype landslide in the assessment of the stabilization efficacy of deep drainage trench systems, is discussed in the following. The study aims at providing indications about the design of the drainage trenches to reduce the pore water pressures on a deep slip surface of such type. Full article
