Search Results (142)

The sub-synchronous oscillation (SSO) characteristics and suppression strategies of a hybrid system comprising doubly fed induction generator (DFIG)-based wind turbines and synchronous pumped storage units connected to the power grid via series-compensated transmission lines are analyzed. A modular modeling approach is used to construct a detailed system model, including the wind turbine shaft system, DFIG, converter control system, synchronous machine, excitation system, power system stabilizer (PSS), and series-compensated transmission lines. Eigenvalue calculation-based small-signal stability analysis is conducted to identify the dominant oscillation modes. Suppression measures are also developed using relative participation analysis, and simulations are carried out to validate the accuracy of the model and analysis method. The analysis results indicate that the SSO phenomenon is primarily influenced by the electrical state variables of the DFIG system, while the impact of the state variables of the synchronous machine is relatively minor. When the level of series compensation in the system increases, SSO is significantly exacerbated. To address this issue, a sub-synchronous damping controller (SSDC) is incorporated on the rotor side of the DFIG. The results demonstrate that this method effectively mitigates the SSO and significantly enhances the system’s robustness against disturbances. Furthermore, a simplified modeling approach is proposed based on relative participation analysis. This method neglects the dynamic characteristics of the synchronous machine while considering its impact on the steady-state impedance and initial conditions of the model. These findings provide theoretical guidance and practical insights for addressing and mitigating SSO issues in hybrid renewable energy systems composed of DFIGs and synchronous machines. Full article

This paper presents a comprehensive analysis of the effects of noise on the detection and localization of faults in transmission lines compensated with a unified power flow controller using traveling wave-based methods. This study focuses on the impact of harmonic and transient noises, which are inherent to power generation, transmission, and UPFC operation. A novel algorithm is proposed combining the Discrete Wavelet Transform and Clarke Transform to detect and localize faults under various noise conditions. The algorithm is tested on a simulated transmission line model in MATLAB/Simulink (Version R2022b) with noise levels of 20 dB, 30 dB, and 40 dB and transient frequencies of 1 kHz, 5 kHz, and 10 kHz. The results demonstrate that the algorithm achieves an average fault localization error of 0.523% under harmonic noise and 0.777% under transient noise, with fault detection rates of 96.3% and 90.75%, respectively. This study highlights the robustness of the traveling wave method in noisy environments and provides insights into the challenges posed by UPFC-compensated lines. Full article

Energy storage systems (ESSs) and active power filters (APFs) are key power electronic technologies for FACTS (Flexible AC Transmission Lines). Battery energy storage has a structure similar to a shunt active power filter, i.e., a storage element and a voltage source inverter (VSI) connected to the grid using a PWM filter and/or transformer. This similarity allows for the design of an ESS with the ability to operate as a shunt APF. One of the key milestones in ESS or APF development is the DC-link design. The proper choice of the capacitance of the DC-link capacitors and their equivalent resistance ensures the proper operation of the whole power electronic system. In this article, it is proposed to estimate the required minimum DC-link capacitance using a spectral analysis of the DC-link current for different operating modes, battery charge mode and harmonic compensation mode, for a nonlinear load. It was found that the AC component of the DC-link current is shared between the DC-link capacitors and the rest of the DC stage, including the battery. This relation is described analytically. The main advantage of the proposed approach is its universality, as it only requires calculating the harmonic spectrum using the switching functions. This approach is demonstrated for DC-link capacitor estimation in two-level and three-level NPC inverter topologies. Moreover, an analysis of the AC current component distribution between the DC-link capacitors and the other elements of the DC-link stage was carried out. This part of the analysis is especially important for battery energy storage systems. The obtained results were verified using a simulation model. Full article

IV line connectors often become contaminated between infusions, which leads to line infections. A flexible shield was developed to prevent this by means of passive protection. It was tested in a simulated bedside environment and protected from touch contamination as well as airborne transmission of skin bacteria to the connector hub. This flexible shield can compensate for the unavoidable human factor infection control lapses that occur during IV line handling by healthcare workers. Full article

A growing interest in offshore wind energy in the Mediterranean Sea has been recently observed thanks to the potential for scale-up and recent advances in floating technologies and dynamic cables: in the Italian panorama, the offshore wind connection requests to the National Transmission Grid (NTG) reached almost 84 GW at the end of September 2024. Starting from a realistic estimate of the offshore wind power plants (OWPPs) to be realized off the southern coasts in a very long-term scenario, this paper presents a novel optimization procedure for meshed AC offshore network configuration, aiming at minimizing the offshore wind generation curtailment based on the DC optimal power flow approximation, assessing the security condition of the whole onshore and offshore networks. The reactive power compensation aspects are also considered in the optimization procedure: the optimal compensation sizing for export cables and collecting stations is evaluated via the AC optimal power flow (OPF) approach, considering a combined voltage profile and minimum short circuit power constraint for the onshore extra-high voltage (EHV) nodes. The simulation results demonstrate that the obtained meshed network configuration and attendant re-active compensation allow most of the offshore wind generation to be evacuated even in the worst-case scenario, i.e., the N1 network, full offshore wind generation output, and summer line rating, testifying to the relevance of the proposed methodology for real applications. Full article

This paper presents a new method for fault location in transmission lines with series compensation, using data from voltage and current measurements at both terminals, applied to artificial neural networks. To determine the fault location, we present the proposal of using current phasors, obtained from the oscillography recorded during the short circuit, as the input to the neural network for training. However, the method does not rely on the internal voltage values of the sources or their respective equivalent Thevenin impedances to generate training files for the neural network in a transient simulator. The source data are not known exactly at the time of the short circuit in the transmission line, leading to greater errors when neural networks are applied to real electrical systems of utility companies, which reduces the dependency on electrical network parameters. To present the new method, a conventional fault location algorithm based on neural networks is initially described, highlighting how the dependency on source parameters can hinder the application of the artificial neural network in real cases encountered in utility electrical systems. Subsequently, the new algorithm is described and applied to simulated and real fault cases. Low errors are obtained in both situations, demonstrating its effectiveness and practical applicability. It is noted that the neural networks used for real cases are trained using simulated faults but without any data from the terminal sources. Although we expect the findings of this paper to have relevance in transmission lines with series compensation, the new method can also be applied to conventional transmission lines, i.e., without series compensation, as evidenced by the results presented. Full article

This paper addresses the optimal placement and sizing of Modular Static Synchronous Series Compensators (M-SSSCs) to enhance power system performance. The proposed methodology optimizes four key objectives: reducing transmission line loadability, minimizing power losses, mitigating voltage deviations, and enhancing voltage stability using the L-index. The methodology is validated on two systems: the IEEE 14-bus test network and a sub-area of the Colombian power grid, characterized by aging infrastructure and operational challenges. The optimization process employs three metaheuristic algorithms—Genetic Algorithm (GA), Particle Swarm Optimization (PSO), and Teaching–Learning-Based Optimization (TLBO)—to identify optimal configurations. System performance is analyzed under both normal operating conditions and contingency scenarios (N − 1). The results demonstrate that M-SSSC deployment significantly reduces congestion, enhances voltage stability, and improves overall system efficiency. Furthermore, this work highlights the practical application of M-SSSC in modernizing real-world grids, aligning with sustainable energy transition goals. This study identifies the optimal M-SSSC configurations and placement alternatives for the analyzed systems. Specifically, for the Colombian sub-area, the most suitable solutions involve installing M-SSSC devices in capacitive mode on the Termocol–Guajira and Santa Marta–Guajira 220 kV transmission lines. Full article

In heavily loaded regional power grids, some AC transmission lines are confronting escalating pressures due to excessive short-circuit currents. To optimize AC channels, most research advocates for retrofitting existing AC lines into multi-line-commutated converter-based high-voltage direct current (LCC-HVDC) lines. However, there is a contradiction between limited land area for AC stations and the relatively large footprint of passive filters in LCC-HVDC; this paper introduces self-adapted LCC (SLCC) by replacing passive filter groups with a static var generator (SVG). Secondly, the reactive power compensation, harmonic filtering control methods of SVGs, and operation characteristics of the SLCC system are explored, and the harmonics of the grid-side current are reduced by nearly 14.6%. Then, to fill the gap of previous studies on solely AC or AC-DC line touching, inspired by emerging DC line-touching risks in double-circuit (LCC and SLCC) lines on the same tower, the equivalent models are formulated to elucidate the evolution mechanisms of voltage/current and extract fault features in various line-touching faults; it finds that the longitudinal differential current during line-touching faults can be capitalized. Based on the current feature, an effective protection algorithm tailored for the identification of DC line-touching faults is proposed. Finally, simulations are conducted to validate the efficacy of proposed control and protect methods, demonstrating the potential to enhance the reliability of AC to DC conversion projects. Full article

The integration of advanced nuclear technologies like the System-Integrated Modular Advanced Reactor (SMART) offers a transformative approach to enhancing grid reliability in developing countries. This study focuses on the Nairobi distribution network in Kenya, a critical region characterized by an evolving energy mix of geothermal, hydro, solar, and wind power sources, comprising 220 kV and 132 kV transmission lines feeding 66 kV, 33 kV, and 11 kV distribution lines to various load centers. Using ETAP 22 simulation software, the research evaluates the impact of SMART integration through three scenarios: baseline operation, grid compensator-only operation, and SMART-SMR integration. Key reliability indices such as the System Average Interruption Frequency Index (SAIFI), System Average Interruption Duration Index (SAIDI), and Expected Energy Not Supplied (EENS) were analyzed. Results reveal that integrating a 100 MW SMART reactor reduces SAIDI by 2.8% (5.0433 h/customer-year) and SAIFI by 5.1% (0.0516 interruptions/customer-year), while maintaining voltage profiles within 98.21–98.91% of nominal. This analysis bridges gaps in prior research by demonstrating SMART’s ability to stabilize power grids in emerging economies, providing critical insights for policymakers aiming to achieve reliable and sustainable energy systems. Full article

This paper proposes a novel strategy for the current injection-based control of distributed energy resources connected to weak grids via a voltage source converter. The current injection controller is no longer synchronized with the point of common coupling but with the strong grid point voltage. The strong grid synchronization control strategy improves the output dynamics of the voltage source converter and recovery after faults in weak grids. The phase difference between the voltage source converter and the strong grid voltages caused by the long power lines does not affect the power control. Furthermore, a time delay-compensation method is proposed which tolerates the communication time delay introduced by the transmission of the synchronization signal from the strong grid point. The performance of the proposed control strategy is verified in detail using MATLAB 2023b simulations and real-time digital simulations on a medium voltage model and also validated in an experiment on a low-voltage grid-feeding inverter setup. Full article

The implementation of inductive compensation in the two-scale models of the extra-high-voltage transmission line, without and with transposition, of the Physical Laboratory of Electric Power Systems (PLEPS) is presented. As they have voltages above the normal operating range, for a situation like that of the real 500 kV Coca Codo Sinclair–El Inga lines in Ecuador, the problem was solved by incorporating parallel inductive reactors located at the ends of the lines. The fixed bus compensation used was carried out by means of three-phase inductors in star connection with neutral-to-ground voltage and built-in iron cores with pitches of 50, 75 and 100% of the design capacity. Full article

Fault location estimation in transmission lines is critical for power system reliability. Various methods have been developed for this purpose, among which transient frequency spectrum analysis (TFSA) stands out as a recent method based on travelling wave (TW) theory. TFSA determines the fault location by analyzing the frequency spectrum of transient currents and/or voltages at the instant of the fault, offering advantages such as independence from fault impedance and the ability to locate faults with one-side measurements. Despite its success in fault location, TFSA has several considerations that warrant detailed investigation. This study explores the effects of source inductance, series compensation, fault arc, and current transformer (CT) characteristics on transient frequencies. Additionally, the impact of noise on TFSA results is examined. The new proposed source inductance compensation method can reduce the error of 6.55% to 0.88%, where the same error can be reduced to 3.45% with the compensation method given in previous study. Strategies to enhance accuracy are discussed and compared to previous studies, including a proposed detection approach providing appropriate data size and precise wave propagation speed calculations. These findings contribute to a deeper understanding of TFSA’s limitations and inform practical improvements for fault location accuracy in power transmission systems. Full article

The doubly fed variable speed pumped storage (DFVSPS) system is a hydraulically, mechanically, and electrically coupled system, and the characteristics of the components from the water conveyance system to the transmission line need to be fully considered in the oscillation analysis. Hence, the model of the water conveyance system is included to investigate the oscillation characteristics of the DFVSPS connecting to the grid via a series-compensated line. A small-signal state-space model of the DFVSPS system in the generation mode is first established. The oscillation characteristics of the DFVSPS are studied, and the dominant state variables for each oscillation mode are identified. The impact of system parameters on oscillations is further studied, and simulations are carried out to validate the accuracy of the model. The results indicate the oscillation mode of the DFVSPS comprises the electrical sub-synchronous oscillation (SSO) mode and the hydraulically, mechanically coupled low-frequency mechanical oscillation modes. When the series compensation level is high, the SSO becomes divergent, and the system is more likely to be unstable. Optimizing the rotor-side control parameters and the governor control parameters, sub-synchronous and low-frequency oscillations could be effectively suppressed, respectively. This study provides reference suggestions for the development and use of the future DFVSPS system. Full article

This paper introduces a novel differential combiner designed to effectively address parasitic capacitances of transistors used in power amplifier (PA) designs with precise compensation at a specified frequency. The combiner consists of a $\lambda /4$ transmission line with an integrated capacitor of value $2C_{OUT}$ at its midpoint, which ensures accurate cancellation of parasitic effects. This design connects the drain pins of two transistors, which are considered identical in this configuration. By eliminating the need for complex parasitic compensation techniques, this method significantly simplifies the design process of Doherty Power Amplifiers (DPAs). Extensive simulations validate the effectiveness of this approach, highlighting its potential as a versatile and straightforward solution for next-generation communication systems. Full article

Wireless Power Transfer (WPT) can effectively solve the problem of autonomous power supply for low-power devices. Rectifier is the key component in WPT technology. In this paper, a novel impedance matching network for the broadband rectifier is proposed. This impedance matching network compensates for the diode impedance and reduces its impedance change when the frequency or input power changes. The passive boosting mechanism utilizing coupled transmission lines (CTLs) improves the power conversion efficiency (PCE) of the diode in the low power region. The structure is especially optimized for low-power device applications. For validation, a broadband rectifier operating at 1.9–3 GHz is fabricated and measured. The structure fabricated on the Rogers 4003 substrate with a thickness of 1.508 mm and the diode is HSMS2860. The DC voltage $V_{out}$ on the load ($R_L=1300$ Ω) was measured. The results show that at 0 dBm, the PCE keeps more than 60% at 1.98–3 GHz. The peak PCE of 79.6% is obtained at 4 dBm. The compact size of the broadband rectifier is 19 mm × 21 mm. This broadband rectifier for low input power ranges can be applied to WPT technology. Full article
