Bearingless interior permanent magnet synchronous motors (BIPMSMs) have received considerable attention in recent research due to their advantages of high speed, high power density, and absence of mechanical wear. In order to improve the torque and suspension performance of the BIPMSM, an optimization design method of BIPMSM is proposed in this paper based on sensitivity analysis, response surface fitting, and the multi-objective whale optimization algorithm (MOWOA). Firstly, the structure and operation principle of the BIPMSM are introduced. Secondly, significant variables are extracted based on sensitivity analysis. Then, regression equations of the significant variables and optimization objectives are fitted by the response surface method, and global optimization is performed with MOWOA. Finally, the motor performance before and after optimization is compared. The results demonstrate that the proposed multi-objective optimization design scheme can significantly improve the performance of the BIPMSM and effectively shorten the design cycle. Full article

Aiming at the multifunctional requirements of the limited space in high-end vehicle side-door latches, a double single-loop RRUPRR mechanism driven by a single motor for both electric releasing and cinching is proposed based on the POC set. The kinematical equations of the RRURR mechanism possess 2 × 2 analytical solutions. In order to apply the current motion/force transmission performance index of the parallel mechanisms to the transmission performance analysis of the serial mechanisms, matching methods for chain-driving transference and the moving/fixed platform inversion are proposed. The solution of the performance index of a single-degree-of-freedom single-loop mechanism is equivalent to the solution of the input motion/force transmission performance index of a parallel mechanism. The overall motion/force transmission performance index of a single-loop mechanism is constructed, and the corresponding calculation procedure is defined. Chain-driving transference can be obtained through forward and inverse solutions of the RRURR mechanism. In response to the extremely high requirements for motion/force transmission performance of electric release mechanisms, the proposed overall motion/force transmission performance index is used to calculate for the input motion screw and corresponding transmission-force screw of the single-loop RRURR mechanism and obtain the overall motion/force transmission performance of the mechanism. The performance atlas of the mechanism shows that it has excellent motion/force transmission characteristics within the workspace. Using ADAMS simulation software, the driving torque required for electric releasing and cinching of a vehicle side-door latch mechanism with a single motor is analyzed. The overall motion/force transmission performance index of a single-loop mechanism can be applied to single-loop overconstrained mechanisms and non-overconstrained mechanisms. Full article

The dynamics of the vibrational mode of motion of the driving member of a nonideal system, a mixing–whipping device based on a simple slide-crank mechanism, was studied. The highly nonlinear differential equations of motion were solved numerically by the Runge–Kutta method. The interaction of the mixing–whipping device with the nonideal excitation source causes the rotational speed of the engine shaft and the rotation angle of the driving member to fluctuate, accomplishing a damped process. The parameters of the device and the nonideal energy source have an effect on the kinematic, vibrational and energy characteristics of the system. An increase in the engine’s torque, crank length, number and radius of piston holes, and piston mass, as well as a decrease in the fluid’s density, leads to a reduction in the oscillation range of the crank angle, amplitude and period of angular velocity oscillations of the engine shaft and the mixing–whipping force power. The effects of a nonideal energy source may be used in designing a mixing–whipping device based on a slider-crank mechanism to select effective system parameters and an energy-saving motor in accordance with the requirements of technological processes and products. Full article

With the acceleration of industrialization, deformable mechanisms that can adapt to complex environments have gained widespread applications. Joints serve as carriers for transmitting forces and motions between components, and their stiffness significantly influences the static and dynamic characteristics of deformable mechanisms. A variable stiffness joint is crucial for ensuring the safety and reliability of the system, as well as for enhancing environmental adaptability. However, existing variable stiffness joints fail to meet the requirements for miniaturization, lightweight construction, and fast response. This paper proposes a piezoelectric-actuated variable stiffness miniature rotary joint featuring a compact structure, monitorable loading state, and rapid response. Given that the piezoelectric stack expands and contracts when energized, this paper proposes a transmission principle for stiffness adjustment by varying the pressure and friction between active and passive components. This joint utilizes a flexible hinge mechanism for displacement amplification and incorporates a torque sensor based on strain monitoring. A static model is developed based on piezoelectric equations and displacement amplification characteristics, and simulations confirm the feasibility of the stiffness adjustment scheme. The mechanical characteristics of various flexible hinge structures are analyzed, and the effects of piezoelectric actuation capability and external load on stiffness adjustment are examined. The experimental results demonstrate that the joint can adjust stiffness, and the sensor is calibrated using the least squares algorithm to monitor the stress state of the joint in real time. Full article

To address the shortcomings of existing robot collision detection algorithms that use six-dimensional force sensors, a force compensation algorithm based on Kane’s dynamics is proposed, along with a collision detection algorithm that uses the six-dimensional force sensor data combined with the robot’s outer surface equations to derive the robot body’s collision point coordinates. Firstly, a collision detection model for a joint-type collaborative robot is presented. Secondly, based on Kane’s dynamics equations, a force compensation model for the joint-type collaborative robot is established and the corresponding force compensation algorithm is derived. Thirdly, a collision detection algorithm is derived, and an example using a cylindrical joint robot with a link’s outer surface equation is used to solve the collision point. The collision is categorized into nine cases, and the coordinates of the collision point are solved for each case. Finally, force compensation and collision detection experiments are conducted on an AUBO-I5 joint-type collaborative robot. The results of the force compensation show that the comparison curves for forces/torques in three directions are consistent, and the relative error is below 5.6%. The collision detection results indicate that the computed collision positions match the actual collision positions, thus verifying the correctness of the theoretical analysis of the force compensation and collision detection algorithms. The research results provide a theoretical basis for ensuring safety in human–robot collaboration. Full article

A semi-analytical investigation is conducted to examine the coupled translational and rotational motions of a composite spherical particle (consisting of an impermeable hard core surrounded by a permeable porous shell) immersed in a viscous fluid parallel to one or two planar boundaries under the steady condition of a low Reynolds number. The fluid flow is described using the Stokes equations outside the porous shell and the Brinkman equation within it. A general solution is formulated by employing fundamental solutions in both spherical and Cartesian coordinate systems. The boundary conditions on the planar walls are implemented using the Fourier transform method, while those on the inner and outer boundaries of the porous shell are applied via a collocation technique. Numerical calculations yield hydrodynamic force and torque results with good convergence across a broad range of physical parameters. For validation, the results corresponding to an impermeable hard sphere parallel to one or two planar walls are shown to be in close agreement with established solutions from the literature. The hydrodynamic drag force and torque experienced by the composite particle increase steadily with larger values of the ratio of the particle radius to the porous shell’s permeation length, the ratio of the core radius to the total particle radius, and the separations between the particle and the walls. It has been observed that the influence of the walls on translational motion is significantly stronger than that on rotational motion. When comparing motions parallel versus normal to the walls, the planar boundaries impose weaker hydrodynamic forces but stronger torques during parallel motions. The coupling between the translation and rotation of the composite sphere parallel to the walls exhibits complex behavior that does not vary monotonically with changes in system parameters. Full article

In this paper, we construct the conformable actuated pendulum model in the conformable Lagrangian formalism. We solve the equations of motion in the absence of force and in the case of a specific force resulting from torques, which generalizes a well known mechanical model. Our study shows that the conformable model captures essential information about the physical system encoded in the parameters which depend on the conformability factor $\alpha$. This dependence can describe internal variations such as viscous friction, transmission, or environmental effects. We solve the equations of motion analytically for $\alpha =1/2$ and using Frobenius’ method for $\alpha \ne 1/2$. Full article

The globally robust control of a four-link manipulator arm (FLMA) is an important subject for a wide range of industrial applications such as COVID-19 prevention robotics, lower limb rehabilitation robotics and underwater robotics. This article uses the feedback linearized approach to stabilize the complex nonlinear FLMA without applying a nonlinear approximator that includes the fuzzy approach and neural network optimal approach. This article proposes a new approach based on the “first” derived nonlinear convergence rate formula of the FLMA to control highly nonlinear dynamics. The linear quadratic regulator (LQR) method is often applied in the balance controlling space of the underactuated manipulator. This proposed approach takes the place of the LQR approach without the necessary trial and error operations. The implications of the proposed approach are “globally” effective, whereas the Jacobian linearized approach is “locally” valid. In addition, the main innovation of the proposed approach is to perform “simultaneously” additional performances including almost disturbance decoupling performance, which takes the place of the traditional posture–energy approach and avoids some torque chattering behaviour in the swing-up space, and globally exponential stable performance, without the need to solve the Hamilton–Jacobin equation. Simulations of comparative examples show that the proposed controller is superior to the singular perturbation and fuzzy approaches. Full article

To address the issues of poor stability and susceptibility to external disturbances in traditional model reference adaptive systems (MRASs) for permanent magnet synchronous motors (PMSMs), this paper proposes a sliding mode control strategy based on an improved model reference adaptive observer. First, the dynamic equations of the PMSM are used as the reference model, while the stator current equations incorporating speed variables are constructed as the adjustable model. Subsequently, a novel adaptive law is designed using Popov’s hyperstability theory to enhance the estimation accuracy of rotor position. A fractional-order system was introduced to construct both a fractional-order sliding surface and reaching law. Subsequently, a comparative study was conducted between the conventional integral terminal sliding surface and the proposed novel sliding mode reaching law. The results demonstrate that the new reaching law can adaptively adjust the switching gain based on system state variables. Under sudden load increases, the improved system achieves a 25% reduction in settling time compared to conventional sliding mode control (SMC), along with a 44% decrease in maximum speed fluctuation and a 42% reduction in maximum torque ripple, significantly enhancing dynamic response performance. Furthermore, a variable-gain terminal sliding mode controller is derived, and the stability of the closed-loop control system is rigorously proven using Lyapunov theory. Finally, simulations verify the effectiveness and feasibility of the proposed control strategy in improving system robustness and disturbance rejection capability. Full article

This work presents the design and experimental validation of a position-controlled rotating mechanism featuring multi-stage variable stiffness. Before designing the overall mechanism, three different compliant mechanisms, based on flexible beams, are parametrically optimized using a SolidWorks–Ansys co-simulation technique. The flexible beams are composed of multiple straight segments, Bezier curves, and multiple arc segments. The corresponding torque–deflection curves of the compliant mechanisms are collected and fitted into analytical expressions, from which the stiffness equation varying with the angular position is derived for stiffness regulation. A combination of three-stage compliant mechanisms connected in serial is realized to prototype the physical mechanism, which can have three different stiffness ranges of the output shaft. The maximum stiffness is about nine times higher than the lowest one, leading to a broader bandwidth of varying stiffness, which can make the mechanism more adaptive to the external payloads for safety consideration. Experimental measurements are carried out, and the comparison shows a good agreement between the experimental and simulation results, which experimentally validated the design concept. The compact and simple structure, as well as the multi-stage variable stiffness ranges, implies high adaptability of the designed mechanism. Full article

Firstly, the Reynolds equation considering gas inertia force is theoretically deduced in the cylindrical coordinate system, and then a mathematical model of aerostatic thrust bearing with three degrees of freedom (3-DOF) is constructed. Secondly, the Reynolds equation and velocity control equation are solved by the finite difference method (FDM), and the characteristics of gas pressure and velocity distribution in the gas film under steady-state conditions are revealed. On this basis, in the single-factor analysis, the bearing capacity error and recovery torque error caused by the inertia force term are quantitatively analyzed. It is found that the bearing rotating speed has a significant influence on the inertial force error, and the bearing radius also has a certain influence on the inertial force error, while the initial clearance, gas supply pressure, and torsion angle have relatively little influence on the inertial force error. Finally, in the multi-factor analysis, the sample regression equation of relative error of bearing capacity and relative error of restoring torque is established by using the multiple regression analysis method. By comparing the estimated values with the simulation results, the validity of the constructed regression equation is verified. Full article

Ocean energy represents a promising resource for renewable energy generation. Hydrokinetic turbines (HKTs) provide a sustainable method to extract energy from ocean currents. However, turbine efficiency remains limited, particularly in marine environments with low flow velocities. A parametric evaluation of blade configurations is conducted in this study to assess their effect on the power and torque performance of a double-stage drag-based Savonius HKT. Numerical simulations are conducted using the Unsteady Reynolds-Averaged Navier-Stokes (URANS) equations with the k-ω SST turbulence model. The numerical model is validated against published data, and analyses on mesh density, domain size, and time step are performed to ensure accuracy. Three blade configurations—(0°, 0°), (0°, 45°), and (0°, 90°) are evaluated under flow velocities of 0.6 m/s, 0.8 m/s, and 1.0 m/s. Results indicate that blade configuration significantly affects turbine performance. The (0°, 0°) configuration performs best at high flow velocity (1.0 m/s), while the (0°, 45°) setup achieves the highest efficiency at 0.6 m/s. The (0°, 90°) configuration performs the least effectively across all conditions. A similar performance trend is observed for the torque coefficient. This study recommends selecting blade configurations based on flow velocity, providing design guidance for double-stage HKTs operating in varying marine conditions. Full article

A partial Lagrangian method is proposed as an inverse dynamics analysis method for multi-link systems. This method, combined with automatic differentiation, allows for the derivation of equations of motion and analytical extraction of motion-induced torque components. We introduce the concept of motion propagation force to describe joint torque components generated by the motion of other joints. This concept aligns with existing notions such as interaction torque, while providing a novel analytical perspective. The effectiveness of the proposed method is confirmed through simulations using a three-DoF arm model, where motion propagation torques are visualized and validated. This method is useful for motion analysis and impedance control in complex robotic systems. Full article

This work focuses on the small Bearingless Brushless DC Motor (BL-BLDCM), to solve the problems, such as larger commutation torque ripple and difficult solution of air-gap magnetic field, a novel BL-BLDCM structure with like-tangential parallel-magnetization interpolar magnetic poles (LTPMIMPs) is proposed, which is abbreviated as BL-BLDCM-LTPMIMP in this work, and the analytical calculation model of its air-gap magnetic field has been investigated. First, inserting a like-tangential parallel magnetizing auxiliary magnetic pole between every two adjacent single-radial-magnetizing main poles, and forming several combination magnetic poles, each of which is composed of a radial-magnetizing main magnetic pole and two semi-auxiliary-magnetic-poles (with different magnetization directions) located on both sides. Then, by solving the Laplace equation and Poisson equation in every subdomain, and combining the relative permeability function, the analytical expressions of the air-gap magnetic fields for the BL-BLDCM-LTPMIMP was obtained. The armature reaction magnetic fields of the torque windings and suspension windings are also analyzed. Finally, through the finite element method (FEM), the correctness and computational accuracy of the analytical calculation model for the air-gap magnetic field is proven. Additionally, the comparison of electromagnetic characteristics with ordinary BL-BLDCM shows that the BL-BLDCM-LTPMIMP can not only effectively improve the amplitude and stability of electromagnetic torque on the basis of obtaining a shoulder-shrugged trapezoidal wave air-gap magnetic field but also has stable radial magnetic levitation force control characteristics. Full article

Energy harvesting from ambient vibrations has received significant attention as an alternative renewable, clean energy source for microelectronic devices in diverse applications such as wearables and environmental monitoring. However, typical vibrations in remote environments exhibit ultra-low frequencies with variations and uncertainty leading to operation away from resonance and severe underperformance in terms of power output. Pendulum-based energy harvesters offer a promising solution to these issues, particularly when designed for parametric resonant response to driven displacement of the pendulum pivot. Parametric excitation has been shown to trigger fast rotational motion of the pendulum VEH that is beneficial for energy generation and the necessary space utilization. Nevertheless, low-frequency ambient vibrations typically come at very weak amplitudes, a fact that establishes significant design barriers when traditional gravitational pendula are used for rotary energy harvesting. In this paper, we propose a novel concept that utilizes permanent magnet arrays to establish pendulum dynamics. Extensive investigation of the restoring torque of the proposed magnetic pendulum concept is conducted with analytical tools and FEA verification. The resulting oscillator exhibits frequency tuning that is decoupled from gravity and adjustable via the circularly arranged magnetic fields, leading to increased flexibility in the concurrently necessary amplitude tuning. Numerical integration of the nondimensional equation of motion is performed in the system’s parameter space to identify the impact on the regions triggering rotational response to parametric excitation. Finally, a theoretical case study is numerically investigated with the device space constrained within 20 cm³, showing a multi-fold improvement in the achieved power density of over 600 μW/cm³/g²/Hz over a broad range of frequencies and driving amplitudes as low as 1.1 Hz at 0.2 g. Full article
