The automation of adhesive application in footwear manufacturing is challenging due to complex surface geometries and model variability. This study presents an integrated 3D vision-based robotic system for adhesive spraying on lasted uppers. A triangulation-based scanning setup reconstructs each upper into a high-resolution point cloud, enabling customized spraying path planning. A six-axis robotic arm executes the path using an adaptive transformation matrix that aligns with surface normals. UV fluorescent dye and inspection are used to verify adhesive coverage. Experimental results confirm high repeatability and precision, with most deviations within the industry-accepted ±1 mm range. While localized glue-deficient areas were observed around high-curvature regions such as the toe cap, these remain limited and serve as a basis for further system enhancement. The system significantly reduces labor dependency and material waste, as observed through the replacement of four manual operators and the elimination of adhesive over-application in the tested production line. It has been successfully installed and validated on a production line in Hanoi, Vietnam, meeting real-world industrial requirements. This research contributes to advancing intelligent footwear manufacturing by integrating 3D vision, robotic motion control, and automation technologies. Full article

This study investigates the depositional environments and soft sediment deformation within the Early Jurassic Ammonitico Rosso Formation in the External Ionian Basin (Western Greece), focusing on its biostratigraphy, sedimentology, and tectonic activity. This research provides new insights into the depositional environment of the Ammonitico Rosso Formation and its transitions with the underlying and overlying formations. Syn-rift tectonics at the time of deposition formed half-grabens, which influenced sedimentary processes and created conditions for seabed slumping. Detailed field mapping and microfacies analysis revealed two distinct depositional environments: deep-water to open-shelf settings and platform-margin reefs. The entire Ammonitico Rosso Formation is allochthonous, deposited as repetitive slices of little-disturbed stratified sediments capped by debrites near the toe of a complex submarine landslide. The presence of well-preserved fossils, such as planktonic and benthic foraminifera, Radiolaria (both Spumellaria and Nassellaria), and ammonites, allowed precise age determinations, suggesting that the first appearance of Globuligerina might predate previous records, occurring first in the Pliensbachian rather than the Toarcian. These findings contribute to the ongoing debate on the depth and conditions of Ammonitico Rosso deposition, supporting the hypothesis of a relatively deep, open-shelf environment influenced by slope instability. Full article

The environmental impact of wind turbine rotor blades, both during manufacturing and at the end of their life cycle, can be significant. The aim of this study was to define and test a methodology for recycling the waste resulting from their production. Particles of waste from the mechanical machining of rotor blades, which were made up of a glass fibre/epoxy matrix mixture, were used to produce toe caps for use by the footwear industry. The addition of 1 wt.% of particles improved the mechanical properties of the epoxy matrix, with a 5.50% improvement in tension and an 8% improvement in stiffness. Characterisation of the laminates, manufactured by hand lay-up technique, revealed that in the three-point bending tests, the additive laminates showed improvements of 18.60% in tension, 7.50% in stiffness, and 10% in deformation compared to the control laminate. The compression test showed that the additive glass fibre toe cap had greater resistance to compression than the control glass fibre toe cap, with a reduction in deformation of 23.10%. The toe caps are suitable for use in protective footwear according to European standard EN ISO 20346:2022. They guaranteed protection against low-velocity impacts at an energy level of at least 100 J and against compression when tested at a compression load of at least 10 kN. Full article

The first step in translation initiation consists in the recruitment of the small ribosome onto the mRNA. This preinitiation complex (PIC) loads via interactions with eIF4F that has assembled on the 5′ cap. It then scans the 5′ TL (transcript leader) to locate a start site. The molecular architecture of the PIC-mRNA complex over the cap is beginning to be resolved. As part of this, we have been examining the role of the 5′ TL length. We observed in vivo initiation events on AUG codons positioned within 3 nts of the 5′ cap and robust initiation in vitro at start sites immediately downstream of the 5′ end. Ribosomal toe-printing confirmed the positioning of these codons within the P site, indicating that the ribosome reads from the +1 position. To explore differences in the eIF4E-5′ cap interaction in the context of long versus short TL, we followed the fate of the eIF4E-cap interaction using a novel solid phase in vitro expression assay. We observed that ribosome recruitment onto a short TL disrupts the eIF4E-cap contact releasing all the mRNA from the solid phase, whereas with a long the mRNA distributes between both phases. These results are discussed in the context of current recruitment models. Full article

The difficulties with the application of low strain integrity testing for evaluating the length of driven precast piles of two sections justify the need for new data acquisition and analysis techniques. The standard time domain analysis of the recorded signals may not allow for distinguishing the desired responses from a pile toe and a splice. In this paper, we propose the use of a set of hammers of different weights and tip materials that will provide various sensitivities of the test to a pile splice. To further analyze the collected data, we study the distributions of phase angles obtained using complex continuous wavelet transform. The characteristic phase shifts that distribute from higher to lower frequencies can be interpreted as responses from a pile toe and a splice. To verify the proposed approaches, a series of numerical simulations were performed using the finite element method for the driven pile models with the different properties of a splice zone. Numerical simulation results show that the pile splices are clearly identified when using the shorter input pulses which can be generated by light hammers with a hard head material. The total length of a simulated pile with a 1 mm air gap between sections was undetectable by standard data analysis approaches and was evaluated when analyzing the wavelet phase angle distributions. Numerically validated data acquisition and analysis techniques were applied to field data analysis and allowed us to confidently identify the length of two-section piles grouped with a pile cap. Full article

Aiming at the problem that the toe cap and upper part of the sole of a shoe easily appear missing when using binocular vision to reconstruct the shoe sole in the industrial production process, an improved matching cost calculation method is proposed to reconstruct shoe soles in three dimensions. Firstly, a binocular vision platform is built, and Zhang’s calibration method is used to obtain the calibration parameters. Secondly, the method of fusing Census and BT costs is used to calculate the matching cost of the image, so that the matching cost calculation result is more accurate. On this basis, 4-path aggregation is performed on the obtained cost, and the optimal matching cost is selected in combination with the WTA algorithm. Finally, left–right consistency detection and median filtering are used to optimize the disparity map and combine the camera calibration parameters to reconstruct the shoe sole in three dimensions. The experimental results show that the average mismatch rate of the four images on the Middlebury website in this method is about 6.57%, the reconstructed sole point cloud contour information is complete, and there is no material missing at the toe and heel. Full article

Toe caps are one of the most important components in safety footwear, but have a significant contribution to the weight of the shoe. Efforts have been made to replace steel toe caps by polymeric ones, since they are lighter, insulated and insensitive to magnetic fields. Nevertheless, polymeric solutions require larger volumes, which has a negative impact on the shoe’s aesthetics. Therefore, safety footwear manufacturers are pursuing the development of an easy, low-cost and reliable solution to optimize this component. In this work, a solid mechanics toolbox built in the open-source computational library, OpenFOAM^®, was used to simulate two laboratory standard tests (15 kN compression and 200 J impact tests). To model the polymeric material behavior, a neo-Hookean hyper-elasto-plastic material law with J2 plastic criteria was employed. A commercially available plastic toe cap was characterized, and the collected data was used for assessment purposes. Close agreements, between experimental and simulated values, were achieved for both tests, with an approximate error of 5.4% and 6.8% for the displacement value in compression and impact test simulations, respectively. The results clearly demonstrate that the employed open-source finite volume computational models offer reliable results and can support the design of toe caps for the R&D footwear industry. Full article

Foot rollover and the ‘ride’ feeling that occurs during heel–toe transition during running have been investigated mostly in laboratory settings due to the technical requirements of ‘golden standard’ measurement devices. Hence, the purpose of the current study was to investigate ‘ride’ and rollover with a heel cap-mounted inertial measurement unit (IMU) when running under field conditions to get realistic results. Twenty athletes ran on a 1 km outdoor track with five different shoe conditions, only differing in their midsole bending stiffness. The peak angular velocity (PAV) in the sagittal plane of the shoe was analyzed. The subjective evaluation of the ‘ride’ perception during heel–toe transition was rated on a visual analogue scale. The results revealed that PAV and ‘ride’ varied for the different shoes. The regression analysis showed that PAV has a significant impact on the ‘ride’ rating (R² = 0.952; p = 0.005). The shoe with a medium midsole bending stiffness had the lowest value for PAV (845.6 deg/s) and the best rating of perceived ‘ride’ on average. Our results show that IMU can be used as a low-cost method to investigate the heel–toe transition during field-running. In addition, we found that midsole bending stiffness influenced PAV and the subjective feeling of ‘ride’. Full article

The study of the microwave scattering mechanisms of the sea surface is extremely important for the development of radar sensing methods. Some time ago, Bragg (resonance) scattering of electromagnetic waves from the sea surface was proposed as the main mechanism of radar backscattering at moderate incidence angles of microwaves. However, it has been recently confirmed that Bragg scattering is often unable to correctly explain observational data and that some other physical mechanisms should be taken into consideration. The newly introduced additional scattering mechanism was characterized as non-polarized, or non-Bragg scattering, from quasi-specular facets appearing due to breaking wave crests, the latter usually occurring in moderate and strong winds. In this paper, it was determined experimentally that such non-polarized radar backscattering appeared not only for rough sea conditions in which wave crests strongly break and “white caps” occur, but also at very low wind velocities close to their threshold values for the wave generation process. The experiments were performed using two polarized Doppler radars. The experiments demonstrated that a polarization ratio, which characterizes relative contributions of non-polarized and Bragg components to the total backscatter, changed slightly with wind velocity and wind direction. Detailed analysis of radar Doppler shifts revealed two types of scatterers responsible for the non-polarized component. One type of scatterer, moving with the velocities of decimeter-scale wind waves, determined radar backscattering at low winds. We identified these scatterers as “microbreakers” and related them to nonlinear features in the profile of decimeter-scale waves, like bulges, toes and parasitic capillary ripples. The scatterers of the second type were associated with strong breaking, moved with the phase velocities of meter-scale breaking waves and appeared at moderate winds additionally to the “microbreakers”. Along with strong breakers, the impact of microbreaking in non-polarized backscattering at moderate winds remained significant; specifically the microbreakers were found to be responsible for about half of the non-polarized component of the radar return. The presence of surfactant films on the sea surface led to a significant suppression of the small-scale non-Bragg scattering and practically did not change the non-Bragg scatterer speed. This effect was explained by the fact that the nonlinear structures associated with dm-scale waves were strongly reduced in the presence of a film due to the cascade mechanism, even if the reduction of the amplitude of dm waves was weak. At the same time, the velocities of non-Bragg scatterers remained practically the same as in non-slick areas since the phase velocity of dm waves was not affected by the film. Full article

A gait event is a crucial step towards the effective assessment and rehabilitation of motor dysfunctions. However, for the data acquisition of a three-dimensional motion capture (3D Mo-Cap) system, the high cost of setups, such as the high standard laboratory environment, limits widespread clinical application. Inertial sensors are increasingly being used to recognize and classify physical activities in a variety of applications. Inertial sensors are now sufficiently small in size and light in weight to be part of a body sensor network for the collection of human gait data. The acceleration signal has found important applications in human gait recognition. In this paper, using the experimental data from the heel and toe, first the wavelet method was used to remove noise from the acceleration signal, then, based on the threshold of comprehensive change rate of the acceleration signal, the signal was primarily segmented. Subsequently, the vertical acceleration signals, from heel and toe, were integrated twice, to compute their respective vertical displacement. Four gait events were determined in the segmented signal, based on the characteristics of the vertical displacement of heel and toe. The results indicated that the gait events were consistent with the synchronous record of the motion capture system. The method has achieved gait event subdivision, while it has also ensured the accuracy of the defined gait events. The work acts as a valuable reference, to further study gait recognition. Full article

Microwave radar is a well-established tool for all-weather monitoring of film slicks which appear in radar imagery of the surface of water bodies as areas of reduced backscatter due to suppression of short wind waves. Information about slicks obtained with single-band/one-polarized radar seems to be insufficient for film characterization; hence, new capabilities of multi-polarization radars for monitoring of film slicks have been actively discussed in the literature. In this paper the results of new experiments on remote sensing of film slicks using dual co-polarized radars—a satellite TerraSAR-X and a ship-based X-/C-/S-band radar—are presented. Radar backscattering is assumed to contain Bragg and non-Bragg components (BC and NBC, respectively). BC is due to backscattering from resonant cm-scale wind waves, while NBC is supposed to be associated with wave breaking. Each of the components can be eliminated from the total radar backscatter measured at two co-polarizations, and contrasts of Bragg and non-Bragg components in slicks can be analyzed separately. New data on a damping ratio (contrast) characterizing reduction of radar returns in slicks are obtained for the two components of radar backscatter in various radar bands. The contrast values for Bragg and non-Bragg components are comparable to each other and demonstrate similar dependence on radar wave number; BC and NBC contrasts grow monotonically for the cases of upwind and downwind observations and weakly decrease with wave number for the cross-wind direction. Reduction of BC in slicks can be explained by enhanced viscous damping of cm-scale Bragg waves due to an elastic film. Physical mechanisms of NBC reduction in slicks are discussed. It is hypothesized that strong breaking (e.g., white-capping) weakly contributes to the NBC contrast because of “cleaning” of the water surface due to turbulent surfactant mixing associated with wave crest overturning. An effective mechanism of NBC reduction due to film can be associated with modification of micro-breaking wave features, such as parasitic ripples, bulge, and toe, in slicks. Full article
