Search Results (12)

In the context of wheelchair racing, research primarily focuses on studying wheelchair ergonomics and determining kinematic, kinetic, and rolling resistance variables. One factor identified as influencing athletes’ performance is wheel skidding on the ground, a parameter complementary to rolling resistance. The objective of this study, therefore, is to identify, within a laboratory setting, the parameters that influence the risk of skidding in racing wheelchairs by measuring skidding torque. The ultimate goal is to enhance athletes’ performance by optimizing the interaction between the athlete and their wheelchair, and the wheelchair and the environment. In this perspective, four parameters were examined: the type of tubular, the camber angle, the tire pressure, and the load applied to the wheel using a skidometer. This tool characterizes a tire’s grip on a surface by measuring torques. The aim is to develop a system for classifying tire grip on dry athletics track at ambient temperature. The findings revealed that only the effects of load and tubular type had a significant impact on the torque values obtained. The tire that minimized the risk of skidding, among all tested combinations, is the Vittoria Pista Speed 23–28″. Furthermore, as the mass applied to the wheel increases, so do the resulting torques. This implies that a heavier athlete would require a greater force to be applied to the hand rim for the tire to skid. However, it was also demonstrated that the risk of skidding in a racing wheelchair is unlikely, as the torques obtained were over a range of 90 to 190 Nm. These values far exceed those typically exerted by para-athletes, which are a maximum of 60 Nm. The long-term goal would be to adjust the mode of torque application on the wheel using the skidometer for a more realistic field approach. Full article

To address the question of which posture trailing-arm vehicles (TAVs) should be adopted while driving, this study introduces an innovative active posture controller (APC) to improve both path-following and handling stability performance. Leveraging a nonlinear tire model that considers corner load variation and wheel camber, alongside the kinematics and double-track model of TAVs, the impact of vehicle body posture on handling performance has been investigated. To fully utilize the four-wheel independent drive and posture adjustable characteristics of the TAV mechanisms, an integrated nonlinear model predictive control (NMPC) combining APC and tire forces distribution is devised. Through simulations conducted using Simulink-Multibody (2023a), the effectiveness of the proposed controller is demonstrated, particularly when compared to the scheme that does not account for the unique posture adjustment mechanisms of TAVs. Full article

The automotive industry is currently transforming, primarily due to the rise of electric and hybrid vehicle technologies and the need to reduce vehicle mass and energy losses to decrease consumption, pollution, and raw material usage. Additionally, road surface manufacturers emphasize improving pavement durability and reducing rolling noise. This necessitates precise load condition definitions and drives the need for reliable wheel testing benches. Many current benches use abrasive-coated rollers or synthetic tapes, but devices capable of testing on actual road surfaces are rare. In this work, a novel device for testing tire-pavement interaction is proposed. The system features a cart moving along a closed-track platform, ensuring test repeatability and enabling structural durability tests on uneven surfaces with installed obstacles. The cart is equipped with a cantilever arm capable of supporting either a testing wheel with customizable dimensions and kinematic parameters or a tire integrated with a complete suspension system, moving along a customizable pavement surface. The system includes actuators and sensors for applying vertical loads and adjusting the alignment of the testing wheel (slip angle, camber angle, etc.), allowing the characterization of tire behavior such as wear, fatigue, rolling noise, and rolling resistance. Multibody simulations were performed to evaluate the bench’s feasibility in terms of kinematics, power requirements, and structural loads. Results confirmed how this novel test bench represents a promising advancement in tire testing capabilities, enabling comprehensive studies on tire performance, noise reduction, and the structural dynamics of vehicle subsystems. Full article

Electric vehicles, with their distinct power systems, weight distribution, and power control strategies compared to traditional vehicles, influence the pressure distribution in the tire contact area, thereby affecting the estimation of road adhesion coefficient. In electric vehicle research, tire adhesion coefficient serves as a measure of the frictional force between the vehicle and the road surface, directly impacting the vehicle’s handling performance. The accurate estimation of the adhesion coefficient aids drivers in better understanding the vehicle’s driving state. However, the existing brush models neglect differences in ground pressure distribution along the width direction of tires during tire camber, potentially leading to inaccuracies in adhesion coefficient estimation. This study proposes a camber brush tire model that considers the width-direction pressure distribution characteristics, aiming to enhance the accuracy of adhesion coefficient estimation under camber conditions. Experimental comparisons between the improved and original models reveal a significant enhancement in estimation precision. Consequently, the findings of this study provide valuable insights for deepening our understanding of tire camber dynamics and for designing control systems for electric vehicles, thereby improving vehicle stability and safety. Full article

With the implementation of strict emission regulations and the use of cleaner fuels, there has been a considerable reduction in exhaust emissions. However, the relative contribution of tire wear particles (TWPs) to particulate matters is expected to gradually increase. This study conducted laboratory wear experiments on tires equipped on domestically popular vehicle models, testing the factors and particle size distribution of TWPs. The results showed that the content of tire wear particle emission was mainly ultrafine particles, accounting for 94.80% of particles ranging from 6 nm to 10 μm. There were at least two concentration peaks for each test condition and sample, at 10~13 nm and 23~41 nm, respectively. The mass of TWP emission was mainly composed of fine particles and coarse particles, with concentration peaks at 0.5 μm and 1.3–2.5 μm, respectively. Both the number and mass of TWPs exhibited a bimodal distribution, with significant differences in emission intensity among different tire samples. However, there was a good exponential relationship between PM₁₀ mass emissions from tire wear and tire camber angle. The orthogonal experimental results showed that the slip angle showed the greatest impact on TWP emission, followed by speed and load, with the smallest impact from inclination angle. Full article

In this paper, we present a method of calculating cornering stiffness for different camber angles. The method removes the need for measurement data at different camber angles. The camber angle is regarded as equivalent to a local shift of load in the contact patch from one half-side to the other. A simple model is presented to describe the load shift. The cornering stiffness from each side, accounting for their loads, is then assumed to contribute to the total stiffness. The load shift model is validated through two finite element models. Cornering stiffnesses given by the model for two different tires are then compared to the measurements. To show the universality of the method, its application to interpolated measurement data is shown. The proposed method shows promising results for moderate camber angles. Full article

In the field of inner-city cargo transportation, solutions such as electrified cargo trailers are increasingly being used. To provide an intelligent drivetrain control system that improves driving dynamics and enables safety, it is necessary to know the characteristics of the trailer system. This includes the behavior of the tires. Existing investigations of bicycle tires focus on camber-angle-dependent models. However, in most trailers, a rigid mounting of the tires without camber is used. For this reason, a bicycle tire model is created within the scope of this study using real measurement data that represent a 20 in tire with typical wheel loads and without camber. The measurements were collected with the mobile tire measurement laboratory of the Bern University of Applied Sciences on an asphalt test site under real conditions. Crosstalk occurring in the measurement hub during the data collection was successfully corrected using a matrix method. With help of the so-called Magic Formula, a tire model was created that can be used for driving dynamics simulations and controller design. Full article

The Personal Mobility Vehicle (PMV), which has an inward-tilting angle, turns with lateral force due to a large camber angle, so it is necessary to consider the lateral movement of the tire vertical load axis during turning. Although the steering torque mechanisms are very different from those of automobiles, there are not many studies of the steering torque mechanisms of PMVs. In this paper, based on the effects of the force of six components acting on the tires, a method for setting the steering axis specifications is derived, including the geometrical minimization of steering moment disturbance due to the vertical load reaction force during turning. Automobile tires have a significant ground camber angle when traveling on rutted roads, but they do not have it on slanted roads because the vehicle body tilts along the road surface. On the other hand, in PMVs, the vehicle body always keeps upright when traveling both on slanted roads and on rutted roads. Therefore, the tires have ground camber angles on both types of road surface. We study the straight running ability under such road surface disturbances based on the geometrical minimization of steering moment disturbance due to the vertical load reaction force during turning. This straight running ability can be a remarkable strong point of PMVs with an inward tilt mechanism. In this study, it was proved that the steering axis parameters can be derived uniquely by taking into consideration the requirement to zero the moment (disturbance) around the steering axis due to the reaction force against the vertical load at all internal tilt angles. Full article

There is a growing interest towards multi-body modelling and simulation that play a critical role in the development and testing of new mechanical systems, in general, and formula cars specifically to avoid expensive and time-consuming experimental track testing. Recent advances in computer-aided engineering packages, allows one not only to evaluate the basic properties that define the dynamic behavior of a newly-designed formula car, but as well as to investigate the impact on the performance of the many adjustable parameters that collectively are referred to as the car set-up. Therefore, by providing a rapid feedback of a given set-up expectation, optimal configurations can be obtained ensuring the highest level of performance. In this paper, a Formula SAE vehicle is expressly targeted. First, a full multi-body model of the prototype is described detailing the properties of each subassembly, e.g., suspensions and antiroll bars, steering system, and powertrain. Then, the basic handling characteristics are obtained via simulated track testing. Based on vehicle dynamics principles, the fine tuning of the vehicle setup is thoroughly discussed to gain the best performance in each of the contest events of the Formula SAE competition. For example, in the skidpad event where cars are required to drive along an eight-shaped track, an almost 2 km/h gain in the maximum travel velocity can be achieved by adjusting the camber angles of all tires. Full article

When a vehicle goes on the straight road with a bank angle, a steering pull makes the driver exert a constant steering torque to the steering wheel, which causes an annoying steering feel to the driver. This paper proposes a steering pull model and sensitivity analysis on the steering pull. In order to develop the steering pull model, pulling forces on the tires, such as plysteer and conicity forces, lateral force due to slip angle, lifting forces due to cast and kingpin, and camber force are modeled. A steering system is also modeled because the generated pulling forces are attenuated as it is transmitted through the steering system. Each component of the steering system, such as lower body linkages, rack and pinion gear, universal joint, and steering column with electric power steering (EPS) system is modeled, and then they are integrated into a complete steering system. Finally, the steering pull model is developed by integrating the pulling force model with the steering system model. For verification, the steering pull of a vehicle is estimated based on the model, and the results are compared with the experimental results. For the verification experiments, a steering pull measurement system using a global positioning system (GPS) and its accessories are used. The result comparison showed that the developed steering pull model provides very accurate estimation results. Based on the steering pull model, the sensitivity of steering pull factors, such as caster angle, kingpin angle, camber angle, rack friction force, and anti-rattle spring (ARS) stiffness is analyzed. Full article

While in the automotive field the relationship between road adherence and tire temperature is mainly investigated with the aim to enhance the vehicle performance in motorsport, the motorcycle sector is highly sensitive to such theme also from less extreme applications. The small extension of the footprint, along with the need to guarantee driver stability and safety in the widest possible range of riding conditions, requires that tires work as most as possible at a temperature able to let the viscoelastic compounds-constituting the tread and the composite materials of the whole carcass structure-provide the highest interaction force with road. Moreover, both for tire manufacturing companies and for single track vehicles designers and racing teams, a deep knowledge of the thermodynamic phenomena involved at the ground level is a key factor for the development of optimal solutions and setup. This paper proposes a physical model based on the application of the Fourier thermodynamic equations to a three-dimensional domain, accounting for all the sources of heating like friction power at the road interface and the cyclic generation of heat because of rolling and to asphalt indentation, and for the cooling effects because of the air forced convection, to road conduction and to turbulences in the inflation chamber. The complex heat exchanges in the system are fully described and modeled, with particular reference to the management of contact patch position, correlated to camber angle and requiring the adoption of an innovative multi-ribbed and multi-layered tire structure. The completely physical approach induces the need of a proper parameterization of the model, whose main stages are described, both from the experimental and identification points of view, with particular reference to non-destructive procedures for thermal parameters definition. One of the most peculiar and challenging features of the model is linked with its topological and analytical structure, allowing to run in real-time, usefully for the application in co-simulation vehicle dynamics platforms, for performance prediction and setup optimization applications. Full article

Tire characteristics and behavior are of great importance in vehicle dynamics since the forces transmitted in the tire-road contact are the main contributors to global vehicle performance. Several research groups have focused on the study and modeling of tires. Some of the most important factors that need to be known are tread characteristics and pressure distribution in the tire-ground contact patch. In this work, a test bench has been used to adequately determine the aforementioned factors. The measurement principle of the test bench is the frustration of total internal reflection (FTIR) of light. It makes use of a laterally illuminated glass on which the tire leans. An interposed plastic interface between them causes the reflection of light. Finally, a video camera captures the bright image formed through the glass. The brightness level in each pixel of the image is related to existing normal pressure. A study of the parameters that affect the test bench calibration such as type of interface material used, diffuse light, hysteresis, creep and transverse light absorption is performed. Experimental tests are conducted to relate tire inflation pressure and camber angle to the pressure distribution. Furthermore, the test bench is used to detect and evaluate the influence of defects in the tire on the contact pressures. Full article
