Conventional model-free control (MFC) is widely used in motor drives due to its simplicity and model independence, yet its performance suffers from imperfect disturbance estimation and input gain mismatch. To address these issues, this paper proposes an adaptive enhanced model-free speed control (AEMFSC) scheme based on an ultra-local model for permanent magnet synchronous motor (PMSM) drives. First, by integrating a nonlinear disturbance observer (NDOB) and a PD control law into the generalized model-free controller, an enhanced model-free speed controller (EMFSC) was developed to ensure closed-loop stability. Compared with a conventional MFSC, the proposed method eliminated steady-state errors, reduced the speed overshoot, and achieved faster settling with improved disturbance rejection. Second, to address the performance degradation induced by input gain $\alpha$ mismatch during time-varying load conditions, we developed an online parameter identification method for real-time $\alpha$ estimation. This adaptive mechanism enabled automatic controller parameter adjustment, which significantly enhanced the transient tracking performance of the PMSM drive. Furthermore, an algebraic-framework-based high-precision identification technique is proposed to optimize the initial $\alpha$ selection, which effectively reduces the parameter tuning effort. Simulation and experimental results demonstrated that the proposed AEMFSC significantly enhanced the PMSM’s robustness against load torque variations and parameter uncertainties. Full article

The rotational speed and load torque of wind turbine gearboxes can vary widely during operation, which has an obvious impact on the gearbox fault diagnosis carried out based on vibration signals. To address this problem, this paper proposes a fault diagnosis method that introduces an adversarial training mechanism and designs a game learning strategy among the feature extractor, fault recognizer, rotational speed estimator, and load estimator. In this way, the network tends to acquire fault features with weaker correlation with rotational speed and load and thus improves the performance of the fault diagnosis network in the face of the samples from the rotational speed and load ranges that are not covered by the training set. At the same time, in order to verify the effectiveness of the proposed method, in this paper, we have designed an experimental platform for wind turbine gearbox scaling, carried out simulation experiments of variable speed and torque faults, collected experimental data, and constructed a variable speed and load fault dataset. Comparing the proposed method with the baseline model, when confronted with data from RPMs or load ranges not covered by the training set, the accuracy of the baseline model drops by anywhere from 10.54% to 16.46%, while the accuracy of the method drops by only 1.39%. The results show that the method can effectively improve the performance of the fault diagnosis network when facing a variation of speed and load. Full article

Torque measurement is a key task in several mechanical and structural engineering applications. Most commercial torquemeters require the shaft to be interrupted to place the sensors between the two portions of the shaft where a torque has to be measured. Contactless torquemeters based on the inverse magnetostrictive effect represent an effective alternative to conventional ones. Most known ferromagnetic materials have an inverse magnetostrictive behavior: applied stresses induce variations in their magnetic properties. This paper investigates the possibility of measuring torsional loads applied to a shaft made of ferromagnetic steel S235 through an inverse magnetostrictive torquemeter. It consists of an excitation coil that produces a time-varying electromagnetic field inside the shaft and an array of sensing coils suitably arranged around it, in which voltages are induced. First, the system is analyzed both in unloaded and loaded conditions by a Finite Element Method, investigating the influence of relative positions between the sensor and the shaft. Then, the numerical results are compared with the experimental measurements, confirming a linear characteristic of the sensor (sensitivity about 0.013 mV/Nm for the adopted experimental setup) and revealing the consistency of the model used. Since the system exploits the physical behavior of a large class of structural steel and does not require the introduction of special materials, this torquemeter may represent a reliable, economical, and easy-to-install device. Full article

This paper presents a coaxial counter-rotating planetary transmission system. The transmission system under study is a two-stage planetary gear train (PGT) comprising a fixed-axes PGT and a differential PGT. A dynamic model of the transmission system is established, considering both the excitations caused by the time-varying mesh stiffness (TMS) and the transmission errors, respectively. The Runge–Kutta algorithm is used to calculate and analyze the dynamic characteristics of the system. This includes studying dynamic meshing forces, planet gear displacements, and load-sharing coefficients (LSCs) under both internal and external excitations, as well as different input torques. The results indicate that when considering external excitations, the variations in the meshing force curves become more pronounced. The radial displacements of the planet gears in the differential PGT are greater than that in the fixed-axes PGT. With increasing input torque, the average displacements of the planet gears in all directions tend to increase. The differential PGT, transmitting a higher power, demonstrates a better load-sharing performance compared to the fixed-axes PGT. Full article

Interior permanent magnet synchronous motors (IPMSMs) are extensively used as traction motors today because of their exceptional torque, power density, and wide, constant power operating range. Under real-world usage, an IPMSM rotor undergoes varying electromagnetic, thermal, and mechanical loads. Under such conditions, fatigue life-based design criteria should be used over stress-based design criteria to ensure the structural integrity of the rotor. Moreover, the driving dynamics can change the rotor temperature continuously, which affects the electromagnetic, mechanical, and fatigue properties of the rotor material. This paper proposes a robust thermomechanical rotor fatigue simulation workflow considering significant loads acting on an IPMSM rotor and the temperature variation throughout a drive cycle. It discusses an accelerated fatigue life estimation approach based on the peak valley extraction method to reduce the simulation time significantly for the stress and fatigue analysis. Then, it presents a method for a stress-life curve generation for variable loading. It also presents a sensitivity study with a median S-N curve, and a 90% reliability and 95% confidence (R90C95) S-N curve. Full article

Exoskeletal robots are of critical importance in the domain of mechanical boosting. The pneumatic artificial muscle (PAM) is commonly used as a flexible actuator in exoskeletal robots designed for upper limbs due to its high power-to-weight ratio, conformability, and safety. This study establishes a new model based on the existing model to improve its control precision by implementing elastic and frictional forces and empirical coefficients, battling against the time-variant hysteresis that PAM’s output force exhibits. In the meantime, a BP neural network is employed in reverse modeling, followed by the adoption of the least-square-based particle swarm optimization algorithm in order to determine the optimized parameter values. PAM provides the Upper Limb Exoskeletal Robot with appropriate auxiliary power, which can be adjusted to accommodate variations in posture change during the lifting process. PAM is also capable of handling variable loads based on the principle of torque balance, constructing a control system according to the inverse dynamics of exoskeletal robots accompanied by an inverse model of PAM’s output force, and finally, rendering tracking control of the elbow angle during the auxiliary process possible. Finally, the tracking error results are calculated and shown; the maximum angular error in the tracking process is 0.0175 rad, MAE value is 0.0038 rad, RMSE value is 0.0048 rad, and IEAT value is 4.6426 rad. This control method is able to improve the precision of tracking control of the elbow angle of the upper limb–exoskeleton coupled system during the process of lifting goods. Full article

This paper is devoted to designing a sensorless high-speed tracking control for surface-mount permanent-magnet synchronous motors, considering a time-varying load torque. This proposal consists of an extended-state observer interconnected with a PI-compensated controller, considering only the measurement of electrical variables for feedback. First, to design the extended-state observer, a rotary coordinate model of the motor is extended in one state to estimate the load torque and the rotor’s position and speed. Later, the estimations are fedback to a PI-compensated controller to attenuate the time-varying load torques. Our proposed methodology aims to overcome a restriction regarding the solution of the Riccati equation respecting the Lipschitz condition for observer stability analysis. Therefore, a PI-compensated controller described as a closed-loop provides a sensorless scheme. Lyapunov stability analysis is applied to determine sufficient conditions to ensure that the states of the closed-loop system are ultimately bounded, which is one of our main contributions. The proposed observer-based controller scheme deals with unmeasured load torque fluctuations. Furthermore, we carry out high-precision emulations to provide testing scenarios of the permanent-magnet synchronous motor with some challenging load torque magnitudes and behaviors. Finally, we conduct experiments on the Technosoft${}^{\circledR }$ development platform to corroborate the feasibility of the proposed control scheme in a real-world scenario. Full article

The speed response of the interior permanent magnet synchronous motor (IPMSM) drive at low speeds was analyzed. To eliminate the effect of external disturbance or parameter uncertainty, a nonlinear speed control loop was designed based on the sliding-mode exponential reaching law, which reduces chatter, which is the major drawback of the constant reaching law sliding-mode control technique. The proposed nonlinear speed control eliminates speed ripples at low speed under load disturbance. The problem of speed convergence at low speed is caused by electromagnetic torque ripples, which cause shaft speed oscillations that affect drive performance. The main objective of the proposed method is to change the traditional IPMSM control design by compensating with an appropriate signal along the reference current and across the output of the speed control loop. To optimize the speed tracking performance during disturbances or parametric variations, a nonlinear speed control scheme is designed that can vigorously adapt to the change in the controlled system. The comparative analysis shows that the method provides excellent transient performance (e.g., fast convergence response, less overshoot, and fast settling time) and standstill performance (e.g., reduced steady-state error) compared with conventional control methods at low speed under varying load conditions. The method is easy to implement and does not require additional computational cost. To demonstrate the effectiveness and feasibility of the design approach, a numerical analysis was conducted, and the control scheme was verified using MATLAB/Simulink considering various operating conditions. Full article

This paper varies load conditions in a single-phase induction motor and deals with consequent effects on the electromagnetic characteristics in terms of a balanced and unbalanced operation. Based on a balanced-load condition, the magnetic field, electromagnetic losses, magnetic torque are quantified by the time-stepping finite element method at six different loads. The spatial distribution of the air-gap magnetic field are investigated to characterize the existence between the load variation and unbalanced operation. The components of electromagnetic losses are analyzed in terms of main parameters degrading the operating efficiency according to the load variation. The result can show the importance of building the magnetic balance for a high performance, and the design guideline for SPIMs running at multiple operating points is discussed. Full article

Adaptive tracking control of the speed of a very elastically attached circular load driven by a direct current motor accompanied with an adaptive conventional and a fractional-order Proportional Integral Derivative (PID) controller is studied. It refers to improving the closed-loop control system response of elastically coupled components of drivelines. The motor and the load mechatronic models and the block diagrams are constructed. Parameters of the PID controller in the model reference control are both constant, as well as vary in time. The adaptive control method is improved by the application of a new closed-loop control structure canceling error dynamics. A few competing control strategies are tested based on the application of two types low and high frequency stepwise increasing variations of loading torque and damping coefficient of motion. Moreover, the performance of the control strategies is verified by Integral Time-Weighted Absolute Error (ITAE) index, since their robustness is evaluated by applying a sine modulated triangle waves of selected electric parameters. Therefore, a dynamic forcing and parameter uncertainty is applied. Simulation results are compared for checking the proposed methods. Full article
