Search Results (13)

This paper presents a novel metascheduling algorithm to enhance communication efficiency in off-chip time-triggered multi-processor system-on-chip (MPSoC) platforms, particularly for safety-critical applications in aerospace and automotive domains. Time-triggered communication standards such as time-sensitive networking (TSN) and TTEthernet effectively enable deterministic and reliable communication across distributed systems, including MPSoC-based platforms connected via Ethernet. However, their dependence on static resource allocation limits adaptability under dynamic operating conditions. To address this challenge, we propose an offline metascheduling framework that generates multiple precomputed schedules corresponding to different context events. The proposed algorithm introduces a selective communication strategy that synchronizes context information exchange with key decision points, thereby minimizing unnecessary communication while maintaining global consistency and system determinism. By leveraging knowledge of context event patterns, our method facilitates coordinated schedule transitions and significantly reduces communication overhead. Experimental results show that our approach outperforms conventional scheduling techniques, achieving a communication overhead reduction ranging from 9.89 to 32.98 times compared to a two-time-unit periodic sampling strategy. This work provides a practical and certifiable solution for introducing adaptability into Ethernet-based time-triggered MPSoC systems without compromising the predictability essential for safety certification. Full article

Time-triggered Ethernet combines time-triggered and event-triggered communication, and is suitable for fields with high real-time requirements. Aiming at the problem that the traditional scheduling algorithm is not effective in scheduling event-triggered messages, a message scheduling algorithm based on multi-agent reinforcement learning (MADDPG, Multi-Agent Deep Deterministic Policy Gradient) and a hybrid algorithm combining SMT (Satisfiability Modulo Theories) solver and MADDPG are proposed. This method aims to optimize the scheduling of event-triggered messages while maintaining the uniformity of time-triggered message scheduling, providing more time slots for event-triggered messages, and reducing their waiting time and end-to-end delay. Through the designed scheduling software, in the experiment, compared with the SMT-based algorithm and the traditional DQN (Deep Q-Network) algorithm, the new method shows better load balance and lower message jitter, and it is verified in the OPNET simulation environment that it can effectively reduce the delay of event-triggered messages. Full article

The rising cost of energy and the urgent need for sustainability have driven industries to adopt smarter solutions for monitoring and optimizing resource consumption. In this study, we present an Industrial Internet of Things (IIoT)-based approach for real-time energy and air consumption monitoring in manufacturing, focusing on a legacy Turret Punch Press (TPP) at Mitsubishi Electric Air Conditioning Systems Europe Ltd. (M-ACE). Due to its age and lack of modern monitoring capabilities, the machine was suspected to be inefficient, requiring a retrofitting strategy for improved transparency and optimization. To address these challenges, a structured IIoT-enabled monitoring system was deployed, integrating KEYENCE MP-F series sensors, an energy monitoring module, and Ethernet communication via Modbus TCP/IP. A comprehensive dashboarding system was developed for real-time visualization and analysis of energy consumption trends, identifying inefficiencies and optimizing machine usage. The data-driven approach revealed significant energy savings of up to 56% and uncovered hidden inefficiencies, including a persistent air leak. By implementing a smart shut-off valve triggered by real-time power consumption data, unnecessary air leakage was eliminated, reducing compressed air waste and overall energy costs. The results demonstrate the effectiveness of IIoT-based retrofitting for industrial energy efficiency, showcasing a scalable framework that can be applied across various machines and production environments. This study highlights the importance of data-driven decision-making in smart manufacturing, contributing to both cost reduction and sustainability goals in industrial settings. Full article

Deterministic Ethernet (DetEth) is widely used in real-time distributed systems, such as avionics and in-vehicle control. Clock synchronization protocols (CSPs) establish global time, which is a critical foundation for deterministic communication in DetEth. However, existing protocols often lack flexibility, making customization and adaptation to specific scenarios difficult and time consuming. We propose OpenSync, which is a software-defined clock synchronization architecture that decouples the synchronization control plane from the data plane. OpenSync includes a programmable time data injector and a fine-grained calibrated timer in the data plane, enabling easy implementation with standard DetEth hardware and support for various CSPs. The control plane provides a synchronization library to configure local clocks and retrieve accurate time data for different methods. To validate OpenSync’s generality and efficiency, we develop an FPGA-based prototype and implement three CSPs through software programming. A fully functional testbed demonstrates that these CSPs meet the accuracy and protocol consistency requirements of their respective application scenarios. Full article

The virtual power plant is one of the key technologies for the integration of various distributed energy resources into the power grid. To enable its smooth and reliable operation, the network infrastructure that connects the components for critical communications becomes a research challenge. Current communication networks based on the traditional Ethernet and long-term evolution cannot provide the required deterministic low latency or reliable communication services. This paper presents a three-layer virtual power plant communication architecture with 5G and time-sensitive networking integrated networks for both determinism and mobility. The service types and traffic requirements of the virtual power plant are analyzed and mapped between 5G and time-sensitive networking to guarantee their quality of service. This paper proposes a semi-persistent scheduling with reserved bandwidth sharing and a pre-emption mechanism for time-critical traffic to guarantee its bounded latency and reliability while improving the bandwidth utilization. The performance evaluation results show that the proposed mechanism effectively reduces the end-to-end delay for both time-triggered traffic and event-triggered traffic compared with the dynamic scheduling method. For event-triggered traffic, the proposed mechanism has comparable end-to-end delay performance to the static scheduling method. It largely improves the resource utilization compared to the static scheduling method when the network load becomes heavy. It achieves an optimum performance tradeoff between delay and resource utilization when the percentage of the reserved resource blocks is 30% in the simulation. Full article

Increasing industrial development and digital transformations have given rise to a technology called Digital Twin (DT) that has the potential to break the barrier between physical and cyberspace. DT is a virtual and dynamic model enabled through a bidirectional data flow that creates high-reliability models with interconnection and fusion between the physical and digital systems for full integration. In smart manufacturing, this technology is increasingly used in research and industry. However, the studies conducted do not provide a definition or a single integrally connected model. To develop the Digital Twin shown in this research, the literature was reviewed to learn about the enabling technologies and architectures used at the industrial level. Then, a methodology was used to obtain the physical process information, create the digital environment, communicate the physical environment, apply simulation models in the digital environment, and parameterize the simulation environment with the physical process in real-time to obtain the digital twin supported with augmented reality. The system was implemented in the MPS-500 modular production station that has industrial sensors and actuators. The virtual environment was designed with Blender and Vuforia to create the augmented reality environment. In the proposed methodology, robust devices (field and control level) and low-cost embedded systems were used for the creation and communication of the virtual environment (monitoring and control); for the joint work of these technologies, they were carried out through the use of the following protocols: Open Platform Communications United Architecture (OPC UA), Ethernet, and machine to machine (M2M), with which a communication was achieved between the different levels of the automation pyramid. The results show that the proposed methodology for the implementation of the DT allows bidirectional communication between the physical and virtual environment and can also be visualized with the support of AR, thus providing its characteristics to the proposed DT. Digital Twin is an essential factor in creating virtual environments and improving applications between the real and digital world, establishing a bidirectional communication through the Ethernet protocol, with a communication time of approximately 100 ms. This technology interacts with the virtual environment and performs mappings, thus achieving timely and dynamic adjustment. This improves data management and production and incorporates process simulation and physical control in real-time, allowing to execute and trigger actions in the physical equipment simultaneously. Full article

Distributed Embedded Systems (DESs) carrying out critical tasks must be highly reliable and hard in real-time. Moreover, to operate in dynamic operational contexts in an effective and efficient manner, they must also be adaptive. Adaptivity is particularly interesting from a dependability perspective, as it can be used to develop dynamic fault tolerance mechanisms, which, in combination with static ones, make it possible to provide better and more efficient fault tolerance. However, constructing a DES with such complexity presents many challenges. This is because all the mechanisms that support fault tolerance, real-time, and adaptivity must be designed to operate in a coordinated manner. This paper presents the Dynamic Fault Tolerance for Flexible Time-Triggered Ethernet (DFT4FTT), a self-reconfigurable infrastructure for implementing highly reliable adaptive DES. Here, we describe the design of its hardware and software architecture and the main set of mechanisms, with a focus on fault tolerance. Full article

The groundbreaking transformations triggered by the Industry 4.0 paradigm have dramatically reshaped the requirements for control and communication systems within the factory systems of the future. The aforementioned technological revolution strongly affects industrial smart and distributed measurement systems as well, pointing to ever more integrated and intelligent equipment devoted to derive accurate measurements. Moreover, as factory automation uses ever wider and complex smart distributed measurement systems, the well-known Internet of Things (IoT) paradigm finds its viability also in the industrial context, namely Industrial IoT (IIoT). In this context, communication networks and protocols play a key role, directly impacting on the measurement accuracy, causality, reliability and safety. The requirements coming both from Industry 4.0 and the IIoT, such as the coexistence of time-sensitive and best effort traffic, the need for enhanced horizontal and vertical integration, and interoperability between Information Technology (IT) and Operational Technology (OT), fostered the development of enhanced communication subsystems. Indeed, established technologies, such as Ethernet and Wi-Fi, widespread in the consumer and office fields, are intrinsically non-deterministic and unable to support critical traffic. In the last years, the IEEE 802.1 Working Group defined an extensive set of standards, comprehensively known as Time Sensitive Networking (TSN), aiming at reshaping the Ethernet standard to support for time-, mission- and safety-critical traffic. In this paper, a comprehensive overview of the TSN Working Group standardization activity is provided, while contextualizing TSN within the complex existing industrial technological panorama, particularly focusing on industrial distributed measurement systems. In particular, this paper has to be considered a technical review of the most important features of TSN, while underlining its applicability to the measurement field. Furthermore, the adoption of TSN within the Wi-Fi technology is addressed in the last part of the survey, since wireless communication represents an appealing opportunity in the industrial measurement context. In this respect, a test case is presented, to point out the need for wirelessly connected sensors networks. In particular, by reviewing some literature contributions it has been possible to show how wireless technologies offer the flexibility necessary to support advanced mobile IIoT applications. Full article

With increasing demands of deterministic and real-time communication, network performance analysis is becoming an increasingly important research topic in safety-critical areas, such as aerospace, automotive electronics and so on. Time-triggered Ethernet (TTEthernet) is a novel hybrid network protocol based on the Ethernet standard; it is deterministic, synchronized and congestion-free. TTEthernet with a time-triggered mechanism meets the real-time and reliability requirements of safety-critical applications. Time-triggered (TT) messages perform strict periodic scheduling following the offline schedule tables. Different scheduling strategies have an effect on the performance of TTEthernet. In this paper, a performance analysis framework is designed to analyze the end-to-end delay, backlog bounds and resource utilization of network by real-time calculus. This method can be used as a base for the performance evaluation of TTEthernet scheduling. In addition, this study discusses the impacts of clock synchronization and traffic integration strategies on TT traffic in the network. Finally, a case study is presented to prove the feasibility of the performance analysis framework. Full article

Ethernet is a popular networking technology in factory automation and industrial embedded systems, frequently using a ring topology for improved fault-tolerance. As many applications demand ever shorter cycle times and a higher number of nodes, the popular ring endure to remain as a valid topology. In this work, we discuss the factors that determine the ring network delay and show how they affect the network cycle time. Since increasing the link capacity has limited reach, we explore a time-triggered protocol that brings the nodes forwarding delay near to the physical layer delay. Additionally, we propose hardware accelerators based on FPGA technology that minimise the packet reception delay from physical reception to delivery to an application handler, preserving Ethernet layers and being compatible with its standard. This paper explains the accelerators concept and implementation, presents measurements using standard Media Access Control implementations, and shows the solution effectiveness with experimental results. We achieved a delay, from physical reception to the triggering of a user-level handler, of 1.1 µs independent of the packet length. Full article

The success of small satellites has lead to the study of new technologies for the realization of Nano and Micro Launch Vehicle (NMLV) in order to make competitive launch costs. The paper has the objective to define and experimentally investigate the performance of a communication system for NMLV interconnecting the End Systems as On-Board Computer (OBC), telemetry apparatus, Navigation Unit...we propose a low cost Ethernet-based solution able to provide the devices with high interconnection bandwidth. To guarantee hard delays to the Guide, Navigation and Control applications we propose some architectural changes of the traditional Ethernet network with the introduction of a layer implemented in the End Systems and allow for the lack of any contention on the network links. We show how the proposed solution has comparable performance to the one of TTEthernet standard that is a very expensive solution. An experimental test-bed equipped with Ethernet switches and Hercules boards by Texas Instruments is also provided to prove the feasibility of the proposed solution. Full article

We propose a 500-frames-per-second high-speed vision (HSV) sensor network that acquires frames at a timing that is precisely synchronized across the network. Multiple vision sensor nodes, individually comprising a camera and a PC, are connected via Ethernet for data transmission and for clock synchronization. A network of synchronized HSV sensors provides a significantly expanded field-of-view compared with that of each individual HSV sensor. In the proposed system, the shutter of each camera is controlled based on the clock of the PC locally provided inside the node, and the shutters are globally synchronized using the Precision Time Protocol (PTP) over the network. A theoretical analysis and experiment results indicate that the shutter trigger skew among the nodes is a few tens of microseconds at most, which is significantly smaller than the frame interval of 1000-fps-class high-speed cameras. Experimental results obtained with the proposed system comprising four nodes demonstrated the ability to capture the propagation of a small displacement along a large-scale structure. Full article

Ethernet-AVB/TSN (Audio Video Bridging/Time-Sensitive Networking) and AFDX (Avionics Full DupleX switched Ethernet) are switched Ethernet technologies, which are both candidates for real-time communication in the context of transportation systems. AFDX implements a fixed priority scheduling strategy with two priority levels. Ethernet-AVB/TSN supports a similar fixed priority scheduling with an additional Credit-Based Shaper (CBS) mechanism. Besides, TSN can support time-triggered scheduling strategy. One direct effect of CBS mechanism is to increase the delay of its flows while decreasing the delay of other priority ones. The former effect can be seen as the shaping restriction and the latter effect can be seen as the shaping benefit from CBS. The goal of this paper is to investigate the impact of CBS on different priority flows, especially on the intermediate priority ones, as well as the effect of CBS bandwidth allocation. It is based on a performance comparison of AVB/TSN and AFDX by simulation in an automotive case study. Furthermore, the shaping benefit is modeled based on integral operation from network calculus perspective. Combing with the analysis of shaping restriction and shaping benefit, some configuration suggestions on the setting of CBS bandwidth are given. Results show that the effect of CBS depends on flow loads and CBS configurations. A larger load of high priority flows in AVB tends to a better performance for the intermediate priority flows when compared with AFDX. Shaping benefit can be explained and calculated according to the changing from the permitted maximum burst. Full article
