In uncrewed aerial vehicle (UAV)-based ground observation and detection missions involving high-speed moving targets or low-light conditions, Time Delay Integration (TDI) cameras enhance image brightness through multi-stage charge accumulation. However, the imaging quality is susceptible to motion blur induced by platform vibrations and velocity mismatch. Based on TDI imaging technology, a TDI image degradation model for a UAV-based imaging platform is formulated. To address spatial blurring caused by platform vibration and velocity mismatch during TDI imaging, we propose a TDI image restoration algorithm based on sharpness-optimized partitioned Point Spread Function (PSF) estimation. The main innovation lies in the first application of partitioned PSF estimation combined with image sharpness optimization in TDI imaging. By formulating an accurate TDI image degradation model, spatial motion blur kernel estimation is transformed into an iterative search problem for partitioned optimal PSF. Solving for optimal sharpness yields the optimal PSF and corresponding local motion parameters, achieving image restoration. Simulation and experimental results demonstrate that the proposed algorithm in this paper effectively removes motion blur in TDI dynamic imaging, while suppressing artifacts and ringing, thus significantly enhancing image quality. Full article

The absolute radiometric calibration of a satellite sensor is an essential process that determines the coefficients required to convert the radiometric quantities of satellite images. This procedure is crucial for ensuring the applicability and enhancing the reliability of optical sensors onboard satellites. This study performs the absolute radiometric calibration of the Compact Advanced Satellite 500-1 (CAS500-1) Advanced Earth Imaging Sensor System-C (AEISS-C), a low Earth orbit satellite developed independently by Republic of Korea for precise ground observation. Field campaign using a tarp, an Analytical Spectral Devices FieldSpecIII spectroradiometer, and a MicrotopsII sunphotometer was conducted. Additionally, reflectance-based vicarious calibration was performed using observational data and the MODerate resolution atmospheric TRANsmission model (version 6) radiative transfer model (RTM). Cross-calibration was also performed using data from the Sentinel-2 MultiSpectral Instrument, RadCalNet observations, and MODIS Bidirectional nReflectance Distribution Function (BRDF) products (MCD43A1) to account for differences in spectral response functions, viewing/solar geometry, and atmospheric conditions between the two satellites. From these datasets, two correction factors were derived: the Spectral Band Adjustment Factor and the BRDF Correction Factor. CAS500-1/AEISS-C acquires satellite imagery using two Time Delay Integration (TDI) modes, and the absolute radiometric calibration coefficients were derived considering these TDI modes. The coefficient of determination (R²) ranged from 0.70 to 0.97 for the reflectance-based vicarious calibration and from 0.90 to 0.99 for the cross-calibration. For reflectance-based vicarious calibration, aerosol optical depth was identified as the primary source of uncertainty among atmospheric factors. For cross-calibration, the reference satellite and RTMs were the primary sources of uncertainty. The results of this study will support the monitoring of CAS500-1/AEISS-C, which produces high-resolution imagery with a spatial resolution of 2 m, and can serve as foundational material for absolute radiometric calibration procedures for other CAS500 satellites. Full article

When using optical remote sensing methods for Kelvin wake imaging, the imaging is affected by sea-surface stochastic fluctuation, imaging noise, and weak reflectivity contrast, resulting in weak wake image signals. In order to better obtain wake optical remote sensing images, this article proposes a multi-objective parameter stochastic optimization method for a time-delayed integration optical remote sensing imaging system. By constructing the wake imaging mechanism framework integrating a hydrodynamic model, rough sea surface probability and statistics model, and Time-Delay Integration Charge-Coupled Device (TDI-CCD) imaging link model, a stochastic multi-objective optimization model with constraints is established. The multi-objective function of this model is specifically defined as follows: maximizing the digital number difference between the crest and trough of Kelvin wakes in imaging results, maximizing the F number, minimizing the integration stages, and minimizing the quantization bits. Meanwhile, a two-stage solution method based on sample average approximation (SAA), branch and bound method (B&B), and the complex method is designed. The model can be used to obtain optimized design results for remote sensing imaging parameters, providing theoretical and methodological support for the design of remote sensing imaging systems. Numerical simulation results show that the optimized parameter combination can achieve clear imaging of the Kelvin wake, and the core indicators meet the design requirements. Full article

Sea surface roughness (SSR) retrieval is a frontier topic in the field of ocean remote sensing, and SSR retrieval based on multi angle, passive, visible spectrum remote sensing images has been proven to have potential applications. Traditional multi angle retrieval models ignored the nonlinear relationship between radiation and digital signals, resulting in low accuracy in SSR retrieval using visible spectrum remote sensing images. Therefore, we analyze the transmission characteristics of signals and random noise in sea surface imaging, establish signals and noise transmission models for typical sea surface imaging visible spectrum remote sensing systems using Complementary Metal Oxide Semiconductor (CMOS) and Time Delay Integration-Charge Coupled Device (TDI-CCD) sensors, and propose a model for SSR retrieval using multi angle passive visible spectrum remote sensing images. The proposed model can effectively suppress the noise behavior in the imaging link and improve the accuracy of SSR retrieval. Simulation experiments show that when simulating the retrieval of multi angle visible spectrum images obtained using CMOS or TDI-CCD imaging systems with four SSR levels of 0.02, 0.03, 0.04, and 0.05, the proposed model relative errors using two angles are decreased by 4.0%, 2.7%, 2.3%, and 2.0% and 6.5%, 4.3%, 3.7%, and 3.2%, compared with the relative errors of the model without considering noise behavior, which are 7.0%, 6.7%, 7.8%, and 9.0% and 9.5%, 8.3%, 9.0%, and 10.2%. When using more fitting data, the relative errors of the model were decreased by 5.0%, 2.7%, 2.5%, and 2.0% and 7.0%, 5.0%, 4.3%, and 3.2%, compared with the relative errors of the model without considering noise behavior, which are 8.5%, 7.0%, 8.0%, and 9.4%, and 10.0%, 8.7%, 9.3%, and 10.0%. Full article

Wide-field-of-view imaging using remote-sensing cameras is of great significance in the study of polar environments. However, because of the drastic change in the direction of Earth’s rotation velocity near the polar regions, image-shift analysis and image quality changes in polar images by large wide-space time-delayed integration (TDI) cameras are poorly understood. Therefore, in this study, a novel velocity projection method was used to obtain a mathematical model of the image-shift velocity field. A quantitative analysis of the simulation showed that the anisotropy of the instantaneous image-shift velocity field varied significantly from low to high latitudes, and rapidly decreased to zero at a very low instantaneous point when there was no anisotropy. After correcting for the camera travelling frequency and bias angle, the value of the modulation transfer function at the edges decreased by less than 5% at 196 levels of integration. Thus, a theoretical basis was provided for using a large wide-space TDI camera to photograph high latitudes. The findings of this study provide a theoretical reference for the current large field-of-view space cameras to obtain high-latitude target information for the edge fuzzy degradation problem. Full article

Digital time-delay integration (TDI) enhances the signal-to-noise ratio (SNR) in infrared (IR) imaging, but its effectiveness in push-broom scanning is contingent upon maintaining a stable image shift velocity. Unpredictable image shifts and rotations, caused by carrier or scene movement, can affect the imaging process. This paper proposes an advanced technical approach for infrared multispectral TDI imaging. This methodology concurrently estimates the image shift and rotation between frames by utilizing a high-resolution visible camera aligned parallel to the optical axis of the IR camera. Subsequently, parameter prediction is conducted using the Kalman model, and real-time compensation is achieved by dynamically adjusting the infrared TDI integration unit based on the predicted parameters. Simulation and experimental results demonstrate that the proposed algorithm enhances the BRISQUE score of the TDI images by 21.37%, thereby validating its efficacy in push-scan imaging systems characterized by velocity-height ratios instability and varying camera attitudes. This research constitutes a significant contribution to the advancement of high-precision real-time compensation for image shift and rotation in infrared remote sensing and industrial inspection applications. Full article

This paper demonstrates the impact of 3D effects on performance parameters in small-sized Time Delay Integration (TDI) image sensor pixels. In this paper, 2D and 3D simulation models of 3.5 μm × 3.5 μm small-sized TDI pixels were constructed, utilizing a three-phase pixel structure integrated with a lateral anti-blooming structure. The simulation experiments reveal the limitations of traditional 2D pixel simulation models by comparing the 2D and 3D structure simulation results. This research validates the influence of the 3D effects on the barrier height of the anti-blooming structure and the full well potential and proposes methods to optimize the full well potential and the operating voltage of the anti-blooming structure. To verify the simulation results, test chips with pixel sizes of 3.5 μm × 3.5 μm and 7.0 μm × 7.0 μm were designed and manufactured based on a 90 nm CCD-in-CMOS process. The measurement results of the test chips matched the simulation data closely and demonstrated excellent performance: the 3.5 μm × 3.5 μm pixel achieved a full well capacity of 9 ke- while maintaining a charge transfer efficiency of over 0.99998. Full article

On-orbit geometric calibration is key to improving the geometric positioning accuracy of high-resolution optical remote sensing satellite data. Grouped calibration with geometric consistency (GCGC) is proposed in this paper for the Jilin1-KF01B satellite, which is the world’s first satellite capable of providing 150-km swath width and 0.5-m resolution data. To ensure the geometric accuracy of high-resolution image data, the GCGC method conducts grouped calibration of the time delay integration charge-coupled device (TDI CCD). Each group independently calibrates the exterior orientation elements to address the multi-time synchronization issues between imaging processing system (IPS). An additional inter-chip geometric positioning consistency constraint is used to enhance geometric positioning consistency in the overlapping areas between adjacent CCDs. By combining image simulation techniques associated with spectral bands, the calibrated panchromatic data are used to generate simulated multispectral reference band image as control data, thereby enhancing the geometric alignment consistency between panchromatic and multispectral data. Experimental results show that the average seamless stitching accuracy of the basic products after calibration is better than 0.6 pixels, the positioning accuracy without ground control points(GCPs) is better than 20 m, the band-to-band registration accuracy is better than 0.3 pixels, the average geometric alignment consistency between panchromatic and multispectral data are better than 0.25 multispectral pixels, the geometric accuracy with GCPs is better than 2.1 m, and the geometric alignment consistency accuracy of multi-temporal data are better than 2 m. The GCGC method significantly improves the quality of image data from the Jilin1-KF01B satellite and provide important references and practical experience for the geometric calibration of other large-swath high-resolution remote sensing satellites. Full article

The integrated interferometric imaging system has pointed out a highly promising direction for the development of high-resolution, small-volume, and lightweight optical imaging systems in orbit. However, the current integrated interferometric imaging system has the problem of a low signal-to-noise ratio (SNR) in orbit, which seriously restricts the practical application and development of the system. To solve this problem, a design method for a multi-waveguide merged multi-frame integration (MWMMFI) system is proposed in this paper. This method proposes a novel non-uniform sampling time axis, which achieves accurate extraction of multi-frame integration signals between interferometric arms, overcoming the limitations of traditional time delay integration (TDI) techniques that are not applicable to tilted optical waveguide arrays. Consequently, it extends the integration time and increases the accumulation of effective optical signals. Additionally, noise is suppressed through an accumulate first and then differentiate algorithm. Ultimately, this achieves an enhancement of the system’s SNR and optimizes the quality of the reconstructed images, all without increasing motion degradation. Simulation experiments indicate that compared to traditional systems, the MWMMFI design can increase the peak signal-to-noise ratio (PSNR) up to 4 times when the merging number is two, and up to 6.58 times when the merging number is three. This provides both technical insights and theoretical guidance for addressing the issue of enhancing the SNR of integrated interferometric imaging systems in orbit. Full article

In semiconductor manufacturing, defect inspection in non-patterned wafer production lines is essential to ensure high-quality integrated circuits. However, in actual production lines, achieving both high efficiency and high sensitivity at the same time is a significant challenge due to their mutual constraints. To achieve a reasonable trade-off between detection efficiency and sensitivity, this paper integrates the time delay integration (TDI) technology into dark-field microscopy. The TDI image sensor is utilized instead of a photomultiplier tube to realize multi-point simultaneous scanning. Experiments illustrate that the increase in the number of TDI stages and reduction in the column fixed pattern noise effectively improve the signal-to-noise ratio of particle defects without sacrificing the detecting efficiency. Full article

This paper presents an investigation of the responsivity of a time-delay integration (TDI) charge-coupled device that employs anti-blooming clocking and uses a varying number of TDI stages. The influence of charge blooming caused by unused TDI stages in a TDI deployed selection scheme is shown experimentally, and an anti-blooming clocking mechanism is analyzed. The impact of blooming on sensor characteristics, such as the responsivity, the conversion gain, and the signal-to-noise ratio, is investigated. A comparison of the measurements with and without this anti-blooming clocking mechanism is presented and discussed in detail. Full article

In this paper, a 7.75 kHz line rate analog domain time delay integration (TDI) CMOS analog accumulator with 128-stage is proposed. An adaptive compensation for the charge loss due to parasitic effects is adopted. Based on the influence mechanism of parasitic effects, alternately charging the top and bottom plates of the storage capacitor while cooperate positive feedback capacitor dynamically compensates for the charge loss of the sampling phase and the holding phase. Using the proposed circuit, after the post-layout simulation verification, the SNR of 128 stage accumulation can be improved by as much as 20.9 dB. Full article

Time delay and integration (TDI) charge-coupled device (CCD) is an image sensor for capturing images of moving objects at low light levels. This study examines the model construction of stitched TDI CCD original multi-slice images. The traditional approaches, for example, include the image-space-oriented algorithm and the object-space-oriented algorithm. The former indicates concise principles and high efficiency, whereas the panoramic stitching images lack the clear geometric relationships generated from the image-space-oriented algorithm. Similarly, even though the object-space-oriented algorithm generates an image with a clear geometric relationship, it is time-consuming due to the complicated and intensive computational demands. In this study, we developed a multi-slice satellite images stitching and geometric model construction method. The method consists of three major steps. First, the high-precision reference data assist in block adjustment and obtain the original slice image bias-corrected RFM to perform multi-slice image block adjustment. The second process generates the panoramic stitching image by establishing the image coordinate conversion relationship from the panoramic stitching image to the original multi-slice images. The final step is dividing the panoramic stitching image uniformly into image grids and employing the established image coordinate conversion relationship and the original multi-slice image bias-corrected RFM to generate a virtual control grid to construct the panoramic stitching image RFM. To evaluate the performance, we conducted experiments using the Tianhui-1(TH-1) high-resolution image and the Ziyuan-3(ZY-3) triple liner-array image data. The experimental results show that, compared with the object-space-oriented algorithm, the stitching accuracy loss of the generated panoramic stitching image was only 0.2 pixels and that the mean value was 0.799798 pixels, achieving the sub-pixel stitching requirements. Compared with the object-space-oriented algorithm, the RFM positioning difference of the panoramic stitching image was within 0.3 m, which achieves equal positioning accuracy. Full article

In this study, we developed a high-resolution, more accurate, non-destructive apparatus for refining the detection of electrode pixels in a thin-film-transistor liquid-crystal display (TFT-LCD). The hybrid optoelectronic apparatus simultaneously uses an array tester linked with the automatic optical inspection of panel defects. Unfortunately, due to a tiny air gap in the electro-optical inspector, the situation repeatedly causes numerous scratches and damages to the modulator; therefore, developing alternative equipment is necessary. Typically, in TFT-LCDs, there are open, short, and cross short electrical defects. The experiment utilized a multiple-line scan with the time delay integration (TDI) of a charge-coupled device (CCD) to capture a sharp image, even under low light, various speeds, or extreme conditions. In addition, we explored the experimental efficacy of detecting the electrode pixel of the samples and evaluated the effectiveness of a 7-inch opaque quartz mask. The results show that an array tester and AOI can detect a TFT-LCD electrode pixel sufficiently; therefore, we recommend adopting the hybrid apparatus in the TFT-LCD industry. Full article

The design of compact hyperspectral cameras with high ground resolution and large field of view (FOV) is a challenging problem in the field of remote sensing. In this paper, the time-delayed integration (TDI) of the digital domain is applied to solve the issue of insufficient light energy brought by high spatial resolution, and a hyperspectral camera with linear variable filters suitable for digital domain TDI technology is further designed. The camera has a wavelength range of 450–950 nm, with an average spectral resolution of 10.2 nm. The paper also analyzed the effects of digital domain TDI on the signal–noise ratio (SNR) and the spectral resolution. During its working in orbits, we have obtained high-SNR images with a swath width of 150 km, and a ground sample distance (GSD) of 10 m @ 500 km. The design of the hyperspectral camera has an improved spatial resolution while reducing the cost. Full article
