With the further implementation and development of the Western Development Strategy, studying the mechanical behavior and deformation characteristics of deep-buried tunnels in layered hard rock under high ground stress conditions holds considerable engineering significance. To study the mechanical properties and long-term deformation and failure characteristics of different bedding stratified rocks, this research employed an MTS815 electro-hydraulic servo rock testing system and a French TOP rheometer. Triaxial compression tests, rheological property tests, and long-term cyclic and unloading tests were conducted on shale samples under varying confining pressures and bedding angles. The results indicate that (1) under triaxial compression, shale demonstrates pronounced anisotropic behavior. When the confining pressure is constant, the peak strength of the rock sample exhibits a “U”-shaped variation with the bedding angle (its minimum value at 60°). For a fixed bedding angle, the peak strength of the rock sample progressively increases as the confining pressure rises. (2) The mode of shale failure varies with the angle: at 0°, shale exhibits conjugate shear failure; at 30°, shear slip failure along the bedding is controlled by the bedding weak plane; at 60° and 90°, failure occurs through the bedding. (3) During the creep process of layered shale, brittle failure characteristics are evident, with microcracks within the sample gradually failing at stress concentration points. The decelerated and stable creep stages are prominent; while the accelerated creep stage is less noticeable, the creep rate increases with increasing stress level. (4) Under low confining pressure, the peak strength during cyclic loading and unloading creep processes is lower than that of conventional triaxial tests when the bedding plane dip angles are 0° and 30°, which is the opposite at 60° and 90°. (5) In the cyclic loading and unloading process, Poisson’s ratio gradually increases, whereas the elastic modulus, shear modulus, and bulk modulus gradually decrease. Full article

In this study, the response mechanism between macro- and microscales of deep hard-rock diorite is investigated under loading and unloading conditions. Moreover, the statistical theory is combined with particle flow code simulations to establish a correlation between unloading rates observed in laboratory experiments and numerical simulations. Subsequent numerical tests under varying confining pressures are conducted to examine the macroscopic mechanical properties and the evolution of particle velocity, displacement, contact force chain failures, and microcracks in both axial and radial directions of the numerical rock samples during the loading and unloading phases. The findings indicate that the confining pressure strength curve displays an instantaneous fluctuation response during unloading, which intensifies with higher initial confining pressures. This suggests that rock sample damage progresses in multiple stages of expansion and penetration. The study also reveals that with increased initial confining pressure, there is a decrease in particle velocity along the unloading direction and an increase in particle displacement and the number of contact force chain failures, indicating more severe radial expansion of the rock sample. Furthermore, microcracks predominantly accumulate near the unloading surface, and their total number escalates with rising confining pressure, suggesting that higher confining pressures promote the development and expansion of internal microcracks. Full article

Shale is a common rock type that is associated with underground engineering projects, and several important factors, such as bedding structure, confining pressure, and the loading and unloading path, significantly influence the anisotropy of shale. Triaxial monotonic loading tests and triaxial incremental cyclic loading and unloading tests of shale under three kinds of confining pressures and five types of bedding inclination angles (θ) were thus performed to investigate the anisotropy of shale in terms of mechanical behavior, acoustic emission (AE), and energy evolution, and reveal the mechanism by which shale anisotropy is weakened. The results show that (1) the compressive strength and elastic modulus of shale decrease and then increase as the θ increases, and that both σ₃ and incremental cyclic loading and unloading reduce the anisotropy in terms of the compressive strength and elastic modulus of shale, with the ratio of plastic strain to total strain reaching its maximum at a θ of 60° during each loading and unloading cycle. (2) The failure modes of shale with θ of 0°, 30°, and 90° under triaxial monotonic loading are similar to the counterparts under triaxial incremental cyclic loading and unloading, while the failure modes of shale with θ of 45° and 60° differ significantly under the two loading conditions, and interestingly, the degree to which the bedding plane participates in shale crack evolution under incremental cyclic loading and unloading is considerably lower than that under triaxial monotonic loading. (3) The cumulative AE count and AE b-value of shale first decrease and then increase as the θ increases, while the Felicity ratio decreases as the number of cycles increases. (4) As the θ increases, the total energy density U₀ and the parameter m, which reflects the accumulation rate of elastic energy, first decrease and then increase, with both reaching a minimum at a θ of 60°. (5) The mode by which cyclic loading and unloading leads to failure in shale with a θ of 60° is similar to that at a θ of 0° and is the main mechanism by which shale anisotropy weakening occurs as a result of cyclic loading and unloading. The results provide experimental support and a theoretical basis for safer and more efficient underground engineering projects that involve shale. Full article

The permeability of reservoirs is a key factor affecting the exploitation and utilization of geothermal resources. This test used a core flow meter and other advanced experimental devices to investigate the evolution of the permeability characteristics of loose sandstone samples (with a diameter of 25 mm and a length of 50 mm) in the Zijiao Town area under various temperatures, confining pressures, injection rates, and cyclic loading and unloading conditions. The results show that (1) as the temperature increases, the overall trend of rock permeability decreases, which is mainly related to the thermal expansion of rock particles. In addition, the higher the temperature, the greater the gravel outflow. (2) The critical pressure for pore closure in the unconsolidated sandstone in the region is approximately 15 MPa. (3) The permeability change of loose sandstone under low injection rate conditions is relatively small and can be neglected. However, there is reason to believe that under high-flow injection conditions, the permeability of this type of rock mass will undergo significant changes. (4) Under the condition of loading and unloading, the permeability ratio curve of the unloading stage at three temperatures is almost a straight line. The higher the temperature, the smaller the slope, and the permeability at 20 °C with the highest recovery degree is only about 50% of the initial one. Full article

The sustainability of rock engineering is an emerging trend in future development, as society increasingly recognizes the importance of environmental conservation and responsible resource utilization. In this context, the field of rock engineering is undergoing a paradigm shift toward more sustainable practices. A significant aspect of this shift is the investigation of energy evolution laws specific to rocks, which assumes paramount importance in ensuring the sustainable utilization of damaged rock roadways. To investigate the impact of confining pressure and pore pressure on the energy evolution characteristics of rock beyond the peak, post-peak cyclic loading and unloading tests were conducted on sandstone specimens under hydraulic coupling conditions using the MTS815 rock mechanical test system. The study encompassed three sets of confining pressures, namely, 10 MPa, 20 MPa, and 30 MPa. Different levels of pore pressure were applied within each confining pressure group. For the 10 MPa confining pressure, the pore pressure values were set at 2 MPa, 4 MPa, 6 MPa, and 8 MPa. Similarly, for the 20 MPa and 30 MPa confining pressures, the corresponding pore pressure values were 2 MPa, 6 MPa, 10 MPa, 14 MPa, 18 MPa, and 22 MPa. The experimental findings indicate that as the confining pressure increases, both the maximum and residual elastic energy densities of the rock gradually increase. The rise in confining pressure impedes the release of elastic energy. Moreover, with increasing confining pressure, the rate of increase in the maximum dissipated energy density diminishes, highlighting the inhibitory effect of confining pressure on energy dissipation and release within the rock. Pore pressure, on the other hand, disrupts the load-bearing structure of the rock and reduces its energy storage capacity. Under a constant confining pressure, for a fixed number of cycles (axial strain), the total input energy density, elastic energy density, and dissipation energy density exhibit a negative correlation with pore pressure. With an increase in the number of cycles (axial strain), the proportion of elastic energy initially rises but subsequently declines, while the proportion of dissipated energy follows the opposite trend. Furthermore, as the confining pressure increases, the peak proportion of elastic energy also tends to increase. This indicates that higher confining pressures promote energy accumulation after rock failure, enhancing the rock’s ability to store elastic energy. Full article

Gas reservoirs have significant engineering characteristics of injection and extraction. The reservoir cap rock is subjected to cyclic alternating loading and has the potential risk of seal failure. Therefore, it is necessary to study the stress−percolation−damage mechanism of the reservoir cap rock in depleted gas reservoirs. The rock Mechanics Test System (MTS) was used to study the permeability characteristics of a typical mud shale cap layer under different loading and unloading rates, analyze the deformation characteristics and permeability performance evolution law of the rock under the confining pressure alternation, and study the effects of loading and unloading rate, confining pressure and number of cycles on the permeability of the cap rock. The test results show that with the increase in the number of cycles, the hysteresis loop moves in the direction of axial strain increase offset. The overall morphology is presented as an elongated type, and the damage of the specimen is small in the cyclic confining pressure; At the beginning of the cycling period, the permeability decreases with the increase in the confining pressure in the form of a negative exponential. At the later stage of the cycling period, the permeability basically stays unchanged, and is maintained at a low level; At low confining pressure, permeability also decreases in a negative exponential form with the increase in the number of confining pressure cycles; The greater the loading and unloading rate at the beginning of the cycle, the more the permeability decreases; There is a tendency of sealing improvement under cyclic loading in the gas storage of depleted reservoirs with mud shale as the cap layer. The results of the study can provide technical parameters for the evaluation of the cap sealing of gas storage of depleted reservoirs. Full article

Low-permeability sandstone reservoirs have been widely used as a gas storage medium worldwide. Compared with the high porosity and high permeability of sandstone, low-permeability sandstone may present different mechanical (deformation, damage or failure) and acoustic responses under cyclic loading-unloading processes caused by the high-rate injection–production of underground gas storage. In this paper, multistage triaxial loading–unloading tests with a continuously increased upper limit of stress were carried out on low-permeability sandstone under six different confining pressures. The results showed that the superposition of stress–strain curves become much denser in the process of each level of stress. Based on the variation of the elastic modulus of low-permeability sandstone under alternating loads, the mechanical behavior of low-permeability sandstone under cyclic loading is divided into three stages: cyclic hardening, stability and cyclic softening. According to the evolution of acoustic emission (AE) signal parameters, AE counts appear intensively at the initial stage of each level of stress and then gradually stabilize. The peak frequency presents the zonal distribution, which is divided into low-frequency, intermediate-frequency and high-frequency zones. Low confining pressure leads to a small b-value. The RA–AF distribution implies that the mixed tensile–shear cracks are continuously generated in low-permeability sandstone during the cyclic loading process, and the shear cracks are more obviously developed. Full article

The shale of the Wufeng–Longmaxi formation in the Sichuan Basin is the preferred layer for shale gas exploration in China, and its petrophysical characteristics are the key to geological and engineering sweet spot prediction. However, the characteristics and impact mechanisms of its acoustic wave velocity and elastic anisotropy are currently unclear. In this paper, the Wufeng–Longmaxi shale is taken as the research object, and the P-wave and S-wave velocities of the samples are tested under the loading and unloading processes of confining pressure. The stress sensitivity variations in parameters such as wave velocity, wave velocity ratio, and anisotropy are discussed. P-wave and S-wave anisotropy parameters are correlated under different pressure conditions. X-ray diffraction, casting thin sections, scanning electron microscopy, micron CT scanning, and other analytical techniques are used to explore the mechanisms of stress sensitivity of elastic parameters. The research results indicate that: (1) the acoustic velocities of samples from different angles are V90° > V45° > V0°, and there is a positive correlation between the wave velocity and the confining pressure. After unloading the confining pressure, irreversible plastic deformation occurs due to the closure of some microfractures in the rock core, causing the wave velocity to be higher than the initial value. (2) The stress sensitivity coefficient of the P-wave (The mean is 3.00 m·s⁻¹·MPa⁻¹) is higher than that of the S-wave (the mean is 1.23 m·s⁻¹·MPa⁻¹), and the stress sensitivity coefficient of the compacted stage (the mean is 3.02 m·s⁻¹·MPa⁻¹) is higher than that of the elastic stage (the mean is 1.21 m·s⁻¹·MPa⁻¹). (3) The anisotropy of the P-wave and S-wave is negatively correlated with the confining pressure. When the confining pressure is loaded to 65 MPa, the change rate of the P-wave anisotropy coefficient is 23%, and its stress sensitivity is higher than that of S-wave anisotropy coefficient (the change rate is 13.7%). After unloading the confining pressure, the degree of anisotropy is reduced due to the closure of some microfractures. The empirical formula of P-wave and S-wave anisotropy parameters under different pressures is established through linear regression, which can provide a reference for mutual predictions. (4) The variation in wave velocity anisotropy with stress can be divided into stress and material anisotropy, which are related to the directional arrangement of microfractures and clay minerals, respectively. The quantitative characterization of shale anisotropy can be realized by evaluating the development degree of reservoir fractures and mineral components, providing a reference for logging interpretations, sweet spot prediction, and fracturing construction of shale gas reservoirs. Full article

Drilling vertical and horizontal wellbores in the shale reservoir may trigger the in-situ stress release around the wellbore walls and change the original stress equilibrium state, leading the wellbores to instability. This stress change in the wellbore corresponds to the stress paths of confining pressure unloading and axial stress loading under laboratory conditions. In this paper, according to the conventional triaxial compression test results, laboratory experiments and DEM simulations by PFC^2D were conducted to deeply study the strength, failure, strain energy evolution, and micro-crack damage mechanism of shale specimens under confining pressure unloading conditions. The shale specimens at different bedding inclinations were tested under different initial axial stress levels and confining pressure unloading rates, with fixed initial unloading confining pressure. This research revealed that confining pressure unloading induces greater plastic deformation, more micro-crack damage and strain energy dissipation, and a more complex failure pattern. The strain energy dissipation and dilatation under confining pressure unloading conditions are mainly induced by the generation and accumulation of tensile cracks. Moreover, the unloading rate has a significant effect on the mechanical properties, and the high unloading rate enhances the failure strength and induces more strain energy dissipation and micro tensile cracks. For the wellbore drilling in shale formations, when the buried depth and vertical stress are fixed, the lower the lateral stress is, the easier it is to form tensile failure around the wellbore wall in the drilling process, and the more induced fractures will be generated in the formation around the wellbore. Full article

To investigate the strength and failure characteristics of silty mudstone using different stress paths, silt-like mudstone specimens were subjected to triaxial unloading tests. The results indicate the following. (1) When subjected to equivalent initial deviator stress levels and differing confining pressures, the peak stress, residual stress, and elastic modulus, exhibited during unloading, increased concordantly with greater initial confining pressure. Both the peak strain and residual strain increased with rising initial confining pressure. The increase in peak strain and residual strain initially decelerated, then noticeably increased, before ultimately decreasing again. Additionally, the unloading failure time and strain rate demonstrated a negative correlation as the confining pressure increased. (2) Under different initial deviatoric stress conditions, the peak stress, residual stress, and residual strain, under unloading confining pressure conditions, decreased as the initial deviatoric stress levels elevated. Conversely, the peak strain and elastic modulus initially increased, then decreased under increasing initial deviatoric stress conditions. The unloading failure time and strain rate were both observed to decrease as the initial deviatoric stress levels increased. (3) Utilizing the Mohr stress circle enabled the characterization of the shear strength variation in the specimens during the unloading process. The cohesion and internal friction angle remained relatively consistent across the different unloading stress paths appraised, with cohesion being greater in path I versus path II, whereas the internal friction angle exhibited an inverse relationship. (4) The specimen failed during unloading due to lateral expansion caused by unloading confining pressure and collapse failure. The failure fracture surfaces predominantly manifested shear failure morphologies. Full article

The artificial freezing method is used to cross the water-rich soft rock strata in order to exploit deep coal resources. At present, studies that consider both freezing effect and unloading rate are insufficient. To study the influences of the excavation rate using the artificial freezing method on the unloading deformation and failure of the water-rich surrounding rock, we carry out mechanical and synchronous acoustic emission (AE) tests on frozen (−10 °C) sandstone samples under different lateral unloading rates. Combined with the AE signals, the stress, strain and failure process are analysed to determine the mechanical behaviours of frozen rock samples under different lateral unloading rates. The damage difference between normal temperature rock and frozen rock during lateral unloading is studied. According to acoustic emission signals, the damage relationships among acoustic emission amplitude, energy, cumulative acoustic emission energy (CAEE), stress and strain were compared and analyzed. In this paper, acoustic emission 3D positioning system is used to monitor the fracture propagation trajectory in the process of unloading confining pressure of frozen sandstone. The results show that the peak stress of frozen sandstone during lateral unloading is about 2.5 times of that at 20 °C. More than 2 AE amplitudes per second are regarded as the precursor of failure (FP), and point FP is taken as the first level warning. The CAEE of rock samples at 20 °C and frozen rock samples shows the same change law over time, increasing slowly before the FP point and exponentially after the FP point. Peak stress increases and axial strain decreases with the increase of unloading rate of frozen rock sample. The CAEE at point FP and the peak acoustic emission energy (AEE) and the CAEE at the time of failure increase when the unloading rate of frozen rock sample increases. Principal component analysis method was used to extract key characteristic energy to obtain a clearer AEE concentration area, which was defined as second-level early warning. The research results can provide guidance for freezing shaft construction to reduce the occurrence of disasters. Full article

Consolidated undrained triaxial shear tests were performed on undisturbed saturated structured clay at three unloading rates (0.1, 0.25, and 2.5 kPa/min) using a GDS triaxial system to determine the effects of different unloading rates and unloading stress paths on the stress–strain relationship, pore pressure variation, and failure strength characteristics of Zhanjiang structured clay. Microstructural changes in the clay were observed during shear tests at different unloading rates. Furthermore, the obtained stress–strain relationship indicates strain-softening under different unloading stress paths. Under the same axial strain, a larger unloading rate caused a larger deviatoric stress. Under the same conditions, the higher the confining pressure, the greater the peak pore pressure, the smaller the unloading rate, the greater the pore pressure development, and the greater the variation in the pore pressure. Moreover, the undrained shear strength increased with an increase in the unloading rate from 0.1 to 2.5 kPa/min. The change in the unloading rate had a greater effect on the undrained strength under the passive tensile path than that under the passive compression path. The microstructure of the Zhanjiang structured clay changed after shear tests at different unloading rates, exhibiting various degrees of adjustment in the particle arrangement, contact relations, pore sizes, and shapes. Full article

Seasonal freeze–thaw environments are one of the key factors that aggravate the mechanical strength decay of excavated and unloaded rock masses on reservoir banks in cold areas. To study the time-dependent mechanical properties of an excavated and unloaded rock mass on a bank slope under freeze–thaw action, triaxial unloading tests were carried out on sandstone, freeze–thaw tests simulating freezing strength were conducted, and triaxial creep tests were implemented with graded incremental loading on unloaded specimens subjected to freeze–thaw action. The test results showed that the total deformation of the unloaded specimens is significantly increased compared with the conventional specimens, and the lateral direction is more likely to produce creep behaviour than the axial direction. The level of confining pressure determines the level of creep deformation of unloaded specimens and affects the variation law of creep rate. The creep behaviour of the unloaded specimens is aggravated by freeze–thaw action and, the longer the freezing period, the larger the creep strain share, and the creep rate increases significantly. The creep damage pattern of the unloaded specimens subjected to freeze–thaw action is mainly manifested as shear damage, and the creep process intensifies the derivation of tension-type cracks in the specimens. The higher the confining pressure of the unloaded specimen, the more obvious the plastic characteristics and the weaker the brittle characteristics during creep failure. The freeze–thaw action significantly reduces the long-term strength of the unloaded specimen, which is approximately 50~55% of the instantaneous strength. The long-term strength decays significantly with an increasing freezing period, and the research results can provide a theoretical reference for the evaluation of the long-term stability of excavated and unloaded rock masses in cold areas. Full article

The deformation and failure of underground engineering are usually caused by unloading. In this work, triaxial unloading confining pressure tests are carried out to simulate the failure process of rock mass caused by unloading, analyze the crack-characteristic stress, and study the energy evolution of rock under unloading and the pre-peak and post-peak energy characteristics combined with the energy theory. The results show that, when the confining pressure increases from 5 MPa to 20 MPa, crack closure stress σ_cc, crack initiation stress σ_ci, dilatancy stress σ_cd, and peak stress σ_p are 6.34 times, 2.75 times, 1.93 times, and 1.66 times higher than the original, respectively. By comparing the increase in crack-characteristic stress, it can be found that the confining pressure has a large effect on the crack closure stress and crack initiation stress, while the dilatation stress and peak stress have relatively little influence. From the perspective of energy evolution, the pre-peak axial absorption energy U₁ increases exponentially, the elastic energy U^e is similar to U₁, and the circumferential consumption energy U₃ and dissipation energy U^d are small. After reaching the peak stress, the growth rate of U₁ decreases slightly, U^e decreases rapidly, and U₃ increases rapidly but only as a small fraction of the total energy, while U^d grows almost exponentially and rapidly becomes the main part of the energy. Under each crack-characteristic stress state, the energy characteristic parameters gradually increase with the increase in confining pressure, which is manifested by the increase in slope in the linear fitting formula of energy characteristic parameters. The release process of the releasable elastic energy after the peak stress can be divided into three stages of “slow–fast–slow”, and the energy release process shows an obvious confining pressure effect. Full article

The quality of excavated and unloaded rock masses on steep and high slopes in cold regions is prone to deterioration, which in turn affects the long-term stability and safety of excavated slopes. Based on a triaxial unloading-damage test of sandstone, the unloading quantity was used to analyze the evolution law of unloading damage; a freeze-thaw cycle test of the unloaded-damaged samples was carried out, and it was found that the average change in porosity and the reloading peak strength damage rate after freeze-thaw increased with the increase in the number of freeze-thaw cycles, and the porosity change characteristics were independent of the value of the confining pressure at the time of the unloading damage. An exponential decay model was used, and based on the average change in porosity after freeze-thaw, a freeze-thaw strength decay model that can take into account the effect of confining pressure was established, and its ability to predict the strength decay of unloaded-damaged rock samples after freeze-thaw was verified by experimental data. The research results provide a reference for the evaluation of freeze-thaw degradation of unloaded rock masses during slope excavation in cold regions. Full article
