Search Results (123)

The terahertz waves are electromagnetic waves with frequencies ranging from 0.1 to 10 THz, exhibiting characteristics of both microwave and infrared, including fingerprint characteristics, coherence, and safety. Due to the weak interactions among most organic macromolecules in substances, the vibrational modes of molecular frameworks, as well as dipole rotation and vibration transitions, often correspond to the terahertz spectral region. Consequently, there has been growing interest in applying terahertz technology within the food industry. This review summarizes the fundamental principles of terahertz spectroscopy for substance detection and highlights recent advances and applications in food analysis. Key applications include harmful contaminant detection, component analysis, quality assessment, and adulteration identification. Additionally, this review discusses current challenges in applying terahertz spectroscopy to food analysis, such as strong water absorption, matrix interference, and the lack of comprehensive spectral databases. Finally, the paper outlines future prospects, including the development of lightweight and cost-effective terahertz sources and detectors for on-site analysis, as well as the integration of terahertz spectroscopy with other modern detection technologies to enhance analytical performance. This work aims to serve as a reference for further research and development of terahertz spectroscopy in the food sector. Full article

In nondestructive evaluation of concrete structures, the far-infrared region, including terahertz waves, which can penetrate concrete and measure the amount of corrosion in the internal steel, has attracted much attention. Magnetite has the potential to be used as a far-infrared detection device that meets the requirements for nondestructive evaluation devices, such as room temperature operation and portability, while also having a low environmental impact. In this study, the sensitivity of magnetite thin films with different concentrations of Pt to electromagnetic waves at a wavelength of 10.6 μm was evaluated and compared: a nanocomposite with Pt nanocrystals dispersed in magnetite thin films was prepared by radio frequency sputtering, electrodes were prepared by a photoresist process, and the resistance variation was recorded after irradiation with 10.6 μm pulse electromagnetic waves. As a result, it was experimentally confirmed that the peak of response was the maximum at the amount of Pt added, where the electrical resistivity reached 12,000 µΩcm, and the S/N ratio was the maximum at the amount of Pt added, where the electrical resistivity reached 14,000 µΩcm. This indicates that Pt-doped magnetite with a Pt content of 14,000 µΩcm electrical resistivity is suitable as a far-infrared detector element material. Full article

Interference caused by multiple reflections is a critical issue in transmission measurements using continuous wave (CW) terahertz and sub-terahertz radiation. This study proposes a practical method to reduce interference effects and improve the stability of transmittance measurements. By deriving analytical expressions for interference patterns under both normal and oblique incidence conditions, we demonstrate that oblique incidence simplifies the interference behavior and allows the reliable extraction of transmittance values from maximum and minimum signal intensities. Using a 95 GHz CW oscillator (Model SFD-753114-103-10SF-P1, Eravant, Torrance, CA, USA) and a 1 mm-thick PET sample, we conducted transmission measurements while varying the detector position. The derived method enabled the calculation of interference-free transmittance values that were consistent across different sample positions. This approach offers a practical technique for material characterization, especially in applications such as nondestructive testing and plastic recycling. Full article

In recent years, electromagnetic waves (terahertz waves) with frequencies between 0.1 and 10 THz, which exist between radio waves and light waves, have attracted much attention. These electromagnetic waves have both the linearity of light waves and the transparency of radio waves and are expected to be applied to the field of human non-destructive testing. While it is known that terahertz waves can be used to detect foreign matter inside an object, we thought that by irradiating terahertz waves to the object to be measured from various directions, it would be possible to analyze the location and direction of contamination by comparing the scattering of the terahertz waves irradiated to the foreign matter. The samples were biomass resources in a jar with an opening of 53 mm and a diameter of 66.8 mm, and an aluminum plate 76 × 50 mm. When terahertz waves were irradiated from the side of the jar with the biomass resources in it, and the aluminum plate inserted, the transmission was higher when the metal plate was parallel to the light source and detector. This indicates that the transmission tendency of terahertz waves changes depending on the position and angle of the metal strip inside with respect to the direction of terahertz wave irradiation. This transmission tendency enables us to locate the position of a foreign object by irradiating terahertz waves from multiple directions, which is expected to be applied not only to the removal of foreign objects but also to various non-destructive inspections. Full article

This study systematically investigates the effects of trap concentration on self-heating and terahertz (THz) responses in GaN HEMTs using Sentaurus TCAD. Traps, inherently unavoidable in semiconductors, can be strategically introduced to engineer specific energy levels that establish competitive dynamics between the electron momentum relaxation time and the carrier lifetime. A simulation-based exploration of this mechanism provides significant scientific value for enhancing device performance through self-heating mitigation and THz response optimization. An AlGaN/GaN heterojunction HEMT model was established, with trap concentrations ranging from 0 to $5\times {10}^{17} {\mathrm{c}\mathrm{m}}^{-3}$. The analysis reveals that traps significantly enhance channel current (achieving 3× gain at $1\times 10^{17} {\mathrm{c}\mathrm{m}}^{-3}$) via new energy levels that prolong carrier lifetime. However, elevated trap concentrations (>$1\times {10}^{16} {\mathrm{c}\mathrm{m}}^{-3}$) exacerbate self-heating-induced current collapse, reducing the min-to-max current ratio to 0.9158. In THz response characterization, devices exhibit a distinct DC component (${\mathrm{U}}_{\mathrm{d}\mathrm{c}}$) under non-resonant detection ($\mathsf{\omega }\mathsf{\tau }\ll 1$). At a trap concentration of $1\times {10}^{15} {\mathrm{c}\mathrm{m}}^{-3}$, ${\mathrm{U}}_{\mathrm{d}\mathrm{c}}$ peaks at $0.12 \mathrm{V}$ when ${\mathrm{V}}_{\mathrm{g}}\mathrm{D}\mathrm{C}=-7.8 \mathrm{V}$. Compared to trap-free devices, a maximum response attenuation of 64.89% occurs at ${\mathrm{V}}_{\mathrm{g}}\mathrm{D}\mathrm{C}=-4.9 \mathrm{V}$. Furthermore, ${\mathrm{U}}_{\mathrm{d}\mathrm{c}}$ demonstrates non-monotonic behavior with concentration, showing local maxima at $4\times {10}^{15} {\mathrm{c}\mathrm{m}}^{-3}$ and $7\times {10}^{15} {\mathrm{c}\mathrm{m}}^{-3}$, attributed to plasma wave damping and temperature-gradient-induced electric field variations. This research establishes trap engineering guidelines for GaN HEMTs: a concentration of $4\times {10}^{15} {\mathrm{c}\mathrm{m}}^{-3}$ optimally enhances conductivity while minimizing adverse impacts on both self-heating and the THz response, making it particularly suitable for high-sensitivity terahertz detectors. Full article

We present THz direct detectors based on an AlGaN/GaN high electron mobility transistor (HEMT), featuring excellent optical sensitivity and low noise-equivalent power (NEP). These detectors are monolithically integrated with various antenna designs and exhibit state-of-the-art performance at room temperature. Their architecture enables straightforward scaling to two-dimensional formats, paving the way for terahertz focal plane arrays (FPAs). In particular, for one detector type, a fully realized THz FPA has been demonstrated in this paper. Theoretical and experimental characterizations are provided for both single-pixel detectors (0.1–1.5 THz) and the FPA (0.1–1.1 THz). The broadband single detectors achieve optical sensitivities exceeding 20 mA/W up to 1 THz and NEP values below 100 pW/$\sqrt{\mathrm{Hz}}$. The best optical NEP is below 10 pW/$\sqrt{\mathrm{Hz}}$ at 175 GHz. The reported sensitivity and NEP values were achieved including antenna and optical coupling losses, underlining the excellent overall performance of the detectors. Full article

We present a method for real-time terahertz imaging that employs a hydrogen cyanide (HCN) laser as a terahertz source at 0.89 THz and an AlGaN/GaN high-electron-mobility transistor (HEMT) terahertz detector as a camera. We developed an HCN laser and constructed a transmission imaging system based on it. This combination utilizes a high-power HCN laser with a highly sensitive terahertz detector, enabling practical applications of real-time terahertz imaging. A resolution test plane was produced to determine that the system could achieve a lateral resolution of 2 mm, and real-time terahertz imaging was carried out on Siemens star, pistachios, and sunflower seeds. The results demonstrate that the hidden structures inside nuts can be observed by terahertz imaging. Through our analysis of terahertz images of both sunflower seeds and pine nuts, we successfully assessed their fullness and demonstrated the capability to distinguish between full and unfilled nuts. These findings validate the potential of this technique for future applications in nut detection. We discuss the limitations of the current setup, potential improvements, and possible applications, and we outline the introduction of aspherical lenses and terahertz transmission tomography. Full article

This research proposes an all-metal metamaterial-based absorber with a novel geometry capable of refractive index sensing in the terahertz (THz) range. The structure consists of four concentric diamond-shaped gold resonators on the top of a gold metal plate; the resonators increase in height by 2 µm moving from the outer to the inner resonators, making the design distinctive. This novel configuration has played a very significant role in achieving multiple ultra-narrow resonant absorption peaks that produce very high sensitivity when employed as a refractive index sensor. Numerical simulations demonstrate that it can achieve six significant ultra-narrow absorption peaks within the frequency range of 5 to 8 THz. The sensor has a maximum absorptivity of 99.98% at 6.97 THz. The proposed absorber also produces very high-quality factors at each resonance. The average sensitivity is 7.57/Refractive Index Unit (THz/RIU), which is significantly high when compared to the current state of the art. This high sensitivity is instrumental in detecting smaller traces of samples that have very correlated refractive indices, like several harmful gases. Hence, the proposed metamaterial-based sensor can be used as a potential gas detector at terahertz frequency. Furthermore, the structure proves to be polarization-insensitive and produces a stable absorption response when the angle of incidence is increased up to 60°. At terahertz wavelength, the proposed design can be used for any value of the aforementioned angles, targeting THz spectroscopy-based biomolecular fingerprint detection and energy harvesting applications. Full article

Terahertz radiation patterns can be registered using various detectors; however, in most cases, the scanning resolution is limited. Thus, we propose an alternative method for the detailed scanning of terahertz light field distributions after passing simple and complex structures. Our method relies on using a dielectric waveguide to achieve better sampling resolution. The optical properties of many materials were analyzed using time-domain spectroscopy. A cyclic olefin copolymer (COC) was chosen as one of the most transparent. This study contains a characterization of the losses introduced by the waveguide and a discussion of the setup’s geometry. As a structure introducing the radiation pattern, a 2D quasi-periodic amplitude grating was chosen to observe the Talbot effect (self-imaging). Moreover, some interesting physical phenomena were observed and discussed due to the possibility of detailed scanning, with subwavelength resolution, registering the terahertz wavefront changes behind the structure. Full article

The practical implementation of terahertz (THz) imaging and spectroscopic systems in real operational conditions requires them to be of a compact size, to have enhanced functionality, and to be user-friendly. This work demonstrates the single-sided integration of Fresnel-zone-plate-based optical elements with InGaAs bow-tie diodes directly on a semiconductor chip. Numerical simulations were conducted to optimize the Fresnel zone plate’s focal length and the InP substrate’s thickness to achieve constructive interference at 600 GHz, room-temperature operation and achieve a sensitivity more than an order of magnitude higher—up to 24.5 V/W—than that of a standalone bow-tie detector. Investigations revealed the strong angular dependence of the incident radiation on the Fresnel zone plate-integrated bow-tie diode’s response. These findings pave a promising avenue for the further development of single-sided integration of flat optics with THz detectors, enabling improved sensitivity, simplified manufacturing processes, and reduced costs for THz detection systems in a more compact design scheme. Full article

Bolometric detection of electromagnetic radiation is a well-established method in a wide frequency range, from millimeter waves through the terahertz region up to infrared. Fabrication of such a detector is often an expensive and demanding process. We propose a simple device based on a commercially available thermistor as a sensing element. To direct radiation to the sensor, we designed and fabricated a 3D-printed optical element integrated with the dielectric waveguide. An electronic setup was prepared to measure the sensor response. The described device is an affordable detector with acceptable detection parameters such as SNR or responsivity at a hundreds of volts per watt level. Full article

Low-density foreign objects (LDFOs) in foods pose significant safety risks to consumers. Existing detection methods, such as metal and X-ray detectors, have limitations in identifying low-density and nonmetallic contaminants. To address these challenges, our research group constructed and optimized a continuous-wave sub-terahertz (THz) imaging system for the real-time, on-site detection of LDFOs in infant snacks. The system was optimized by adjusting the attenuation value from 0 to 9 dB and image processing parameters [White (W), Black (B), and Gamma (G)] from 0 to 100. Its detectability was evaluated across eight LDFOs underneath snacks with scanning at 30 cm/s. The optimal settings for puffed snacks and freeze-dried chips were found to be 3 dB attenuation with W, B, and G values of 100, 50, and 80, respectively, while others required 0 dB attenuation with W, B, and G set to 100, 0, and 100, respectively. Additionally, the moisture content of infant snacks was measured using a modified AOAC-based drying method at 105 °C, ensuring the removal of all free moisture. Using these optimized settings, the system successfully detected a housefly and a cockroach underneath puffed snacks and freeze-dried chips. It also detected LDFOs as small as 3 mm in size in a single layer of snacks, including polyurethane, polyvinyl chloride, ethylene–propylene–diene–monomer, and silicone, while in two layers of infant snacks, they were detected up to 7.5 mm. The constructed system can rapidly and effectively detect LDFOs in foods, offering a promising approach to enhance safety in the food industry. Full article

Terahertz (THz) communication is a crucial technique in sixth generation (6G) mobile networks, which allow for ultra-wide bandwidths to enable ultra-high data rate wireless communication. However, the current subcarrier spacing and the size of fast Fourier transform (FFT) of the orthogonal frequency division multiplexing (OFDM) in 5G NR are insufficient regarding the bandwidth requirements of terahertz scenarios. In this paper, a novel waveform is proposed to address the ultra-wideband issue, namely the generalized filter bank orthogonal frequency division multiplexing (GFB-OFDM) waveform. The main advantages are summarized as follows: (1) The K-point IFFT is implemented by two levels of IFFTs in smaller sizes, i.e, performing M-point IFFT in N times and performing N-point IFFT in M times, where $K=N\times M$. (2) The proposed waveform can accommodate flexible subcarrier spacings and different numbers of the subbands to provide various services in a single GFB-OFDM symbol. (3) Different bandwidths can be supported using a fixed filter since the filtering is performed on each subband. In contrast, the cyclic prefix orthogonal frequency division multiplexing (CP-OFDM) in 4G/5G requires various filters. (4) The existing detection for CP-OFDM can be directly employed as the detector of the proposed waveform. Lastly, the comprehensive simulation results demonstrate that GFB-OFDM outperforms CP-OFDM in terms of the out-of-band leakage, complexity and error performance. Full article

Field programmable gate arrays (FPGAs) have not only enhanced traditional sensing methods, such as pixel detection (CCD and CMOS), but also enabled the development of innovative approaches with significant potential for particle detection. This is particularly relevant in terahertz (THz) ray detection, where microbolometer-based focal plane arrays (FPAs) using microelectromechanical (MEMS) resonators are among the most promising solutions. Designing high-performance, high-pixel-density sensors is challenging without FPGAs, which are crucial for deterministic parallel processing, fast ADC/DAC control, and handling large data throughput. This paper presents a MEMS-resonator detector, fully managed via an FPGA, capable of controlling pixel excitation and tracking resonance-frequency shifts due to radiation using parallel digital lock-in amplifiers. The innovative FPGA architecture, based on a lock-in matrix, enhances the open-loop readout technique by a factor of 32. Measurements were performed on a frequency-multiplexed, 256-pixel sensor designed for imaging applications. Full article

This article concerns optical detection issues in the terahertz (THz) range. This is a kind of guide to various types of uncooled thermal detectors in the most often applications. Particular attention is paid to the principle of their operation, technology, and practical features. In addition, some detection methods were also characterized by comparing their performances. The article ends with a performance summary of the selected THz thermal detectors. Full article
