Atmospheric turbulence introduces distortions to the wavefront of propagating optical radiation. It causes image resolution degradation in astronomical telescopes and significantly reduces the power density of radiation on the target in focusing applications. The impact of turbulence fluctuations on the wavefront can be investigated under laboratory conditions using either a fan heater (roughly tuned), a phase plate, or a deformable mirror (finely tuned) as a turbulence-generation device and a wavefront sensor as a wavefront-distortion measurement device. We designed and developed a software simulator and an experimental setup for the reconstruction of atmospheric turbulence-phase fluctuations as well as an adaptive optical system for the compensation of induced aberrations. Both systems use two 60 mm, 92-channel, bimorph deformable mirrors and two tip-tilt correctors. The wavefront is measured using a high-speed Shack–Hartmann wavefront sensor based on an industrial CMOS camera. The system was able to achieve a 500 Hz correction frame rate, and the amplitude of aberrations decreased from 2.6 μm to 0.3 μm during the correction procedure. The use of the tip-tilt corrector allowed a decrease in the focal spot centroid jitter range of 2–3 times from ±26.5 μm and ±24 μm up to ±11.5 μm and ±5.5 μm. Full article

The S-band (i.e., 2–4 GHz) is essential in multiple fields of radio astronomy, ranging from pulsar and solar studies to investigations of the early universe. The Italian 64 m fully steerable Sardinia Radio Telescope (SRT) is a system designed to operate in a wide frequency band ranging from 300 MHz to 116 GHz. Recently, the Astronomical Observatory of Cagliari (OAC) has been developing a new cryogenic seven-beam S-band radio receiver. This paper describes the design, fabrication and electromagnetic characterization of the feed horn for this new receiver. It has been designed to observe the sky in the 3–4.5 GHz frequency range and it will be composed of seven feed horns arranged in a regular hexagonal layout with a central element. The feed horns are optimized for placement in the primary focus and consequently illuminate the 64 m primary mirror of the SRT. The electromagnetic characterization of the single feed horn is crucial to verify the receiver’s performance; for this reason, a single feed horn has been manufactured to compare the measured reflection coefficient and the radiated far-field diagram with the results of the electromagnetic simulations, performed using the CST^® Suite Studio 2024 and Ansys HFSS^® Electromagnetics Suite 2021 R1 (To make the S-parameters and the radiation diagram measurement procedure feasible, the single feed horn has been connected to two adapters: a circular-to-rectangular waveguide adapter and a coax-to-rectangular waveguide adapter. The results of the measurements performed in the anechoic chamber are in very good agreement with the simulated results. Additionally, the feed horn phase center position is evaluated, merging the measurements and simulations results for an optimal installation on the primary focus of the SRT. Full article

Retrolensing is a gravitational lensing effect in which light emitted by a background source is deflected by a black hole and redirected toward the observer after undergoing nearly complete loops around the black hole. In this context, we explore the possibility of seeing objects of the solar system in past eras through telescope observations by using black holes as a gravitational mirror. We consider the motion of the light around Reissner–Nordström space–time and discuss the properties of the trajectories of boomerang photons. It was shown that, depending on the angle of emission and the position of the source, the photons could return to the emission point. Afterward, we explore the possibility of considering the returning photons in retrolensing geometry where the observer is between the source and the lens in which two classes of black holes are explored: The supermassive Sgr A* black hole at the galactic center and a nearby stellar black hole. For the first time in the literature, we propose the study of the returning photons of planets instead of stars in retrolensing geometry. Full article

This paper presents the technical design of the pathfinder Barcelona Raman LIDAR (pBRL) for the northern site of the Cherenkov Telescope Array Observatory (CTAO-N) located at the Roque de los Muchachos Observatory (ORM). The pBRL is developed for continuous atmospheric characterization, essential for correcting high-energy gamma-ray observations captured by Imaging Atmospheric Cherenkov Telescopes (IACTs). The LIDAR consists of a steerable telescope with a 1.8 m parabolic mirror and a pulsed Nd:YAG laser with frequency doubling and tripling. It emits at wavelengths of 355 nm and 532 nm to measure aerosol scattering and extinction through two elastic and Raman channels. Built upon a former Cherenkov Light Ultraviolet Experiment (CLUE) telescope, the pBRL’s design includes a Newtonian mirror configuration, a coaxial laser beam, a near-range system, a liquid light guide and a custom-made polychromator. During a one-year test at the ORM, the stability of the LIDAR and semi-remote-controlled operations were tested. This pathfinder leads the way to designing a final version of a CTAO Raman LIDAR which will provide real-time atmospheric monitoring and, as such, ensure the necessary accuracy of scientific data collected by the CTAO-N telescope array. Full article

The paper deals with the assembling, integration, and test (AIT) phase of the laboratory model of an innovative telescope in the framework of the project DORA (deployable optics for remote sensing applications). The telescope is a Cassegrain type of instrument, with an entrance pupil of ∅300 mm, f/16 aperture, and FOV of 0.16°. It has been designed to be mounted onboard a micro-satellite frame, allowing for switching between a stowed configuration during the launch phase and a deployed one once in orbit. The telescope is matched to an infrared Fourier spectrometer, operating in the spectral range of 5–25 $\mathsf{\mu }$m, for the observation of terrestrial atmospheric phenomena, but it can also be adopted for planetary exploration missions. The telescope breadboard has been assembled in the INAF-IAPS premises and has undergone measurements for the determination of the accuracy and repeatability of the mechanism opening. The mechanical tests have demonstrated that the deployment mechanism adopted complies with the requirements imposed by the infrared Fourier spectrometer, guaranteeing a repositioning of the secondary mirror with respect to the primary mirror within 100 $\mathsf{\mu }$m (in-plane displacement) and 0.01° (tilt) of the nominal position. Full article

High-sensitivity and large-scale surveys are essential in advancing radio astronomy, enabling detailed exploration of the universe. A Phased Array Feed (PAF) installed in the focal plane of a radio telescope significantly enhances mapping efficiency by increasing the instantaneous Field of View (FoV) and improving sky sampling capabilities. This paper presents the design and optimization of a novel C-Band Phased Array Feed antenna for the Sardinia Radio Telescope (SRT). The system features an 8 × 8 array of dual-polarized elements optimized to achieve a uniform beam pattern and an edge taper of approximately 5 dB for single radiating elements within the 3.0–7.7 GHz frequency range. The proposed antenna addresses key efficiency limitations identified in the PHAROS 2 (PHased Arrays for Reflector Observing Systems) system, including the under-illumination of the Sardinia Radio Telescope’s primary mirror caused by narrow sub-array radiation patterns. By expanding the operational bandwidth and refining the radiation characteristics, this new design enables significantly improved performance across the broader frequency range of 3.0–7.7 GHz, enhancing the telescope’s capability for wide-field, high-resolution observations. Full article

Aperture space telescopes are widely used in space debris size information detection and celestial body detection work. For the problem of limited space inside the optical system of large aperture telescopes, a space telescope mounting method based on the intrinsic coefficient sensitivity matrix is proposed by combining the wavefront detection technology. Compared with the traditional sensitivity matrix method, the method in this paper does not need to partition the detector and simplifies the construction of the wavefront reconstruction matrix. Characterisation of the system wave aberration is realised by using the eigenfactors, and the sensitivity matrix model is established according to the amount of misalignment. The experimental tests are carried out on the telescope with a diameter of 1.2 m, and the results show that the root mean square (RMS) values of the wavefront aberration in the centre field of view are less than $\lambda /16$ under the cases of eccentricity misalignment of the sub-mirror and tilting misalignment with the phase-aberration correction, which is of good value for the mounting of space telescope optical systems. Full article

We propose an observation system based on the Lagrange L1 point of the Earth–Moon system to observe solar spectral radiation reflected from the Earth, enabling continuous hyperspectral observation of the Earth’s hemisphere. The system can observe the solar spectral radiation reflected by the Moon, with its data applicable to on-orbit spectral radiation calibration. In this paper, the spectral irradiance at the entrance pupil of the Earth spectral radiation observation system (ESROS) is analyzed, and the optical design of the ESROS is introduced. An off-axis two-mirror telescope system, a coupling system of a microlens array and a fiber bundle, and an optical splitting system based on concave grating are used to achieve the full field of view hyperspectral splitting and miniaturization of the instrument. Finally, the stray radiation suppression of the instrument is introduced. The results show that the spectral resolution of the system is better than 5 nm in the 380–1000 nm band, and the spectral resolution is better than 10 nm in the 1000–1700 nm band. When observing the Earth, the signal-to-noise ratio is greater than 200. The external stray radiation suppression reaches the order of 10⁻⁹. The ESROS will provide crucial data support for researching global energy balance, climate change, and the spectral characteristics of exoplanets, facilitating planetary science and the exploration of extraterrestrial life. Full article

Considering the application of titanium nitride (TiN) films as a release layer in producing Wolter-I X-ray telescope mirror shells by the electroformed nickel replication (ENR) technique, this research pays attention to the influence of nanometer-scale thickness variation in the microstructure and physical properties of TiN films deposited by the pulsed direct current (DC) magnetron sputtering method. This topic has received limited attention in the existing literature. TiN films (9.8 nm to 42.9 nm) were fabricated to comprehensively analyze the evolution in microstructure, depth distribution of elements, surface morphology, and intrinsic stress. With increasing thickness, TiN transitioned from amorphous to (200) and (111)–(200) mixed-oriented crystallization, explaining inflection points in the increasing roughness curve. Elements (C, N, O, Si, and Ti) and chemical bond proportions (Ti-N, Ti-N-O, and Ti-O) varied with film depth, and the fitting of film density can be optimized according to these variations. Crystallite size increased with thickness, which led to a reduction in intrinsic stress. It is evident that as film thickness increases, TiN forms a stable crystal structure, thereby reducing intrinsic stress, but resulting in increased roughness. Considering the impact of changes in thin film thickness on physical properties such as roughness, crystallinity, and intrinsic stress, a TiN film with a thickness of approximately 25 nm is deemed suitable for application as a release layer. Full article

Over the past 30 years, researchers have developed X-ray-focusing telescopes by employing the principle of total reflection in thin metal films. The Wolter-I focusing mirror with variable-curvature surfaces demands high precision. However, there has been limited investigation into the removal mechanisms for variable-curvature X-ray mandrels, which are crucial for achieving the desired surface roughness and form accuracy, especially in reducing mid-spatial frequency (MSF) errors. It is essential to incorporate flexible control in deterministic small-tool polishing to improve the tool’s adaptability to curvature variations and achieve stable, Gaussian-like tool influence functions (TIFs). In this paper, we introduce a curvature-adaptive prediction model for compliance figuring, based on the Preston hypothesis, using a compliant shaping tool with high slurry absorption and retention capabilities. This model predicts the compliance figuring process of variable-curvature symmetrical mandrels for X-ray grazing incidence mirrors by utilizing planar tool influence functions. Initially, a variable-curvature pressure model was developed to account for the parabolic and hyperbolic optical surfaces’ curvature characteristics. By introducing time-varying removal functions for material removal, the model establishes a variable-curvature factor function, which correlates actual downward pressure with parameters such as contact radius and contact angle, thus linking the variable-curvature surface with a planar reference. Subsequently, through analysis of the residence time distribution across different TIF models, hierarchical filtering, and PSD distribution, real-time correction of the TIFs was achieved to enable customized variable-curvature polishing. Furthermore, by applying a time-varying deconvolution algorithm, multiple rounds of flexible polishing iterations were conducted on the mandrels of a rotationally symmetric variable-curvature optical component, and the experimental results demonstrate a significant improvement in form accuracy, surface quality, and the optical performance of the mirror. Full article

Space-based gravitational wave (GW) detection employs the Michelson interferometry principle to construct ultra-long baseline laser interferometers in space for detecting GW signals with a frequency band of 10⁻⁴–1 Hz. The spaceborne telescope, as a core component directly integrated into the laser link, comes in various configurations, with the off-axis four-mirror design being the most prevalent. In this paper, we present a high-performance design based on this configuration, which exhibits a stable structure, ultra-low wavefront aberration, and high-level stray light suppression capabilities, effectively eliminating background noise. Also, a scientifically justified positioning of the entrance and exit pupils has been implemented, thereby paving adequate spatial provision for the integration of subsequent optical systems. The final design realizes a wavefront error of less than λ/500 in the science field of view, and after tolerance allocation and Monte Carlo analysis, a wavefront error of less than λ/30 can be achieved with a probability of 92%. The chief ray spot diagram dimensions are significantly small, indicating excellent control of pupil aberrations. Additionally, the tilt-to-length (TTL) noise and stray light meet the stringent requirements for space-based gravitational wave detection. The refined design presented in this paper proves to be a more fitting candidate for GW detection projects, offering more accurate and rational guidance. Full article

The resolution of a telescope is closely related to its aperture size; however, the aperture of a single primary mirror telescope cannot be indefinitely enlarged due to design and manufacturing constraints. Segmented mirror technology can achieve the same resolution as a single primary mirror of equivalent aperture, provided that the segments are co-phased correctly. This paper proposes a method for high-precision detection of piston errors in segmented mirror telescope systems, based on far-field information and transfer learning. By training a ResNet-18 network model, this method can predict piston errors with high precision within 10 ms of a single-frame far-field diffraction image. Simulation results demonstrate that the method is robust to tip-tilt errors, wavefront aberrations, and noise. This approach is simple, fast, highly accurate in detection, and resistant to noise, providing a new solution for piston error detection in segmented mirror systems. Full article

To satisfy the demands of high image quality and resolutions, telescope alignment is indispensable. In this paper, a wavefront sensorless method based on a modified stochastic parallel gradient descent algorithm (SPGD) called the adaptive moment estimation SPGD (Adam SPGD) algorithm is proposed. Simulations are carried out using a four-mirror telescope, whose aperture is 6 m and fields of view are Φ2°. Three misalignments are shown as examples. Positions of the secondary mirror and third mirror are employed to compensate aberrations. The results show that merit functions and energy distributions of corrected images match with the designed ones. The mean RMS of residual wavefront errors is smaller than λ/14 (λ = 0.5 μm), indicating that the misalignments are well compensated. The results verify the effectiveness of our method. Full article

The X-ray satellite “Einstein Probe” of the Chinese Academy of Sciences (CAS) was successfully launched on 9 January 2024 at 15:03 Beijing Time from the Xichang Satellite Launch Center in China with a “Long March-2C” rocket. The Einstein Probe is equipped with two scientific X-ray telescopes. One is the Wide-field X-ray Telescope (WXT), which uses lobster-eye optics. The other is the Follow-up X-ray Telescope (FXT), a Wolter-I type telescope. These telescopes are designed to study the universe for high-energy X-rays associated with transient high-energy phenomena. The FXT consists of two modules based on 54 thin X-ray Wolter-I grazing incidence Ni-replicated mirrors produced by the Italian Media Lario company, as contributions from the European Space Agency and the Max Planck Institute for Extraterrestrial Physics (MPE), which also provided the focal-plane detectors. Meanwhile, the Institute of High Energy Physics (IHEP), together with the Harbin Institute of Technology and Xi’an Institute of Optics and Precision Mechanics, has also completed the development and production of the structural and thermal model (STM), qualification model (QM) and flight model (FM) of FXT mirrors for the Einstein Probe (EP) satellites for demonstration purposes. This paper introduces the precision manufacturing adopted in China of Wolter-I X-ray mirror mandrels similar to those used for the EP-FXT payload. Moreover, the adopted electroformed nickel replication process, based on a chemical nickel–phosphorus alloy, is reported. The final results show that the surface of the produced mandrels after demolding and the internal surface of the mirrors have been super polished to the roughness level better than 0.3 nm RMS and the surface accuracy is better than 0.2 μm, and the mirror angular resolution for single mirror shells may be as good as 17.3 arcsec HPD (Half Power Diameter), 198 arcsec W90 (90% Energy Width) @1.49 keV (Al-K line). These results demonstrate the reliability and advancement of the process. As the first efficient X-ray-focusing optics manufacturing chain established in China, we successfully developed the first focusing mirror prototype that could be used for future X-ray satellite payloads. Full article

Novel freeform optical design methods can be classified in two categories, depending on whether they focus on the generation of a starting point or the development of new optimization tools. In this paper, we design a freeform three-mirror anastigmat (TMA) and compare different surface representations using either a differential ray tracer as a new optimization tool or a commercial ray tracer (ANSYS-ZEMAX OpticStudio). For differential ray tracing, we used FORMIDABLE (Freeform Optics Raytracer with Manufacturable Imaging Design cApaBiLitiEs), an optical design library with differential ray tracing and Non-Uniform Rational B-Splines (NURBS) optimization capabilities, available under the European Software Community License (ESCL). NURBS allow a freeform surface to be represented without needing any prior knowledge of the surface, such as the polynomial degree in polynomial descriptions. OpticStudio and other commercial optical design software are designed to optimize polynomial surfaces but are not well-suited to optimize NURBS surfaces, requiring a custom optical design library. In order to demonstrate the interest in using NURBS representation, we designed and independently optimized two freeform telescopes over different iteration cycles; with NURBS using FORMIDABLE or with XY polynomials using OpticStudio. We then compared the resulting systems using their root mean square field maps to assess the optimization quality of each surface representation. We also provided a full-system comparison, including mirror freeform departures. This study shows that NURBS can be a relevant alternative to XY polynomials for the freeform optimization of reflective three-mirror telescopes as it achieves more a uniform imaging quality in the field of view. Full article
