This paper, based on the Johnson–Cook damage model, investigates the damage mechanism of high-strength steel tailor welded blanks (TWBs) (Usibor1500P and Ductibor500) during the forming process. Initially, specimens with varying notch sizes were designed and fabricated to perform uniaxial tensile tests to determine their mechanical properties. Then, the deformation process of the notched specimens was simulated using finite element software, revealing the distribution and variation of stress triaxiality at the fracture surface. By combining both experimental and simulation data, the parameters of the Johnson–Cook (J–C) damage model were calibrated, and the effects of temperature, strain rate, and stress triaxiality on material fracture behavior were further analyzed. Based on finite element analysis, the relevant coefficients for stress triaxiality, strain rate, and temperature were systematically calibrated, successfully establishing a J–C fracture criterion for TWB welds, Usibor1500P, and Ductibor500 high-strength steels. Finally, the calibrated damage model was further validated through the Nakajima-type bulge test, and the simulated Forming Limit Diagram (FLD) closely matched the experimental data. The results show that the analysis based on the J–C damage model can effectively predict the fracture behavior of tailor welded blanks (TWB) during the forming process. This study provides reliable numerical predictions for the damage behavior of high-strength steel laser-customized welded sheets and offers a theoretical basis for engineering design and material performance optimization. Full article

In this study, high-strength steels B1500HS and B340LA were used as base materials, and laser welding experiments were conducted within a parameter range of welding power from 1500 W to 3000 W and welding speed from 15 mm/s to 35 mm/s. Microstructural analysis, microhardness testing, and uniaxial tensile tests were performed to systematically investigate the effects of different welding parameters on the weld microstructure and macroscopic mechanical properties, leading to the identification of an optimal welding parameter range that avoids defect-prone regions. The bending formability of tailor-welded blanks (TWBs) was evaluated using hat-shaped bending tests, with finite element simulations employed to analyze the effects of welding parameters on stress distribution and material hardening behavior. Based on the identified high-quality welding parameters, a suitable welding parameter range for reverse bending conditions was determined, effectively improving the bending formability of TWBs and providing theoretical guidance and experimental support for their engineering applications. Full article

Finite element (FE) analysis of the tensile test of TWB-HPF 22MnB5 steel was performed and compared with the experimental results. To improve the accuracy of the simulation, the damage theory of FLD and ductile damage theory were used in 2D and 3D simulations. The tensile strength of 22MnB5 steel was determined under various welding heat inputs for FE simulation. Crack propagation of the welded region indicated that the fracture was observed in the base metal under normal welding conditions. Also, the crack propagated along the HAZ region due to higher heat input of the welding, and lead fractures have been highlighted as a potential complication. Full article

The mechanical properties and cross-sectional geometric dimensions of the fusion zone (FZ), heat affected zone (HAZ), and base metal (BM) of 6xxx series aluminum alloys are inconsistent after filler wire welding, which reduces the formability of aluminum alloy tailor welded blanks (TWBs). This paper proposes a post-weld cold rolling-solution heat treatment (PWCR-SHT) composite process, and the effects of weld excess metal, plastic deformation, and SHT on the formability of aluminum alloy TWBs are studied. The results show that the PWCR-SHT composite process eliminates the weld excess metal and internal pores, reduces the stress concentration at the weld toe, eliminates the local strain hardening behavior, and causes recrystallization in the FZ region. The cupping value of aluminum alloy TWBs using SHT is 105% of BM, in comparison, the cupping value of aluminum alloy TWBs using the PWCR-SHT composite process is 119% of BM, which is the result of the combined effect of geometric dimensions consistency and mechanical properties consistency. Full article

Friction stir welding, as a solid-state welding technique, is especially suitable for effectively joining high-strength aluminum alloys, as well as for multi-material welds. This research investigates the friction stir welding of thin aluminum and steel sheets, an essential process in the production of hybrid tailor-welded blanks employed in deep drawing applications. Despite its proven advantages, the welding process exhibits variable outcomes concerning formability and joint strength when utilizing an H13 welding tool. To better understand these inconsistencies, multiple welds were performed in this study, joining 1 mm thick steel to 2 mm thick aluminum sheets, with a cumulative length of 7.65 m. The accumulation of material on the welding tool was documented through 3D scanning and weighing. The integrity of the resulting weld seam was analyzed through metallographic sections and X-ray imaging. It was found that the adhering material built up continuously around the tool pin over several welds totaling between 1.5 m and 2.5 m before ultimately detaching. This accretion of material notably affected the welding process, resulting in increased intermixing of steel particles within the aluminum matrix. This research provides detailed insights into the dynamics of friction stir welding in multi-material welds, particularly in the context of tool material interaction and its impact on weld quality. Full article

Using a tailor-welded blank (TWB) and hot-press forming (HPF), a 22MnB5 blank was surface-treated under four conditions. The penetration rates of the Fe_xAl_y compounds under the four surface-treatment conditions were investigated, and the hardness values were measured. A finite element (FE) simulation was performed for the characteristics of the heat-affected zone (HAZ), using the hardness value and results of previous researchers. In particular, the mechanical property settings of the mesh were designed to realize the conditions for the Fe_xAl_y compounds in the HAZ. Fine meshing was performed by partitioning the HAZ sections. For the mechanical properties of the HAZ with the Fe_xAl_y compounds, the strength was predicted from the hardness value, and the elongation values investigated by other researchers were used. The forming limit diagram, which was proportional to the elongation, was predicted. Specific elements were defined as the areas with Fe_xAl_y compounds, which played the same role as impurities. Tensile TWB–HPF specimens with different HAZ characteristics under four surface-treatment conditions were fabricated. Experiments and FE simulations were performed and compared. Details are as follows: For loads, a minimum error rate of 3% and a maximum error rate of 6% were obtained. For displacement, a minimum error rate of 9% and a maximum error of 25% were obtained. The feasibility of the simulation was verified by comparing the simulation and experimental results. A match of more than 75% was obtained. Full article

The present paper aims to study the behavior of tailor welded blanks subjected to a single point incremental forming (SPIF) process from an experimental point of view. This process was chosen to deform truncated cone shapes of AA1050 aluminum alloy with different thicknesses. A uniaxial tensile test was performed to determine the mechanical characteristics of the alloy. Initial experimental tests implicated the use of variable wall angle parts which were processed on unwelded sheet blanks for determination of the behavior of the material and the forming forces. Afterwards, the wolfram inert gas (WIG) welding technique was used for joining two sheet blanks with different thicknesses either through one pass on one side, or by one pass on both sides. The conclusion of this paper indicates that one-sided welded blanks cannot be deformed successfully without fracture. In case of two-sided welded blanks, the results showed that the desired depth of 25 mm can be reached successfully. In case of the SPIF process, if welded blanks must be deformed, then the suitable method is to weld the blanks on both sides. Full article

Emerging grades of press-hardening steels such as Ductibor^® 1000-AS are now commercially available for use within tailor-welded blanks (TWBs) to enhance ductility and energy absorption in hot-stamped automotive structural components. This study examines the constitutive (hardening) response and fracture limits of Ductibor^® 1000-AS as functions of the as-quenched microstructure after hot stamping. Three different microstructures consisting of bainite and martensite were obtained by hot stamping with die temperatures of 25 °C, 350 °C, and 450 °C. Mechanical characterization was performed to determine the hardening curves and plane-stress fracture loci for the different quench conditions (cooling rates). Uniaxial-tension and shear tests were conducted to experimentally capture the hardening response to large strain levels. Shear, conical hole-expansion, plane-strain notch tension, and Nakazima tests were carried out to evaluate the stress-state dependence of fracture. A mean-field homogenization (MFH) scheme was applied to model the constitutive and fracture behavior of the mixed-phase microstructures. A dislocation-based hardening model was adopted for the individual phases, which accounts for material chemistry, inter-phase carbon partitioning, and dislocation evolution. The per-phase fracture modelling was executed using a phenomenological damage index based upon the stress state within each phase. The results revealed that the 25 °C hot-stamped material condition with a fully martensite microstructure exhibited the highest level of strength and the lowest degree of ductility. As bainite was formed in the final microstructure by quenching at higher die temperatures, the strength decreased, while the ductility increased. The predicted constitutive and fracture responses in the hot-stamped microstructures were in line with the measured data. Accordingly, the established numerical strategy was extended to predict the mechanical behavior of Ductibor^® 1000-AS for a broad range of intermediate as-quenched microstructures. Full article

The automotive industry is constantly looking for innovative techniques to produce lighter, more efficient, and less polluting vehicles to comply with the increasingly restrictive environmental regulations. One of the latest technologies, which is still developing, is based on the fabrication of the body-in-white and car parts through the stamping of aluminum tailor welded blanks. Tailor welded blanks (TWBs) are generally a combination of two/three metal sheets with different thicknesses and/or mechanical strengths, which are commonly laser butt-welded. Even though the aluminum TWBs have the main advantage of producing lightweight parts, their use is still limited by the lower formability than their parent materials and by the fact that laser welding of aluminum sheets still remains a process easily subjected to weld defects (i.e., internal porosity) and, hence, requires strict control of process parameters. This study has investigated the effects of the main laser welding process parameters (laser power, welding speed, and focus position) on the mechanical properties and formability of aluminum TWBs made of the 6xxx series. The research results show that the welding conditions highly influence the weldability of such alloys. Heat input over 70 J/mm is responsible for excessive porosity and molten pool (and consequent root concavity), which are responsible for the lowest mechanical strength and formability of joints. Differently, low amounts of imperfections have a limited influence on the mechanical behaviors of the TWB joints. Overall, a narrow weldability window is required to ensure welded joints with proper strength and limited or no porosity. Full article

The formability of aluminum alloy 5754-O tailor-welded blanks prepared by friction stir welding was studied experimentally. The strain evolution and deformation during limiting dome height experiments were studied using digital image correlation and the ARAMIS software. The influence of the sheet thickness of the base materials on the punch loading, fracture strain and formability were investigated experimentally. It was found that the punch loading, fracture strain and limiting dome height values increase with the increasing sheet thickness of the base materials. A linear relationship between the limiting dome height value and the sheet thickness was demonstrated. An increase of 16.8% in the fracture strain of aluminum tailor-welded blanks was observed for an increase of 36% in sheet thickness. This paper provides a methodology for experimentally determining the forming limits of aluminum alloy tailor-welded blanks accurately. Full article

In this paper, the potential of directional ultrasonic wave superposition by moving sound generators for laser beam welding of high-strength steel alloys 1.5528 (22MnB5) is studied. Steel sheets of identical thickness and in form of tailored blanks were joined in butt joint configuration. The influences of the various excitation parameters of the moving sound generators on the ultrasonic coupling and their influence on the distribution of the AlSi coating components within the melting zone and the weld seam characteristics are investigated. Etched cross-sections, scanning electron microscopy, energy dispersive X-ray spectroscopy, and electron backscattering measurements were used as the investigation methods to determine the AlSi distribution in the weld as well as its microstructure. The results presented a series of experiments which show that a suitable superposition of ultrasonic waves by the moving sound generators lead to a more homogeneous distribution of AlSi particles in the melt as well as to a finer microstructure within the weld, which improves the mechanical–technological properties. Full article

Even though they initially appeared as a method of using waste from other production processes, tailored welded blanks (TWB) presented several advantages by combining materials with different characteristics. On the one hand, this study focuses on minimizing the adverse effects caused by the springback of TWB parts. The proposed method is based on the Taguchi technique using orthogonal type 2³ networks. On the other hand, genetic algorithms were applied to obtain maximum performance parameters within the dynamic loadings of tubular structures made of TWB by advantageous positioning of the weld line. The obtained data were compared and evaluated through software platforms such as MATLAB, Design Expert, and Dynaform, and experimental validation. By generating an objective function, the construction of thin-walled tubular structures can be controlled for a predetermined deformation and maximum energy absorption. The data obtained has an error rate of less than 3%, thus considering that this method can be used successfully in the qualitative and quantitative estimation of dynamically loaded TWB tubular structures. Full article

To improve the formability in the deep drawing of tailor-welded blanks, an adjustable drawbead was introduced. Drawbead movement was obtained using the multi-objective optimization of the conflicting objective functions of the fracture and centerline deviation simultaneously. Finite element simulations of the deep drawing processes were conducted to generate observations for optimization. The response surface method and artificial neural network were used to determine the relationship between variables and objective functions; the procedure was applied to a circular cup drawing of the tailor-welded dual-phase steel blank. The results showed that the artificial neural network had better prediction capability and accuracy than the response surface method. Additionally, the non-dominated sorting-based genetic algorithm (NSGA-II) could effectively determine the optima. The adjustable drawbead with the optimized movement was confirmed as an efficient and effective solution for improving the formability of the deep drawing of tailor-welded blanks. Full article

A finite element model is proposed to investigate the effect of thickness differential on Limiting Dome Height (LDH) testing of aluminum tailor-welded blanks. The numerical model is validated via comparison of the equivalent plastic strain and displacement distribution between the simulation results and the experimental data. The normalized equivalent plastic strain and normalized LDH values are proposed as a means of quantifying the influence of thickness differential for a variety of different ratios. Increasing thickness differential was found to decrease the normalized equivalent plastic strain and normalized LDH values, this providing an evaluation of blank formability. Full article

The present paper aims to study the behaviour of Metal Active Gas (MAG) tailor welded blanks during the single point incremental forming process (SPIF) from an experimental point of view. The single point incremental forming process was chosen for manufacturing truncated cone and truncated pyramid shaped parts. The same material (S355) and the same thickness (0.9 mm) were selected for the joining of blank sheets because the main goal of the paper was to study the influence of the MAG welding process throughout the SPIF process. A Kuka robot, equipped with a force transducer and an optical measurement system were used for manufacturing and evaluating the parts by SPIF. The selected output data were major and minor strain, thickness reduction, forces and springback at the SPIF process. Another line test was performed to evaluate the formability in SPIF. The main conclusion of the paper is that during the SPIF process, fractures occur in one side welded blanks even at moderate wall angles, while in the case of double side welded blanks there is a decrease of formability but parts can still be produced at moderate angles (55 degrees) without any problems. Full article
