Search Results (16)

The increasing penetration of renewable energy sources (RESs) has significantly altered the operational characteristics of modern power systems, resulting in reduced system inertia and fault current capacity. These developments introduce new challenges for maintaining frequency and voltage stability, particularly in low-inertia grids that are dominated by inverter-based resources (IBRs). This paper presents a hierarchical control framework that integrates synchronous condensers (SCs) and grid-forming (GFM) inverters through a leader–follower consensus control architecture to address these issues. In this approach, selected GFMs act as leaders to restore nominal voltage and frequency, while follower GFMs and SCs collaboratively share active and reactive power. The primary control employs droop-based regulation, and a distributed secondary layer enables proportional power sharing via peer-to-peer communication. A modified IEEE 14-bus test system is implemented in PSCAD to validate the proposed strategy under scenarios including load disturbances, reactive demand variations, and plug-and-play operations. Compared to conventional droop-based control, the proposed framework reduces frequency nadir by up to 0.3 Hz and voltage deviation by 1.1%, achieving optimised sharing indices. Results demonstrate that consensus-based coordination enhances dynamic stability and power-sharing fairness and supports the flexible integration of heterogeneous assets without requiring centralised control. Full article

The integration of large-scale renewable energy and power electronic devices into the grid, as well as the uneven distribution of power units and loads, further increases the risk of transient instability at critical load centers. The installation of synchronous condensers (SCs) in the grid can enhance its transient stability. Therefore, it is necessary to focus on the siting and sizing of SCs, considering both economic and safety factors. To address this issue, this paper proposes a configuration method based on full electromagnetic transient (EMT) simulation. Initially, relevant indicators for measuring transient voltage stability are defined. Subsequently, the most severe fault scenario was identified through EMT simulation, and the reactive power voltage sensitivity index was generated. Finally, an optimization configuration model is established with the objective of minimizing installation costs and the constraint of ensuring transient voltage stability, and the model is solved using an iterative linear optimization algorithm. The proposed method is applied in a case study of the power grid platform in S Province, and simulation results indicate that it effectively improves transient voltage stability within heavily loaded regions, demonstrating its economic and practical effectiveness. Full article

The dedieselization program is one of the PLN’s (Indonesia’s state-owned utility company) programs to reduce the greenhouse gas effect. The program manifestation is the integration of photovoltaic (PV) systems into isolated island networks by substituting diesel generators. This condition introduces challenges such as diminished system strength, specifically, decreased frequency and voltage stability. This study focuses on Panjang Island, one of the target locations for the PLN’s dedieselization program, which currently relies entirely on diesel generators for electricity. As part of the transition to a PV-based power supply, retired diesel generators are proposed for conversion into synchronous condensers (SCs) to enhance system stability by providing inertia and reactive power support. By employing system modeling, steady-state analysis, and dynamic simulations, this study evaluates the effects of SC penetration on Panjang Island. The findings demonstrate that SCs improve grid stability by offering voltage support, increasing short-circuit capacity, and contributing to system inertia. Furthermore, a system assessment flowchart is also proposed to guide SC deployment based on network characteristics. Short-circuit ratios (SCRs) and voltage drops are evaluated as key parameters to determine the feasibility of SC penetration in a system. Converting retired diesel generators into SCs provides a resilient, stable grid as renewable energy penetration increases, optimizing system performance and reducing network losses. Full article

This paper presents a comprehensive RMS-based phasorial model of an E-STATCOM with grid-forming (GFM) control, designed to improve power system stability in isolated grids. Unlike previous approaches, this model integrates a governor with an internal power system stabilizer (PSS) and an active current limiter (ACL) to enhance frequency regulation and mitigate oscillations. Additionally, an exciter with a nonlinear modulation function is introduced to optimize voltage regulation and reactive power support. A detailed conventional supercapacitor (SC) model is also incorporated, enabling dynamic DC-voltage control based on active power variations, improving frequency stability. The proposed E-STATCOM RMS model includes algebraic equations, dynamic governor and exciter models, supercapacitor-based energy storage control, and an advanced current-limiting strategy. Simulations are conducted on the Fuerteventura–Lanzarote (Canary Islands, Spain) power system, comparing the E-STATCOM with a synchronous condenser (SynCon) in frequency response, voltage regulation, and fault performance. The results show that the E-STATCOM improves frequency stabilization and energy efficiency while complying with grid codes. This study introduces a novel RMS-based modeling approach for GFM E-STATCOMs, bridging the gap between theoretical phasorial analysis and real-world applications. The findings confirm that E-STATCOMs are a viable alternative to SynCons, enhancing grid stability in high-renewable-penetration systems. Full article

The issues of low inertia, overvoltage, and wide-frequency oscillations in high-proportion renewable energy systems have become prominent, posing major challenges to renewable energy integration and threatening grid stability. Currently, many wind-rich areas ensure grid safety and stability by reducing wind farm output. To enhance the active power delivery capability of wind farms, this paper proposes a hybrid solution of a small synchronous condenser (SC) and static var generator (SVG) within wind farm stations to optimize reactive power and voltage at the point of grid connection. First, it was analyzed that the low short-circuit ratio (SCR) is a key factor affecting the stable operation of wind farms, and the sub-transient reactance of the SC can increase the SCR. Based on this, a method for configuring the capacity of the SC was developed. Next, simulation models for both the SC and the SVG were established, and their reactive power compensation capabilities were verified. The hybrid control approach combined the advantages of both devices, providing comprehensive voltage support across sub-transient, transient, and steady-state conditions for renewable energy stations. Furthermore, based on a practical 50.5 MW wind farm, which has been operating with a power delivery consistently limited to 60% of its capacity, a simulation model and scenarios were set up. A comparison of the simulation results shows that, with only the SVG in operation, the wind farm is prone to oscillations after a grid fault. However, after adopting the hybrid control of the SC and SVG, the wind farm operates stably. Therefore, installing a small SC within wind farms can effectively address the limitations of voltage stability and a low short-circuit ratio, thereby supporting higher levels of renewable energy integration. Full article

The increasing deployment of large-scale wind turbines in place of conventional generators is expected to lead to the dominance of asynchronous power sources in future power systems, further accelerating the trend toward grid electrification. As a result, the ability of power sources to support system voltage and frequency is gradually diminishing. Synchronous condensers (SCs), which are synchronous machines operating without prime movers, serve as effective devices for providing both dynamic voltage support and inertia. They can significantly enhance the system’s capacity to maintain voltage and frequency stability. However, most existing studies on the optimization of synchronous condenser configurations tend to focus on only one aspect at a time rather than addressing both simultaneously, limiting the full potential of these devices. Optimizing either the voltage or frequency in isolation often results in suboptimal improvements in the other. Moreover, the simultaneous optimization of both voltage and frequency can lead to non-convergent outcomes, complicating the search for an optimal solution. To address this, the paper proposes a hierarchical optimization strategy for synchronous condenser configuration aimed at enhancing both voltage and frequency stability. First, the connection sites for the synchronous condensers are determined based on short-circuit ratio (SCR) constraints. Next, an outer layer optimization model is developed to minimize the total installed capacity of the condensers while taking into account the SCR and transient overvoltage levels as constraints. Following this, an inner layer optimization model is introduced, incorporating a rate of change in the frequency $f_{RoCoF}$ and maximum frequency deviation $f_{nadir}$ as constraints. The model is solved using the bacterial foraging optimization algorithm (BFOA). Finally, a case study of a power grid with a high proportion of wind power validates the effectiveness of the proposed synchronous condenser configuration strategy. Compared to traditional methods, the total required capacity of synchronous condensers was significantly reduced. Full article

In a multi-fed DC environment, the UHV DC recipient grid faces significant challenges related to DC phase shift failure and voltage instability due to the high AC/DC coupling strength and low system inertia level. While the new large-capacity synchronous condensers (SCs) can provide effective transient reactive power support, the associated investment and operation costs are high. Therefore, it is valuable to investigate the optimization of SC configuration at key nodes in the recipient grid in a scientific and rational manner. This study begins by qualitatively and quantitatively analyzing the dynamic characteristics of DC reactive power and induction motors under AC faults. The sub-transient and transient reactive power output model is established to describe the SC output characteristics, elucidating the coupling relationship between the SC’s reactive power output and the DC reactive power demand at different time scales. Subsequently, a critical stabilized voltage index for dynamic loads is defined, and the SC’s reactive power compensation target is quantitatively calculated across different time scales, revealing the impact of transient changes in DC reactive power on the transient voltage stability of the multi-fed DC environment with dynamic load integration. Finally, an optimal configuration model for the large-capacity SC is proposed under the critical stability constraint of dynamic loads to maximize the SC’s reactive power support capability at the lowest economic cost. The proposed model is validated in a multi-fed DC area, demonstrating that the optimal configuration scheme effectively addresses issues related to DC phase shift failures and voltage instability resulting from AC bus voltage drops. Full article

The transmission end of large-scale wind power generation bases faces challenges such as high AC-DC coupling strength, low system inertia, and weak voltage support capabilities. Deploying distributed synchronous condensers (SCs) within and around wind farms can effectively provide transient reactive power support, enhance grid system inertia at the transmission end, and improve dynamic frequency support capabilities. However, the high investment and maintenance costs of SCs hinder their large-scale deployment, necessitating the investigation of optimal SC configuration strategies at critical nodes in the transmission grid. Initially, a node inertia model was developed to identify weaknesses in dynamic frequency support, and a critical inertia constraint based on node frequency stability was proposed. Subsequently, a multi-timescale reactive power response model was formulated to quantify the impact on short-circuit ratio improvement and transient overvoltage suppression. Finally, a two-stage optimal configuration strategy for distributed SCs at the transmission end was proposed, considering dynamic frequency support and transient voltage stability. In the first stage, the optimal SC configuration aimed to maximize system inertia improvement per unit investment to meet dynamic frequency support requirements. In the second stage, the configuration results from the first stage were adjusted by incorporating constraints for enhancing the multiple renewable short-circuit ratio (MRSCR) and suppressing transient overvoltage. The proposed model was validated using the feeder grid of a large energy base in western China. The results demonstrate that the optimal configuration scheme effectively suppressed transient overvoltage at the generator end and significantly enhanced the system’s dynamic frequency support strength. Full article

With the rapid development of high-voltage direct current (HVDC) transmission systems, the coupling between AC and DC grids is becoming increasingly close. Voltage disturbances in the grid can easily cause commutation failures in the DC system, threatening its safe and stable operation. The new generation of synchronous condensers (SCs) and modified synchronous condenser units are powerful reactive power support devices widely used in large-capacity DC transmission systems. To maximize the voltage support and commutation failure suppression of SCs, this paper proposes improvements in the initial operating state of SCs, using the Shanxi–Wuhan HVDC receiving end in the Hubei power grid as an example, to better support the HVDC commutation process. Additionally, a reactive power output optimization strategy for SCs is proposed, considering the reactive power equivalent factor of electrical connections between grid nodes. This strategy determines the optimal reactive power output limit of SCs near the converter station to suppress DC commutation failures. Simulation results show that this strategy effectively utilizes the dynamic support capabilities of SCs, prevents DC commutation failures, improves HVDC transmission capacity, and enhances the safety and stability of the receiving end power grid, providing theoretical guidance for reactive power output control. Full article

System strength is both supplied and demanded in a power system during normal operations and in the presence of disturbances. This is characterised by stable voltage and frequency, supporting renewable generation such as wind and solar. Because the retirement of synchronous generators reduces system strength supply, and the connection of new inverter-based resource (IBR) generators increases demand, there is an urgent need for new sources of system strength. This paper provides an overview of the challenges brought about by grid modernisation. It highlights tangible solutions provided by synchronous condensers (SCs) to bolster grid strength, stability, and reliability while accommodating the rising influx of renewable energy sources (RESs). Furthermore, this paper examines the role of SCs in improving weak grids, voltage control, power quality, short-circuit levels, and inertia management. It introduces the role of innovative hybrid synchronous condenser (HSC) systems to boost grid reliability and resilience. It also elaborates on the optimisation strategies for SC sizing, placement, and control and outlines economic aspects of their deployment. The review also highlights future directions and challenges in SC technology, emphasising the need for ongoing research and development to enhance system design and operation. Full article

In isolated power systems with very high instantaneous shares of renewables, additional inertia should be used as a complementary resource to battery energy storage systems (BESSs) for improving frequency stability, which can be provided by synchronous condensers (SCs) integrated into the system. Therefore, this paper presents a methodology to infer the system dynamic security, with respect to key frequency indicators, following critical disturbances. Of particular interest is the evidence that multiple short-circuit locations should be considered as reference disturbances regarding the frequency stability in isolated power grids with high shares of renewables. Thus, an artificial neural network (ANN) structure was developed, aiming to predict the network frequency nadir and Rate of Change of Frequency (RoCoF), considering a certain operating scenario and disturbances. For the operating conditions where the system frequency indicators are violated, a methodology is proposed based on a gradient descent technique, which quantifies the minimum amount of additional synchronous inertia (SCs which need to be dispatch) that moves the system towards its dynamic security region, exploiting the trained ANN, and computing the sensitivity of its outputs with respect to the input defining the SC inertia. Full article

A high share of distributed energy resources (DERs) in power distribution grids has posed many challenges for system operation and control. Microgrid (MG) application with different distributed control approaches for DERs has been drawn a lot of attention from the research community to provide more flexibility, reliability and resilience for the system. This paper develops a distributed secondary control for DERs in MGs and on top of that using synchronous condenser (SC) participating in the secondary control for voltage support. The proposed distributed secondary control framework of MGs is designed to obtain four objectives as follows: (i) frequency restoration, (ii) average voltage restoration, (iii) arbitrary active power sharing among SGs and BESSs and (iv) arbitrary reactive power sharing among all SGs, BESSs and SCs. The comparison results under different scenarios show that with SC participating in the distributed secondary control in MGs, the system frequency and voltage response are much improved and quickly recovered to the nominal values thanks to the natural inertia response and fast reactive power control of SC sharing with other DERs in the MGs. Additionally, a multi-agent system is implemented to realize the proposed control method in hardware environment. Full article

Considering the advantages that dynamic reactive power (var) equipment (such as synchronous condensers (SCs), which can control var independently and improve voltage stability), SCs are widely used in AC/DC hybrid power grid to provide emergency var and voltage support. In order to evaluate the dynamic var reserve capacity of SCs and analyze the influence of SCs on the operation characteristics of power system, a model with double-infeed line-commutated converter-based high-voltage direct currents (LCC-HVDCs) and SCs is established. Through theoretical derivation and PSCAD/EMTDC simulation, the effects of SCs on the operation characteristics of double-infeed LCC-HVDCs networks are studied. Then, the non-smooth voltage waveform of electromagnetic transient simulation is approximately transformed into smooth waveform by data fitting method. Finally, the processed voltage waveform is searched step by step to explore the boundary of voltage safety region to determine the dynamic var reserve capacity of SCs. The numerical results show that SCs can enlarge the voltage security region of the direct current (DC) subsystem, thus effectively improving the steady-state and transient security level of the double-infeed LCC-HVDCs networks. Full article

The synchronous condenser (SC) has a broad application prospect in ultra-high-voltage direct current (UHVDC) systems. The SC’s loss of excitation (LOE) is an important grid-related fault that may cause damage to the UHVDC. However, as the premise of the scientific protection configuration, knowledge of the SC’s LOE feature and its impact on UHVDC is still missing. This article first analyzes the SC’s LOE feature, offering a basic cognition of this fault. Secondly, the LOE SC’s reactive power response to system voltage variation is studied in the single-machine infinite-bus system. This lends a foundation for transient UHVDC research. Finally, the LOE SC’s impacts on steady and transient UHVDC are evaluated, respectively, considering different AC strengths and system faults through PSCAD/EMTDC (V4.6, Manitoba HVDC Research Center, Winnipeg, MB, Canada) simulations. The results show that: (1) LOE the SC absorbs reactive power while maintaining synchronous operation, its excitation current declines monotonically; (2) the LOE SC has an insignificant effect on steady-state UHVDC; (3) the LOE SC can restrain the overvoltage and benefit the rectifier’s transient stability; and (4) to reduce the inverter’s commutation failure, keeping LOE SC is more effective than separating it beforehand, while separating the LOE SC after the system voltage drop performs best. These conclusions could provide insights for the protection’s criterion and operation mode selections. Full article

Since thyristor cannot turn off automatically, line commutated converter based high voltage direct current (LCC-HVDC) will inevitably fail to commutate and therefore auxiliary controls or voltage control devices are needed to improve the commutation failure immunity of the LCC-HVDC system. The voltage control device, a synchronous condenser (SC), can effectively suppress the commutation failure of the LCC-HVDC system. However, there is a need for a proper evaluation index that can quantitatively assess the ability of the LCC-HVDC system to resist the occurrence of commutation failures. At present, the main quantitative evaluation indicators include the commutation failure immunity index and the commutation failure probability index. Although they can reflect the resistance of the LCC-HVDC system to commutation failures to a certain extent, they are all based on specific working conditions and cannot comprehensively evaluate the impact of SCs on suppressing the commutation failure of the LCC-HVDC system under certain fault ranges. In order to more comprehensively and quantitatively evaluate the influence of SCs on the commutation failure susceptibility of the LCC-HVDC system under certain fault ranges, this paper proposes the area ratio of commutation failure probability. The accuracy of this new index was verified through the PSCAD/EMTDC. Based on the CIGRE benchmark model, the effects of different synchronous condensers on LCC-HVDC commutation failure were analyzed. The results showed that the new index could effectively and more precisely evaluate the effect of SCs on commutation failures. Moreover, the proposed index could provide a theoretical basis for the capacity allocation of SCs in practical projects and it could also be utilized for evaluating the impact of other dynamic reactive power compensators on the commutation failure probability of the LCC-HVDC system under certain fault ranges. Full article
