A numerical study was conducted on winglet designs with multiple sweep angles for improving the performance of horizontal axis wind turbine (HAWT) blades, and their effect on reducing the wing tip vortex was investigated by CFD analysis. The effects of sweep angles were examined through NREL Phase VI turbine blades considering a wind speed range of 7 to 25 m/s. Numerical simulations were performed using RANS equations and the SST k–ω turbulence model. The interaction of the blade rotation and wind flow was modeled using a moving reference frame method. The numerical results were found to be in good agreement with the inferences drawn from the experiments for a baseline blade without a winglet, thereby validating the computational method. The investigations revealed that multi-swept winglets predicted a 14.6% torque increment, providing higher power output than single-swept winglets compared to the baseline blade at a wind speed of 15 m/s. Implementing multiple sweep angles in winglet design can improve the blade performance effectively without further increments in winglet length. Full article

The current limited efficiency and reliability of tidal current turbines (TCTs) have posed significant challenges in effectively harnessing tidal stream energy. To address this issue, this paper undertakes both numerical and experimental studies to explore the advantages of swept blades over conventional straight blades in terms of energy capture efficiency and cavitation resistance. It is found that both the sweep length and sweep angle of the blade can influence the power generation efficiency of the TCT. For the particular swept blade investigated in this study, the highest power coefficient is achieved when the sweep length is 0.544 m and the sweep angle is 28.88°. The research also demonstrated that the swept-blade TCT shows a higher power generation efficiency than the straight-blade TCT across a broad range of rotor speeds. To be precise, with the swept blades, the power coefficient of the TCT can be improved by 5–17%, depending on the tip speed ratio. Additionally, swept blades exhibit a superior cavitation resistance. This is evidenced by their higher cavitation numbers across all tip speed ratios in comparison to conventional straight blades. Full article

It is well known that wind power generation addresses the energy needs of small and remote populations as one of the alternatives to petroleum-based energy’s greenhouse effect. Although there are several publications on rotor design and performance analysis, more should be written about the starting of wind turbines, mainly the small ones, where starting can be a big issue. The present paper evaluates the impact of the swept blade angle on the aerodynamic torque, thrust force, and minimal wind speed required to start the operation of a compact horizontal-axis wind turbine. It presents a novel investigation of the influence of swept rotor blades on the starting performance of a turbine drivetrain. The methodology uses the blade element moment theory coupled to Newton’s second law, in which Palmgren’s extended approach is employed. When the proposed methodology is compared to the experimental data available in the literature, it exhibits good agreement. However, when the wind turbine starts to run, the results show that swept blades do not always enhance the torque coefficient or reduce the thrust force as indicated in some scientific papers. For backward-swept blades, the maximum value decreases 4.0%. Similar behavior is found in thrust force for forward-swept blades. Therefore, more study is required to evaluate many blade foils in several operational environments to confirm this statement. Full article

Current performance analysis processes for drag-dominant tidal turbines are unsuitable as disk actuator theory lacks support for varying swept blockage area, bypass flow downstream interaction, and parasitic rotor drag, whereas blade element momentum theory is computably effective for three-blade lift-dominated aerofoil. This study proposes a novel technique to calculate the optimal turbine tip speed ratio (TSR) with a cost-effective and user-friendly moment balancing algorithm. A reliable dynamic TSR matrix was developed with varying rotational speeds and fluid velocities, unlike previous works simulated at a fixed fluid velocity. Thrust and idle moments are introduced as functions of inlet fluid velocity and rotational speed, respectively. The quadratic relationships are verified through regression analysis, and net moment equations are established. Rotational speed was a reliable predictor for Pinwheel’s idle moment, while inlet velocity was a reliable predictor for thrust moment for both models. The optimal (C_p, TSR) values for Pinwheel and Savonius turbines were (0.223, 2.37) and (0.63, 0.29), respectively, within an acceptable error range for experimental validation. This study aims to improve prevailing industry practices by enhancing an engineer’s understanding of optimal blade design by adjusting the rotor speed to suit the inlet flow case compared to ‘trial and error’ with cost-intensive simulations. Full article

In order to investigate the output power and wake velocity of small multi-rotor wind turbines compared to single-rotor wind turbines, which operate in the same swept area at various blade tip distances, this paper used the wind tunnel test method to examine single-rotor wind turbines with diameter D of 0.4 m and 0.34 m corresponding to the triple-rotor wind turbines and double-rotor wind turbines with a single rotor diameter D of 0.24 m, respectively. The experimental results indicated that, without rotation speed control, the triple-rotor wind turbine produced more power than the single-rotor wind turbine with an equivalent swept area and that the output power tended to rise initially and then fall as the distance between each rotor increased. Moreover, the power increase reached a maximum of 8.4% at the 0.4D blade tip distance. In terms of wake measurement, triple-rotor wind turbines had smaller wake losses and faster recovery rates than single-rotor wind turbines. The smaller the blade tip distance, the earlier the wake merged and fused and the faster the recovery rate. In designing small multi-rotor wind turbines, the above discussion can serve as a guide. Full article

To explore the internal flow mechanism and improve the performance of a supersonic compressor, an efficient global optimization design method was developed for an axial flow compressor and applied in the optimization design of a prototype supersonic compressor. Based on the multiple circular arc (MCA) blade parameters, the method can be used to parameterize the elementary stage of the blade. The optimized solution is obtained by changing the elementary stage and stacking lines of the blade during the optimization process. It has the advantages of fewer optimization variables, strong physical intuition, and a smooth surface. The optimization results show that a change in the rotor blade shape parameters has a significant effect on the compressor efficiency under design conditions, while a change in the skewed-swept parameters of the stator is the main factor that improves the compressor’s performance under near-stall conditions. Further numerical results show that the optimized rotor changes the form of the shock, weakens the degree of shock boundary layer interference, inhibits the radial migration flow of the supersonic rotor, reduces the loss of the rotor blade top, and improves the performance of the compressor under design conditions. The stator’s optimization restrains the generation of a concentrated shedding vortex at the root of the blades and greatly improves the stall margin of the compressor. Finally, the total pressure ratio and flow rate are less than 1% of the values based on the prototype operating conditions, the design mass flow of the optimized high-load supersonic compressor is increased by 0.25%, the isentropic efficiency is increased by 1.05%, and the stall margin is enhanced by 3.5%, thus verifying the effectiveness of the optimization method. Full article

This study targets determining impellers of impeller-only axial fans with an optimal hub-to-tip ratio for the highest achievable total-to-static efficiency. Differently from other studies, a holistic approach is chosen. Firstly, the complete class of these fans is considered. Secondly, the radial distribution of blade sweep angle, stagger angle, chord length, and camber are varied to adapt the blades to the complex flow in the hub and tip regions. The tool being used is an optimization scheme with three key components: (i) a database created beforehand by Reynolds-averaged Navier–Stokes (RANS)-predicted performance characteristics of 14,000 designs, (ii) an artificial neural network as a metamodel for the fan performance as a function of 26 geometrical parameters, and (iii) an evolutionary algorithm for optimization, performed on the metamodel. Typically, the hub-to-tip ratios for the impellers proposed by the optimization scheme are smaller than those obtained by applying the classic design rules. A second outcome are the shapes of the blades, which are adapted for a minimum exit loss. These shapes deviate substantially from the classic and even the state-of-the-art “swept-only” or “swept with dihedral” designs. The chord length, stagger, and sweep angle are distributed from hub to tip in a complex manner. The inherent reason is that the scheme tries to minimize not only the dynamic exit loss but also frictional losses due to secondary flows in the hub and tip regions, which eventually results in the maximum achievable total-to-static efficiency. Upon request, the authors will provide the full geometry of the four impellers analysed in some detail in this study to any individual for experimental validation or further analysis of their performance. Full article

The effect of blade sweep has been studied numerically with the Lattice Boltzmann Method on a family of low-speed free-vortex axial fans with sweeps of ±45°. Good overall aerodynamic agreement is first demonstrated on all fans at the design condition, particularly in the tip gap. The local larger wall-pressure fluctuations seen in the unswept and backward swept fans compared to the forward case are traced to the stronger tip vortices that remain in the rotational plane or even move upstream. These stronger and faster vortices interacting with the fan blades are then responsible for the larger noise levels observed in the acoustic spectra of these fans, and particularly for large subharmonic humps. Excellent agreement between experimental and numerical noise predictions is finally reported stressing the dominant tip noise. Full article

In order to widen the range of high-efficiency area of a high-specific-speed axial flow pump and to improve the operating efficiency under non-design conditions, the parameters of the axial flow pump blades were optimized. An optimization system based on computational fluid dynamics (CFD), optimized Latin hypercube sampling (OLHS), machine learning (ML), and multi-island genetic algorithm (MIGA) was established. The prediction effects of three machine learning models based on Bayesian optimization, support vector machine regression (SVR), Gaussian process regression (GPR), and fully connected neural network (FNN) on the performance of the axial flow pump were compared. The results show that the GPR model has the highest prediction accuracy for the impeller head and weighted efficiency. Compared to the original impeller, the optimized impeller is forward skewed and backward swept, and the weighted efficiency of the impeller increases by 1.31 percentage points. The efficiency of the pump section at 0.8Q_d, 1.0Q_d, and 1.2Q_d increases by about 1.1, 1.4, and 1.6 percentage points, respectively, which meets the optimization requirements. After optimization, the internal flow field of the impeller is more stable; the entropy production in the impeller reduces; the spanwise distribution of the total pressure coefficient and the axial velocity coefficient at the impeller outlet are more uniform; and the flow separation near the hub at the blade trailing edge is restrained. This research can provide a reference for the efficient operation of pumping stations and the optimal design of axial flow pumps under multiple working conditions. Full article

The hydrokinetic turbine is used worldwide for electrical generation purposes, as such a technology may strongly reduce environmental impact. Turbines designed using backward swept blades can significantly reduce the axial load, being relevant for hydro turbines. However, few works have been conducted in the literature in this regard. For the case of hydrokinetic rotors, backward swept blades are still a challenge, as the authors are unaware of any optimization procedures available, making this paper relevant for the current state of the art. Thus, the present work develops a new optimization procedure applied to hydrokinetic turbine swept blades, with the main objective being the design of blades with reduced axial load on the rotor and possibly a reduction in the cavitation. The proposed method consists of an extension of the blade element momentum theory (BEMT) to the case of backward swept blades through a radial transformation function. The method has low computational cost and easy implementation. Once it is based on the BEMT, it presents good agreement when compared to experimental data. As a result, the sweep heavily affects the chord and twist angle distributions along the blade, increasing the turbine torque and power coefficient. In the case of the torque, it can be increased by about 18%. Additionally, even though the bound circulation demonstrates a strong change for swept rotors, Prandtl’s tip loss seems to be not sensitive to the sweep effect, and alternative models are needed. Full article

For the design of a horizontal-axis tidal current turbine with adaptive variable-pitch blades, both numerical simulations and physical model experiments were used to study the hydrodynamic performance of symmetrical airfoil blades based on backward swept models. According to the lift–drag ratio of symmetrical airfoils, variable airfoil sections were selected for each part of the blade in the spanwise direction. Then, three kinds of blades were designed by using different swept-back models from wind turbines. A rotation model with a multi-reference frame was employed to conduct a three-dimensional steady numerical simulation of the turbine model based on the CFD method. The axial thrust and energy-capturing efficiency under different tip speed ratios, as well as the corresponding starting torque under different flow rates, were analyzed. The simulation results indicate that model 2 has optimal start-up performance, and model 3 has the largest power coefficient. The thrust coefficient of model 1 is the smallest. In all, model 2 has better comprehensive performance. The experiments of model 2 show that it has suitable hydrodynamic performance to capture bidirectional energy via passively variable pitch. This research provides an important solution for the design and optimization of horizontal-axis turbines to harvest bidirectional tidal current energy. Full article

To study the output power and wake flow characteristics of a wind turbine with swept blades, taking the blade tip offset and the location of the sweep start as two variables, the straight blade of the DTU-LN221 baseline airfoil was optimally designed with sweep. Then the designed wind turbine was numerically simulated, and the swept blade with the best optimal output power characteristics was selected for the wind tunnel test. The results indicate that for both forward and backward swept blades, increasing the blade tip offset and the sweep start location could decrease the power and thrust coefficients. Compared with the backward swept design, the forward swept design significantly improved the blades’ power characteristics. By adopting swept blades instead of straight blades, wind turbines could generate more power at high tip speed ratios, especially in yaw conditions. The streamwise velocity recovery of the wind turbine with swept blades was slower than that with straight blades as the lateral velocity near the wake region was higher than that with straight blades. Besides, the wind turbine with swept blades had a greater turbulence intensity of the wake near the wake center than that with straight blades with or without yaw condition. Full article

Most small–medium-sized turbine studies have focused on presenting new design methods and corresponding performance improvements rather than detailed dynamic investigations. This paper presents comprehensive dynamic investigations of a straight and a swept-back blade for a 100 $\mathrm{k}$$\mathrm{W}$ turbine by performing modal analysis, dynamic load analysis, and flutter analysis. The considered load cases include steady wind and operational conditions under normal and extreme turbulence. Modal results show that although both blades have similar natural frequencies, their mode shapes are quite different due to the couplings in flapwise-torsion directions introduced by the back-swept geometry. This coupling alters the aeroelastic response of the blade, which results in different loads in the operational conditions. The load analysis results show that the blade damage equivalent fatigue loads for the swept blade are much lower (up to 29% for the flapwise bending moment and 31% for the edgewise bending moment) than the straight blade. For the ultimate loads, blade root edgewise load for the swept blade is almost 50% lower than the straight blade while the flapwise ultimate load is similar for both blades. Moreover, both blades have no aeroelastic instability near the operational conditions, and the flutter limit for the swept-back blade is lower than the straight blade. Full article

Post-Optimum Sensitivity Analysis (POSA) extends numerical design optimization to provide additional information on how the design and performance would change if various parameters and constraints were varied. POSA is challenging since it typically requires accurate gradients and gradient-based optimization problems that provide Lagrange multipliers. To overcome this problem, this paper introduces a technique to automatically tune gradients with statistical methods and algorithms to calculate the Lagrange multipliers after an optimization. This allows these methods to be applied to problems with noisy gradients or problems solved with gradient-free optimization algorithms. These methods have been applied to swept wind turbine blades. Swept blades can reduce wind turbine loads by twisting out of the wind when the wind speed increases. The methods have shown that introducing design freedom in the sweep, blade root flap-wise bending moments and blade tip deflection has a weaker influence on the design. Instead, blade root torsion moment and material failure become the driving constraints. Full article

Accurate prediction of the aerodynamic characteristics of wind rotors subjected to various wind profiles is of considerable importance in the aerodynamics and structural design of wind turbines. As a very complex atmospheric phenomenon, the impact of a low-level jet (LLJ) on the aerodynamic characteristics of wind rotors is becoming more and more significant with the increase in wind turbine height. Additionally, during calculating the aerodynamic characteristics of the wind rotor, the known wind speed, rotor speed, and blade-pitch angle are generally required. However, when the wind profile is in the LLJ condition, it is difficult to determine the blade-pitch angle and rotor speed. Therefore, in this paper, the blade-element-momentum (BEM) method is exploited by considering the coupling with the generator-torque controller and blade-pitch controller. In order to solve the problem of the unknown rotor speed and blade-pitch angle under the LLJ condition, a C++ code is developed. Then, the influence of the LLJ on the aerodynamic characteristics of the wind rotor is exclusively examined. The research results show that the calculation method can precisely evaluate the rotor speed, blade-pitch angle, and aerodynamic characteristics of the wind rotor. The influence of the LLJ on the aerodynamic loads of the wind rotor is greater than that of the wind shear. When the LLJ is placed inside the rotor swept area, the aerodynamic loads of the blade exhibit two local maximums and local minimums with the variation of the azimuth angle in a rotation period. The closer the LLJ height is to the hub height, the greater the average aerodynamic loads of the wind rotor are, and the smaller the amplitude of aerodynamic loads of the blade is relative to the average value. When the LLJ height is positioned outside the rotor swept area, the change law of the aerodynamic loads of the blade would be similar to that of the wind subjected to a very strong wind shear inflow. This study provides a crucial reference for a more rational assessment of the aerodynamic characteristics of wind turbines under the action of complex wind profiles, as well as revealing the influence of the LLJ on the aerodynamic characteristics of wind turbines. Full article
