Search Results (38)

Green hydrogen plays a vital role in facilitating the transition to sustainable energy systems, with stable and high-capacity offshore wind resources serving as an ideal candidate for large-scale green hydrogen production. However, as the capacity of offshore wind turbines continues to grow, the increasing size and weight of these systems pose significant challenges for installation and deployment. This study investigates the application of high-temperature superconducting (HTS) materials in the generator and the power conducting cables as a promising solution to these challenges. Compared to conventional wind turbines, HTS wind turbines result in significant reductions in weight and size while simultaneously enhancing power generation and transmission efficiency. This paper conducts a comprehensive review of mainstream electrolysis-based hydrogen production technologies and advanced hydrogen storage methods. The main contribution of this research is the development of an innovative conceptual framework for a superconducting offshore wind-to-hydrogen energy system, where a small amount of liquid hydrogen is used to provide a deep-cooling environment for the HTS wind turbine and the remaining liquid hydrogen is used for the synthesis of ammonia as a final product. Through functional analysis, this study demonstrates its potential for enabling large-scale offshore hydrogen production and storage. Additionally, this paper discusses key challenges associated with real-world implementation, including optimizing the stability of superconducting equipment and ensuring component coordination. The findings offer crucial insights for advancing the offshore green hydrogen sector, showing that HTS technology can significantly enhance the energy efficiency of offshore wind-to-hydrogen systems. This research provides strong technical support for achieving carbon neutrality and fostering sustainable development in the offshore renewable energy sector. Full article

For the large-scale fusion magnets of the International Thermonuclear Experimental Reactor (ITER) tokamak, wound with cable-in-conduit conductors, the application of sophisticated numerical models able to analyse the thermal–hydraulic behaviour during plasma scenarios is of paramount importance to guarantee an adequate stability margin during operating conditions. The SuperMagnet code has been developed by CryoSoft with the intent to simultaneously simulate the electrical, thermal and hydraulic phenomena occurring during the operation of superconducting coils. In this work, the SuperMagnet code is applied to analyse the thermal–hydraulic behaviour of the central solenoid of the ITER tokamak under the plasma scenario. The central solenoid (CS) is composed of six modules for a total amount of 240 pancakes. The software is able to tackle the complex structure of the CS and its cryogenic closed loop. In the present work, the circulation pump operation and the heat transfer to the helium bath are investigated. The results presented here show the temperature evolution of the magnet and of the supercritical helium during the plasma scenario, which allows the determination of the operation margin of the CS. Full article

Embedding stacked HTS tapes into twisted slots is one design approach for constructing fusion conductors. This paper adopts a Cable-in-Conduit Conductor (CICC) structure, utilizing commercially REBCO coated conductors. The cable framework is made of copper and features six helically twisted slots filled with 2G HTS tapes. Two 1 m long samples with twist pitches of 200 mm and 300 mm, respectively, were fabricated. In one slot, copper and superconducting tapes were alternated, while the remaining grooves were filled with copper tapes. The 90 µm thick copper-plated bare tapes provided by Shanghai Superconductor were used for testing. By measuring the critical current of tapes positioned at different locations within the grooves at 77 K, the characteristics of each tape in the stacked arrangement were individually characterized. The study obtained the current degradation patterns of tapes located at different positions within the grooves under various bending radii. This paper will present and discuss the preliminary results of the bending measurements conducted at 77 K under a self-field. Full article

In recent years, the scientific and industrial interest regarding alternative technologies for transmission cables has increased. These conductors should efficiently transmit significant amounts of power between grid nodes, which are expected to be particularly congested due to the projected global increase in electricity production. Superconducting cables are considered a promising solution in this context, offering the potential to transmit large amounts of energy with minimal losses and compact dimensions, thereby potentially benefiting the environment. To evaluate the feasibility of integrating superconducting cables into existing grids, techno-economic approaches should be adopted. Such techniques enable the conceptual design of a specific cable structure, allowing users to explore a wide range of operating parameters to derive optimal designs. This paper reports a comprehensive techno-economic analysis of High Voltage Alternating Current (HVAC) cables realized with High-Temperature Superconducting (HTS) tapes, with the aim to transmit extremely high-power level. The optimal coaxial design is selected using Optimization Tool for Superconducting Cable Research (OSCaR) by implementing a graded approach to the critical current of the HTS tapes used for the different phases. This optimization aims to achieve the most effective balance between the cost of the coated conductors and their electrical properties. The whole set of model equations, the user-defined parameters, and the applied constraints are detailed. The OSCaR tool is then applied to assess the impact on the optimized design of the cable system and the corresponding cost indexes of several crucial parameters, such as the maximum transmitted power, the voltage level, and the line length. Full article

The laying of power cables is a crucial aspect of developing and maintaining modern electrical infrastructure, which is vital for transmitting electricity reliably and efficiently. This review discusses the challenges and advancements in cable laying technologies, emphasizing the critical role of these techniques in meeting the increasing demands for power transmission in the backdrop of the global shift to renewable energy. Three main traditional cable laying methods are explored, including underground, overhead, and submarine, each suited to specific environmental and operational conditions. Then, the cable faults due to the impropriate laying process are discussed. Subsequently, the challenges and advancements encountered in cable laying processes are investigated, especially the difficulties of the cable laying of underground cable, submarine cable, and high-temperature superconductivity cable. This review also considers the impact of technological innovations on improving efficiency in cable laying processes, highlighting the advances driven by digitalization and automation. Full article

This study aimed to enhance the performance of Ag-stabilized high-temperature superconducting (HTS) tapes with a focus on reducing magnetization losses. Two approaches were employed: dividing the tapes into narrower widths and introducing striation at the level of the superconducting layer. The process of laser ablation proved to be an effective method for implementing these modifications. The quality of the cut edges and grooves was assessed using scanning electron microscopy. To evaluate the electrical properties, measurements were conducted on the critical current and magnetization loss in samples at different stages: in their initial state, after cutting, and after the striation process. Of the two modifications, the striation process more effectively reduced the AC losses in the HTS tapes, approximately by one order of magnitude. The retention of critical current remained high after cutting, but varied with the number of created filaments after the striation process. Subsequently, a short cable was wound from the cut and striated HTS tape. This cable demonstrated a remarkable sixfold reduction in AC losses compared to the initial HTS tape. Full article

Ensuring the energy transition in order to decrease CO₂ and volatile organic compounds emissions and improve the efficiency of energy processes requires the development of advanced materials and technologies for the electrical energy sector. The article reviews superconducting materials, functional nanomaterials used in the power industry mainly due to their magnetic, electrical, optical, and dielectric properties and the thin layers of amorphous carbon nitride, which properties make them an important material from the point of view of environmental protection, optoelectronic, photovoltaic and energy storage. The superconductivity-based technologies, material processing, and thermal and nonthermal plasma generation have been reviewed as technologies that can be a solution to chosen problems in the electrical energy sector and environment. The study explains directly both—the basics and application potential of low and high-temperature superconductors as well as peculiarities of the related manufacturing technologies for Roebel cables, 1G and 2G HTS tapes, and superconductor coil systems. Among the superconducting materials, particular attention was paid to the magnesium di-boride MgB₂ and its potential applications in the power industry. The benefits of the use of carbon films with amorphous structures in electronics, sensing technologies, solar cells, FETs, and memory devices were discussed. The article provides the information about most interesting, from the R&D point of view, groups of materials for PV applications. It summarises the advantages and disadvantages of their use regarding commercial requirements such as efficiency, lifetime, light absorption, impact on the environment, costs of production, and weather dependency. Silicon processing, inkjet printing, vacuum deposition, and evaporation technologies that allow obtaining improved and strengthened materials for solar cell manufacturing are also described. In the case of the widely developed plasma generation field, waste-to-hydrogen technology including both thermal and non-thermal plasma techniques has been discussed. The review aims to draw attention to the problems faced by the modern power industry and to encourage research in this area because many of these problems can only be solved within the framework of interdisciplinary and international cooperation. Full article

The Société Nationale des Chemins de fer Français (SNCF) is facing a significant challenge to meet the growth in rail traffic while maintaining continuous service, particularly in densely populated areas such as Paris. To tackle this challenge, the SNCF has implemented several electrification projects. These projects aim to reduce line losses and decrease voltage drops on the railway network. Amongst the possible technological choices, high temperature superconductor (HTS) cables have been evaluated, since they offer greater energy density at lower electrical losses than conventional cables. This feature is advantageous in order to transmit more electrical energy at a lesser footprint than conventional cable, therefore avoiding costly modifications of the existing infrastructures. In the present work, the electromagnetic response of two HTS cables topologies, unipolar and bipolar, was analyzed, and their impact on a direct current (DC) railway network under load was assessed. A commercial finite element (FE) software, COMSOL Multiphysics, was used to carry out a detailed FE model that accounts for the non-linearity of the electrical resistivity ρ (J, B, θ) of the superconducting cable. This FE model was coupled with a lumped-parameter circuit model of the railway network, which is particularly suited for transient simulations considering train motion. Based on a case study representing a portion of the Parisian railway network, it was found that the insertion of a superconducting cable can result in a reduction of electrical losses by 60% compared to conventional cable as well as an 8.6% reduction in the total electrical consumption of the traction network. Full article

To draw a complete vortex phase diagram for a CaKFe₄As₄ polycrystalline iron-based superconductor, different kinds of magnetic measurements have been performed focusing on the critical parameters of the sample. Firstly, magnetic moment versus field measurements m(H) were performed at low fields in order to evaluate the lower critical field H_c1. After that, by performing relaxation measurements m(t), a field crossover H_cross was detected in the framework of a strong pinning regime. The irreversibility field H_irr as a function of the temperature curve was then drawn by plotting the critical current densities J_c versus the field for temperatures near T_c. J_c(H) has demonstrated a second magnetization peak effect phenomenon, and the second peak field H_sp has been identified and plotted as a function of temperature, providing information about an elastic to plastic transition in the vortex lattice. Finally, the upper critical field H_c2 as a function of the temperature has been obtained. H_c1, H_cross, H_sp, H_irr, H_c2 have been fitted and used for drawing the complete vortex phase diagram of the sample. It can be helpful for the understanding of the applicative ranges in the field and temperature of the materials with not-optimized fabrication characteristics, as usually is found in superconducting wires and cables for power applications. Full article

Since the report by Fietz and Webb (Phys. Rev.1968, 178, 657–667), who considered the pinning force density, $\overrightarrow{F_p}=\overrightarrow{J_c}\times \overrightarrow{B}$ (where J_c is the critical current density and B is applied magnetic flux density), in isotropic superconductors as a unique function of reduced magnetic field, $\frac{B}{B_{c2}}$ (where $B_{c2}$ is the upper critical field), $\left|\overrightarrow{F_p}\right|$ has been scaled based on the $\frac{B}{B_{c2}}$ ratio, for which there is a widely used Kramer–Dew–Hughes scaling law of $\left|\overrightarrow{F_p}\left(B\right)\right|=F_{p,max}{\left(\frac{B}{B_{c2}}\right)}^p{\left(1-\frac{B}{B_{c2}}\right)}^q$, where $F_{p,max}$, $B_{c2}$, p, and q are free-fitting parameters. To describe $\left|\overrightarrow{F_p}\left(B\right)\right|$ in high-temperature superconductors, the Kramer–Dew–Hughes scaling law has been modified by (a) an assumption of the angular dependence of all parameters and (b) by the replacement of the upper critical field, B_c2, by the irreversibility field, B_irr. Here, we note that $\overrightarrow{F_p}$ is also a function of critical current density, and thus, the $\left|\overrightarrow{F_p}\left(J_c\right)\right|$ scaling law should exist. In an attempt to reveal this law, we considered the full $\left|\overrightarrow{F_p}\left(B,J_c\right)\right|$ function and reported that there are three distinctive characteristic ranges of $\left(\frac{B}{B_{c2}},\frac{J_c}{J_c\left(sf\right)}\right)$ (where $J_c\left(sf\right)$ is the self-field critical current density) on which $\left|\overrightarrow{F_p}\left(B,J_c\right)\right|$ can be splatted. Several new scaling laws for $\left|\overrightarrow{F_p}\left(J_c\right)\right|$ were proposed and applied to MgB₂, NdFeAs(O,F), REBCO, (La,Y)H₁₀, and YH₆. The proposed scaling laws describe the in-field performance of superconductors at low and moderate magnetic fields, and thus, the primary niche for these laws is superconducting wires and tapes for cables, fault current limiters, and transformers. Full article

The aim of the presented study is to optimize the different classes of high-temperature superconducting (HTS) DC cables for improving their performances in a cryo-electric aircraft considering their weight, peak temperature during faults, and the ratio of current passing through each tape to the critical current of HTS tapes. These terms were interpreted into three objective functions, and a multi-objective optimization algorithm known as non-dominated sorting genetic algorithm II was used to find the optimal solution clusters. The cable optimization was conducted for different former materials by changing the former thickness and radius. Results showed that the DC HTS cables with aluminum former have the lowest weight while cables with copper formers have the best thermal performance against faults. Full article

Compared with the traditional cable, the high-temperature superconducting (HTS) cable has the advantages of low loss and large capacity transmission. At present, the research on HTS cables mainly focuses on the calculation of AC loss, the performance under specific working conditions and cooling system design. Relatively little research has been carried out on the basic design and overall layout optimization of the cables. In this paper, an HTS cable with a rated current of 4 kA was designed. Firstly, according to the selected superconducting cable parameters, the body design of cables with different structures was carried out and the corresponding finite element models were built. Then, the performance analysis of HTS cables with different layouts was carried out based on the proposed cable performance evaluation indicators and the CORC double-layer structure was determined as the scheme of this cable. Finally, the AC loss of the cable with this topology was calculated to be 9.81 J/m under rated conditions. The cooling system can ensure the safe operation of the cable in the rated temperature range. Full article

Compared with traditional cables, superconducting multi-stage cables have the natural advantages of greater transmission power and less energy loss, which have gradually attracted attention. However, conventional multi-stage cables are based on low temperature superconducting (LTS) technology and there is considerable scope for improvement in their performance. In this paper, a novel structure of the multi-stage high temperature superconducting (HTS) twisted cable prepared by the soldered-stacked-square (3S) wire is proposed. The AC loss characteristics of the twisted cable are deeply studied by experiments and simulation. Through the experiment, the influence of the voltage-leads on the AC loss measurement accuracy is eliminated, and frequency dependent is shown in the AC loss of the twisted cable. Besides, the simulated value of AC loss is consistent with the experimental value, which verifies the accuracy of the simulation. The AC loss of twisted cable is only 20% of that of the thin strip model, which reveals its outstanding advantages in AC loss. Full article

Current-limiting superconducting cable uses the quench resistance of superconductor under short-circuit current to improve the short-circuit impedance of the system. In this paper, the design of current-limiting 10 kV three-phase tri-axial superconducting cable is studied. The design methods of cable conductor layer, insulation layer and current-limiting characteristics are given, and one 5 m-long sample is fabricated for testing. The sample is made of stainless-steel-reinforced yttrium barium copper oxide (YBCO) tape, with an expected rated current of 2.5 kA and rated voltage of 10 kV. The test results show that the designed cable can transmit a maximum AC current of 3.0 kA at 77 K. The cable has passed the power frequency withstand voltage, partial discharge and lightning impulse tests. The current limiting characteristics under the action of DC pulse current show that the cable can quickly quench and produce resistance, and the corresponding equivalent resistance value also changes along with current amplitude and duration. Full article

Superconducting power lead equipment for epoxy insulation, such as high-temperature superconducting DC power or liquefied natural gas energy pipelines, as well as high-temperature superconducting cables, has long been used in extreme environments, from liquid nitrogen temperatures to normal temperatures. It is easy to induce surface discharge and flashover under the action of strong electric field, which accelerates the insulation failure of current leads. In this paper, two-dimensional nano-material GO was used to control the electrical properties of epoxy resins. The DC surface discharge and flashover characteristics of the prepared epoxy resin–GO composite insulation materials were tested at room temperature with liquid nitrogen. The surface discharge mechanism of the epoxy resin–GO composite insulation materials was analyzed. The experimental results show that the insulation properties of epoxy composites doped with GO changed. Among them, the surface flashover voltage of 0.05 wt% material is the best, which can inhibit the discharge phenomenon and improve its insulation properties in extreme environments, from room temperature to liquid nitrogen temperature. It is found that the development process of surface discharge of composite insulating materials under liquid nitrogen is quite different from that under room temperature. Before critical flashover, the repetition rate and amplitude of surface discharge remain at a low level until critical flashover. Furthermore, the voltage of the first flashover is significantly higher than that of the subsequent flashover under the action of the desorption gas on the surface of the composite insulating material and the gasification layer produced by the discharge. Given that the surface flashover voltage of 0.05 wt% epoxy composite is the best, the research and analysis of 0.05 wt% composite is emphasized. In the future design of superconducting power lead insulation, the modification method of adding GO to epoxy resin can be considered in order to improve its insulation performance. Full article
