Search Results (9)

Search Parameters:
Keywords = substation connector

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
20 pages, 12414 KB
Article
Modelling a DC Electric Railway System and Determining the Optimal Location of Wayside Energy Storage Systems for Enhancing Energy Efficiency and Energy Management
by Hammad Alnuman
Energies 2024, 17(12), 2825; https://doi.org/10.3390/en17122825 - 8 Jun 2024
Cited by 5 | Viewed by 2539
Abstract
Global demand for fossil fuels is highly increasing, necessitating energy efficiency to be enhanced in transitioning to low-carbon energy systems. Electric railways are highly efficient in reducing the transportation demand for fossil fuels as they are lightweight and their energy demand can be [...] Read more.
Global demand for fossil fuels is highly increasing, necessitating energy efficiency to be enhanced in transitioning to low-carbon energy systems. Electric railways are highly efficient in reducing the transportation demand for fossil fuels as they are lightweight and their energy demand can be fed by renewable energy resources. Further, the regenerative braking energy of decelerating trains can be fed to accelerating trains and stored in onboard energy storage systems (ESSs) and stationary ESSs. It is fundamental to model electric railways accurately before investigating approaches to enhancing their energy efficiency. However, electric railways are challenging to model as they are nonlinear, resulting from the rectifier substations, overvoltage protection circuits, and the unpredictability and uncertainty of the load according to the train position. There have been few studies that have examined the ESS location’s impact on improving the energy efficiency of electric railways while using specialised simulation tools in electric railways. However, no single study exists that has studied the location impact of stationary ESSs on the energy efficiency of electric railways while the trains are supported by onboard ESSs. Given these goals and challenges, the main objective of this work is to develop a model using commercial software used by industry practitioners. Further, the energy saving is aimed to be maximised using stationary ESSs installed in optimal locations while trains are supported by onboard ESSs. The model includes trains, onboard ESSs, rail tracks, passenger stations, stationary ESSs, and traction power systems involving power lines, connectors, switches, sectioning, and isolators. In this article, a test scenario is presented comprising two trains running on a 20 km with three passenger stations and two substations. The trains and track are modelled in OpenTrack simulation software (Version 1.9) while the power system is modelled in OpenPowerNet simulation software (Version 1.11). The two simulation tools are used in the railway industry and can produce realistic results by taking into account the entire electrical network structure. A stationary ESS is added on the wayside and moved in steps of 1 km to obtain the optimal location before investigating the impact of stationary ESSs on the performance and energy management of onboard ESSs. It is found that the energy saving when installing a stationary ESS at the optimal location is 56.05%, the peak-power reduction of Substation 1 is 4.37%, and the peak-power reduction of Substation 2 is 18.67%. Full article
(This article belongs to the Special Issue New Challenges in Railway Energy Management Systems)
Show Figures

Figure 1

7 pages, 2565 KB
Proceeding Paper
Reducing Equipment Failure Risks by Redesigning of Products and Processes
by Ashweni Jain, Niranjan Parkhi and Prafulla Wankhade
Eng. Proc. 2023, 59(1), 42; https://doi.org/10.3390/engproc2023059042 - 13 Dec 2023
Viewed by 1357
Abstract
Low-voltage (LV) network assets, although they do not play a significant role in reliability indices compared to medium-voltage (MV) assets like the transformer and switchgears, are required to be designed in a way that would mitigate the risk of sporadic failures, hence incurring [...] Read more.
Low-voltage (LV) network assets, although they do not play a significant role in reliability indices compared to medium-voltage (MV) assets like the transformer and switchgears, are required to be designed in a way that would mitigate the risk of sporadic failures, hence incurring an R&M cost. LV assets like LV cables, distribution panels, molded-case circuit breakers (MCCBs), and miniature circuit breakers (MCBs) generally do not have a planned maintenance (PM) schedule and are procured based on the run-to-failure concept in view of the huge volume. These assets are exposed to the harshest of environmental and operation conditions. Hence, it is imperative that we take the necessary measures during the design stage such that they are able to cater to their stringent duties, which include frequent short circuits, exposure to the environment, and thermal overloads. It is also important to periodically review the product design based on site feedback and product performance to re-calibrate the product and its associated processes. Through this technical paper, several case studies are presented wherein special terminal connectors with shear bolts were designed to mitigate the thermal hotspot issues causing frequent fire and failures—i.e., vertical fuse switch disconnectors (VFSDs) and miniature circuit breaker (MCBs). A case study on condition monitoring through a substation inspection schedule is also presented, through which potential failures were averted in time. The observations and measurements are mapped in an SAP system for trend analysis. With the adoption of effective product and process design, AEML has reduced asset failures. Full article
(This article belongs to the Proceedings of Eng. Proc., 2023, RAiSE-2023)
Show Figures

Figure 1

18 pages, 5176 KB
Article
Energy Balance of Wireless Sensor Nodes Based on Bluetooth Low Energy and Thermoelectric Energy Harvesting
by Yuming Liu, Jordi-Roger Riba and Manuel Moreno-Eguilaz
Sensors 2023, 23(3), 1480; https://doi.org/10.3390/s23031480 - 28 Jan 2023
Cited by 17 | Viewed by 3836
Abstract
The internet of things (IoT) makes it possible to measure physical variables and acquire data in places that were impossible a few years ago, such as transmission lines and electrical substations. Monitoring and fault diagnosis strategies can then be applied. A battery or [...] Read more.
The internet of things (IoT) makes it possible to measure physical variables and acquire data in places that were impossible a few years ago, such as transmission lines and electrical substations. Monitoring and fault diagnosis strategies can then be applied. A battery or an energy harvesting system charging a rechargeable battery typically powers IoT devices. The energy harvesting unit and rechargeable battery supply the sensors and wireless communications modules. Therefore, the energy harvesting unit must be correctly sized to optimize the availability and reliability of IoT devices. This paper applies a power balance of the entire IoT device, including the energy harvesting module that includes two thermoelectric generators and a DC–DC converter, the battery, and the sensors and communication modules. Due to the small currents typical of the different communication phases and their fast-switching nature, it is not trivial to measure the energy in each phase, requiring very specific instrumentation. This work shows that using conventional instrumentation it is possible to measure the energy involved in the different modes of communication. A detailed energy balance of the battery is also carried out during charge and discharge cycles, as well as communication modes, from which the maximum allowable data transfer rate is determined. The approach presented here can be generalized to many other smart grid IoT devices. Full article
(This article belongs to the Special Issue Challenges in Energy Perspective on Mobile Sensor Networks)
Show Figures

Figure 1

17 pages, 4086 KB
Article
Fire Resistance of an Assembled Integrated Enclosure Panel System
by Cong Zeng, Ziwen Wang, Junliang Chen and Dehong Wang
Buildings 2022, 12(10), 1582; https://doi.org/10.3390/buildings12101582 - 1 Oct 2022
Cited by 4 | Viewed by 8180
Abstract
Due to increasing economic development in recent years, large-scale prefabricated structures have been used for substations. However, the assembly of steel structures suffers from technical problems, such as the mismatch between the fire protection level of the main structure and the enclosure system. [...] Read more.
Due to increasing economic development in recent years, large-scale prefabricated structures have been used for substations. However, the assembly of steel structures suffers from technical problems, such as the mismatch between the fire protection level of the main structure and the enclosure system. This paper proposes an assembled integrated enclosure panel system for covering and fireproofing steel structures, such as beams and columns, consisting of sandwich wall panels and autoclaved lightweight concrete (ALC) wall panels covering the main steel structure. Fire resistance tests were carried out for each part and the entire integrated enclosure panel system to fully investigate its fire resistance performance. ALC and gypsum were selected as the external fire protection materials for the sandwich wall panel test for theoretical analysis and fire resistance test. The fire resistance test results show that the designed solutions of sandwich wall panels and ALC panels covering steel beams and columns meet the fire protection requirements of the ISO-834 standard fire test. The proposed size scheme of the integrated enclosure panel system is an integrated sandwich wall panel composed of 50 mm thick ALC board + 50 mm thick rock wool layer + 50 mm thick ALC board and the integrated structure of 100 mm thick ALC board covering beams and columns. The designed U-shaped connectors between the wall panels are suitable for the assembled integrated enclosure panel system. Full article
(This article belongs to the Section Building Structures)
Show Figures

Figure 1

12 pages, 3109 KB
Article
Design of an Anti-Corona Device for HVAC Substation Connectors
by Ane Miren Larrea, Manuel De La Hoz, Agurtzane Etxegarai, Angel Javier Mazon and Itxaso Aranzabal
Energies 2022, 15(16), 5781; https://doi.org/10.3390/en15165781 - 9 Aug 2022
Cited by 1 | Viewed by 2403
Abstract
One of the aspects to consider during high-voltage (HV) equipment design is the reduction in the probability of corona effect onset. Indeed, the corona effect is related to high electric field values beyond the equipment’s insulation levels and insulation strength, among other factors. [...] Read more.
One of the aspects to consider during high-voltage (HV) equipment design is the reduction in the probability of corona effect onset. Indeed, the corona effect is related to high electric field values beyond the equipment’s insulation levels and insulation strength, among other factors. This issue can be addressed during the design step, either by modifying the geometry of the electrical device or by including additional elements in the equipment structure to smooth out the voltage gradient along critical regions, such as anti-corona devices. The study of anti-corona devices for HV insulators is well documented, in contrast to substation connectors. Therefore, the present study proposed the design of a novel anti-corona device for HV substation connectors, including a method for the selection of its dimensions. This study shows that the relationship between the dimensional design variables and the critical electrical field on the connector is described by linear and rational functions. Thus, the design process times are cut down due to a reduction in the number of simulations required to run the assessment of the anti-corona device arrangement impact. Full article
(This article belongs to the Special Issue Advances in High Voltage Engineering)
Show Figures

Figure 1

15 pages, 4409 KB
Article
Research on Real-Time Infrared Image Fault Detection of Substation High-Voltage Lead Connectors Based on Improved YOLOv3 Network
by Qiwei Xu, Hong Huang, Chuan Zhou and Xuefeng Zhang
Electronics 2021, 10(5), 544; https://doi.org/10.3390/electronics10050544 - 25 Feb 2021
Cited by 27 | Viewed by 3098
Abstract
Currently, infrared fault diagnosis mainly relies on manual inspection and low detection efficiency. This paper proposes an improved YOLOv3 network for detecting the working state of substation high-voltage lead connectors. Firstly, dilated convolution is introduced into the YOLOv3 backbone network to process low-resolution [...] Read more.
Currently, infrared fault diagnosis mainly relies on manual inspection and low detection efficiency. This paper proposes an improved YOLOv3 network for detecting the working state of substation high-voltage lead connectors. Firstly, dilated convolution is introduced into the YOLOv3 backbone network to process low-resolution element layers, so as to enhance the network’s extraction of image features, promote function propagation and reuse, and improve the network’s recognition performance of small targets. Then the fault detection model of the infrared image of the high voltage lead connector is created and the optimal infrared image test data set is obtained through multi-scale training. Finally, the performance of the improved network model is tested on the data set. The test results show that the improved YOLOv3 network model has an average detection accuracy of 84.26% for infrared image faults of high-voltage lead connectors, which is 4.58% higher than the original YOLOv3 network model. The improved YOLOv3 network model has an average detection time of 0.308 s for infrared image faults of high-voltage lead connectors, which can be used for real-time detection in substations. Full article
(This article belongs to the Special Issue Smart Grid and Future Electrical Networks)
Show Figures

Figure 1

13 pages, 3399 KB
Article
Experimental Study of the Corona Performance of Aged Sand-Cast Substation Connectors
by Jordi-Roger Riba, Santiago Bogarra, Álvaro Gómez-Pau and Manuel Moreno-Eguilaz
Energies 2020, 13(11), 2785; https://doi.org/10.3390/en13112785 - 1 Jun 2020
Cited by 3 | Viewed by 2761
Abstract
Substation connectors, like many other high-voltage products, are tested once manufactured. However, the corona behavior of aged specimens can differ from that exhibited by newer ones, thus generating detrimental technical and environmental effects. Manufacturers need to know the long-term corona behavior of substation [...] Read more.
Substation connectors, like many other high-voltage products, are tested once manufactured. However, the corona behavior of aged specimens can differ from that exhibited by newer ones, thus generating detrimental technical and environmental effects. Manufacturers need to know the long-term corona behavior of substation connectors to offer their customers maximum safety and transparency about such critical products. This paper analyzes the ageing effect on the surface roughness and the visual corona extinction voltage of sand-cast aluminum connectors, which were artificially aged in a salt spray chamber for different periods. The experimental results show an important variability of the surface roughness and corona extinction voltage (CEV) among connectors with the same ageing level due to the sand-casting manufacturing process. The results in this paper also show a slight increase in the surface roughness with the ageing period, although there is not a clear pattern between the applied ageing level and the experimental CEV value. It is concluded that the inherent variability among connectors due to the sand-cast process has more influence than the ageing effect itself. Full article
Show Figures

Figure 1

18 pages, 4250 KB
Article
Comparative Study of AC and Positive and Negative DC Visual Corona for Sphere-Plane Gaps in Atmospheric Air
by Jordi-Roger Riba, Andrea Morosini and Francesca Capelli
Energies 2018, 11(10), 2671; https://doi.org/10.3390/en11102671 - 8 Oct 2018
Cited by 56 | Viewed by 10846
Abstract
Due to the expansion of high-voltage direct current (HVDC) power systems, manufacturers of high-voltage (HV) hardware for alternating current (ac) applications are focusing their efforts towards the HVDC market. Because of the historical preponderance of ac power systems, such manufacturers have a strong [...] Read more.
Due to the expansion of high-voltage direct current (HVDC) power systems, manufacturers of high-voltage (HV) hardware for alternating current (ac) applications are focusing their efforts towards the HVDC market. Because of the historical preponderance of ac power systems, such manufacturers have a strong background in ac corona but they need to acquire more knowledge about direct current (dc) corona. Due to the complex nature of corona, experimental data is required to describe its behavior. This work performs an experimental comparative analysis between the inception of ac corona and positive and negative dc corona. First, the sphere-plane air gap is analyzed from experimental data, and the corona inception voltages for different geometries are measured in a high-voltage laboratory. Next, the surface electric field strength is determined from finite element method simulations, since it provides valuable information about corona inception conditions. The experimental data obtained are fitted to an equation based on Peek’s law, which allows determining the equivalence between the visual corona surface electric field strength for ac and dc supply. Finally, additional experimental results performed on substation connectors are presented to further validate the previous results by means of commercial high-voltage hardware. The results presented in this paper could be especially valuable for high-voltage hardware manufacturers, since they allow determining the dc voltage and electric field values at which their ac products can withstand free of corona when operating in dc grids. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1

16 pages, 6124 KB
Article
Three-Dimensional Finite-Element Analysis of the Short-Time and Peak Withstand Current Tests in Substation Connectors
by Francesca Capelli, Jordi-Roger Riba and Joan Pérez
Energies 2016, 9(6), 418; https://doi.org/10.3390/en9060418 - 30 May 2016
Cited by 13 | Viewed by 8089
Abstract
Power devices intended for high-voltage systems must be tested according to international standards, which includes the short-time withstand current test and peak withstand current test. However, these tests require very special facilities which consume huge amounts of electrical power. Therefore, mathematical tools to [...] Read more.
Power devices intended for high-voltage systems must be tested according to international standards, which includes the short-time withstand current test and peak withstand current test. However, these tests require very special facilities which consume huge amounts of electrical power. Therefore, mathematical tools to simulate such tests are highly appealing since they allow reproducing the electromagnetic and thermal behavior of the test object in a fast and economical manner. In this paper, a three-dimensional finite element method (3D-FEM) approach to simulate the transient thermal behavior of substation connectors is presented and validated against experimental data. To this end, a multiphysics 3D-FEM method is proposed, which considers both the connector and the reference power conductors. The transient and steady-state temperature profiles of both the conductors and connector provided by the 3D-FEM method prove its suitability and accuracy as compared to experimental data provided by short-circuit tests conducted in two high-current laboratories. The proposed simulation tool, which was proven to be accurate and realistic, may be particularly useful during the design and optimization phases of substation connectors since it allows anticipating the results of mandatory laboratory tests. Full article
Show Figures

Figure 1
