Search Results (15)

This paper aims to fabricate a hybrid piezoelectric/triboelectric nanogenerator via fusion deposition modeling as a proof of concept in the wearable device industry. The nanogenerator structure consists of a TPU/ZnO nanocomposite and an Ecoflex layer. The nanocomposite layer is fabricated using two different weight percentages (15 wt% and 20 wt%) and poled piezoelectric sheets, generating 2.63 V to 3.46 V. Variations regarding the nanogenerator’s physical parameters were implemented to examine the effect on nanogenerator performance under different frequencies. The hybrid nanogenerator enabled energy harvesting for wearable devices. It was strapped on the side of the wrist to generate a potential difference with the motion of the wrist, creating a contact separation piezoelectric/triboelectric nanogenerator. Furthermore, a piezoelectric sheet was placed at the bottom of the wrist to harvest energy. The hybrid nanogenerator provided a maximum triboelectric response of 5.75 V and a maximum piezoelectric response of 2.85 V during wrist motion. The piezoelectric nanogenerator placed at the bottom of the wrist generated up to 4.78 V per wrist motion. Full article

Objective: Botulinum neurotoxin type A (BoNT/A) injections and the new vibration ergometry training (VET) are studied for their combined effect on improving functional mobility in patients with asymmetric lower limb spasticity. Method: Gait was analyzed using the Infotronic^® system, which measures ground reaction forces and foot contact patterns by means of special force-sensitive shoes strapped over feet or street shoes. Gait was measured several times, depending on the protocol patients underwent. Seven patients with asymmetric lower limb spasticity were analyzed according to the control protocol (CG-group): after a baseline walk of 20 m (NV-W1) patients received their routine BoNT/A injection and had to walk the same distance a second time (NV-W2). Approximately 3–5 weeks later, they had to walk a third time (NV-W3). A further seven patients (VG-group) were analyzed according to the vibration protocol: after a baseline walk (V-W1), patients underwent a first vibration training (VET1), walked a second time (V-W2), received their routine BoNT/A injection, and walked a third time (V-W3). About four weeks later, they had to walk again (V-W4), received another vibration training (VET3), and walked a fifth time (V-W5). At least six months after the analysis according to the vibration protocol, these patients were also analyzed according to the control protocol. Eleven gait parameters were compared between the CG- and VG-group, and within the VG-group. Result: Patients in the VG-group experienced a significant improvement in gait four weeks after BoNT/A injection, unlike the patients in the CG-group. VG-patients also showed improved gait after two VET sessions. However, there was no further functional improvement of gait when BoNT/A injections and VET sessions were combined. Conclusions: BoNT/A injections enhance functional mobility in patients with mild asymmetric leg spasticity. VET also induces an immediate gait improvement and offers a further treatment approach for leg spasticity. Whether combining BoNT treatment and vibration training offers superior outcomes compared to either treatment alone requires further investigation. Full article

Textile-based electrodes offer several advantages such as washability, flexibility, and reusability. However, there are challenges when it comes to long-term, real-time continuous monitoring, particularly during self-administration situations which introduce severe motion artifacts. In response to these challenges, researchers have explored various moisture retaining filling textiles to enhance the sustainability of long-term EMG monitoring. This study focuses on comparing three alternative textile fillings: 3D knitted fabric, nonwoven fabric, and microfiber sandwiched between embroidered textile electrodes to evaluate their moisture retention performance and ability to record EMG. The developed electrodes are comprised of embroidered a polyamide-silver hybrid conductive thread, with the filling textiles sandwiched between this yarn and the support fabric and bobbin yarn. The support fabric is an elastic textile band. The creation of these electrodes utilized satin stitch techniques. Impedance characteristics were analysed using an IVI-UM setup with a two-electrode configuration. The electrodes were applied to the subject’s bicep muscles using the elastic strap with a pressure of 12 mmHg. The developed textile filled embroidered electrodes using the satin stitch technique exhibited better dry and wet electrode skin-contact impedance performance compared to the normal satin stitch-based embroidered electrodes against to (Ag/AgCl) electrodes. Further evaluation focused on assessing the long-term stability and wettability of the wet electrode conditions with various drying time. The wet 3D knit (W3D) large satin stitched sandwiched electrodes displayed lower impedance characteristics than those made with wet nonwoven (WNW), wet microfiber (WMF), and the dry embroidered electrodes, with worst performing the normal satin stitch embroidered electrode. It was observed that increasing drying time increases skin-contact impedance, emphasizing the significance of selecting the appropriate filling materials capable of retaining moisture comfort over extended periods. This choice is vital for achieving long-term EMG monitoring and maintaining low contact impedance, which directly impacts the signal quality. The study evaluated the effects of moisture retention time for each textile filling type on sustainable long-term EMG monitoring. Among the tested electrodes, the wet ring satin stitch 3D knit (W3D) sandwiched embroidered electrode out-performed the others WNW, and wet MF based sandwiched electrode achieving a signal-to-noise ratio of 54.93 dB and a root mean square of 0.195 mV, respectively, at the parametric values identified in the experiments. Full article

This study aims to describe the numerical modeling and nonlinear finite element analysis of typical spinal braces as a first step towards optimizing their topology for 3D printing. Numerical simulation was carried out in Abaqus CAE software Version 2021, utilizing a CAD (Meshmixer Version 3.5.474) scan of an actual spinal brace. Boundary conditions were defined by means of contact surfaces between the human body and the supporting pads located in the interior of the brace. The process of tightening the straps on the rear face of the brace was simulated via appropriate imposed displacements. The response is described through the deformations and developing stresses of the brace and the contact pressures in the areas of interaction with the human body. Parametric analysis indicated that increasing the cross-sectional thickness or elastic modulus of the brace material results in higher maximum von Mises stresses and lower displacements. The comparison between 3D-printed and conventional braces highlighted the potential of 3D-printing technology to achieve comparable performance with customized designs, leveraging the constitutive properties of 3D-printed material obtained from tension tests. The tension tests demonstrated that the 3D-printed material achieved higher values of modulus of elasticity compared to traditional brace materials. Finally, the topology optimization criteria to be applied for the design of spinal braces in the next step of this ongoing research are briefly described. Full article

This paper presents a novel mathematical model to determine the minimum cost for the design of reinforced-concrete strap combined footings under biaxial bending, with each column using a genetic algorithm. The pressure is assumed to be linearly distributed along the contact area. This study comprises two steps: firstly, identifying the smallest ground contact area, and secondly, minimizing the cost. The methodology integrates moment, bending shear, and punching shear calculations according to the ACI standard. Some authors present a smaller area (but limited to one or two property lines) and the design considers that the thickness of the footings and beam are equal, and do not show the lower cost of a strap combined footing; generally, the beam has a greater thickness than the footings and therefore the footings would have an unnecessary thickness that would generate a higher cost. A numerical example is shown to find the lowest cost for the design of strap combined footings considering four different conditions such as square footings and other limitation at the ends of the footings. The minimum area does not guarantee that it is the lowest cost. The proposed model is versatile, applicable to T-shaped and rectangular combined footings, and is not restricted to specific property lines. The contributions include eliminating trial and error practices, accommodating various design conditions, and emphasizing equilibrium in the derived equations. The model is adaptable to different building codes, offering a comprehensive approach to achieving optimal design and cost considerations for strap combined footings. Full article

As an important electrical connection component in electrical equipment, the strap contact is directly related to the long-term operation stability of equipment. The electrical contact resistance (ECR) of the electrical connection structure is an important indicator for evaluating the reliability of the electrical contact system. In this research, the theoretical calculation of ECR of the strap contacts used by the G-W theoretical model and the fractal theoretical model is improved and compared. After comparison with the experimental measurement values, the rationality and accuracy of the two theoretical models are discussed. The results show that when the load is small (1–3 N), the maximum error of G-W model is 41%, while the fractal model method has a maximum error of 9%. When the load is large (4–10 N), the results of the two are almost the same, and the errors are both within 14%. In summary, the error range of the fractal model is smaller and the change trend is closer to the experimental value, which is suitable for a relatively better ECR analytical calculation theory. The research results can provide a theoretical basis for research on the electrical contact performance of the electrical contact structure of electrical equipment. Full article

Recently, there has been an increase in the number of reports on textile-based dry electrodes that can detect biopotentials without the need for electrolytic gels. However, these textile electrodes have a higher electrode skin interface impedance due to the improper contact between the skin and the electrode, diminishing the reliability and repeatability of the sensor. To facilitate improved skin–electrode contact, the effects of load and holding contact pressure were monitored for an embroidered textile electrode composed of multifilament hybrid thread for its application as a surface electromyography (sEMG) sensor. The effect of the textile’s inter-electrode distance and double layering of embroidery that increases the density of the conductive threads were studied. Electrodes embroidered onto an elastic strap were wrapped around the forearm with a hook and loop fastener and tested for their performance. Time domain features such as the Root Mean Square (RMS), Average Rectified Value (ARV), and Signal to Noise Ratio (SNR) were quantitatively monitored in relation to the contact pressure and load. Experiments were performed in triplicates, and the sEMG signal characteristics were observed for various loads (0, 2, 4, and 6 kg) and holding contact pressures (5, 10, and 20 mmHg). sEMG signals recorded with textile electrodes were comparable in amplitude to those recorded using typical Ag/AgCl electrodes (28.45 dB recorded), while the signal-to-noise ratios were, 11.77, 19.60, 19.91, and 20.93 dB for the different loads, and 21.33, 23.34, and 17.45 dB for different holding pressures. The signal quality increased as the elastic strap was tightened further, but a pressure higher than 20 mmHg is not recommended because of the discomfort experienced by the subjects during data collection. Full article

The evolution of fiber optic technology in the past few decades has led to significant advancements in various fields, including high-speed and long-distance communication, big data transport, optical imaging, and sensing. However, relatively few studies have examined the use of fiber optic sensors (FOSs) as point and distributed sensors in geophysics. Distributed Acoustic Sensing (DAS) is a widely used method for subsurface imaging and monitoring in wells, specifically in Vertical Seismic Profiling (VSP) surveys. This method allows for detailed analysis of subsurface structures and properties of reservoirs. Four different strategies for deploying FOS cables in DAS VSP are evaluated and compared: cementing behind casing, cable behind inflatable liner, strapping to production tubing, and wireline deployment. Cementing the fiber behind casing is considered the most effective method for coupling with the formation. However, the other methods also have their own advantages and limitations. The fiber cable behind inflatable liner, for example, allows for accessibility to the fiber without affecting the acoustic signal, while strapping the fiber to production tubing can still record DAS signals; tubing noise and signal attenuation from the annular fluid, however, can make it difficult to differentiate from the seismic signal. Nonetheless, this method has the benefit of being simpler to deploy and replace in case of failure. Wireline deployment can pick up some acoustic signals in regions where the cable touches the well wall, but in vertical sections where the cable is not in contact with the wall, the signal is attenuated. Results from pilot tests in a field in Canada are discussed and evaluated, and suggestions for improving the VSP signal are provided. Full article

Accelerometry is becoming a popular method to access human movement in outdoor conditions. Running smartwatches may acquire chest accelerometry through a chest strap, but little is known about whether the data from these chest straps can provide indirect access to changes in vertical impact properties that define rearfoot or forefoot strike. This study assessed whether the data from a fitness smartwatch and chest strap containing a tri-axial accelerometer (FS) is sensible to detect changes in running style. Twenty-eight participants performed 95 m running bouts at ~3 m/s in two conditions: normal running and running while actively reducing impact sounds (silent running). The FS acquired running cadence, ground contact time (GCT), stride length, trunk vertical oscillation (TVO), and heart rate. Moreover, a tri-axial accelerometer attached to the right shank provided peak vertical tibia acceleration (PK_ACC). The running parameters extracted from the FS and PK_ACC variables were compared between normal and silent running. Moreover, the association between PK_ACC and smartwatch running parameters was accessed using Pearson correlations. There was a 13 ± 19% reduction in PK_ACC (p < 0.005), and a 5 ± 10% increase in TVO from normal to silent running (p < 0.01). Moreover, there were slight reductions (~2 ± 2%) in cadence and GCT when silently running (p < 0.05). However, there were no significant associations between PK_ACC and the variables extracted from the FS (r < 0.1, p > 0.05). Therefore, our results suggest that biomechanical variables extracted from FS have limited sensitivity to detect changes in running technique. Moreover, the biomechanical variables from the FS cannot be associated with lower limb vertical loading. Full article

Nine grades of steel from different European steelmakers, namely 304L, 316L, and 904L, were evaluated. The austenitic steels studied are used in the manufacture of watch straps. The evaluations have been carried out in accordance with the ASTM standards which specifically concern the forms of corrosion, pitting (G48-11, FeCl₃), intergranular (A262-15, Strauss method) test and Tuccillo–Nielsen test. The polarization electrochemical test on link watch straps was implemented by the microelectrode technique. Stress corrosion has also been investigated in the assembly of laser welded pin and link. It should be noted that, despite the fact that the grade of steel is in conformity with the classification standards, we note that the corrosion behavior is very different from one steelmaker to another. There are parameters that can change the quality of steel such as the technology process, casting volume, deoxidizers’ addition, remelted steel process and traces of pollutants. In consequence, we observe an extensive dispersion of results concerning nickel release, according to the EN 1811 European legislation regarding the protection of the population’s health, specifically relating to skin contact. In conclusion, steels DIN 1.4441 (316L Med) and DIN 1.4539 (904L) present a very good resistance to the morphologies of pitting and crevice corrosion. The 316L and 304L steel grades, also known as DIN 1.4435, DIN 1.4404 and DIN 1.4306, display a major difference in pitting and crevice corrosion behavior. Full article

A printed monopole antenna for millimeter-wave applications in the 5G frequency region is described in this research. As a result, the proposed antenna resonates in three frequency bands that are designated for 5G communication systems, including 28 GHz, 38 GHz, and 60 GHz (V band). For the sake of compactness, the coplanar waveguide (CPW) method is used. The overall size of the proposed tri-band antenna is 4 mm × 3 mm × 0.25 mm. Using a watch strap and human tissue, such as skin, the proposed antenna gives steady results. At 28 GHz, 38 GHz, and 60 GHz, the antenna’s gain is found to be 5.29 dB, 7.47 dB, and 9 dB, respectively. The overall simulated radiation efficiency is found to be 85% over the watch strap. Wearable devices are a great fit for the proposed tri-band antenna. The antenna prototype was built and tested in order to verify its performance. It can be observed that the simulated and measured results are in close contact. According to our comparative research, the proposed antenna is a good choice for smart 5G devices because of its small size and simple structure, as well as its high gain and radiation efficiency. Full article

Smart watch antenna design is challenging due to the limited available area and the contact with the human body. The strap of smart watch can be utilized effectively for integration of the antenna. In this study, an antenna integrated on a smart watch strap model using computer simulation technology (CST) was designed. The antenna was designed for industrial, scientific, and medical (ISM) frequency bands at 2.45 and 5.8 GHz. Roger 3003C was used as substrate due to its semi-flexible nature. The antenna size is 28.81 × 19.22 × 1.58 mm³ and it has a gain of 1.03 and 5.97 dB, and efficiency of 80% and 95%, at 2.45 and 5.8 GHz, on the smart watch strap, respectively. A unit cell was designed having a dimension of 19.19 × 19.19 × 1.58 mm³ to mitigate the effect of back radiation and to enhance the gain. The antenna backed by the unit cell exhibited a gain of 2.44 and 6.17 dB with efficiency of 50% and 72% at 2.45 and 5.8 GHz, respectively. The AMC-backed antenna was integrated into a smart watch strap and placed on a human tissue model to study its human proximity effects. The specific absorption rate (SAR) values were calculated to be 0.19 and 1.18 W/kg at the designed ISM frequencies, and are well below the permissible limit set by the FCC and ICINPR. Because the antenna uses flexible material for wearable applications, bending analysis was also undertaken. The indicated results prove that bending along the x- and y-axes has a negligible effect on the antenna’s performance and the antenna showed excellent performance in the human proximity test. The measured results of the fabricated antenna were comparable with the simulated results. Thus, the designed antenna is compact, has high gain, and can be used effectively for wireless IoT applications. Full article

Some controllable process parameters in the riveting process such as the gap between sheets, have an important impact on the quality of a riveted butt joint. In this paper, the finite element model of a riveted single-strap butt joint is established with the help of ABAQUS analysis software, and the riveting process is simulated under five kinds of gaps between sheets. From the perspectives of rivet upsetting size, rivet interference, radial deformation of sheet, and analysis of residual stress around the hole of sheet, the influence of the gap between sheets on the connection quality of the riveted butt joint is summarized. The results show that the left and right sheets will contact each other and there is extrusion stress between the sheets when the gap is zero. When the applied tensile load continues to increase, due to the influence of the secondary bending, the strap sheet responsible for the connection produces warping deformation, and there will be no further contact between the sheets. When the gap between sheets increases from 0 to 2 mm, the maximum deformation of strap sheets increases from 0.876 to 0.927 mm, which proves that the gap between sheets have no significant effect on the deformation of the strap sheet. Full article

Sleep is an essential element to human life, restoring the brain and body from accumulated fatigue from daily activities. Quantitative monitoring of daily sleep quality can provide critical feedback to evaluate human health and life patterns. However, the existing sleep assessment system using polysomnography is not available for a home sleep evaluation, while it requires multiple sensors, tabletop electronics, and sleep specialists. More importantly, the mandatory sleep in a designated lab facility disrupts a subject’s regular sleep pattern, which does not capture one’s everyday sleep behaviors. Recent studies report that galvanic skin response (GSR) measured on the skin can be one indicator to evaluate the sleep quality daily at home. However, the available GSR detection devices require rigid sensors wrapped on fingers along with separate electronic components for data acquisition, which can interrupt the normal sleep conditions. Here, we report a new class of materials, sensors, electronics, and packaging technologies to develop a wireless, soft electronic system that can measure GSR on the wrist. The single device platform that avoids wires, rigid sensors, and straps offers the maximum comfort to wear on the skin and minimize disruption of a subject’s sleep. A nanomaterial GSR sensor, printed on a soft elastomeric membrane, can have intimate contact with the skin to reduce motion artifact during sleep. A multi-layered flexible circuit mounted on top of the sensor provides a wireless, continuous, real-time recording of GSR to classify sleep stages, validated by the direct comparison with the standard method that measures other physiological signals. Collectively, the soft bioelectronic system shows great potential to be working as a portable, at-home sensor system for assessing sleep quality before a hospital visit. Full article

Heart rate (HR) as an important physiological indicator could properly describe global subject’s physical status. Photoplethysmographic (PPG) sensors are catching on in field of wearable sensors, combining the advantages in costs, weight and size. Nevertheless, accuracy in HR readings is unreliable specifically during physical activity. Among several identified sources that affect PPG recording, contact pressure (CP) between the PPG sensor and skin greatly influences the signals. Methods: In this study, the accuracy of HR measurements of a PPG sensor at different CP was investigated when compared with a commercial ECG-based chest strap used as a test control, with the aim of determining the optimal CP to produce a reliable signal during physical activity. Seventeen subjects were enrolled for the study to perform a physical activity at three different rates repeated at three different contact pressures of the PPG-based wristband. Results: The results show that the CP of 54 mmHg provides the most accurate outcome with a Pearson correlation coefficient ranging from 0.81 to 0.95 and a mean average percentage error ranging from 3.8% to 2.4%, based on the physical activity rate. Conclusion: Authors found that changes in the CP have greater effects on PPG-HR signal quality than those deriving from the intensity of the physical activity and specifically, the individual best CP for each subject provided reliable HR measurements even for a high intensity of physical exercise with a Bland–Altman plot within ±11 bpm. Although future studies on a larger cohort of subjects are still needed, this study could contribute a profitable indication to enhance accuracy of PPG-based wearable devices. Full article
