The design of a removable module is proposed in order to enable the use of open wagons for container transportation. This module secures a container placed on an open wagon considering conditions for its strength under conditions of the operational load. The use of rectangular pipes was proposed as profiles for the removable module. The possibility of optimizing the cross-section parameters of the beams of the removable module frame was investigated. The optimization was carried out according to the criterion of a reduction in the material consumption of the removable module frame. It was established based on the preformed calculations that this optimization contributes to reducing the unit mass of the frame beam by 1.5% compared to using a typical rectangular profile. A spatial model of the removable module was built, and its strength was calculated considering the results of the optimization process. The results of the calculations show that the strength of the removable module is ensured under the considered load schemes. Moreover, within the framework of the research, an experimental study of the hatch cover strength of an open wagon when loaded by the removable module was carried out. At the same time, experimental tests were carried out in laboratory conditions using the method of the electrical strain gage. It was established that the strength of the hatch cover is maintained. The conducted research will contribute to the creation and development of the use of open wagons for container transportation and, accordingly, to increasing the efficiency of containerized cargo transportation, including in international traffic. Full article

This study thoroughly investigated the compressive and tensile strength characteristics of black shale using both experimental and analytical approaches. Uniaxial compression tests were conducted to determine the elastic constants of black shale modeled as idealized, linear elastic, homogeneous, and transversely isotropic. Additionally, Brazilian tests were carried out on shale, considering it a transversely isotropic material. Strain measurements were recorded at the center of disc specimens subjected to diametric loading. By placing strain gages at the disc centers, the five elastic constants were accurately estimated. The effects of experimental methods and diametric loading on the elastic constant determination were evaluated and analyzed, and the indirect shear strength of the black shale, considering anisotropy, was determined using the estimated stress concentration coefficient. This study revealed that the indirect tensile strength of black shale is significantly influenced by the angle between the anisotropic planes and the diametric loading direction. Moreover, it was revealed that the stress concentration coefficients for anisotropic rocks vary from those of isotropic rocks, depending on the inclination angle of the bedding planes. This study confirms that the shear (tensile) strength of anisotropic black shale is not constant but varies with the orientation of the anisotropic planes in relation to the applied load. Full article

This paper presents an analysis of factors causing the change in the real gage factor of high-temperature strain gages installed with ceramic cements. A calibration tool to mimic the load on the strain gage during the testing of gas turbines and to determine the real gage factor is described. Calibration data obtained for two samples of nickel–chromium strain gages and two samples of iron–chromium–aluminum strain gages are given and analyzed. Full article

To better address mechanical behavior, it is necessary to make use of modern tools through which it is possible to run predictions, simulate scenarios, and optimize decisions. sources integration. This will increase the capability of detecting material modifications that forerun damage and/or to forecast the stage in the future when very likely fatigue is initiating and propagating cracks. Early warning outcomes obtained by the synergetic implementation of NDE-based protocols for studying mechanical and fatigue and fracture behavior will enhance the preparedness toward economically sustainable future damage control scenarios. Specifically, these early warning outcomes will be developed in the form of retopologized models to be used coupled with FEA. This paper presents the first stage of calibration and the combination of a system of different sensors (photogrammetry, laser scanning and strain gages) for the creation of volumetric models suitable for the prediction of failure of FEA software. The test objects were two components of car suspension to which strain gauges were attached to measure its deformation under cyclic loading. The calibration of the methodology was carried out using models obtained from photogrammetry and experimental strain gauge measurements. Full article

The hole-drilling method (HDM) is a common technique used for the determination of residual stresses, especially for metal alloy components, though also for polymers. This technique is usually implemented with strain gages, though other methods for determining the fields of displacements are quite mature, such as the use of digital image correlation (DIC). In the present paper, this combined methodology is applied to a 3D-printed PLA precurved specimen that is flattened in order to impose a bending distribution which can be considered known with a reasonable accuracy. The back-calculated stress distribution is in agreement with the expected (imposed) bending stress, however, a converging iterative procedure for obtaining the solution is introduced and discussed in the paper. Full article

For the purpose of validation and identification of mechanical systems, measurements are indispensable. However, they require knowledge of the inherent uncertainty to provide valid information. This paper describes a method on how to evaluate uncertainties in strain measurement using electric strain gages for practical engineering applications. Therefore, a basic model of the measurement is deduced that comprises the main influence factors and their uncertainties. This is performed using the example of a project dealing with strain measurement on the concrete surface of a large-span road bridge under static loading. Special attention is given to the statistical modeling of the inputs, the underlying physical relationship, and the incorporation and the impact of nonlinearities for different environmental conditions and strain levels. In this regard, also experiments were conducted to quantify the influence of misalignment of the gages. The methodological approach used is Monte Carlo simulation. A subsequent variance-based sensitivity analysis reveals the degree of nonlinearity in the relationship and the importance of the different factors to the resulting probability distribution. The developed scheme requires a minimum of expert knowledge of the analytical derivation of measurement uncertainties and can easily be modified for differing requirements and purposes. Full article

Indentation tests were used for early detection of deformation-induced damage of Inconel 718. Damage was produced in a controlled manner using specially designed specimens with a variable width of the gage part. Static tension, LCF, and HCF tests were performed to induce material damage. Accumulated plastic strain intensity was used as the reference measure of deformation-induced damage. Detection of damage progress in its early phase was based on the use of strain-hardening cross-effect. Experimentally determined correlation of hardness and indentation work with reference damage parameter was analyzed. The results of our analysis lead to the conclusion that the proposed experimental procedure is useful for the detection of deformation-induced damage in the early stage of the process. Full article

The National Renewable Energy Laboratory manufactured, instrumented, and deployed thermoplastic composite blades and a data acquisition system (NDAQ) on one of Verdant Power’s Gen5d 5 m diameter tidal turbines in New York’s East River. The thermoplastic blades had internal strain gages, and the NDAQ was a stand-alone system for monitoring and recording the strain and angular position of the blades. The turbine with thermoplastic blades operated and produced power successfully for 3 months, contributing energy to the New York City electric grid. The NDAQ hardware, instrumentation, and structure all survived the deployment and were still functional upon retrieval of the system, but no data were collected. Even though the data retrieval was not a success, data acquisition for deployed subsea marine renewable structures is a new undertaking, and it is critical to share lessons learned from national laboratory experiences. The successful deployment of thermoplastic composite blades marks a significant advancement toward improved materials for subsea components, as well as an advancement in recyclable composite materials. This article outlines the methodology and lessons learned for the instrumentation and data acquisition system. Full article

Severe damage or collapse of reinforced concrete dapped-end beams (RC-DEBs) may occur during the service life. The collapse of the Concorde overpass structure in Laval, Quebec, Canada, in 2006 revealed the causes of collapse, i.e., insufficient shear strength (no stirrups), misplacement of hanger reinforcement, etc. In addition, the inspection report of RC half-joint bridges in England until 2018 expressed that damages or failures of half-joint structures can be attributed to the poor condition of structures or non-compliant reinforcement detailing. These conditions exhibited how important it is to understand the proper detailing of dapped-end reinforcement. To date, some studies have performed investigations on the effect of inadequate dapped-end reinforcement on the structural behavior of DEBs. However, the results of the research to date were not yet complete enough to disclose the role of each group of dapped-end reinforcement in resisting the working load. Therefore, this study was carried out to investigate the main role of each group of dapped-end reinforcement separately on the structural performance of RC-DEBs. Eight large-scaled RC-DEBs (with sizes of 1800 mm length, 120 mm width and 250 mm height) were prepared, cast and cured. All DEB specimens were tested under the three-point loading up to failure. To localize the effect of shear failure, the shear span-depth ratio $(a_v⁄d)$ of 1.43 was set. Test results exhibited that arrangement of a specific group of dapped-end reinforcement separately affects the structural performance of DEBs significantly. The diagonal reinforcement (DR) group was found to be more effective than the vertical hanger reinforcement (HR) group. The failure load capacity of the DR group (DEB-18) achieved 0.29 times that of the control beam (DEB-3). Meantime, the nib flexure reinforcement (NFR) group demonstrated the most important role in the structural performance of DEBs compared to other dapped-end reinforcement groups. The failure load capacity of the NFR group (DEB-39) reached 0.62 times that of the control beam, while rupture deflection of the NFR group also exhibited the highest value than other groups, i.e., 0.62 times that of the control beam. In addition, analysis results of rosette strain gages (RSGs) data indicated that regions near to re-entrant corner and its vicinity experienced the highest stress concentration factor (SCF) compared to other places of the beams. These regions were more susceptible to experiencing the first crack, progressive crack, damage or failure first than other regions of DEBs. The greater the value of SCF, the greater the probability of collapse occurring in the related structural elements, which is also followed by a lower failure load capacity. DEB-1 (without dapped-end reinforcement) has the highest SCF (205.68), and the lowest failure load capacity (12.58 kN), whilst DEB-3 (with the complete dapped-end reinforcement) has the lowest SCF (79.62), but the highest failure load capacity (105.26 kN). Obviously, DEB-3 can withstand the working load properly. Its adequate dapped-end reinforcement is able to accommodate and distribute the high stress flows in the dapped-end region properly, which causes the SCF value to decrease. Full article

The results of measuring gradient strain fields by embedded or mounted point fiber-optic sensors based on Bragg gratings and distributed fiber-optic sensors based on Rayleigh scattering are discussed. Along with the experiment, the results of numerical modeling of strain measurement errors associated with the assumption of uniaxial stress state in the area of the embedded Bragg grating and measurement errors by distributed fiber-optic sensors associated with gage length are presented. Experimental results are presented for 3D printed samples and samples made of polymer composite material. The geometry of the samples was chosen based on the results of numerical simulations, and provides different variants of non-uniform strain distribution under uniaxial tension, including the variant in which the derivative of the strain distribution function changes its sign. A good agreement of numerical results and experimental data obtained by distributed and point fiber-optic sensors in areas where the derivative of the strain distribution function keeps a sign and an increase in the error of strain measurement results by distributed fiber-optic sensors in areas where this derivative changes sign are demonstrated. Full article

Piezoresistive structures inspired by serpentines, auxetic, and kirigami arrangements have demonstrated good flexibility and sensitivity under tension. Piezoresistive structures display optimal performance when the characteristics entail reliable stretchability and repeatability. These structures can be implemented as wearable sensors by compressing and elongating the conductive nanocomposites to vary the flow of electrons and to provide resistance change. To guarantee the reliability of these structures for strain sensing, it is important that the resistance change in these structures remains constant under repeated loads. In this study, the performance of different piezoresistive structures under cyclic tensile load is investigated and compared. Based on the performance of different types of structures, novel hybrid structures have been also proposed to design for both high stretchability and sensitivity of piezoresistive sensors. All the structures were tested with position limits rather than a fixed force to avoid permanent deformation. First, small position limits were used to determine Young’s Modulus, then a 10-cycle tensile test with larger position limits was used to further study the electromechanical behavior of different piezoresistive structures under larger deformation and repetition. Finally, the gage factor was derived for all the studied structures, and they were re-categorized based on properties’ similarities. Full article

Shortage of labor and increased work of young people are causing problems in terms of care and welfare of a growing proportion of elderly people. This is a looming social problem because people of advanced ages are increasing. Necessary in the fields of care and welfare, pneumatic artificial muscles in actuators of robots are being examined. Pneumatic artificial muscles have a high output per unit of weight, and they are soft, similarly to human muscles. However, in previous research of robots using pneumatic artificial muscles, rigid sensors were often installed at joints and other locations due to the robots’ structures. Therefore, we developed a smart actuator that integrates a bending sensor that functions as a human muscle spindle; it can be externally attached to the pneumatic artificial muscle. This paper reports a smart artificial muscle actuator that can sense contraction, which can be applied to developed self-monitoring and robot posture control. Full article

Data on the strain and stress status of the pipe in the circumferential direction are required for various pipe manufacturing procedures (e.g., in the oil business, the process of manufacturing seamless pipes with a conical shaft). The aim of this study is to develop a procedure to determine the strain and stress behavior of Pipe Ring Tensile Specimens (PRTSs) in the hoop direction, as there are a lack of official standardized methods for testing PRTS. This paper discusses the application of the Digital Image Correlation method for testing plastic PRTSs. PRTSs are tested using a specially designed steel tool with two D blocks. A 3D-printed PRTS is placed over two D-shaped mandrels, which are fixed on a tensile tool and tensile testing machine. The strain evolution in the gage length of the specimens is captured using the three-dimensional Digital Image Correlation (3D DIC) method. To check the geometry of the cross-section of the PRTS after fracture, all the specimens are 3D scanned. For the study, six groups of PRTS are analyzed, consisting of three filling percentages (60, 90, and 100%) and two geometry types (Single and Double PRTS). The results show that the type and percentage of filling, as well as the method of printing, affect the material behavior. However, the approach with the DIC system, 3D printer, and scanner shows that they are effective instruments for mapping complete strain fields in PRTS, and thus are effective in characterizing the mechanical properties of pipes. Full article

Background: Biomechanical analysis of human mandible is important not only to understand mechanical behavior and structural properties, but also to diagnose and develop treatment options for mandibular disorders. Therefore, the objective of this research was to generate analytical and experimental data on mandibles, construct custom 3D models, and compare the analytically derived maximum strains with strain gage data in five areas of interest for each mandible. Methods: We investigated the surface strains in the cadaveric human mandibles under different configurations of cyclic compressive loads in an experimental setting and compared these experimental strain data with results derived from computational finite element analysis (FEA), accurately replicating the experiments. Strains on the surface of each mandible were measured with strain gauges, and subsequently a subject-specific finite element (FE) volume mesh was generated from computed tomography (CT) scans of each mandible. Strain patterns of each mandible were derived from the FEA simulating the experimental setup and matched with the experimental data. Findings: Analysis of experimental data showed that strain as measured at the condylar locations was significantly different from those at other locations on the mandible, and that the sex and age of the subject did not have a significant correlation with the strain. Comparing the FE numerical predictions with the experimental data, we found a good statistical correlation and statistical agreement between in-vitro measurements and FE results. Interpretation: The study demonstrates that our methodology of generating subject-specific FE models is a valid and accurate, non-invasive method to evaluate the complex biomechanical behavior of human mandibles. Full article

In this study, the static safety factor and fatigue life of fastening devices of an agricultural by-product collector were evaluated under hard flat ground driving conditions. The strain gage-based measurement system was constructed, and the strain gage was attached on the highest stress spot of the fastening devices derived from structural analysis. The static safety factor and fatigue life of the fastening devices were calculated using the measured strain values and by converting it into stress data. The two operating conditions are considered to be the loading part of the by-product collector, lifted and non-lifted. The results for all fastening devices showed that the static safety factor was larger than 1.0 and the fatigue life was much greater than the expected lifetime under both operating conditions. Therefore, it can be concluded that the fastening devices of the by-product collector can be operated reliably under hard flat ground driving conditions. In future work, we plan to evaluate the safety of the fastening devices in various actual orchard farm environments. Full article
