Search Results (23)

This study investigated the influence of curing temperature and time on both the mechanical properties and cytotoxicity of stereolithographic polymethyl methacrylate (PMMA) resin. After printing using stereolithographic equipment, the resin was cured at 45 °C, 60 °C, and 75 °C for up to 120 min. Our results reveal that the mechanical properties achieved a peak after approximately 30 min of curing at the two highest temperatures, followed by a subsequent decrease, while curing at 45 °C resulted in a constant increase in mechanical properties up to 120 min. Testing with S. epidermidis and E. coli exhibited a bland antibacterial effect, with the number of living bacteria increasing with both the time and temperature of curing. To assess potential cytotoxicity, the materials were also tested with human fibroblasts, and the trends observed were similar to what was previously seen for both bacteria strains. Interestingly, an association was observed between the intensity ratio of two Raman bands (around 2920 and 2945 cm⁻¹), indicative of long-PMMA-chain formation and cytotoxicity. This finding suggests that Raman spectroscopy has the potential to serve as a viable method for estimating the cytotoxicity of 3D printed PMMA objects. Full article

A 3D-printed device was designed and printed by a stereolithographic technique (SLA) and coated with a highly selective solid phase extraction resin for on-site diclofenac extraction from wastewater, avoiding the transport and treatment of large volumes of samples in the laboratory. The best results in terms of chemical and mechanical resistance were obtained with Rigid 10K resin. The “stick-and-cure” impregnation technique was used to coat the 3D-printed device with Oasis^® HLB resin. The coated 3D-printed device can be reused up to eight times without losing extraction efficiency. The eluent and derivatization reagent volumes were optimized by a multivariate design. The proposed method allowed for the extraction and determination of diclofenac by PTV-GC-MS, achieving methodological detection and quantification limits of 0.019 and 0.055 μg L⁻¹, respectively, with a preconcentration factor of 46. The analysis time was 23 min per sample. To validate the proposed methodology, addition/recovery tests were carried out in different wastewater samples, obtaining recoveries above 90%. The methodology was applied at the wastewater treatment plant (WWTP) of Calvià (Mallorca, Spain), finding diclofenac in concentrations of 15.39 ± 0.07 μg L⁻¹ at the input of the primary decantation process, 4.48 ± 0.03 μg L⁻¹ at the output of the secondary decantation, and 0.099 ± 0.001 μg L⁻¹ at the output of the tertiary treatment, demonstrating the feasibility of the on-site extraction method in monitoring diclofenac over a wide concentration range. Finally, a greenness index of 0.58 for the proposed on-site sample preparation was achieved according to the AGREEprep metrics, making it an eco-friendly alternative for diclofenac monitoring. Full article

Background and Objectives: The use of stereolithographic (SLA) 3D printing technology in dentistry has expanded, particularly for the fabrication of provisional dental restorations. Understanding the mechanical properties and quality of SLA 3D-printed materials is essential to ensure clinical success and patient safety. This systematic review aims to critically evaluate and summarize the available evidence on the mechanical properties and quality of SLA 3D-printed materials. Methods: A comprehensive literature search was conducted in PubMed, Scopus, Embase, Cochrane, and Web of Science up to October 2024. Studies comparing the mechanical properties of SLA 3D-printed provisional restoration materials with those of milled, conventional, or other additive manufacturing methods were included. Nine studies met the inclusion criteria. Data on flexural strength, hardness, fracture resistance, surface roughness, marginal adaptation, accuracy, cement film thickness, shear bond strength, and biofilm formation were extracted and analyzed. Results: The findings from the included studies indicate that SLA 3D-printed materials exhibit varied mechanical properties. Some studies reported that SLA 3D-printed resins had significantly lower flexural strength and hardness compared to milled PMMA and bis-acrylic resins. Other studies found that SLA 3D-printed resins showed clinically acceptable marginal adaptation, surface roughness, and fracture strength comparable to those fabricated by subtractive manufacturing and conventional methods. In terms of accuracy, build orientation influenced the dimensional accuracy of SLA-printed restorations. Studies assessing cement film thickness found that SLA-printed provisional restorations had higher cement film thickness compared to other materials. Regarding repairability and fatigue resistance, limitations were observed in some SLA resins. Conclusions: The mechanical properties and quality of SLA 3D-printed materials for provisional dental restorations vary among studies. While SLA technology holds promise for efficient fabrication of provisional restorations, inconsistencies in material properties suggest a need for further research to optimize materials and printing parameters. Standardization of protocols is necessary to ensure reliable clinical performance of SLA 3D-printed provisional restorations. Full article

Rapid prototyping techniques offer significant advantages in terms of fabrication speed, accessibility, and low cost. This study explores the use of low-cost stereolithographic resins to produce prototypes intended for underwater conditions. The objective is to evaluate the feasibility of different low-cost resin brands by identifying their water absorption percentage and their response in terms of appearance and deformation after prolonged exposure to an underwater environment. Through three different tests, the suitability of the resins and possible coatings is evaluated, allowing for obtaining data not disclosed by commercial manufacturers and indicating that there are low-cost brands that offer water absorption levels suitable for underwater use. The coefficients for water absorption at saturation begin at 3.3% in saltwater and increase for chlorinated water. Additionally, significant insights are gained regarding the use of coatings. It is found that coatings commonly applied to filament-printed prototypes are generally less suitable for parts produced through stereolithography intended for underwater applications. The most effective strategy is to avoid using coatings altogether. Full article

Microfluidic devices (µFDs) have been explored extensively in drug screening and studying cellular processes such as migration and metastasis. However, the fabrication and implementation of microfluidic devices pose cost and logistical challenges that limit wider-spread adoption. Despite these challenges, light-based 3D printing offers a potential alternative to device fabrication. This study reports on the development of millifluidic devices (MiFDs) for disease modeling and elucidates the methods and implications of the design, production, and testing of 3D-printed MiFDs. It further details how such millifluidic devices can be cost-efficiently and effortlessly produced. The MiFD was developed through an iterative process with analytical tests (flow tests, leak tests, cytotoxicity assays, and microscopic analyses), driving design evolution and determination of the suitability of the devices for disease modeling and cancer research. The design evolution also considered flow within tissues and replicates interstitial flow between the main flow path and the modules designed to house and support organ-mimicking cancer cell spheroids. Although the primary stereolithographic (SLA) resin used in this study showed cytotoxic potential despite its biocompatibility certifications, the MiFDs possessed essential attributes for cell culturing. In summary, SLA 3D printing enables the production of MiFDs as a cost-effective, rapid prototyping alternative to standard µFD fabrication for investigating disease-related processes. Full article

Computer-assisted preparation of porcelain laminate veneers (PLVs) using stereolithographic templates has been developed to enhance the accuracy of tooth preparation. However, the digital workflows involved in guided PLV preparation remain inconsistently defined across various practices. Therefore, this scoping review aimed to examine publications on computer-assisted PLV preparation to identify the key stage of digital workflows involved in designing and fabricating stereolithographic templates, as well as to highlight the limitations of various template designs. This scoping review aimed to identify publications on digital workflows for designing and fabricating stereolithographic templates in computer-assisted porcelain laminate veneer preparation. A systematic search on MEDLINE/PubMed, Web of Science and Scopus identified English-language articles published from 2014 to March 2024. Eligible articles focused on digitally designed and fabricated tooth reduction templates for porcelain laminate veneers, excluding conventional tooth preparation procedures for tooth reduction assessment. Seven clinical reports were included, demonstrating various 3D data acquisition techniques for virtual patient generation. All articles described virtual diagnostic wax-ups on digital casts, with two using a virtual articulator. Only five articles documented chair-side mock-ups with resin trial restorations to evaluate planned dental esthetics. Additionally, virtual tooth preparation prior to templates design was included in only four articles. The templates were designed using different software and ranged from simple designs with access windows to complex stacked templates with rotary instrument sleeved windows. Each template design had limitations affecting tooth reduction accuracy. All articles reported printing templates in clear acrylic resin using different technologies. In conclusion, the review highlights a lack of standardization in the digital workflow for designing stereolithographic templates for PLVs. Establishing a sound protocol for designing the tooth reduction templates is essential to ensure the accuracy and consistency of veneer preparation. Full article

In invisible orthodontics, the role of composite attachments in facilitating complex tooth movements is crucial. This study, which evaluates the efficacy of a novel clinical attachment procedure, holds significant implications for the field. The technique used two templates (one pre-drilled and the other pre-loaded with high-viscosity composites) and was compared with the standard procedure. Fifty attachments were planned for four dental arch prototypes. Dental impressions were taken using digital scans for virtual planning and after tested techniques. The stereolithographic files (STL) obtained were aligned with those of the virtual planning, and a colorimetric map was used to evaluate the composite resin’s maximum excess and defect deviation. The enamel–resin interfaces were observed by scanning electron microscopy (SEM). The Fisher test for the distribution of detachments and morphological defects and the Mann–Whitney test for the maximum values of excess and defect were used. No significant results were found between groups for morphological defects and detachments, and the maximum values of defect and excess were reported. SEM images for the experimental technique showed integrated adhesion. This innovative procedure, which has proven reliable and operationally straightforward, holds promise, instilling confidence in its practicality and potential to advance the field of orthodontics. Full article

Anatomical and functional tissue loss is one of the most debilitating problems and involves a great cost to the international health-care sector. In the field of bone tissue, the use of scaffolds to promote tissue regeneration is a topic of great interest. In this study, a combination of additive manufacturing and computational methods led to creating porous scaffolds with complex microstructure and mechanical behavior comparable to those of cancellous bone. Specifically, some representative models of triply periodic minimal surfaces (TPMSs) were 3D-printed through a stereolithographic technique using a dental resin. Schwarz primitive and gyroid surfaces were created computationally: they are characterized by a complex geometry and a high pore interconnectivity, which play a key role in the mechanism of cell proliferation. Several design parameters can be varied in these structures that can affect the performance of the scaffold: for example, the larger the wall thickness, the lower the elastic modulus and compressive strength. Morphological and mechanical analyses were performed to experimentally assess the properties of the scaffolds. The relationship between relative density and elastic modulus has been analyzed by applying different models, and a power-law equation was found suitable to describe the trend in both structures. Full article

Engineering microfluidic devices relies on the ability to manufacture sub-100 micrometer fluidic channels. Conventional lithographic methods provide high resolution but require costly exposure tools and outsourcing of masks, which extends the turnaround time to several days. The desire to accelerate design/test cycles has motivated the rapid prototyping of microfluidic channels; however, many of these methods (e.g., laser cutters, craft cutters, fused deposition modeling) have feature sizes of several hundred microns or more. In this paper, we describe a 1-day process for fabricating sub-100 µm channels, leveraging a low-cost (USD 600) 8K digital light projection (DLP) 3D resin printer. The soft lithography process includes mold printing, post-treatment, and casting polydimethylsiloxane (PDMS) elastomer. The process can produce microchannels with 44 µm lateral resolution and 25 µm height, posts as small as 400 µm, aspect ratio up to 7, structures with varying z-height, integrated reservoirs for fluidic connections, and a built-in tray for casting. We discuss strategies to obtain reliable structures, prevent mold warpage, facilitate curing and removal of PDMS during molding, and recycle the solvents used in the process. To our knowledge, this is the first low-cost 3D printer that prints extruded structures that can mold sub-100 µm channels, providing a balance between resolution, turnaround time, and cost (~USD 5 for a 2 × 5 × 0.5 cm³ chip) that will be attractive for many microfluidics labs. Full article

Photopolymer resins used in stereolithographic 3D printing are limited to penetration depths of less than 1 mm. Our approach explores the use of near-infrared (NIR) to visible upconversion (UC) emissions from lanthanide-based phosphors to initiate photopolymer crosslinking at a much higher depth. This concept relies on the use of invisibility windows and non-linear optical effects to achieve selective crosslinking in photopolymers. SLA resin formulation capable of absorbing light in the visible region (420–550 nm) was developed, in order to take advantage of efficient green-UC of Er³⁺/Yb³⁺ doped phosphor. NIR-green light UC shows versatility in enhancing curing depths in laser patterning. For instance, a structure with a curing depth of 11 ± 0.2 mm, cured width of 496 ± 5 µm and aspect ratios of over 22.2:1 in a single pass via NIR-green light UC. The penetration depth of the reported formulation approached 39 mm. Therefore, this technique would allow curing depths of up to 4 cm. Moreover, it was also demonstrated that this technique can initiate cross-linking directly at the focal point. This shows the potential of NIR-assisted UC as a low-cost method for direct laser writing in volume and 3D printing. Full article

Herein we report on the preparation of a bioactive glass (BAG)-based photocurable resin for the additive manufacturing of BAG scaffolds with high filler loadings. The preparation of glass/ceramics resins for stereolithography with high filler loading is always a challenge, especially for fillers with a high refractive index variance. Various photocurable resin compositions with and without bioactive glass fillers have been investigated to see the influence of bioactive glass on physical properties of the resin and resulting green body. The effect of concentration of monomers, reactive diluent, light absorber (Sudan orange G dye), photoinitiator (PI), non-reactive diluent, and fillers (BAG) on rheology and photocuring behavior of the resin and tomography of the resulting 3D structures have been investigated. The BAG contents affect the rheology of resin and influence the rate of the polymerization reaction. The resin compositions with 55–60% BAG, 10% PEG-200 (diluent), 1% of PI and 0.015% of the dye were found to be suitable compositions for the stereolithographic fabrication. A higher percentage of PI caused over-curing, while a higher amount of dye decreased the cure depth of the resin. The micro-computed tomography (µ-CT) and scanning electron microscopic (SEM) images of the resulting green bodies display a relatively dense glass scaffold without any visible cracks and good interlayer connection and surface finishing. These properties play an important role in the mechanical behavior of 3D scaffolds. This study will be helpful to prepare high density glass/ceramic slurries and optimize their printing properties. Full article

Ceramic materials are chemical- and temperature-resistant and, therefore, enable novel application fields ranging from automotive to aerospace. With this in mind, this contribution focuses on developing an additive manufacturing approach for 3D-printed waveguides made of ceramic materials. In particular, a special design approach for ceramic waveguides, which introduces non-radiating slots into the waveguides sidewalls, and a customized metallization process, are presented. The developed process allows for using conventional stereolithographic desktop-grade 3D-printers. The proposed approach has, therefore, benefits such as low-cost fabrication, moderate handling effort and independence of the concrete waveguide geometry. The performance of a manufactured ceramic WR12 waveguide is compared to a commercial waveguide and a conventionally printed counterpart. For that reason, relevant properties, such as surface roughness and waveguide geometry, are characterized. Parsing the electrical measurements, the ceramic waveguide specimen features an attenuation coefficient of 30–60 dB/m within the E-Band. The measured attenuation coefficient is 200% and 300% higher compared to the epoxy resin and the commercial waveguide and is attributed to the increased surface roughness of the ceramic substrate. Full article

In this paper, stereolithographic additive manufacturing of ceramic dental crowns is discussed and reviewed. The accuracy of parts in ceramic processing were optimized through smart computer-aided design, manufacturing, and evaluation. Then, viscous acrylic resin, including alumina particles, were successfully compounded. The closed packing of alumina particles in acrylic pastes was virtually simulated using the distinct element method. Multimodal distributions of particle diameters were systematically optimized at an 80% volume fraction, and an ultraviolet laser beam was scanned sterically. Fine spots were continuously joined by photochemical polymerization. The optical intensity distributions from focal spots were spatially simulated using the ray tracing method. Consequently, the lithographic conditions of the curing depths and dimensional tolerances were experimentally measured and effectively improved, where solid objects were freely processed by layer stacking and interlayer bonding. The composite precursors were dewaxed and sintered along effective heat treatment patterns. The results show that linear shrinkages were reduced as the particle volume fractions were increased. Anisotropic deformations in the horizontal and vertical directions were recursively resolved along numerical feedback for graphical design. Accordingly, dense microstructures without microcracks or pores were obtained. The mechanical properties were measured as practical levels for dental applications. Full article

(1) Surgical intervention becomes crucial in situations in which lack of action would cause a decrease in quality of life for the patient. As healthcare professionals, our next objective is to reduce patient fear perception. This work’s aim is to illustrate how physical tridimensional models can serve not only as confidence boosters for the patient, but also as a valid tool to aid both the clinician and the fostering of a patient–doctor relationship. (2) An example case managed using a stereolithographic model in the pre-surgical planning stage is presented in which surgical planning was carried out by analysis of radiographic investigations combined with a tridimensional resin model derived from the patient’s x-ray exam. (3) Successful enucleation, surgical debridement, and stable follow-up shows the effectiveness of the applied surgical protocol, confirming that planification using a physical representation of the tridimensional exam aids in the correct surgical management of said lesions. (4) The effectiveness o101f the surgical act itself as well as the follow-up showing ossification of the bony lesion and absence of relapse of a highly recurrent lesion confirms the effectiveness of the tools used for this surgical intervention. Full article

A simple and efficient process for fabricating customized aspheric lenses is reported, in which a stereolithographic 3D printer combined with the meniscus equilibrium post-curing technique is employed. Two kinds of UV-curable resins, DentaClear and HEMA, were used for printing aspheric lenses in our experiments. The printed DentaClear lens featured low surface profile deviation of ~74 $\mathsf{\mu }\mathrm{m}$ and showed satisfactory optical imaging resolution of 50.80 lp/mm, i.e., 4.92 $\mathsf{\mu }\mathrm{m}$. The surface roughness of the printed lens with DentaClear was measured to be around 2 nm with AFM. The surface roughness was improved as a result of post-curing, which reduced the ripples on printed lens surfaces. In contrast, the printed HEMA lens exhibited a significant stair-stepping effect with a large surface profile deviation of ~150 $\mathsf{\mu }\mathrm{m}$. The ripples were somewhat apparent even if the printed HEMA lens surface was smoothed by means of post-curing. No sharp image can be obtained with the HEMA lens in the resolution testing. The composition of HEMA resin may be the reason for the relatively poor surface quality and optical properties. Full article
